231 DECKEL used machine for sale

Inv. Num. : 9073 Type: FP 4 MA Producer: DECKEL Created: 1998, GO 2003 Parameters: Control system: HEIDENHAIN Work table length: 800 mm Work table width: 465 mm Maximum vertical spindle speed: 4000 1/min X-axis travel: 465 mm Y-axis travel: 370 mm Z-axis travel: 380 mm Machine height: 1734 mm Machine length: 2000 mm Machine width: 1600 mm Machine weight: 1720 kg

Inv. Num. : 8185 Type: FP 3 NC Producer: Deckel Generated: Parameters: Work table length: 700 mm Work table width: 460 mm Maximum vertical spindle speed: 4000 1/min X-axis travel: 400 mm Y-axis travel: 400 mm Travel Z axis: 340 mm Machine height: 1800 mm Machine length: 2000 mm Machine width: 1400 mm Machine weight: 1900 kg

Key data: 800 mm, 650 , 650

We have various spare parts in stock for the following machine. Please inquire! DMU 80E Built in 1999 Spindle Hours 35000 Heidenhain LE 426M Travels X/Y/Z axis 800/650/550 mm Tool changer with double gripper for 24 tools Tool holder ISO 40 Spindle speed 20-12000 rpm Feed speed 20-10000 mm/min Rapid traverse 15 m/min Spindle motor 15 kW Table size 1100 x 650 mm Weight approx. 6500 kg Dimensions: 3400x2400x2800 mm Accessories: Coolant device, el. Handwheel HR410

Universal milling head, milling chuck, milling extension, angle milling head -Manufacturer: Deckel, milling head from milling machine FP4L -Mounting: SK40 -Milling head: swiveling -Tool clamp: electric motor -Individual components: see photos -Transport dimensions: 1690/360/H745 mm -Weight: 548 kg

Rotary table, rotary indexing table, dividing head, dividing head -Clamping surface: Ø 305 mm -Height: 120 mm -Dimensions: 420/370/H120 mm -Weight: 50 kg

Control panel, operating unit, control board, operating panel, operating unit, keyboard, CNC control -Manufacturer: Deckel, control unit from milling machine Deckel FP4L -Transport dimensions: 1200/800/H220 mm -Weight: 33 kg

Cross table, cross-sliding table, clamping table, clamping plate with T-slots, clamping angle -Cross table for lid type: KF12 -Table surface: 400 x 400 mm -Travel path: x 50 mm/y 65 mm -Weight: 60 kg

Flat belt pulley, toothed pulley, multi-belt pulley -Spare part comes: from a machining center cover type FP3A -Diameter: 80 mm -Recording: 28 mm -Dimensions: 80/80/H61 mm -Weight: 1.2 kg

Rotary encoder, tachometer, encoder -Spare part comes: from a machining center cover type FP3A -Number: 1x speedometer available -Price: per piece -Dimensions: 83/122/H95 mm -Weight: 1.1 kg

Spiral milling device, dividing head, dividing attachment, rotary table, rotary table -Admission inside: SK40 -Tip height: 65 mm -Distance between centers: 440 mm -Passage: Ø mm -Reversing coupling for: left u. Right spiral -Pivotable for conical spirals: 0 - 45 ° -Dimensions: 760/430/H310 mm -Weight: 61 kg

Spiral milling attachment, dividing head, dividing head, rotary table, rotary table dividing head, spiral milling attachment with all accessories -comes from a lid FP2 -Dividing head: Spiral milling attachment with all accessories, change gears, dividing plates -Maximum width: 415 mm -Recording: SK40 - Suitable for: Milling cutter sharpening -Translation: 1:40 -Dividing head: swiveling -Dimensions: 820/390/H440 mm -Weight: 80 kg

Universal tool milling machine DECKEL FP 4 MK with 3 axes active digital display Heidenhain TNC 113 Year of Make: 1990 Travel: X 500 Y 400 Z 400 Speed range: 50 – 2500 rpm With the following accessories: Rigid angle table 800 mm x 460 mm clamping surface Sliding vertical milling head Extendable drill quill Stepless feed via potentiometer Hydraulic tool clamping Hydraulic vise GRESSEL 125 mm Various SK 40 milling mandrels Splash guard cabin Automatic lubrication pump for X,Y,Z axis Machine Light Coolant Setup 4 pcs machine shoes Operating instructions

3 Axis Digital Display FAGOR Year of Make: 1975 Travel: X 500 Y 200 Z 400 Speed range: 40 – 2000 rpm With the following accessories: Universal table 660 x 380 mm clamping surface Vertical milling head Extendable drill quill Milling cutter protective housing Machine Light Various tool holders SK 40 Chip tray Coolant Setup 4 pcs machine shoes Operating instructions THE MACHINE IS IN VERY GOOD CONDITION

Clamping surface of the fixed angle table: 195 x 605 mm Table movement longitudinal/vertical automatic and by hand: 290/300 / 330/340 mm Headstock transverse movement by hand: 150 mm Spindle holder: ISA 40 16 spindle speeds: 40 - 2000 rpm 16 feeds: 10 - 500 mm/min Spindle drive motor: 380 V, 1/1.4 kW Weight approx.: 660 kg Space requirement: 1200 x 900 x 1570 mm

Tool milling machine DECKEL FP1 with 3 axis active digital display TNC 113 from educational institution -Travel X/Y/Z 300x160x340mm -Speed range 40-2000 rpm -Feed infinitely variable in three axes Hobkn Asv Abp Tju S Tjl -Rapid traverse in all three axes -Vertical milling head - 100mm movable -Vertical - Horizontal milling device -Drive power 1.5/1.9KW -Rigid angle table -3 axis digital display Heidenhain TNC113 -Coolant device -Work light -Documentation Dimensions: LxWxH 1.3x1.2x1.6 meters / Weight 850Kg

Tool milling machines DECKEL FP1 -Travel X/X/Z 245-150-340mm -Without vertical head / machine was only used for horizontal milling work -Speed range 95-1900 rpm -Built-in rotary table - Automatic feeds X & Y axis -Various collets -Documentation Dimensions: LxWxH 1.1x0.9x1.6 meters / Weight 650Kg

Tool Milling Machine Deckel FP2E -Extremely smooth running + fully functional -Automatic feeds + rapid traverse in X + Z axis -Machine with sliding head means larger Y-travel -Travel X/Y/Z 400x200x400mm -Speed range 40-2000 rpm -Tool holder ISO 40 -Vertical horizontal milling device -Vertical head swivel with drilling quill -Angle table -Various tool holders -Documentation Dimensions: LxWxH 1.5x1.7x1.8 meters / Weight 1500Kg

Milling machine Deckel FP 4 BJ 1985

This 3-axis DECKEL DMC 104V vertical machining center was manufactured in 2007. It features a Heidenhain iTNC 530 control system, a spindle with a maximum speed of 18,000 rpm, and a tool holder type HSK 63. The machine offers X/Y/Z travels of 1020/600/500 mm and a rapid traverse rate of 70 m/min. Consider the opportunity to buy this DECKEL DMC 104V vertical machining center. Contact us for more information about this machine.

DECKEL FP 2 tool milling machine with new 3-axis digital display -Well-maintained original condition -Travel X/Y/Z 400x200x400mm -Digital display 3-axis "NEW" -Angle table - table clamping surface 700x350mm -Speed range 40 - 2000 rpm -Automatic feeds / rapid traverses in all three axes -Tool holder ISO 40 -Vertical - Horizontal milling device -Vertical head swivel with drilling quill -Coolant device -Documentation Dimensions: LxWxH 1.5x1.7x1.8 meters / Weight 1500Kg

Tool milling machine DECKEL FP 2 LB from university in well-maintained original condition -3 - Axis digital display "ACURITE" -Travel X/Y/Z 795x300x400mm -Automatic feeds / rapid traverses in all 3 axes (18 pieces) -Spindle speeds 40-2000 rpm (18 pieces) -Horizontal + vertical milling device - ISO 40 - Tool holders -Table clamping surface 1000x440mm -Table clamping surface with additional table 1000x700mm -Vertical head swivel with drilling quill -Coolant device -Various tool holders -Machine light -Documentation Dimensions: LxWxH 2.5x2.4x1.8 meters / Weight 2200Kg

TOOL MILLING MACHINE - Cover FP 3 incl. Heidenhain 3-axis digital display -Machine with spindle brake motor -Travel X/Y/Z 500x300x400mm -Automatic feeds in all 3-axis -Rapid traverses in all 3-axes -Heidenhain 3-axis digital display -Speed range 40-2000 rpm -Vertical head swivel with drilling quill -Vertical - Horizontal milling device -Tool holder ISO 40 -Drive power 3 KW -Rotary tilt swivel table -Coolant device -Machine feet -Machine documentation Dimensions: LxWxH 1.6x1.2x1.8 meters / Weight : 1500Kg

Tool milling machine DECKEL FP 2 LB 3 axis digital display maintained original condition - 3-axis digital display - Travel X/Y/Z: 795 × 300 × 400 mm - Automatic feeds and rapid traverses in all 3 axes (18 stages) - Spindle speeds: 40–2000 rpm (18 steps) - Horizontal and vertical milling equipment - ISO 40 tool holders - Table clamping surface: 1000 × 440 mm - Swivelling vertical head with drilling quill - Coolant device - Various tool holders - Documentation available L×W×H 2.5×2.4×1.8 meters / Weight 2200Kg

gebr. Cover FP3 NC, built in 1983 in neat condition: Travel X: 400 mm, Y: 400 mm, Z: 400 mm Table size approx. 700 × 460 mm Tool holder SK 40 Spindle motor power typ. 2.0 – 3.0 kW Feed speed approx. 2 – 3,600 mm/min Rapid traverse up to approx. 4,000 mm/min Total weight approx. 1,800 – 2,000 kg Power supply / connection 380 V three-phase current Control Dialog 2

This 4-axis DECKEL DMC 835 V was manufactured in 2007. It features an NC dividing head EA 410, manual tailstock, and a TS 640 measuring probe. Additional highlights include a coolant/air blast switch, flushing gun for chip removal, and an electronic handwheel. This machine is complete with accessories. If you are looking to get high-quality milling capabilities consider the DECKEL DMC 835 V machine we have for sale. Contact us for more information.

This DECKEL FP4A was manufactured in 1994. A vertical machining centre featuring a travel range of X=565mm, Y=505mm, Z=400mm, SK40 tool holder, and a spindle speed of up to 4000 rpm. Consider the opportunity to buy this DECKEL FP4A vertical machining centre. Contact us for more information.

Year of construction 80s Technical data: Travel X/Y/Z: 400 / 400 / 400 mm Tool holder: SK 40 Speed range: 40 - 4000 1/min Feed, step-by-step Adjustable: 2 - 360 mm/min Rapid traverse: 4000 mm/min Angle table: 700 x 460 mm, max. load 350 kg Tool Changer: Number of tools: 20 Max. tool diameter: 80 mm Max. tool length: 300 mm Max. tool weight: 6 kg Equipment: - Control: CNC path control lid Dialog 11 - Hydromechanical clamping system SK 40 with tightening bolt DIN 69872 - Vertical and horizontal working spindle - Milling head can be swivelled manually +/- 90° - Geometrically stepped direct transmission for maximum torque - Milling performance on the working spindle

A CNC 3-axis universal milling machine Deckel (DMG Mori) is available. Travel X/Y/Z: 1200mm/600mm/500mm, tool holder: SK40, speed: 5000rpm, feed rate: 10m/min, rapid traverse: 10m/min, table dimensions X/Y: approx. 1600mm/675mm, max. table load: 2000kg. Machine dimensions X/Y/Z: approx. 3300mm/2400mm/2400mm, weight: approx. 7000kg, control: Grundig Dialog 11. An on-site inspection is possible.

A CNC universal milling machine Deckel is available. Travel X/Y/Z: 400mm/400mm/400mm, table dimensions X/Y: 700mm/460mm, max. table load: 350kg, tool holder: SK40, quill stroke: 80mm, speed: 4000rpm, feed rate: 3600mm/min, rapid traverse: 4m/min. Machine dimensions X/Y/Z: approx. 1800mm/1800mm/2200mm, weight: approx. 2500kg, control: Contour 3. The tool change magazine is no longer in operation. Documentation available. An on-site inspection is possible.

Key data: 990 mm, 390 mm, 590 mm

For sale is a robust and powerful universal milling machine of the brand DECKEL, type FP33. The machine impresses with its high stability, generous travel distances and SK50 tool holder – ideal for workshops, maintenance or manufacturing companies with high requirements. Technical data: Manufacturer: DECKEL Type: FP33 Tool holder: SK 50 Travels:  • X = 990 mm  • Y = 390 mm  • Z = 590 mm Table size (L x W): 1200 mm x 1000 mm Spindle speed: 31.5 – 1600 rpm Motor power: 5.5 kW Machine weight: approx. 4,500 kg Dimensions (L x W x H): 3300 x 2500 x 2000 mm ⚙️ Condition & Notes: Good general condition (more details on request) Delivery: Loading on truck possible Viewing possible by appointment
