2 PITTLER pv 2500 used machines

Maximum turning diameter: 2800 mm Maximum swing diameter: 3000 mm diameter of spindle flange: 1100 mm control: Siemens 840 D sl Table rpm: 230 1/min Maximum speed of driven tools: 6000 1/min x-travel: 2700 mm z-travel: 1000 mm Feed - X: 24 m/min feed capacity - x: 22 kN tool taper: CAPTO C8 total power requirement: 200 kVA dimensions of the machine ca.: 10,4 x 6.3 x 5,7 m weight of the machine ca.: 120 t Equipment/Accessories: - 2 tool changers one with 25 positions and one with 41 positions - 2 x chip conveyors - Coolant system, 6 bar - High-pressure cooling, 70 bar - Knoll paper belt filter - 12-jaw balancing chuck, RÖHM - internal coolant supply - Hydraulic unit - Automatic door - Electric handwheel - Technical documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: max. 2.800 mm diameter of spindle flange: 1.100 mm max. swing diameter: 3.000 mm control: 840 D sl Siemens Main spindle:: turning speed range - main spindle: max. 230 min/-1 power capacity - main spindel: 206 kW max. Torque: 53.000 Nm max. load: - kg C-Axis: Tool Mount:: Rechts / Right tool taper: Capto C8 swivellable: B: 0 - 270 ° Spindle speed - driven tool pos.: max. 6.000 min -1 max. Torque: 120 Nm Tool Mount:: Links / Left tool taper: Capto C8 tool magazin:: Rechts / Right number of toolpositions: 41 pos. max. tool weight: 20 kg max. tool length: 400 mm workpiece diameter at full load: 150 mm tool taper: Capto C8 tool magazin:: Links / Left number of toolpositions: 25 pos. workpiece diameter at full load: 150 mm max. tool weight: 20 kg max. tool length: 400 mm tool taper: Capto C8 axis stroke:: x-axis: 1: 2.700 mm x-axis: 2: 2.700 mm z-axis: ( 2x 1.000 ) mm fee ...
