3 PIERCE plasma cutting machines used machines

Inv. Num. : 6144 Type: Scorpion 2000 Producer: Pierce Created: 2004 Parameters: Work table length: 3000 mm Work table width: 1500 mm Minimum sheet thickness: 2 mm Maximum sheet thickness when cutting: 15 mm Equipment: Source: Hypertherm 1650 Vacuum New Burner PC board replacement. According to GO.

Inv. Num. : 7817 Type: RUR 2500 G Producer: PIERCE Created: 2014 Parameters: Work table length: 6000 mm Work table width: 3000 mm Maximum sheet thickness when cutting: 120 mm Equipment: Rails Burning Machine Baths

Inv. Num. : 8712 Type: RUR 2500 GP Producer: Pierce Created: 2007 Parameters: Work table length: 6000 mm Work table width: 2000 mm Track size: 8000 x 2500 mm Plasma Source: Cebora CP200 Autogenous: Harris Maximum sheet thickness (plasma): 20 mm Maximum sheet thickness (oxy-fuel): 200 mm Positioning speed: 12000 mm/min Equipment: Wrykrys Program Nesting USB stick

Inv. Num. : 8766 Type: SPITFIRE 1500 Producer: Pierce Created: 2012 Parameters: Software: Lantek Expert Duct Work table length: 3000 mm Work table width: 1500 mm Maximum sheet thickness when cutting: 15 mm Plasma Source: HYPERTHERM 85A Machine height: 1400 mm Machine length: 3650 mm Machine width: 2520 mm Equipment: Exhaust fan

This 3-axis plasma cutting machine manufactured in 2015 features a maximum sheet size of 3000x2000 mm and can handle thicknesses up to 60 mm. Equipped with a Kjellberg HiFocus 360i source and a Pierce control system from 2015, it ensures precise cuts. Including a KEMPER extraction system with 7000m3/h output. If you are looking to get high-quality cutting capabilities consider the PIERCE RUM 2500 P machine we have for sale. Contact us for more information.

Inv. Num. : 8005 Type: RUM 2500 P Producer: PIERCE Created: 2015 Parameters: Control system: Pierce 4/2015 Software: PIERCE WYKRYS CZ Work table length: 3000 mm Work table width: 2000 mm Maximum sheet thickness when cutting: 60 mm Equipment: Technical documentation Plasma source Kjellberg HiFocus 360i Suction KEMPER

Inv. Num. : 8886 Type: RUR 2500 Producer: PIERCE Created: 2005 Parameters: Work table length: 6000 mm Work table width: 2000 mm Equipment: Source: Plasma and autogen

Plasma cutting machine CLOOS type CPS 40/80Year of construction 1990Power at 60 % ED 80 Amp.Power at 100 % ED 40 Amp.Adjustment range 40 and 80 Amperes (2 steps)Cutting capacity for steel max. 25 mmHose package length 5.5 metersMains connection 400 Volt with 32 Amp. Plug and hand torch CLOOndimension L x W x H 700 x 600 x 750 mmWeight 160 kgGood condition; used

Plasma Cutting Machine, Plasma Cutting Machine MESSER GRIESSHEIM Type Plasmastar HA 95Fabr. No. 4040 Year of construction 1990Power 95 Amp. - 60% ED 45 Amp. - 70 % EDEsetting range 2 stepsCutting capacity 25 mm (clean cut)Separating cut max. 45 mmHand torch PHC 95/140Power connection 380 volts, 50 Hz, 32 Amp. Plug- Water-cooled- 8 meters hose package length- Operating instructionsSpace required L x W x H 900 x 480 x 850 mmWeight 160 kgvery good condition; used

Plasma Cutting Machine MB - Welding Technology Type Plasmaprof 50Identical to CEBORA ash. No. 244311 Year of construction approx. 1992Power 50 Amp. = 35 % ED 30 Amp. = 100 % EDEsetting range 2 stagesHose package length approx. 6 metersCompressed air connection 4.7 barMains connection 400 Volt, 50 Hz, 32 Amp. PlugSpace required L x W x H 500 x 350 x 700 mmWeight approx. 80 kgGood condition; used

Cut-off cuts up to 35 mm, cutting capacity 50 A at 100 %, cutting capacity 120 A at 60 %, insulation class IP 21

Cut-off cuts up to 35 mm, cutting capacity 50 A at 100 %, cutting capacity 120 A at 60 %, insulation class IP 21

Osein CUT-40P Plasma Cutter 2-in-1 - Plasma Cutting & MMA-Welding Plasma cutter CUT-40P – Compact & powerful cutter Product features Suitable for plasma cutting of metal Compact and portable design Stable cutting performance Ideal for workshop, maintenance and hobby use Easy operation ✔ Precise cutting ✔ High efficiency ✔ Reliable operation ✔ Compact and lightweight Technical specifications – CUT-40P General Function: Plasma cutting (CUT) Power supply: 220V Frequency: 50/60 Hz Max. input current: 29.6 A Rated current (eff): 22.9 A Open circuit voltage: 297 V Cutting performance Cutting current range: 20 – 40 A Maximum cutting thickness: < 20 mm Duty cycle At 25°C: 60%: 40 A 100%: 31 A At 40°C: 60%: 40 A 100%: 31 A Performance Efficiency: 85.5% Power Factor: 0.59 Insulation class: F Protection class: IP21S Dimensions & weight Dimensions (L x H x W): 41 x 15.5 x 28 c ...

The STIGAL DYNAMIC SPEED HQ 1500X3000 plasma cutter was manufactured in 2013 by the Polish company Stigal. A computer-controlled thermal cutter is designed for cutting out shapes from a sheet of metal. It is equipped with, among others in: CNC G-CODE control, CAD / CAM WRYKRYS software, CEBORA PROF 165 HQC aggregate, or a cover protecting the operator's eyesight. The cutter's cutting width is 1500 mm, length is 3000 mm and the thickness is 20 mm. The machine's torch moves at a speed of 330 mm / s and cuts metal sheets with a maximum thickness of 20 mm. The total weight of the machine is 3 tons. Technical data of the STIGAL DYNAMIC SPEED HQ 1500X3000 cutter - cutting length: 3000 mm - cutting width: 1500 mm - maximum material thickness: 20 mm - maximum cutting thickness: 20 mm - permissible table load: 150 kg / m2 - maximum travel speed: 90 m / min - type of burner height adju ...

AMG S820 plasma-gas cutting machine built by the Taiwanese company ASIA MACHINE GROUP in 2013, is used for precision cutting of workpieces made of carbon steel and acid-resistant steel. The machine characterised by a robust and high-quality construction has two torches – a HYPERTHERM plasma torch with THC voltage height adjustment and collision protection, and a KOIKE gas torch with functions for automatic piercing. The plasma cutting machine performs workpiece cutting processes on a large work table of surface area (L x W) 6100 x 2500 mm with an additional laser pointer to facilitate workpiece positioning on the table. In order to eliminate any contamination generated during laser and gas cutting, the usual exhaust extraction has been replaced by an waterbed table powered by water with a pressure of up to 2 bar. The water mirror in the table’s bath effectively absorbs the exhaust ...

SAF OPTITOME 15 CNC plasma cutting machine was built in France in 2003. The machine is used to cut shapes in workpieces made of stainless steel, mild steel or aluminium. Depending on the previously choiceed nozzle, workpieces can have a thickness from 2 or 3 mm up to 18 mm. The high cutting quality is achieved thanks to the use of a lightweight and rigid transverse beam with efficient drive, mounted on an extremely rigid and robust machine frame. The installed working table with dimensions (L x W) of 3000 x 1500 mm allows the reduction of mechanical stresses arising during thermal cutting or sheet loading/unloading. The plasma cutting machine is supplied with equipment consisting of among others: a NERTAJET HP 125 plasma source with a power of 125 A and a DIGISAF 100 CNC control. Technical data of the SAF OPTITOME 15 plasma - materials to be cut: stainless steel, mild steel, alumi ...

ECKERT JANTAR plasma cutting machine was manufactured in 2017 in Poland. Characterised by a robust and stable construction, the machine is designed for cutting shapes in workpieces made of mild steel, stainless steel or aluminium. For precise machining of sheets having a maximum thickness of 38 mm (mild steel) or 25 mm (stainless steel and aluminium), it uses a plasma torch equipped with an HD3000 support with distance adjustment by measuring the plasma arc voltage. The process of cutting workpieces is carried out on a working area measuring 2000 mm in length and 3000 mm in width, equipped with an extraction table eliminating the impurities generated during processing. The plasma cutting machine is offered with a wide range of equipment, including: modern CNC controller ECS 872 for full control over the operation of the machine, and a HYPERTHERM HPR130XD plasma source. Technical da ...

ZAKMET HYPERZAKMET 6000X2500 plasma cutting machine was built in 2008 in Poland. The machine is used to cut pre-programmed shapes in details having a maximum thickness of 38 mm (carbon steel) or 20 mm (aluminium and stainless steel). A powerful HYPERTHERM HyPerformance HPR 130 laser source with a power of 130 A is used for the cutting process, allowing extremely precise and accurate machining to be achieved. The plasma cutting machine has a solidly built work table with a length of 6000 mm and a width of 2500 mm, which can be extended by means of an additional control panel. The plasma cutting machine is also equipped with FASTCAM CAD/CAM software for simple and effective programming of the cut shapes, and a modern HYPERTHERM EDGE CNC controller, which allows for full control of the machine. Characteristics of the ZAKMET HYPERZAKMET 6000X2500 plasma cutting machine - working area  ...

TECHNICAL SPECIFICATIONS Manufacturer: MicroStep Europe Designation: Plasma cutting machine CNC Type: SPL-P 9001.20+S500 Year of construction: 2008 Design: with KJELLBERG plasma source HiFocus 280i Composed of: - MicroStep CNC guide machine SPL-P 9001.20+S500 - CNC machine control MSNC-500 for WindowsXP - CNC flame cutting table with sectional extraction / 9000x2000 mm - Slag trays for the integrated shaft - Kjellberg plasma source HiFocus 280i, with autom. Gas console - CNC interface for HiFocus 280i

ECKERT JANTAR 2 plasma-gas cutting machine manufactured in 2013 in Poland, is designed for cutting sheets made of e.g. black steel and stainless steel. The machine’s high-quality steel portal has been extended by an additional 700 mm to facilitate the loading and unloading of larger sized workpieces. A sectional extraction table with a length of 6000 mm and a width of 3000 mm effectively eliminates contamination generated during the cutting process, ensuring a high level of safety and great user comfort. Outside the working area of the JANTAR 2 plasma cutting machine, there is a system for cutting pipes and profiles with a special gear and rotating head, giving the possibility of precise cutting of pipes up to 300 mm in diameter by plasma or gas. The machine is also equipped with, among others, an ECS 872 CNC control, a WALTER SKTG 5.5/15 SM screw compressor, a KJELLBERG HiFocus 161 ...

Plasma Cutting/Oxyfuel ESAB Numorex for sale Technical data: - Plasma source: 240/360 A - Bevel plasma torch for chamfer cutting - Vibrating suction bench for evacuating pieces - Smoke extraction system.

ECKERT JANTAR 2 plasma cutting machine was manufactured in 2008 in Poland. The machine equipped with a large working table of 12500 x 2500 mm (length x width) is designed for cutting oversized metal sheets made of carbon and low-alloy steel of maximum thickness of 25 mm (plasma cutting) or 110 mm (oxygen cutting). The torches are powered by a highly efficient HYPERTHERM HPR260 plasma source with a power of 260 A, guaranteeing excellent precision and many years of trouble-free operation. The ECKERT JANTAR 2 12.5×2.5 m plasma-gas cutting machine ensures a high level of safety. A KEMPER filtration system with self-cleaning filters and an extraction table eliminate contamination generated during workpiece machining. The plasma cutting machine is numerically controlled by an ECS 859 controller with all the necessary functions for efficient use of the machine. Technical parameters of th ...

STIGAL DYNAMIC SPEED HQ plasma cutting machine manufactured in 2012, precisely cuts workpieces made of plain steel, stainless steel and aluminium on a large work table with dimensions (L x W) of 4000 x 2000 mm (the table grate will be replaced with a new one before sale). The numerically-controlled plasma cutting machine ensures a high degree of operational safety, as the machine is equipped with an extraction table designed to eliminate the contamination generated during cutting. The plasma cutting machine is also equipped with a reliable CEBORA PROF 165 HQC plasma source and GudePol GO-R refrigeration dryer. Technical data of the plasma cutting machine STIGAL DYNAMIC SPEED HQ - work table surface (L x W): 4000 x 2000 mm - cutting length: 4000 mm - cutting width: 2000 mm - maximum sheet thickness: 20 mm - plasma source power: 120 A - power consumption: 7000 W - DYNAMIC SPEED H ...

ESAB EAGLE 2000 plasma cutting machine was built in 2009 in Germany. The machine is designed for machining stainless steel, structural steel, low-alloy steel and aluminium with a maximum thickness of 30 mm and has a very stable and vibration-free welded construction. Excellent cutting precision with simultaneous low operating costs is ensured by the ESAB Precision Plasmarc 201 plasma source with a power of 200 A, which generates a narrow plasma beam with high energy density per small area of material. The plasma cutting machine portal was fixed by two dynamic servo drives operating with low backlash on the machined profile rails (X axis). The dynamic servo drive in the transverse carriage drives the spur gear, which then meshes with the toothed bar of the machine portal, causing transverse movement (Y axis). The plasma cutting machine is equipped with an ESAB CNC control with the late ...

Inv. Num. : 6794 Type: 3015 Producer: BODOR Created: 2023 Parameters: Laser power: 12 kW Working table length: 3000 mm Working table width: 1500 mm Machine weight: 9000 kg
