100 BYSTRONIC used machine for sale

3 KW Fiber Dimensions round cross-sections (min.–max.) 10–130 mm Square dimensions Cross-sections (min.–max.) 10 × 10–130 × 130 mm Dimensions of other cross-sections (min.–max. length of sides) 10 × 10–130 × 130 mm Max. pipe weight 17 kg/m Loading length 6,500 mm Unloading length 4,000 mm Cross-sections round, square, rectangular, oval, closed standard profile very few hours

Bystar 3015 4.4KW CO2 Laser very good condition at call

Laser power: 10kW (10000W), working range: 3000mm/1500mm, max. material thickness: mild steel: 25mm, stainless steel: 30mm, aluminum: 30mm, copper: 12mm, brass: 15mm. Positioning speed: 120m/min, positioning accuracy: +/-0.05mm, max. workpiece weight: 1100kg. Machine dimensions X/Y/Z: approx. 9500mm/3500mm/3500mm, suction dimensions X/Y/Z: approx. 1500mm/1500mm/4000mm, machine weight: approx. 12000kg, operating hours: approx. 17000h. Documentation available. On-site inspection is possible. Expected to be available from June 2025.

Working hours laser on: 28.313 (15.05.2024) h Working hours beam on: 8.421 (15.05.2024) h Laser power: 6000 Watt Working range laser: 3048 x 1524 x 70 mm Max. steel: 25 mm Max. stainless steel: 30 mm Max. aluminium: 30 mm Max. copper: 12 mm Max. brass: 12 mm Length: 11000 mm Width: 6050 mm Height: 2565 mm Machine weight: 12000 kg Electrical connected load: 31 kW

Specifications: Working length: 6200 mm Pressing force: 400 tons CNC control: CYBELEC ModEva 10S Number of controlled axes: 7 Controlled axes: Y1/Y2; X/1; R; Z1/Z2 Stroke: 315 mm Projection: 410 mm Crowning Motor power: 75 kW Tool clamping at the top and bottom Laser monitoring: FIESLER Dimensions (length x width x height): approx. 6300 x 2500 x 3850 mm Weight: approx. 40,5 tons Accessories: many tools Zustand / condition: very good condition

table length: 8000 mm table width: 2500 mm burner heads: 1 control: Selectron CNC 96 output: 4 kw total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table length: 6000 mm table width: 2500 mm burner heads: 1 z-axis: 210 mm Table load: 2600 kg total power requirement: 3 kW weight of the machine ca.: t dimensions of the machine ca.: m capacitive tactile sensing changing table Nachtaktmöglichkeit filter system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

VSG glass cutting table with roller conveyor and conveyor belts used Manufacturer: BYSTRONIC Year: 1996 Cutting width max. approx. 306 cm Dimensions cutting table total approx. 8 x 5 x 1.8 m Dimensions roller conveyor approx. 6 x 3 x 1 m The roller conveyor can be tilted hydraulically Conveyor belt approx. 6 x 3 x 1 m Conveyor belt approx. 3 x 3 x 1 m Table approx. 2.7 x 3.5 m The plant has been dismantled Changes and errors in the technical data, specifications and prices as well as prior sale reserved.

Key data: 4000 mm

Ref.Nr. 00792 Name of the system: Used laser cutting machine Manufacturer: Bystronic Model Bystar 4020 Year of construction 2015 Power On (August 2024) 27.749 h Cutting time (August 2024) 9,665 h Power 6000 watts Control Byvision Working area 4000 x 2000mm Cutting range 170mm Interchangeable table system with 2 interchangeable tables + Extraction system + Cooler Cuttable thicknesses (max) steel 25mm Stainless steel 25mm Aluminum 15mm Footprint l x w x h 13850mm x 7300mm x 2350mm Machine weight 18000 kg Condition Technically very good condition Delivery by arrangement Immediately possible

The laser system for automatic sheet metal processing consists of two - Laser cutting machines Bystronic BySprint Fiber 3015 - Laser sources Bystronic Fiber 4000 - Laser loading/unloading systems Bystronic Bytrans 3015 - Bystronic storage systems - Suction Donaldson Max. sheet length: 3000 mm Max. sheet width: 1500 mm Cutting range: 3048 mm (x), 1524 mm (y), 70 mm (z) Max. positioning speed: 100 m/min Max. workpiece weight: 890 kg Laser power: 4000 watts Max. structural steel: 20 mm Max. stainless steel: 15 mm Max. aluminum: 15 mm Location: Zweibrücken Professional assembly and loading are included in the offer.

Key data: 3000 mm

The laser system for automatic sheet metal processing consists of two - Laser cutting machines Bystronic ByAutonom 3015 - Bystronic ByLaser 6000 laser sources - Laser loading/unloading systems Bystronic Bytrans Cross 3015 - Bystronic Bycell Cross 3015 storage systems - Suction Donaldson DFPR06-SPRK Max. sheet length: 3000 mm Max. sheet width: 1500 mm Cutting range: 3048 mm (x), 1524 mm (y), 80 mm (z) Max. positioning speed: 120 m/min Max. axle acceleration: 30 m/s² Max. workpiece weight: 890 kg Laser power: 6000 watts Wavelength: 10.6 μm Max. structural steel: 25 mm Max. stainless steel: 25 mm Max. aluminum: 15 mm Location: Zweibrücken Another identical plant is available at the site. Professional assembly and loading are included in the offer.

pressure: 320 t chamfer lenght: 4100 mm : 600 : 250 : 2900 mm Stroke: 265 mm throat: 400 mm distance between columns: 3750 mm dayligth: 550 mm table width: 60 mm oil volume: 600 l weight: 29.000 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Ref. -No.: 10368 Manufacturer: BYSTRONIC Year of construction: 2011 Type of control: CNC Control: Bystronic ByVision Storage location: Halberstadt - Germany Country of origin: Schweiz Manufacturer: BYSTRONIC Laser medium: CO² Kohlenstoffdioxid wavelength: 10600 Nm Maximum power: 6000 Cw Workspace X: 3048 mm Work area Y: 1524 mm Stroke Z axis: 100 mm Positional deviation Pa: +/- 0.1 mm/m Position spread Ps: +/- 0,05 mm Positioning in axis-parallel X and Y maximum: 120 m / min Positioning simultaneously X/Y maximum: 169 m / min Axis acceleration X/Y maximum: 30 m/s^2 table load capacity: 890 kg table change time: 25 s

table length: 3000 mm table width: 1500 mm total power requirement: 51 kW burner heads: weight of the machine ca.: t dimensions of the machine ca.: m with changing table (without automtic storage) ByVision Touchscreen and manual control unit Technische Daten / technical details: Laserleistung / laser capacity 6 kW Materialdicke Stahl / thickness of the material steel 25 mm Materialdicke Edelstahl / thickness of the stainless steel 20 Mm Materialdicke Alu / thickness of the material Aluminium 12 mm Blechgröße x,y / sheet size x,y 3000, 1500 mm Schneidbereich x,y,z, / cutting area x,y,z 3048, 1524, 80 mm Antriebsleistung / drive capacity 51 kW Gewicht ca. / weight ca. 15000 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was created with Mo ...

Used machine in good condition. Available for immediate delivery. - Operating hours: 16.304 - Pressure force: 150 t - Bending length: 3.100 mm - Axes: Y1, Y2, X, R, Z1 & Z2 - Distance between uprights: 2.750 mm - Working speed: 10 mm/seg - Returning speed: 150 mm/seg - Locking speed: 150 mm/seg - Throat: 315 mm - Stroke max: 215 mm - Power: installed max: 11 + 15 kW - Weight: 9.800 kg - Dimensions (long x wide x high): 3.910 x 1.900 x 2.660 mm

With ByTrans V2 head Upgrade - Laser Type: fiber - Working area (X x Y x Z): 3.100 x 1.580 x 100 mm - Max. workpiece weight: 1.100 kg - Positioning speed X/Y: 120 m/min - Simultaneous positioning speed: 169 X+Y m/min - Laser Output: 6 kW - Maximum material thickness mild steel: 25 mm - Maximum material thickness brass: 15 mm - Maximum material thickness cupper: 12 mm - Maximum material thickness stainless steel: 30 mm - Maximum material thickness aluminium: 30 mm - Control: BYSTRONIC ByMotion - Machine ON Working hours: 53.062 h - Beam ON Working hours: 17.662 h - Electric consumption entire unit: 36 kW - Dimensions (long x wide x high): 12.150 x 5.700 x 3.200 mm - Weight: 19.000 kg

Used machine in good condition. Available for immediate delivery. - Working area (X x Y x Z): 3.048 x 1.524 x 70 mm - Laser Type: fiber - Max. workpiece weight: 890 kg - Positioning speed X/Y: 100 m/min - Simultaneous positioning speed: 140 X+Y m/min - Laser Output: 3 kW - Maximum material thickness brass: 6 mm - Maximum material thickness mild steel: 20 mm - Maximum material thickness cupper: 12 mm - Maximum material thickness stainless steel: 30 mm - Maximum material thickness aluminium: 12 mm - Control: BYSTRONIC ByMotion - Machine ON Working hours: 33.318 h - Beam ON Working hours: 19.925 h - Weight: 12.000 kg - Dimensions (long x wide x high): 10.150 x 3.250 x 2.500 mm - Electric consumption entire unit: 21,4 kW

This Bystronic Bysprint Pro 2015 was manufactured in 2012. It features a 4.4 kW laser power and a working area of 3000 x 1500 mm. It can process stainless steel up to 20 mm, aluminum up to 12 mm, and steel up to 25 mm. Operating hours are 34,000 with a total of 80,000 hours under power. Consider the opportunity to buy this Bystronic Bysprint Pro 2015 co2 laser cutting machine. Contact us for more information.

TECHNICAL DETAILS Travel X x Y: 4000 x 2000 mm Cutting range X x Y x Z: 4064 x 2032 x 70 mm Workpiece weight: 1270 kg Positioning speed per axis / simultaneous: 100 / 140 m/min Axis acceleration: 12 m/s² Position accuracy: ±0.1 mm Repeatability: ± 0.05 mm Edge Detection Accuracy: ± 0.5mm Table: Interchangeable table system Laser Source: Fiber 4000 Power: 4000 W Wavelength: 1μm Polarization: unpolarized Pulse Rate: 1 - 2500 Hz Sheet thickness steel: 20 mm Sheet thickness aluminium: 15 mm Sheet thickness stainless steel: 15 mm Sheet thickness copper: 8 mm Sheet thickness brass: 8 mm MACHINE DETAILS Dimensions: 12.9 x 6.75 x 2.5 m Weight: 15 t Power: 25 kW Switch-on time: 23,477 h Laser switch-on time: 5,248 h

This Bystronic Bysprint Pro 3015 was manufactured in 2012. It features a BYSTRONIC ByLaser 4400 CO2 laser and is equipped with BYSTRONIC ByVision CNC control and a BYSTRONIC Byloader 3015 sheet loader. If you are looking to get high quality cutting capabilities consider the Bystronic Bysprint Pro 3015 machine we have for sale. Contact us for more information.

Bystar 4020 Year of construction 2006 4.4 Kw with pipe cutting axis very good condition

BYSTRONIC LASER 4020 2001 Working range 2000 x 4000 Power : 4000 Watt Operating hours 60000 Voltage Stabilizer Automatic focal length adjustment Cut Control system (intercepts cut losses) Sideros vacuum cleaner with filters replaced 2023 Sheet metal loading arm PCs and CPUs updated in 2012 Resonator overhaul with new mirrors and ceramics, carried out in November 2020 Front and Rear Exhaust Drawer System

Bystronik By Speed Laser year - .2004- 4400w Machine equipped with Bytrans loading and unloading connected to a sheet metal magazine with 76 drawers divided into 12 unloading and the remainder of virgin sheet metal.

This fiber laser cutting machine was manufactured in 2006. A Bystronic ByStar 4020 with ByLaser 4400, it features a work table of 4064mm by 2032mm and can handle a maximum load of 1580kg. Its specialized for stainless steel and aluminum with a laser power of 4400kW. If you are looking to get high-quality cutting capabilities, consider the Bystronic ByStar 4020 machine we have for sale. Contact us for more information.

This Bystronic Bysprint Fiber 3015 3kW was manufactured in 2012. It features a max laser power of 3,000 W and handles sheet sizes up to 3000 × 1500 mm. It supports a max cutting thickness of 20 mm for steel and 12 mm for stainless steel and aluminium. If you are looking to get high-quality cutting capabilities, consider the Bystronic Bysprint Fiber 3015 3kW machine we have for sale. Contact us for more information about this machine.

This Bystronic ByAutonom 3015 was manufactured in 2014. A robust CO2 laser cutting machine from Switzerland, it features a 6kW laser power and can handle steel up to 25mm thick. With a maximum positioning speed of 169m/min and a quick table changeover time of 22s, its designed for efficiency. Consider the opportunity to buy this Bystronic ByAutonom 3015 CO2 laser cutting machine. Contact us for more information about this machine.

This 3-axis Bystronic BySpeed 4020 was manufactured in 2012. It features a maximum sheet size of 4000 x 2000 mm and is equipped with a 4.4 kW CO2 resonator. If you are looking to get high-quality laser cutting capabilities, consider the Bystronic BySpeed 4020 machine we have for sale. Contact us for further details.

This 3-axis Bystronic BySprint Fiber 4020 + ByTrans Extended 4020 was manufactured in 2014. Ideal for precision fiber laser cutting, this machine ensures efficient operation and consistent performance. Consider the opportunity to buy this Bystronic BySprint Fiber 4020 + ByTrans Extended 4020 fiber laser cutting machine. Contact us for more information.

This Bystronic ByTrans 3015 Standard was manufactured in 2014. Ideal for automation systems, it offers reliable performance for handling tasks. Consider the opportunity to buy this Bystronic ByTrans 3015 Standard automation system. Contact us for more information.

Payload: 1,300 kg Max. vacuum lifter: 4,000 x 2,000 mm Number of suction cups: 19 pcs. Dimensions LxWxH: 480 x 200 x 250 cm Weight: 1,400 kg
