3 ALZMETALL ax 3 sv used machines

bore capacity in steel (diameter): 40.0 mm threading: M 24 throat: 293 mm bore stroke: 120 mm morse taper: 3 Kurzspindel MK table:: 515 x 360 mm turning speeds: 80 - 1125 U/min feed: 0.10 + 0.20 mm/U column diameter: 115 mm distance spindle /table: 117 / 701 mm total power requirement: 1.0 / 1.6 kW weight: 270 kg height of the machine: 1840 mm Furnishing: - Lockable main switch with motor protection switch - Mushroom pushbutton (latching) for EMERGENCY STOP - Infinitely variable speed adjustment - Digital speed display - Feed overload protection - Protection class IP 54 - Spindle protection with electrical fuse - Operating instructions in German including special equipment: - Thread cutting device pos. 20.0 (Thread cutting with stop) - Coolant device B pos. 25. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Offer 25234 Specifications: - Drilling capacity in steel ST 60 32 mm - Drilling capacity in steel ST 60 40 mm - Long spindle MK 3 - Drilling spindle speeds infinitely adjustable - Level 1 160 - 1125 rpm - Level 2 320 - 2250 rpm - Drilling spindle stroke 120 mm - Feeds 0.1 + 0.2 mm/rev - Projection 293 mm - Column diameter 115 mm - Table size 300 x 300 mm - With 2 T-slots 14 x 224 mm - Emergency stop button - Machine vise - 10 pcs HSS – drill bits 10 – 25 mm - Space requirement approx. W 500 x H 1750 x D 900 mm - Weight approx. 270 kg

- Drilling capacity in St 60, 30 mm - Short spindle MK 3 - Spindle stroke 120 mm - Projection 293 mm - Table support 420 x 300 mm, 2 T-slots - Machined base plate 320 x 329 mm, 2 T-slots - Distance base plate - drill chuck 1000 mm - Feed via turnstile - Weight 220 kg - Spindle speed 160 - 2250 rpm. - Operating voltage 380V-50Hz - Infinitely variable speed adjustment, by means of an adjustment lever - Engine speed in 2 stages, 700/1435 rpm - Tapping device with rotation direction change after reaching the end stops - Coolant device fully installed. - Coolant tank in machine base - Work light with LED - RÖHM drill chuck 1 - 16 mm - Precision machine vice new (test winner)
