3 DONAU radial drilling machines used machines

Used Radial Drilling Machine DONAU Donauflex 145 Year of Make: 2006 Only a few hours of operation. • Drilling capacity in steel 45 mm • Boom travel 1,050 mm • Drilling radius min. 540 mm / max. 1,590 mm • Spindle speed 15 - 2,800 rpm • Tapping device • Tool holder MK 4 • Hydraulic clamping for boom and lifting column • Electromagnetic feed clutch • Machine light

Code 81221 Description Position Controlled Fast Radial Drilling machine Make DONAU Model DR 32 NC Serial No. 7107 Year 1984 Control Heidenhain TNC 145 Drilling cap. in St. 60 in full 32 mm Drilling cap. in Castiron GG 22 in full 45 mm Thread cutting in St. 60 M 26 Thread cutting in Castiron GG 22 M 36 Table 1120 x 800 mm X – Axis 800 mm Y – Axis 630 mm Z – Axis ( Quill ) 170 mm Max. distance Column-Spindel 750 mm Vertical movement Spindelhead 400 mm Spindle taper MC 4 Spindle speeds 45 – 2240 rpm Quill movement 170 mm Rapide feed 8000 mm/min Feeds 4000 mm/min Motor 2,2 / 4,0 kW 380 Volts Dimension 5,0 x 4,0 x 2,7 meters (L x W x H) Weight 3000 kg Accessoiries Position controlled in X – Y – Z ( Quill ) Coolant Machine can also be used without control Condition Machine is in good  ...

Code 111258 Description Rapid Radial Drilling machine Make DONAU Model DR – 24 Serial No. 2300 – 3 Year 1984 Drilling cap. in St. 60 in full 28 mm Drilling cap. in Cast Iron 35 mm Tapping cap. in St. 60 M 20 Tapping cap. In Cast Iron M 30 Spindle taper 3 MK Spindle radius max / min. 1000 / 400 mm Min/max height spindle / top of table 80 / 650 mm Arm traverse 450 mm Spindle traverse 175 mm Number of speeds 18 steps Speed range 45 – 2240 rpm Number of feeds 4 Feed range 0,075 – 0,15 – 0,3 – 0,45 mm/rev. Working surface table 1200 x 500 mm Motor 1,1 / 1,6 kW – 380 Volts Dimension W x D x H 1200 x 1600 x 1910 mm Weight 1400 kg Accessoiries screw cutting Condition Machine is in normal condition

Rapid radial / Rapid radial / Snel radial DANUBE DR 13

Offered is a rapid radial/column drilling machine. Drilling capacity: up to approx. Ø50mm. Speed range: 58-1275rpm. Thread cutting device: available, outreach: 920mm, machine lamp: available, baseplate/table size X/Y: approx. 1100mm/400mm, T-slots: 2 at the rear left, motor power: approx. 1.5kW without coolant system, machine weight: approx. 1200kg. Inspection under power by arrangement possible.

High speed radial drilling machine, radial drilling machine, drilling machine, boom drilling machine, high speed radial drilling machine -Clamping table: 400 x 1100 mm -Projection: 930 mm -Taper mount: MK4 -Engine power: 1.35/1.8 kW -Speed: 41-1700 rpm -Columns: Ø 200 mm -Spindle stroke: 125 mm -Thread cutting device: YES -Feed: 0.075 - 0.3 mm/rev -Dimensions: 1800/1235/H2240 mm -Weight: 1500kg

bore capacity in steel (diameter):45 mm WORKING RANGE -BORING-:. - drilling capacity full bore (steel):45 mm - drilling capacity full bore (cast iron):55 mm - horizontal travel:1050 mm - vertical travel:450 mm - sleeve stroke:200 mm WORKING SPINDLE / HEAD:. - spindle revolutions (min):15 /min - spindle revolutions (max):2800 /min - number of gears:2 - taper fixture : MK 4 :. - spindle power (continuous):5.5 kW - torque (max.):250 Nm - max. distance spindle ... clamping surface:710 mm - thread cutting attachment : yes :. TABLE:. - clamping surface (left-right):1200 mm - clamping surface (front-back):750 mm ELECTRICAL SPECIFICATIONS:. - total power consumption:7 kW - mains power supply:9.3 kVA - mains voltage:400 V - mains frequency:50 Hz DIMENSIONS / WEIGHTS:. - space requirements length:3000 mm - space requirements width:3000 mm - total height:3000 mm - total weigh ...

Code 220406 Description of fast radial MK-4 Brand DONAU Type DR – 32 Machine r. 686 – 3 Year of construction ± 19.. Capacity in steel 60 32 mm Capacity in GG 45 mm Tapping in steel 60 M 26 Thread cutting in GG M 36 Spindle holder 4 MK Projection 900 mm Table 1200 x 600 mm Vertical movement of the boom 400 mm Spindle stroke 190 mm Spindle table min. – max. 80 – 650 mm 18 spindle speeds 31 – 1370 rpm Spindle feeds 0.1 – 0.15 – 0.2 – 0.3 mm/rev Power 1.5 / 2.2 kW – 380 volts Accessories tapping device Dimensions Br. x D x H 1200 x 1600 x 1910 mm Weight 1700 kgs Condition machine is in normal condition

Code 230302 Description of fast radials Brand DONAU Type DR – 13 G Machine r. 321 – 2 Year of construction 1966 Capacity in steel 60 13 mm Capacity in GG 16 mm Thread cutting capacity in steel M8 – M 10 Thread cutting capacity in cast iron M 10 – M 12 Spindle holder 2 MK Projection 820 mm Table 1000 x 700 mm Vertical movement of the boom 400 mm Spindle stroke 100 mm Spindle table min. – max. 180 – 580 mm Spindle speeds infinitely variable in 2 steps 200 – 1100 / 600 – 3400 rpm Power 0,37 / 0,44 kW – 380 Volt Dimensions Br. x D x H 1000 x 1300 x 1800 mm Weight 590 kgs Condition machine is in normal condition

Key data: 40 mm, 1007 mm

Code 231027 Rewriting Controlled Fast Radials Make DONAU Type DR 40 Machine No. 1137 – 3 Built in 1988 Drilling into full stem 60 40 mm Drilling into full GG 22 50 mm Tapping capacity into the St. 60 M 33 Tapping capacity into the GG 22 M 45 Steep taper of the drilling spindle SK 40 Feed normal ( 5x ) 0.075 – 0.6 mm/rev Drilling spindle speeds 18 pcs. 35 – 1800 rpm Drilling spindle stroke 200 mm Drilling radius min/max 350 / 1300 mm Projection min/max 120 / 1007 mm Height adjustment of the drilling spindle head 450 mm Distance drilling spindle/table min/max 350 / 800 mm Table top 1225 x 750 mm Power 2 / 3 kW 380 Volt Weight 2000 kgs Dimensions LxWxH 2300 x 1225 x 2400 mm Accessories for tapping device Coolant system Condition machine is in good condition

Specifications: - Drilling capacity into solid steel ST 60 28 mm - Drilling capacity GG 25 40 mm - Threading ST 60 M 30 - Threading GG 25 M 40 - Drilling spindle holder MK 3 - Spindle diameter 50 mm - Quill stroke 150 mm - 18 drilling spindle speeds 45 - 2240 rpm - 4 drill feeds 0.1 - 0.45 mm - min./ max. distance spindle – table 300 / 700 mm - Drilling radius min / max 305 / 1005 mm - Table height 820 mm - Table size 1200 x 600 mm - Drive 400 V / 6 kW - Space requirement approx. W 1300 x H 2800 x D 2300 mm - Weight approx. 1500 kg -with: - Tapping device - hydr. Columns + Boom Clamp - Coolant device - T – Vertical grooves on the left side of the machine

Key data: 40 mm, 900 mm

40 DONAU fully functional, Condition : well used

Key data: 32 mm

Boom travel approx. 600 mm Distance table - spindle nose min. 250, max. 650 mm Quill stroke 190 mm Speed range: 18 speeds 41-1,850 rpm Drill feeds: 4 pieces ( from 0.1 - 0.3 mm/rev ) Work table 600mm x 1200mm Tool holder MK 4

Danube DR 23 - High Radial Drilling Machine -Drilling capacity / steel approx. 28mm -Projection approx. 700mm -Morse taper MK 3 -Speed range 70-1550 rpm - Gearbox -Feed range 0.075-0.3mm -Drilling depth 130mm -Tapping device -Hydraulic clamping -Documentation Dimensions: Hjbkn Asvw D Smeu S Tol LxWxH 2x1.7x1.9 meters / Weight 1900Kg

Works perfectly.

Drilling capacity steel/cast iron: 25mm/32mm, tapping capacity steel/cast iron: M20/M24, tool holder: MK4, spindle speed: 3500rpm, feed rate: 1050mm/min, throat range: 420mm-1320mm, cantilever travel: 900mm, column vertical travel: 430mm, quill stroke: 140mm, swivel range: 325°, table dimensions X/Y: 1200mm/600mm, drive power: 1.6kW, machine dimensions X/Y/Z: approx. 2500mm/900mm/1500mm, weight: approx. 2200kg. Documentation available. On-site inspection is possible.

Manufacturer: DONAU Model: DR 50 Find more here - / Contact us at -

Offered is a used Donau DR 32 rapid radial drilling machine series 731. Tool holder: MK4, spindle stroke: 200mm, outreach: approx. 900mm-1050mm, height adjustment: approx. 400-600mm, speed range: 40-2000rpm, feeds: 0.1/0.2/0.3/0.4mm per revolution, integrated coolant system, equipped with swiveling arm, large T-slot table, weight approx. 1500kg-1800kg, machine dimensions X/Y/Z approx. 1800mm/1000mm/2200mm. Inspection is possible by appointment.

hobbing length: 1750 mm milling width: 260 mm max. module: 10 min. module: 12 total power requirement: 8 kW weight of the machine ca.: 4500 kg dimensions of the machine ca.: m D O N A U - K N A P P (Germany) Universal Automatic Rack Milling Machine Model UZFM – V 300 H Year approx. 1980 Serial No. 80-234x Max. length of rack 1,750 mm Milling travel / milling width cross max. 260 mm Module, steel / cast iron 10 / 12 Table clamping size 275 x 1,850 mm Mounting height below cutter, depending on cutter Ø 136 – 410 mm Cutter Ø, min./max Ø 125 + 2 x cutting depth / Ø 160 mm Cutter width max. floating / with support 50 / 140 mm Cutter mandrel Ø max. 50 mm Milling spindle head, swivelling right / left 30 / 45 ° 9 spindle speeds 22 � ...

hobbing length: 2100 mm milling width: 300 mm max. module: 16/18 min. module: total power requirement: 10 kW weight of the machine ca.: 5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 2900 mm y-travel: 1000 mm z-travel: 700 mm control: Heidenhain total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

hobbing length: 1750 mm milling width: 260 mm max. module: 10 mm table size incl. water gutter: 460 x 2100 mm table clamping surface:: 250 x 1850 mm cutter width - max.: 100 mm feed of the milling slide, stepless: 0 - 500 mm/min. rapid traverse feeds: 3000 mm/min milling head -swivable +/-: 30 ° Rotation speed range of milling head, in 9 steps: 29 - 178 rpm Milling head swivable 2 sides helical gearcutting: 30 ° total power requirement: kW weight of the machine ca.: 4 t dimensions of the machine ca.: 4 x 1,85 x 1,85 m Equipment/accessories - 7 vices - change wheels - Clamping devices - Documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 32 mm arm length: 1230 mm table surface area: 1200 x 500 mm bore stroke: 180 mm feed - independent: 0,10 - 0,15 - 0,20 - 0,30 mm turning speeds: 60 - 1800 U/min taper MK: 4 total power requirement: 2,7 kW weight of the machine ca.: 1,8 t dimensions of the machine ca.: 2,2 x 1,8 x 2,3 m Quick radial with: - Feed - Thread cutting device The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

hobbing length: 1750 mm milling width: 260 mm max. module: 10 table size incl. water gutter: 460 x 2100 mm table clamping surface:: 250 x 1850 mm cutter width - max.: 100 mm feed of the milling slide, stepless: 0 - 500 mm/min. rapid traverse feeds: 3000 mm/min milling head -swivable +/-: 30 ° Rotation speed range of milling head, in 9 steps: 29 - 178 rpm Milling head swivable 2 sides helical gearcutting: 30 ° total power requirement: 4 kW weight of the machine ca.: 4 t dimensions of the machine ca.: 4 x 1,85 x 1,85 m Milling length 1750 mm Milling width 260 mm Module - max. 10 Table dimensions incl. water channel 460 x 2100 mm Table clamping surface: 250 x 1850 mm Milling cutter width - max. 100 mm Feed of the milling carriage, infinitely variable 0 - 500 mm/min. Rapid traverse 3000 mm/min Milling head - tiltable + / - 30 ° Speed range of the milling spindle, in 9 steps 29 - 178 rpm M ...

Radial drilling machine WEBO type R4bRFabr. No. 15 / E195 Year of construction approx. 1965Drilling capacity 40 mmThroat: approx. 1250 mmSpindle holder: MK 4Spindle speed: 30 - 1325 rpm. 9 stepsFeed from 0.12 - 2 mm/rev. 9 steps; used
