other packaging machinery used for sale (675)

Tightening banding machine with shrink tunnel Manufacturer: Kiener Type ASK 450 Kiener Tightening Banding Machine Auto Skinetta 450 with hinge chain belt and shrink tunnel with bar chain belt and hot air gun on the side and from above. Siemens Control Film width 40-450 mm single lane Foil thickness 25-60 My Thickness tolerance +/- 10 % Roll diameter up to film width 200 mm Outer diameter approx. 300 mm Up to film width 600 mm Outer diameter approx. 250 mm

Deblister machine Manufacturer: RBP Bauer GmbH Type RBP Model D 3600

Automatic Adelski capping machine for automatically closing bottles with screw caps. Number of capping heads: 3, max. capacity: approx. 10000bottles/h, direction of travel: right → left. Including approx. 160000pcs caps. Weight: approx. 1750kg. Documentation and wiring diagrams available. Viewing possible by appointment.

Stretch film wrapper with Siemens S7 straightening, needed

A Uhlmann blister packaging line in need of repair is available. 1) Uhlmann UPS 4 ETX blister machine, year of manufacture: 2008, design: modular balcony design, modules: 12, blister capacity: 10 tablets, blister format X/Y/Z: 100mm/39mm/5.7mm, packaging output: 220blisters/min, roll width forming/sealing: 256mm/246mm, feed: 102mm, max. forming film roll diameter: 800mm, max. lidding film roll diameter: 300mm, filling section length: 1360mm, theoretical output: 50cycles/min, film width range: 63mm-300mm, punching width range: 28mm-284mm, max. forming depth: 12mm, min. blister dimensions X/Y/Z: 30mm/3.5mm/60mm, max. blister dimensions X/Y/Z: 110mm/12mm/145mm, max. stack height: 85mm, max. blisters per stack: 10, weight: approx. 7000kg. 2) Uhlmann C 2155 cartoner, year of manufacture: 2008, cartoning output: 10-150cartons/min, max. stacking output: 400blisters/min, product carrier height:  ...

A Behn bag filling machine for powder and flakes is available. Accuracy class: Gkl X(1), filling material: resin powder, verification: 2019, filling principle: screw filling, filling nozzle diameter: 60mm, weighing range: 2kg-32kg, scale interval: 20g, inlet diameter: 350mm, flange diameter: 520mm, machine weight: approx. 1000kg. The control system of the machine has been overhauled. Including approx. 4000 bags and spare parts for the control system. An on-site inspection is possible.

A Haver & Boecker bagging system for valve bags with a turbine system for powdered bulk materials is available. Weighing system: gross weighing, filling material: phenolic resin, bag layers: 2-4, filling weight range: 25kg-30kg, filling capacity: approx. 150-175bags/h, explosion protection class: EEx de II C T6, pack silo height: 800mm, load cell: Z3H2-A, certification valid until 2026. Documentation available. An on-site inspection is possible.

STREMA A 5000B IIDBE Double-Head Pallet Wrapper High-Performance Double-Head Wrapper for Industrial Beverage Production The STREMA Doppelkopfwickler is a robust and efficient double-head pallet wrapping system designed for industrial packaging lines in the beverage sector. With integrated pallet handling equipment and protective safety features, this system is well suited for automated end-of-line pallet securing and transport preparation. Machine Overview: Machine Type: Double-Head Pallet Wrapper Manufacturer: STREMA Model: A 5000B IIDBE Year of Manufacture: 2017 Technical Specifications: Capacity: 15 wrappings / 127 pallets per hour Lifting Station: Yes Availability: Immediately available Included Equipment: The double-head pallet wrapper includes: Pallet lifting station Top sheet applicator / cover sheet system Safety fence Pallet transport conveyors Half-pal ...

Suitable for: screw caps, drop inserts, press-on caps, flip-top caps, cup-to-cup closures, pipettes, brushes, spray pumps, triggers, rubber stoppers, crimp caps, ROPP caps and other closure types, equipment: mechanical rotary indexing table, pneumatic cap feeders, closing station for 1 closure type, extraction connection, IBC including drip tray, continuously adjustable transition from the discharge arm, machine enclosure: stainless steel 1.4301 (AISI 304), max. output depending on bottle, fill level and closure type: 60 bottles/min, compressed air connection filtered, oil-free: 6bar, connected load: 1.5kW, power supply: 3x 400V, connection area height: 792mm, cable routing: 317mm, overall length: 4200mm, with documentation. An on-site inspection is possible.

Robopac Pallet Wrapper – HELIX HS40 Machine Type: Robopac HELIX HS40 – Automatic Rotary Arm Stretch Winder Technical data: • Installed power: 4.5 kW • Voltage: 400 V / 50 Hz + N • Air consumption: 150 Nl/min • Operating pressure: 6 bar Product data: • Pallet size: 1,200 × 800 mm • Load size (variant 1): 1,000 × 700 mm • Load size (variant 2): 1,280 × 1,000 mm • Winding height: min. 250 mm – max. 1,600 mm • Loading weight: min. 50 kg – max. 1,500 kg ______________________________________________________________________ _ Robopac Pallet Stretch Wrapper – HELIX HS40 Machine type: Robopac HELIX HS40 – Automatic rotary arm stretch wrapper Technical specifications: • Installed power: 4.5 kW • Voltage: 400 V / 50 Hz + N • Air consumption: 150 Nl/min • Working pressure: 6 bar Product specifications: • Pallet size: 1200 × 800 mm  ...

Deblister machine Manufacturer: IDI Pharma mobile

Deblister machine Manufacturer RBP Bauer Type D 2500

Turntable diameter: 1650mm, turntable height: 65mm, mast height: 2560mm, max. load capacity: 2000kg, max. pallet dimensions X/Y/Z: approx. 1200mm/1100mm/2400mm. Machine dimensions X/Y/Z: approx. 2600mm/1650mm/2600mm, weight: approx. 550kg. Documentation available. An on-site inspection is possible.

A fully automatic horizontal tunnel stretch wrapper Bang & Co for securing products on corrugated cardboard blanks is available. Turntable speed: 100rpm, max. conveyor speed: 18m/min, carton width range: 70mm-650mm, min. product length: 200mm, max. spool diameter: 140mm, max. spool height: 125mm, film roll inner diameter: 38mm, film thickness range: 18µm-40µm. Machine dimensions X/Y/Z: approx. 1600mm/1250mm/1650mm, weight: approx. 500kg, operating hours: approx. 6851h. Dokumentation vorhanden. An on-site inspection is possible.

Weighing range min.: 175g, temperature range: 10-40°C, voltage: 230V, frequency: 50Hz, with EC declaration of conformity. An on-site inspection is possible, not under power.

Two complete blister packaging lines from the pharmaceutical industry are available. 1.1) Automatic case packer IMA CP 28 BA, year of manufacture: 2000, min. carton dimensions X/Y/Z: 220mm/120mm/120mm, max. carton dimensions X/Y/Z: 600mm/400mm/350mm, output: 8cartons/min, machine dimensions X/Y/Z: approx. 4900mm/1900mm/2650mm, weight: approx. 1500kg. 1.2) Bundle wrapping machine IMA BFB MS 300 A with stretch banding, year of manufacture: 2005, bundle length range: 20mm-360mm, bundle width range: 55mm-220mm, bundle height range: 55mm-220mm, output: approx. 40bundles/min, max. film roll diameter: 300mm, machine dimensions X/Y/Z: approx. 2900mm/1300mm/1950mm, weight: approx. 1500kg. 1.3) Mini robot. Overall line dimensions X/Y/Z: 10750mm/2350mm/2250mm, transport weight 1/2: approx. 4700kg/5000kg, total weight: approx. 10000kg. Without shrink tunnel. 2.1) Blister packaging line IMA Giant 1 B ...

Ratiostrech RS 10/2 2009 incl. ramp

Fully automatic stretch winding machine Spinny S2300 with electromechanical nider holder Pallet dimensions: L 1200 x W 800 x H 2600 mm Maximum weight: 1000 kg Hourly rate: approx. 20 pal./hour (depending on pallet height and type of winding) Conveying height: 500 mm Technical specifications: • Winding cycle, programmable via the electronic control panel and SIEMENS S7-1200, KTP700 Control Panel • Control SIEMENS PLC S7 1200 SAFE and HMI KTP700 • 15 freely programmable winding programs • Turntable stop in the end position • Conveying height: 500 mm • Usable width of roller conveyor: 1000 mm • Photocell for autom. Pallet height detection • Clamp for attaching the film to the pallet load • Automatic film cutting system at the end of the wrapping cycle • Frequency converter for adjusting the turntable speed 5 to 15 rpm • Frequency converter for adjust ...

A Wolf checkweigher with an integrated weighing unit Wipotech IW 40K is available. Infeed conveyor length: 600mm, weighing conveyor length: 700mm, outfeed conveyor length: 600mm, belt width: 400mm, direction of travel: right-left, max. product weight: 17kg, graduation: 1g, max. weighing weight: 15kg, throughput: approx. 200 products/min. Machine dimensions X/Y/Z: approx. 1300mm/500mm/1300mm, weight: approx. 200kg. Documentation vorhanden. An on-site inspection is possible.

A Happel layer palletizer is available. Products: bags/cartons/bundles/containers/drums, package rotation: 90°/180°/270°, pallet format: 800mm/1200mm, max. pallet height: 1500mm, min. product dimensions X/Y/Z: 150mm/150mm/40mm, max. layer weight: 150kg, max. palletizing capacity: approx. 2500pieces/h. Machine dimensions X/Y/Z: approx. 4000mm/2600mm/2500mm, weight: approx. 2500kg. An on-site inspection is possible.

Turntable diameter: 1500mm, max. load capacity: 1500kg, max. pallet dimensions X/Y: 1200mm/1000mm, max. pallet height: 2100mm, speed: 12rpm, max. film roll width: 500mm. An on site inspection is possible.

Stock shape glue + press belt, Type: SFAM 712_G, Year: 1995, Max.Size: 1650mm, Pressband Tünkers, Type: SFAM 712_G

BRASSE 1450 SE, Year: 2008, Max.Size: 1055 x 1450 mm, Max cutting force: 400 t, Max.Speed: 5500 Sh/h, Quicklock system, Centerline, in production

Labeller for disposable syringes Manufacturer: Bausch & Ströbel Type SME 6005 This machine allows the insertion of labels (self-adhesive labels), as well as piston rods into disposable syringes. Capacity 6000 syringes/h Volume of syringes 0.5 to 10 ml Diameter of syringes 7 to 17 mm Label dispenser LAETUS Control Camera

A tray sealing machine for the food industry is offered. Tray formats: Format A X/Y/Z: 267mm/326.5mm/65mm, Format B X/Y/Z: 227mm/178mm/35mm, Format C X/Y/Z: 106mm/145mm/36mm, VG function, Busch R5 vacuum pump. Inspection by appointment possible.

Offered is a valve bag filling system (50kg) with connected palletizer. Bag type: valve bags (paper, PE or PP), filling weight: adjustable up to max. 50kg, piping system with integrated conveying screw / dosing screw, pneumatic bag clamping, weighing unit, discharge conveyor belt. Automatic layer palletizer - Ehcolo PM 400. Year of manufacture: 2001, capacity: up to approx. 400 bags per hour, incline conveyor / bag flattener, empty pallet magazine, complete machine enclosure. Inspection possible by arrangement.

packaging line, consist of the following plant components: - Thermoforming machine from the manufacturer GEA, type PowerPak RT500, incl. accessories and spare tools (year of construction approx. 2015) The system pulls the product cups 50 mm deep, at an output of 10 cycles/min and thus 120 packs/min. Some of GEA's transport rails are still in place. - Inserting robot from the manufacturer Alpma, type ER 10 with integrated checkweighbridge (built approx. 2019) The inserting robot has its own vacuum pump - Leak monitoring system from the manufacturer DVC (year of construction approx. 2019) Technical specifications Automatic checkweigher/checkweigher Manufacturer: Minebea Intec Type: EWK Model No.: FLEXUS 10/WS 2kg WZG-0CE Year of manufacture 2018 Max. packages/min: 128 Max. belt speed: 0.791 m/s Pneumatic pressure: 300 kPa Temperature limits: 5 - 40 °C Connected lo ...

An Illig slide blister machine is available. Blister length range: 110mm-500mm, blister width range: 50mm-280mm, max. blister depth: 80mm, fold-over edge. An on-site inspection is possible.

A film wrapping machine Heine Ilsemann is available. Materials: polypropylene/cellophane/PVC/coated paper, output: 200cycles/min, connected load: 8kW, machine dimensions X/Y/Z: approx. 3500mm/1100mm/2000mm, weight: approx. 2200kg. An on-site inspection is possible.

A continuous glass capping machine VTB with gas flushing for twist-off lids is available. Glass volume: 225ml/380ml, capping capacity: 10-60lids/min, product material: stainless steel 1.4301, machine dimensions X/Y/Z: approx. 3000mm/1000mm/2300mm, weight: approx. 1200kg. Documentation available. An on-site inspection is possible. Expected to be available August 2026.
