Machining Center - Horizontal MAZAK FH 8800

x-travel:1300 mm
y-travel:1100 mm
z-travel:1000 mm
spindle turning speed range:10 - 10000 U/min
numbers of positions in the tool changer:80
spindle taper::MAS BT 50
size of pallet:800 x 800 mm
number of pallets:2
total power requirement:65 kVA
weight of the machine ca.:24 t

The MAZAK FH8800 is a robust horizontal CNC machining centre designed for the precise and productive machining of large workpieces. The machine features travel ranges of 1,300 × 1,100 × 1,000 mm, two 800 × 800 mm pallets and a high-performance spindle running at 10,000 rpm.

Technical specifications
·Travel ranges (X/Y/Z): 1,300 / 1,100 / 1,000 mm
·Pallet size: 800 × 800 mm
·Number of pallets: 2
·Spindle speed: 10,000 rpm
·Control system: Mazatrol 640 M CNC
·Tool holder: BT50
·Tool magazine: Chain magazine
·High-pressure pump for cooling lubricant (centralised supply at the production site, Figure 13)
·Machine weight: approx. 24,000 kg
·Total power requirement: approx. 65 kVA


seller offer No. resale 3402-260704
