CNC Turning- and Milling Center OKUMA LB 3000EX II-MC1000 Space Turn
metal working machines / lathes
turning diameter:340 mmturning length:1000 mmcontrol:OSP 300 LA swing diameter over cross slide guide:470 mmswing diameter max. over bed cover:580 mmtravel -x axis:260 mmtravel -z axis:1065 mmrapid travel - longitudinal/face:30 / 25 m/minbar material dia.:52 mmspindle diameter:80 mmSpindle RPM:5000 ...
Manufacturer: OKUMA
Model:LB 3000EX II-MC1000 Space Turn
Type of machine: CNC Turning- and Milling Center
item-No.: 169655578
Quantity: 1
Date: 08.06.2026
Year of manufacture: 2017
Location: Schweiz
Price:
Machine in stock:Yes
Seller-item-No.:1070-100717
turning diameter:340 mm
turning length:1000 mm
control:OSP 300 LA
swing diameter over cross slide guide:470 mm
swing diameter max. over bed cover:580 mm
travel -x axis:260 mm
travel -z axis:1065 mm
rapid travel - longitudinal/face:30 / 25 m/min
bar material dia.:52 mm
spindle diameter:80 mm
Spindle RPM:5000 1/min
spindle drive:22 / 15 kW
turret stations / rotary tool stations:12/12 VDI 40
:7 kW
speed of driven tools:6000 1/min
Tailstock Travel:1015 mm
tailstock quill taper MT:5
total power requirement:38,7 kVA
weight of the machine ca.:6500 kg
dimensions of the machine ca.:4 x 2,5 x 2 m
High precision Turning and Milling Centre with turret for milling tools and main spindle with C- axis.
The Stiefelmayer mandrel for inside clamping of hollow shafts can b e replaced by regular 250 mm Kitagawa chuck.
Machine can be shown undeer power
turning length:1000 mm
control:OSP 300 LA
swing diameter over cross slide guide:470 mm
swing diameter max. over bed cover:580 mm
travel -x axis:260 mm
travel -z axis:1065 mm
rapid travel - longitudinal/face:30 / 25 m/min
bar material dia.:52 mm
spindle diameter:80 mm
Spindle RPM:5000 1/min
spindle drive:22 / 15 kW
turret stations / rotary tool stations:12/12 VDI 40
:7 kW
speed of driven tools:6000 1/min
Tailstock Travel:1015 mm
tailstock quill taper MT:5
total power requirement:38,7 kVA
weight of the machine ca.:6500 kg
dimensions of the machine ca.:4 x 2,5 x 2 m
High precision Turning and Milling Centre with turret for milling tools and main spindle with C- axis.
The Stiefelmayer mandrel for inside clamping of hollow shafts can b e replaced by regular 250 mm Kitagawa chuck.
Machine can be shown undeer power
