4 BOEHRINGER cnc turning machines used machines

Universal CNC lathe BOEHRINGER NG 200 Manufacturer: BOEHRINGER Type [ type]: NG200 CNC double Control unit: Siemens 840D Year of construction[construction year]: 10/2001 Rotating diameter: 290 mm Turning length: 850 mm Control: SIEMENS 840 D Orbital diameter over bed: 600 mm Revolver 1 Revolver 2 Counter spindle Counter headstock Tailstock C-axis Powered tools Automatic machine doors – newly retrofitted Z-axis resolution: 40nm (2nm interpolated) Travel in Z: 740mm Rapid traverse speed in Z: 25 m/min Centering tip SK 30 X-axis resolution: 125nm (8nm interpolated) Travel in Z: 220mm Rapid traverse speed in Z: 25 m/min Distance between main and counter spindle: 1034mm Drive power: 30-72 kW Torque: 662 Nm Speed range max.: 4500 rpm Spindle head: Size 6/8 DIN 55026 Spindle diameter in the front. Bearing [spindle]: 120 mm Chuck diameter: 200-315mm Spindl ...

BOEHRINGER VDF DUS 1000 CNC lathe was built in 1993 in Germany. The machine, designed for machining workpieces with a maximum diameter of 1000 mm, delivers excellent turning results during even the most intensive challenges, thanks to its extremely stable design and reliable components. The spindle is driven by an stepless AC motor, which allows efficient turning in two different, optimally adapted speed ranges. All axes, on the other hand, have powerful servo drives, guaranteeing excellent dynamics and positioning accuracy throughout the machine’s lifetime. This is rounded off by an intuitive SIEMENS CNC control with many functions for easy operation and programming. The BOEHRINGER VDF 1000 DUS lathe weighs approximately 10100 kg. Technical specifications of BOEHRINGER VDF DUS 1000 metal lathe - turning diameter above the bed: 1000 mm - turning diameter over transverse slide: 710 ...

BOEHRINGER NG 180-2 CNC turning center was built in 2006 in Germany. This reliable and efficient machine performs precision machining of workpieces with a maximum diameter of 290 mm using a high-speed spindle and high-quality cutting tools taken from a 12-position turret. The entire turning process is performed with excellent stability, thanks to a vibration- and oscillation-resistant design made of high-quality raw materials. The BOEHRINGER NG 180 CNC lathe is controlled by an intuitive SIEMENS CNC control, whose excellent optimisation allows to maximise production efficiency. The total weight of the machine is 10000 kg. Technical specifications of the BOEHRINGER NG 180-2 lathe - CNC control: SIEMENS SINUMERIK - turning diameter: 290 mm - turning length: 850 mm - 12-position turret head - maximum spindle rotational speed: 4000 rpm - minimum spindle rotational speed: 10 rpm - d ...

Key data: 800 mm, 2000 mm, 800 mm

Model V 800 Machine no. 1049.2955-07 Year of manufacture 1980 Circumferential diameter over bed 800 mm Turning length 2,000 mm Center width 2,000 mm Spindle bore diameter 128 mm Number of bed sleds 1 Quill Cone Morse 6 Voltage 380 V Three-phase current 50 Hz incl. documentation

Key data: 610 mm, 375 mm

The machine is in very good condition and still under power. Pick-up can be arranged at short notice.

Lathe with 4 tools only for 3-cylinder crank shaft

weight of the machine ca.:18 t centre distance:700 mm max. swing diameter:200 mm Lathe with 4 tools only for 3-cylinder crank shaft

weight of the machine ca.:18 t centre distance:700 mm max. swing diameter:200 mm Lathe with 4 tools only for 3-cylinder crank shaft

Control Siemens

Turning diameter over bed/face slide: 420mm/280mm, turning length: 1000mm, spindle bore: 78mm, max. speed: 3550rpm, drive power: 35kW, tool positions: 12 (with driven tools), tool holder: VDI50, rapid traverse: 10m/min. Machine dimensions X/Y/Z: approx. 4100mm/2300mm/2200mm, weight: approx. 10000kg, control: Siemens 840T with C-axis. After a buffer battery replacement, the software of the machine was deleted, whereby some machine parameters were deleted without documentation and automatic operation is currently impossible. Expected to be available from Q1, 2025.

Turning diameter over bed/cross slide: 570mm/365mm, centre height: 280mm, turning length: 1000mm, spindle bore: 62mm, speed: 2500rpm, feed rate X/Z: 5m/10m/min, quill diameter: 80mm, quill stroke: 190mm. Machine dimensions X/Y/Z: approx. 6000mm/2500mm/2000mm, weight: approx. 5600kg, control: Siemens Sinumerik 805. Documentation available. An on-site inspection is possible.

Center height: 280mm, distance between centers: 2000mm, turning diameter over bed/cross slide: 570mm/365mm, spindle bore: 62mm, speed: 2500rpm, max. workpiece weight: 1000kg, bed width: 360mm. Machine dimensions X/Y/Z: approx. 4000mm/2250mm/2000mm, weight: approx. 5500kg, control: Siemens. An on-site inspection is possible.

CNC TURNING CENTER (no tailstock) VDF Boehringer — Model VDF 250 Cm MACHINE IDENTITY Machine type CNC Turning Center (Chuck-type lathe) Manufacturer VDF Boehringer GmbH & Co. KG Model VDF 250 Cm Serial No. 1114.3705-24 Year of manufacture 1997 Control system Siemens Sinumerik 840C Condition Used — fully functional WORKING AREA Swing diameter over bed 550 mm Swing diameter over cross slide 480 mm Maximum turning length 1,000 mm Tailstock None SPINDLE Spindle head size 8 DIN 55026 Spindle bore 103 mm Max. spindle speed 4,500 rpm AXES X-axis travel 405 mm Z-axis travel 1,099 mm Rapid traverse 10 m/min Feed speed range 0.1 – 10,000 mm/min C-axis Yes — full workhead rotation TOOL TURRET Number of positions 12 Tool holder standard VDI 50 DIN 69880 Live / driven tools Yes Driven tool speed Up to 2,500 rpm Driven tool power 5.4 kW Max. driven torque 25  ...

Tip height: 330 mm centre distance: 1500 mm circular diameter: bed 690 mm spindle bore: 82 mm spindle retainer: short taper size 8 taper tailstock: 6 MK spindle speed: 7.1-1400 rpm feeds: longitudinal/plan 0.05 112/0.025 56 mm / U thread pitches: 0.25-560 mm electrical connection: 380 V, 15 kW space: 3350 x 1800 x 1400 mm weight: 4800 kg

turning diameter: 290 mm turning length: 850 mm swing diameter: 600 mm control: Siemens type: 840 D mm spindle passage: 103 mm turning speeds: 3000 U/min live tooling: 3000 U/min rapid travel - grinding spindle: 25 m/min total power requirement: 65 kW weight of the machine ca.: 11 t dimensions of the machine ca.: m Offer price without tools Optionally, the accessories can also be purchased: 106 steel holders for indoor and outdoor use. External machining, 20 driven tools (including 10 x angle tools) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 570 mm turning length: 1000 mm control: Sinumerik 805 Siemens clamping length: ca 1200 mm greates pass round over bed: 570 mm swing diameter over face slide: 365 mm turning speed range - main spindle: 3 - 2.500 min/-1 power capacity - main spindel: 15 / 19 kW spindle bore: 62 mm spindle head: DIN 55027 No. 8 diameter of quill: 80 mm taper of center: MK 5 quill stroke: 190 mm total power requirement: 40 kVA weight of the machine ca.: 5,6 t Lathe cycle controled - SIEMENS Sinumerik 805 / Simeodrive 611 - 4-Jaw Chuck, Handwheel, Covering - Chip Tray & coolant - adjustable feet - approx 20 tool holders 2021 Electrics/controls check by Boehringer The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 490 mm turning diameter over slide rest: 280 mm turning length: 2000 mm centre height: 245 mm centre distance: 2000 mm spindle bore: 62 mm total power requirement: 7,5 kW weight of the machine ca.: 3,5 t dimensions of machine L x W x H: 3,78 x 1,17 x 1,42 m Accessories: 3-jaw chuck 240 mmø, face plate 400 mmø, MULTIFIX-tool post, solid steady, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 800 mm turning length: 3000 mm swing diameter over bed slide: xx mm total power requirement: xx kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 820 mm turning length: 300 mm turning diameter over slide: 465 mm control: max. torque on the spindle: 3000 Nm turning speeds: 5,6-1120 U/min Feed: 1-5000 mm/min Rapid movement: 5000 mm/min tailstock quill taper MT: 6 3 jaw chuck Forckrath: mm steady: mm main drive motor: 50 kW diameter of main spindle: 170 mm spindle passage: 128 mm tailstock quill diameter: 125 mm tailstock quill stroke: 250 mm z-axis: 3000 mm x-axis: 550 mm total power requirement: 52 kW weight of the machine ca.: 7,1 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turret of a Boehringer lathe The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

centre height: ca. 150 mm centre distance: 1300 mm : vorhanden diameter: ca 250 mm digital readout: 1x make: Heidenhain u. Werkzeug-Sc serial number: 63-06 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Details Machine no. 2042.6616-05 Year of manufacture 2004 Circumferential diameter over bed 1,000 mm Circumferential diameter over bed 1,000 mm Center height over flat web 500 mm Bed width 560 mm Bed slide guide length 800 mm Spindle diameter front bearing 170 mm Spindle bore 128 mm Three-phase motor infinitely variable (AC motor) Drive power 37 kW Torque max. 4,069 Nm Total speed range 6.4 - 1,600 Gear stages 2 Heidenhain control system Manualplus 4110, completely renewed about 1 to 2 years ago 2 Lynettes Equipped with rotary power chuck, diameter approx. 500 mm. Including a lot of accessories of clamping jaws, estimated 15 sets, as well as approx. 15 sets of Multifix base holders, size D. Machine was equipped with a separate milling device, with its own control system, value approx. € 20,000.00. Only served by the owner, ver ...

core drilling diameter max.: 200 mm bore depth: 3500 mm swing diameter: 700 mm turning speeds: 475 U/min steady: 275 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

core drilling diameter max.: 200 mm bore depth: 2500 mm swing diameter: 700 mm turning speeds: 475 U/min steady: 370 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 400 mm

Description Lead and pull spindle lathe VDF Boehringer Göppingen Details Height 1,500 mm Width 1,700 mm Length 4,000 mm without tailstock Bed width 550 mm Bed height 800 mm Bed length 2,000 mm Face Plate Ø 900 mm Forkardt Chuck Ø 500 mm without tailstock, but can be placed Max. workpiece lengths without tailstock 1,500 mm Turning diameter over bed 800 mm Turning diameter over support 640 mm Center height 400 mm 6 pieces of baking 4-fold turning steel holder
