Carousel Turning Machines (Lathes) used for sale (33)

Inv. Num. : 9289 Type: Tandem 400 Producer: FAMAR Created: 2013 Parameters: Table diameter: 480 mm Max. workpiece diameter: 400 mm Max. length of the workpiece: 300 mm Number of Spindles: 2

faceplate diameter: 6300 mmswing diameter: 9700 mmturning height: 4900 mmram head dimension: 360 x 360 mmfaceplate turning speed range: 0,4 - 50 U/minworkpiece weight: 150 tmain drive motor: 71 kWControl: Siemens Sinumerik 840D total power requirement: 230 kVAweight of the machine ca.: - tdimensions of the machine ca.: - m2010 overhauled and modernised, new electric etc, equipped with:- Siemens Sinumerik 840D (2 Panels Left/right Side)- C-axis and milling spindle- 2 ram support on cross beam- milling spindle with 1000 rpm, 28kW (right ram)- Turning support (left ram)The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 9157 Type: SK 12 Producer: TOS Created: 1963 Parameters: Table diameter: 1120 mm Maximum workpiece weight: 5000 kg Max. workpiece diameter: 1250 mm Max. workpiece height: 1000 mm

faceplate diameter: 4500 mmswing diameter: 5000 mmturning height: 2500 mmworkpiece weight max.: 63 tno. of the slides: 2 max. ram stroke: 1600 mmfaceplate turning speed range: 0,3 - 32 U/minAnzahl der Drehzahlstufen: 4 total power requirement: 130 kWweight of the machine ca.: 145 tdimensions of the machine ca.: 6,6 x 11,4 x 8,4 m- DRO- 2 swivable Rams (-15° / +40°)The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

RAFAMET KCH 360/450 vertical turret lathe was built in 1987 in Poland by Fabryka Obrabiarek RAFAMET. The machine is used for precise machining of large and heavy workpieces whose size does not allow effective machining with standard machines. RAFAMET KCH 360/450 is distinguished by its stable design, equipped with two vertical supports and one side support. Machining is performed on a work table with a diameter of 3600 mm by means of a reliable vertical spindle. The work table offers 20-position speed adjustment in the range of 0.6 to 50 rpm, enabling precise adjustment of the parameters to the production requirements. The position of the head in all linear axes is continuously monitored by state-of-the-art SONY digital readout, which ensures high precision measurement. All this makes the offered KCH 360/450 vertical turret lathe an excellent choice for, among others, the energy, ship ...

faceplate diameter: 3600 mmswing diameter: 4500 mmturning height: 1850 mmmax. workpiece weight: kgvertical adjustment of the crossrail: mmtravel -x axis: mmtravel -y axis: mmtravel -z axis: mmturning speed range: 0,6- 50 U/minpower capacity: kWmax. torque on the faceplate: weight of the machine ca.: 72 tdimensions: mverticale turning machine double coloumn - digital scale - double coloumn - 2x ram - movable cross slide - extra toolholder (four station) on the side of facing plateThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 1000 mm, 450 mm

Inv. Num. : 9150 Type: CNC 10 A/B Producer: DÖRRIES Created: GO 2015 Parameters: Control system: Siemens Sinumerik SL Table diameter: 1000 mm Engine power: 69 kW Max. workpiece diameter: 1500 mm Max. workpiece height: 450 mm Max. workpiece weight: 5000 kg Maximum table speed: 2-120/ 20-400 1/min Equipment: Chip conveyor 4-position turret Hydraulic/Manual 3-Jaw Chuck

faceplate diameter: 1250 mmswing diameter: 1400 mmturning height: 1400 mmcontrol: Siemens 840D travel -x axis: -80 / +1100 mmtravel -z axis: 1060 mmworkpiece height max.: 1400 mmmax. workpiece weight: 8000 kgShank diameter: 200 x 240 mmtable turning speeds: 2- 400 U/mindrive capacity - spindle motor: 44 kWmax. torque on the faceplate: 14510 Nmrapid traverse: 12 m/minturning speed range - milling: 0,01 - 7,4 U/minspeeds of tool: 4 - 3000 U/minwork piece power: 22 kWTorque: 840 Nmtotal power requirement: 90 kVAweight of the machine ca.: tdimensions of the machine ca.: mequipped with:- CNC control Siemens 840Dsl- C-axis- driven tools- tool changer 12-fold (driven tools)- complete enclosure- chip conveyor- coolant systemThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 9082 Type: SKJ 8 NC Producer: TOS Created: GO 2020 Parameters: Control system: MEFI CNC 872 Max. workpiece diameter: 800 mm Max. workpiece height: 630 mm Max. workpiece weight: 2000 kg Length: 2000 mm Width: 2550 mm Height: 3700 mm Weight: 10000 kg Equipment: Hydraulic table clamping Electric rotation of the cutter head Ball screws GO 2020: Complete machine overhaul with conversion to a new MEFI CNC 872 control system Conversion from the original hydraulic drives to Yaskawa servo motors New electrical installation New hydraulic system and central lubrication

faceplate diameter: 2950 mmswing diameter: 3200 mmturning height: 3500 mmtable load: 20 tfeed range: 3000 mm/minmain drive motor: 70 kWmilling drive: 16,1 kWControl: total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: m CNC-control FAGOR 8070 C-axis with 360,000 positions Milling headInspection under power in the factory possible.Machine location is Spain.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 9058 Type: SPV 40 CNC Producer: CZ. TECH Created: 2008 Parameters: Control system: SIEMENS Table diameter: 533 mm Feed length X-axis: 550 mm Feed length Z-axis: 850 mm Max. turning diameter: 850 mm Max. workpiece height: 800 mm Max. workpiece weight: 800 kg Weight: 12500 kg

faceplate diameter: 6300 mmswing diameter: 7000 mmturning height: mmram adjustment: mmcross rail adjustment - vertical: mmram head - cross travel: mmram swivable +/-: °main drive: kWtable revolutions:: 0 - 14 U/mnworkpiece weight: 75 /125 tram head dimension: mmtotal power requirement: 170 kWweight of the machine ca.: 120 tdimensions of the machine ca.: 10 x 10 x 7 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 9028 Type: SK 12 Producer: TOS Created: 1971 Parameters: Equipment: Accessories

faceplate diameter: 1130 mmswing diameter: 1500 mmturning height: 1100 mmfaceplate diameter: mmswing diameter: mmtotal power requirement: 30 kWweight of the machine ca.: tdimensions of the machine ca.: mBrand: STANKOTYPEL 1512Build in: 1977with pneumatick 3-jaw stuck 1130 mmmax. turning diameter 1500 mmmax. turning height 1100 mmMotor 30 KWThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 5000 mm, 8000 mm, 4000 mm

Berthiez Vertical Turning Lathe • Year of manufacture: 1982 • CNC type: older system (CNC axes) Dimensions and Working Parameters • Table diameter: 5000 mm • Maximum turning diameter: 8000 mm • Maximum turning diameter at center: 5000 mm • Maximum workpiece height: 4000 mm • Ram travel (T): 3600 mm • Saddle travel (TA): 650 mm Speed and Power • Table rotation range: 0.6 – 60 rpm • Table motor power: 140 kW • Maximum load on hydraulic support: 160 t • Ram feed speed: 400 mm/min • Saddle feed speed: 2500 mm/min • Spindle rotation for milling: 0.01 – 0.50 rpm • Positioning speed: 0.001 – 0.50 rpm Tool Carriages 1. Hand-Operated (Primary) Carriage • Kulannum section size: 360 × 360 mm • Axial travel (CA): 2500 mm • Horizontal travel (CB): 3400 mm • Tilt range (E-F): 15° – 45° 2. Side Tool C ...

faceplate diameter: 1000 mmswing diameter: 1400 mmturning height: 1400 mmcontrol: SIEMENS 850M total power requirement: 125 kWweight of the machine ca.: 38 tdimensions of the machine ca.: mStocknumber 1020042Type of machine CNC VTLMake PIETRO CARNAGHIType AC 10 CNCBuild in 1987Type of control Siemens 850 M/EFaceplate diameter 1000 mmMax. Swing diameter 1400 mmTurning height max. 1400 mmTotal Power (KW) totaal 125 Lenght (mm) 11000Width (mm) 8000Height (mm) 6000Weight 38000 kg Additional informationwith driven toolswith pallet changerThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 8852 Type: SKJ 8 CNC Producer: TOS Created: GO 2006 Parameters: Control system: MEFI CNC 859 Table diameter: 780 mm Motor power: 40 kW Max. workpiece diameter: 1050 mm Max. workpiece height: 630 mm Max. workpiece weight: 2000 kg Weight: 9000 kg Equipment: Ant electric drives

faceplate diameter: 3.000 mmswing diameter: 7.000 mmturning height: 3.000 mmControl: FANUC 18i-TB total power requirement: 60/75 kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 8679 Type: VL 5S Producer: Emag Created: 2007 Parameters: Control system: Siemens 840 SL Feed length X-axis: 570 mm Feed length Z-axis: 200 mm Max. turning diameter: 220 mm Maximum workpiece weight: 120 kg Maximum spindle speed: 4500 1/min Max. workpiece height: 110 mm Weight: 6500 kg Equipment: Turret with Leiftool drive Chip conveyor

Inv. Num. : 8680 Type: VSC 250 DS Producer: Emag Created: 2007 Parameters: Control system: Siemens 840 SL Table diameter: 260 mm Feed length X-axis: 680 mm Feed length Z-axis: 200 mm Maximum turning length: 100 mm Max. turning diameter: 250 mm Maximum workpiece weight: 40 kg Motor power: 35 kW Length: 3800 mm Width: 2100 mm Height: 2400 mm Weight: 7500 kg Equipment: Chip conveyor

Inv. Num. : 5411 Type: SK 12 Producer: TOS Created: 1961 Parameters: Table diameter: 1200 mm Max. turning diameter: 1300 mm Maximum workpiece weight: 4 t Max. workpiece height: 1000 mm Weight: 18.3 t

Inv. Num. : 8204 Type: SK 12 Producer: TOS Created: 1953 Parameters: Max. turning diameter: 1350 mm Clamp plate diameter: 1180 mm Length: 2360 mm Width: 3860 mm Height: 4260 mm Weight: 18300 kg

Key data: 3600 mm, 4200 mm, 4800 mm

Specifications Control Siemens Sinumerik 840 Dsl Main dimensions and travels Face plate diameter 3,600 mm Circumferential diameter (max.) 4,200 mm Workpiece height (max.) 4,800 mm Total height of the machine 8,700 mm Maximum workpiece weight 80,000 kg. Table base Y Horizontal table displacement 2,000 mm Crossbar Vertical adjustment of the crossbeam in 100 mm increments 2,800 mm Crossbeam Support (Right) Horizontal adjustment support - 1,800 to + 2,200 mm Vertical displacement of the chisel slide valve 1,500 mm Cross-section of the chisel slide 240x240 mm Tool stations 20 pcs. Side Support (Right) Vertical adjustment support 2,800 mm Horizontal displacement of the chisel slide valve 1,000 mm Cross-section of the chisel slide 240x240 mm Turning diameter max./min. 4500/2500 mm Tool Changer Main Drive: Main motor power 105 kW Face plate speed ...

Key data: 4000 mm, 5000 mm

Specifications Control SIEMENS SINUMERIK 840 Dsl Main dimensions and travels Face plate diameter 4,000 mm Circumferential diameter (max.) 5,000 mm Workpiece height (max.) 5,000 mm Total height of the machine 9,250 mm Maximum workpiece weight 80,000 kg Table base Y Horizontal table displacement 2,500 mm Crossbar Vertical adjustment of the crossbeam 3,200 mm in 50 steps Crossbeam Support (Right) Horizontal adjustment support - 2740 + 2740 mm Vertical displacement of the chisel slider 1,800 mm Cross-section of the chisel slider 250x210 mm Side Support (Right) Vertical adjustment support -25 + 2170 mm Horizontal displacement of the chisel slider 1,000 mm Cross-section of the chisel slider 250x210 mm Turning diameter max./min. 4,500/2,500 mm Main Drive: Main motor power 100 kW Face plate speed range 0.63 – 63 rpm. Maximum torque a ...

Inv. Num. : 7997 Type: SC 3200 Producer: TITAN Created: GO 2020 Parameters: Control system: Sinumerik 840D SL Table diameter: 3000 mm Max. turning diameter: 3300 mm Motor power: 55 kW Max. workpiece height: 2260 mm Max. workpiece weight: 18000 kg Maximum table speed: 92 1/min Weight: 48000 kg

overhauled: 2007 Control Siemens ... Sinumerik 840 D Max. workpiece diameter ... 2500mm Table diameter ... 2240mm Max. workpiece height ... 1250mm Axis Z ... 1000mm Max. workpiece weight ... 10000 kg Main engine power ... 55kW L x W x H 7000x4400x5500mm Machine weight ... 37900kg The machine is in good condition. More info on request.

Clamping claw box made of solid steel GR 9 (new) 4 pieces

Inv. Num. : 6598 Type: SK 12 Producer: ZPS Created: 1964, GO 1994 Parameters: Table diameter: 1180 mm Clamping plate speed: 5.3-225 1/min Max. turning diameter: 1350 mm Max. workpiece height: 900 mm Max. workpiece weight: 5000 kg Length: 2360 mm Width: 3860 mm Height: 4260 mm Weight: 18300 kg

Description SHOOTING FRORIEP 40Dv Carousel Lathe. Modernized in 1998, among other things, a driven tool system (C-axis) was installed and the control was modernized to 840 C. Details Serial number 11330051 Year of construction 1980 Control SIEMENS electrical connection 400 V Face plate diameter 3,500 mm Workpiece height 3,000 mm Face plate over corridor 160 mm Total power requirement 71 kW Space requirement approx. 13 x 6 m Reconstruction 1998

Inv. Num. : 6305 Type: SKJ 20 Produzent: TOS Erzeugt: 1982 Parametern: Tischdurchmesser: 2000 mm Maximales Werkstückgewicht: 15000 kg Max. Werkstückhöhe: 1200 mm Maximale Tischdrehzahl: 170 1/min Gewicht: 35000 kg

Vertical lathe KOLOMNA 1540 T CONVENTIONAL MACHINE READY TO INSTALL Spindle diameter 4.000 mm Working diameter 4.140 mm Max working height 2.060 mm Ram travel 1.250 mm Weight over spindle 100 ton Motor power spindle 100 kW Boring/milling unit included Nr.02 RAM with visualization by DRO Excellent conditions, mechanical really like a new.

Table diameter 1450mm Max working diameter 1600mm Max height under crosstravel 1000mm Nr. 02 RAM Visualization by DRO 4 axes Good working conditions Machine weight18 ton

Qty. 1 Second-hand roll lathe Mfc.: Herkules Type: WD-700 Built: 1952 General overhauled by Hoesch-MFD in 1990 Centre height: 600 mm Turning length: 2750 mm 2-axis digital display – Mfc.: Micro Wizard Longitudinal drive Standstill torque: 14 Nm Rated revolution: 2500 RPM Feeding range: 5 – 100 mm/min. Rapid speed: 2500 mm/min. Plain drive Standstill torque: 14 Nm Rated revolution: 3000 RPM Feeding range: 5 – 100 mm/min. Rapid speed: 2500 mm/min.
