wmw niles lathes used for sale

Face plate diameter: 1.250mm Center height above foundation slab: 1,250mm Weight: 19t Power: 55Kw Max. torque on the face plate: 31,500Nm Maximum workpiece mass between centres: 16,000 kg Speed range: 2.24 – 224 rpm

Parallel Lathe WMW NILES type DLZ 500 IV L 1000 Between points: 1000 mm Maxi Ø on bench: 500 mm Maxi Ø over saddle: 300 mm Spindle diameter: Ø 50 mm Spindle speed: from 28 to 1400 RPM 3-jaws chuck Ø 200 mm Threadings: Metric + Whitworth Tailstock CM4 Auto Feeds transverse + longitudinal + rapid Lubricant pump Voltage: 380 V Dimensions (L x W x H): 3000 x 1400 x 1500 mm Weight: approx 2,5 T

WMW Niles Ø 1400 x 2000 mm Distance between centers: 2000 mm Swing over bed: 1400 mm Swing over cross-slide: 1100 mm Swing in gap: 1800 mm Diametre of main spindle bore: 90 mm Power on main spindle: 14 kW Number of speeds: 382 rpm Chuck (3/4 pinch) -- diametre: 1200 mm

centre distance: 5000 mm turning diameter over bed: 4000 mm turning dia. in gap: 5000 mm spindle bore: 104 mm turning speeds: 1,4 - 71 (18x) U/min total power requirement: 30 kW weight of the machine ca.: t dimensions of the machine ca.: m 4-jaw face plate Ø 3.150 mm modular lathe! The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Four-jaw chuck, four-jaw lathe chuck, 4 jaw chuck -Type: DH250x4/TGL30-2332 -Chuck size: Ø 250 mm -Throughout: Ø 80 mm -Rezess: Ø 210 mm -Hole circle: Ø 230 mm -Number: 3x available -Price: per piece -Weight: 18 kg

Three-jaw chuck, three-jaw lathe chuck -Chuck size: Ø 200 mm -Weight: 18 kg

Three-jaw chuck, three-jaw lathe chuck, 3-jaw chuck -Mouth size: Ø 200 mm -Short cone mount for: bayonet disc attachment -Cone size: 6 -Cone: Ø 106 mm -Bolt circle: Ø 133.4 mm -Through hole: Ø 54 mm -Weight: 15 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Chuck size: Ø 160 mm -DKRD Ø: 160 mm -Weight: 15.5 kg

three-jaw chuck, three-jaw lathe chuck -Handover: in current condition as viewed -Short cone: has been shortened -Chuck size: Ø 200 mm -Through hole: Ø 54 mm -Hole: cone Ø 104.5 mm -as per pictures, without additional accessories -Weight 14.4 kg

three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Chuck size: Ø 250 mm -Cone: Short cone 8 Ø 139 mm -Bolt circle: Ø 170 mm -Through hole: Ø 80 mm -Weight: 24 kg

Wedge rod feed, swivel feed, swivel swivel feed, power clamp feed -Feed size: Ø 250 mm -Weight: 35.5 kg

Three-jaw chuck, three-jaw lathe chuck, 3-jaw chuck -Feed size: Ø 200 m -Through hole: Ø 54 mm -Weight: 12 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Chuck size: Ø 160 mm -TGL: 30-2312 -Weight: 11.2 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -DH: 200x3-III -TGL: 30-2332 -Chuck size: Ø 200 mm -Weight: 16.7 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -DH: B200x3x6 -TGL: 30-2332 -Chuck size: Ø 200 mm -Cone: Ø 104 mm -Hole circle: Ø 132 mm -Through hole: Ø 54 mm -Weight: 15 kg

Three-jaw chuck, three-jaw lathe chuck, 3-jaw chuck -Mouth size: Ø 250 mm -Recess: Ø 210 mm -Passage: Ø 80 mm -Weight: 20.7 kg

Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Chuck size: Ø 250 mm -Short taper: 6 -Throughout: Ø 80 mm -Weight: 25.9 kg

Three-jaw chuck, three-jaw lathe chuck, 3-jaw chuck -Feed size: Ø 200 m -Through hole: Ø 54 mm -Short cones: 5 -Bolt circle: 105 mm -Weight: 16.2 kg

Three-jaw chuck, three-jaw lathe chuck, 3-jaw chuck -Mouth size: Ø 200 mm -threaded mounting -Through hole: Ø 53 mm -Weight: 19.7 kg

Three-jaw chuck, three-jaw lathe chuck, 3-jaw chuck -Mouth size: Ø 250 mm -Recess inlet: Ø 210 mm -Through hole: Ø 80 mm -Weight: 18 kg

Three-jaw chuck, three-jaw lathe chuck -Chuck size: Ø 250 mm -one set: hard interchangeable jaws -Passage: 81 mm -Rezess: Ø 210 mm -Hole circle: Ø 230 mm -Weight: 19 kg

Three-jaw chuck, 3-jaw chuck -Type: DHB 200x3x5 TGL 30 2332 -Mouth size: Ø 200 mm -Passage: Ø 54 mm -max.: 3000 rpm -Short taper mount: Ø 105 mm -Weight: 24 kg

three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -DH250x3-III -TGL 30-2332 -Chuck size: Ø 250 mm -Cone: Short cone 8 Ø 140 mm -Bolt circle: Ø 172 mm -Through hole: Ø 80 mm -Weight: 28 kg

faceplate diameter: 3500 mm swing diameter: 4000 mm turning height: 3150 mm slide adjustment: 1700 mm table load: 25 t turning speeds: U/min Feed: mm/U digital readout: Heidenhain Rest: 2 Side head: total power requirement: 90 kW weight of the machine ca.: 95 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 5300 mm swing diameter: 6300 mm turning height: 2800 mm slide adjustment: 1700 mm table load: 50 t turning speeds: 0,3-14 U/min Feed: 0,056-10 mm/U digital readout: Sony Rest: 2 Side head: chip conveyor: total power requirement: 120 kW weight of the machine ca.: 187 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Three-jaw chuck, three-jaw lathe chuck -DH200x3-III -TGL: 30-2332 -Mouth size: Ø 200 mm -Recess: Ø 155 mm -Bolt circle: Ø 174 mm -Through hole: Ø 57 mm -Weight: 12 kg

3-jaw chuck, three-jaw chuck WMW DH-B 200x3x6 ( DH-B200x3x6 ) TGL 30-2332 Outer Ø: 200 mm Bolt circle Ø : 133.5 mm Bore Ø: 54 mm Height with jaws: 140 mm used, tested ! Dimensions: 200 x 200 x 121 mm

3- Jaw Chuck WMW NILES DHK 200x3 Outer Ø: 200 mm Flange: 155 mm Bore Ø: 60 mm Bolt circle: 175 mm Height with jaws: 125 mm Chuck number: 507 Dimensions: 200 x 200 x 125 mm

Precision three-jaw chuck, chuck, faceplate, 3-jaw chuck -DHK: 200x3 -TGL: 30-2333 -Mouth size: Ø 200 mm -Bakes: individually and fully adjustable -Interchangeable jaws -Through hole: 55 mm -Recess: Ø 160 mm -Quantity: 1x food available Price: per piece -Weight: 16 kg

diameter:315 mm Speed:max. 2400 min. -1 weight of the machine ca.:25 kg

max. width of grinding wheel: 50 mm ratio: 0 max. dia. of grinding wheel: 400 mm total power requirement: 3 kW weight of the machine ca.: 1000 kg dimensions of the machine ca.: m Pre-Dressing Device for Gear Grinding Wheels The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

diameter: 315 mm bore: 95 mm tool adaptor: Din 55027 Gr. 8 revolutions per minute: max. 1500 U/min Machine dealer with own stock of 1600 m². The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter:480 mm turning length:1250 mm control:H 645 weight of the machine ca.:8 t dimensions of the machine ca.:5 x 2 x 2 m centre distance:1580 mm swing over bed:495 mm swing diameter:üb.Querschlitten ca.350 mm working area:1600 mm control:H645 connected load:50 kW

turning length:630 mm total power requirement:16 kW weight of the machine ca.:5 t dimensions of the machine ca.:3400 x 1500 x 1600 mm swing diameter over slide rest:Hinterdrehschlitten 250 mm centre height:über Hinterdrehschlitten 150 mm center height over bed:300 mm turning spindle:Kopf DIN 55021 Gr. 8 centre distance:1000 mm accessories::2 Schränke Wechselräder

turning diameter over bed: 500 mm turning diameter over slide rest: 330 mm turning diameter in the gap: 600 mm turning length: 3000 mm bed width: 505 mm spindle bore: 72 mm spindle head: DIN 55022 Gr. 8 taper in tailstock: MK 5 turning speed range: 22,4- 1120 U/min power requirement: 18,5 kW dimensions: 5,3 x 1,75 x 1,53 m weight of the machine ca.: 5,2 t used lathe in nice condition with digital scale - 2 axis digital scale - 4 jaw chuck Ø 250 mm - 3 jaw chuck Ø 260 mm - Multifix C toolholder system - some toolholders - steady The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

overhauled: 2007 Control Siemens ... Sinumerik 840 D Max. workpiece diameter ... 2500mm Table diameter ... 2240mm Max. workpiece height ... 1250mm Axis Z ... 1000mm Max. workpiece weight ... 10000 kg Main engine power ... 55kW L x W x H 7000x4400x5500mm Machine weight ... 37900kg The machine is in good condition. More info on request.

MOWEG (NILES) DKZ 4000 -UNIVERSAL CAROUSEL LATHE Year of construction : 1977 Chuck diameter : 3,500 mm Max. swivel range : 4,000 mm Max. turning height : 2,000 mm Max. table load : 20 T Column travel : 1,250 mm With digital display

table length: - mm table width: - mm grinding wheel diameter: 400 mm max. width of grinding wheel: 50 mm total power requirement: 1,5 kW weight of the machine ca.: 0,3 t dimensions of the machine ca.: 1 x 1 x 1 m For Pre-Dressing the Gear Grinding Wheels apart from the machine, particularly to profile grinding wheels for two-flank grinding, module 12 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 2000 mm gear width: . mm max. module: 22 max. hob diameter: 250 mm hob turning speeds: 16-92 U/min total power requirement: 13 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 1650 mm turning diameter over slide rest: 1200 mm turning length: 7500 mm turning dia. in gap: 2500 mm spindle diameter: 105 mm speed: 3,55 - 180 (x24) U/min voltage: 380 V total power requirement: 45 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: . mm turning length: 2000 mm control: Siemens 840 D sl mainspindle: turning speed max.: 3800 1/min mainspindle: torque max.: 1200 Nm tailstock:: diameter of quill: 140 mm center point: MK6 quill power: 5 - 30 kN feed rate Z-axis: 0,1 - 30000 mm/min rapid traverse Z-axis: 40 m/min feed rate X-axis: 0,1 - 18000 mm/min rapid traverse X-axis: 25 m/min total power requirement: 125 kW weight of the machine ca.: 20 t The machine can still be inspected under power at the production plant. The condition of the machine is good, the accuracy during turning operation is very good. The milling drive is not functional. A quotation from Niles for the repair of the milling drive is available on request. Including hydraulic steady rest. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 1650 mm turning diameter over slide rest: 1200 mm turning length: 7500 mm turning dia. in gap: 2500 mm spindle diameter: 105 mm speed: 3,55 - 180 (x24) U/min voltage: 380 V total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 4000 mm turning diameter over slide rest: . mm turning length: 5000 mm total power requirement: 30 kW weight of the machine ca.: . t dimensions of the machine ca.: . m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Grinding wheel, cup wheel, bench grinder, surface grinding machine, cylindrical grinding machine -Inside: Ø 32 mm -Outer: Ø 200 mm -Width: 6 mm -Number: 9x discs available -Price: per piece -Weight: 0.4 kg

Grinding wheel, cup wheel, bench grinder, surface grinding machine, cylindrical grinding machine -Inside: Ø 32 mm -Outer: Ø 250 mm -Width: 6 mm -Number: 2x discs available -Price: per piece -Minimum purchase: complete -Weight: 0.6 kg

Grinding wheel, cup wheel, bench grinder, surface grinding machine, cylindrical grinding machine -Inside: Ø 32 mm -Outer: Ø 250 mm -Width: 32 mm -Number: 1x discs available -Price: per piece -Weight: 3 kg

Grinding wheel, cup wheel, bench grinder, surface grinding machine, cylindrical grinding machine -Inside: Ø 51 mm -Outer: Ø 200 mm -Width: 19 mm -Number: 1x discs available -Price: per piece -Weight: 1.2 kg

Grinding wheel, cup wheel, bench grinder, surface grinding machine, cylindrical grinding machine -Inside: Ø 51 mm -Outer: Ø 200 mm -Width: 20 mm -Number: 1x discs available -Price: per piece -Weight: 1.3 kg

Grinding wheel, cup wheel, bench grinder, surface grinding machine, cylindrical grinding machine -Inside: Ø 32 mm -Outer: Ø 200 mm -Width: 32 mm -Number: 1x discs available -Price: per piece -Weight: 2.1 kg

Grinding wheel, cup wheel, bench grinder, surface grinding machine, cylindrical grinding machine -Inside: Ø 32 mm -Outer: Ø 200 mm -Width: 25 mm -Number: 3x discs available -Price: per piece -Weight: 1.9 kg

Grinding wheel, cup wheel, bench grinder, surface grinding machine, cylindrical grinding machine -Inside: Ø 32 mm -Outer: Ø 200 mm -Width: 30 mm -Number: 9x discs available -Price: per piece -Weight: 1.8 kg

Grinding wheel, cup wheel, bench grinder, surface grinding machine, cylindrical grinding machine -Inside: Ø 32 mm -Outer: Ø 200 mm -Width: 30 mm -Number: 6x discs available -Price: per piece -Weight: 1.8 kg

Grinding wheel, cup wheel, bench grinder, surface grinding machine, cylindrical grinding machine -Inside: Ø 51 mm -Outer: Ø 200 mm -Width: 40 mm -Price: per piece -Number: 8x available -Weight: 2.2 kg

Grinding wheel, double bench grinder, surface grinder, cylindrical grinder -Inner diameter: 32 mm -Outer diameter: Ø 250 mm -Width: 6 mm Price: per piece -Quantity: 40x available -Weight: 0.6 kg

Grinding wheel, double bench grinder, surface grinder, cylindrical grinder -Inner diameter: 32 mm -Outer diameter: Ø 250 mm -Width: 8 mm Price: per piece -Quantity: 50x available -Weight: 0.9 kg

Grinding wheel, double bench grinder, surface grinder, cylindrical grinder -Inner diameter: 32 mm -Outer diameter: Ø 250 mm -Width: 8 mm -Price: per piece -Quantity: 10 available -Weight: 0.9 kg

Grinding wheel, cup wheel, double bench grinder, surface grinder, cylindrical grinder -Inner diameter: 50 mm -Outer diameter: Ø 200 mm -Width: 40 mm -Number: 12 grinding discs available Price: per piece -Weight: 2.1 kg

Grinding wheel, cup wheel, bench grinder, surface grinder, cylindrical grinder -Manufacturer: Niles, grinding wheel - Inside: Ø 32 mm -Outside: Ø 200 mm -Width: 20 mm -Number: 2x discs available -Price per piece -Weight: 1.4 kg/pc.

Grinding wheel, cup wheel, bench grinder, surface grinder, cylindrical grinder -Manufacturer: Niles, grinding wheel 20 Jot - Inside: Ø 32 mm -Outside: Ø 200 mm -Width: 20 mm -Weight: 1.3 kg

turning diameter over bed: 2000 mm turning diameter over slide rest: 1600 mm turning length: 10000 mm control: FANUC 0i TF workpiece weight: 25 t steady: 4 feed: 1 - 3000 mm/min main drive: 60 kW main spindle speeds:: 1,5 - 160 U/min bed width: 1150 mm faceplate: 1600 mm tail stock: tailstock quill diameter: 260 mm total power requirement: 110 kW weight of the machine ca.: 120 t the machine is currently being overhauled and equipped with - new electrics (Siemens, Schneider, cabinet) - CNC control FANUC 0i TF - new Fanuc motors - new hydraulic parts - complete mechanical overhaul - Ball screw (B-axis) - bed overhaul - three-track bed - Grinding device 1500 rpm - Milling Unit - Face plate with 4 jaws - 3 steady rests - incl 1 year warranty from overhauler on electrical and hydraulic components and 2 years on FANUC CNC Completion of overhaul after order (approx. 2 months) The data for th ...

Grinding wheel, cup wheel, bench grinder, surface grinding machine, cylindrical grinding machine -Inside: Ø 51 mm -Outer: Ø 200 mm -Width: 40 mm -Number: 7x discs available -Price: per piece -Weight: 1.9 kg

weight of the machine ca.:3 t

With two machining modules, X-axis: -50 to 725mm, Y-axis: -200 to 300 / -250 to 250mm, rapid traverse X-, Y-, Z-axis: 18/12/30m/min, control: Siemens Sinumerik, temperature range: 5–40°C, power type/frequency: 3 PEN / 50Hz, rated voltage: AC 400V, control voltage: DC 24V, auxiliary voltage: AC 230V, connected load: 102kVA, rated current: 148A, rated current (fast): 148A, fuse (slow): 160A, length: 8000mm, width: 3000mm, height: 4000mm, weight: approx. 17t, operating hours: approx. 80,000h. The machine is fully functional, the ball screw drive (recirculating spindle) of the Z-axis was renewed in 2024 and it has been regularly maintained. Comes with documentation, control cabinet, hydraulic unit, filter elements, and chip conveyor. An on-site inspection is possible.

turning length: 2500 mm control: Sinumerik 840 D spindle head: A 11 tool numbers: 48 swing diameter over bed slide: 750 mm swing over bed: 780 mm c-axis: 0,1-30 1/min diameter of quill: 160 mm taper bore: MK 5 tool length - max.: 500 mm weight of tools max.: 15 kg weight of the machine ca.: 27 t dimensions of the machine ca.: 8,4 x 4,0 x 2,5 m Technical details: Nominal turning length: 2,500 mm Swing diameter over bed slide: 750 mm Swing diameter over bed: 780 mm Working height: 1,300 mm Spindle head to DIN 55026: A 11 Bore through: 123 mm Diameter in front bearing: 200 mm Oriented spindle stop: 0-359 degrees Drive power at 100/60 % duty cycle: 37/45 kW Total speed range: 10-2,500 1/min Number of speed ranges: 2 Speed range I: 10-775 1/min Speed range II: 20-2,500 1/min Max. torque at 60 % duty cycle: 2,500 rpm. Torque at 60 % ED: 2,083 Nm (up to 186 rpm) The data for this ad was crea ...

max. wheel diameter: 630 mm gear width: 215 mm max. module: 12 min. module: 1 number of teeth: 5 - 140 stroke length max.: 225 mm table diameter: 500 mm table load: 400 kp grinding wheel diam. min/max.: 270-350 mm max.helical angle: 45 ° no. of strokes: 75 - 315 p.M. total power requirement: 8,5 kW weight of the machine ca.: 6,3 t dimensions of the machine ca.: 3,2 x 3,6 x 3,7 m change gears, program control, complete covering, coolant/Filtering attachment The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 1250 mm gear width: 430 mm max. module: 30 min. module: 2 no. of teeth: 10 - 400 max.helical angle: 45 ° Stößelhublänge: 25 - 450 mm stroke position adjustment: 310 mm Doppelhubzahl - stufenlos: 70 - 190 U/min grinding wheel diam. min/max.: 290 - 400 mm table diameter: 1000 mm table load: 4000 kp dimensions of the machine ca.: 7,7 x 4,5 x 3,3 m total power requirement: 30 kW weight of the machine ca.: 28 t - Complete covering - Oil mist extraction - Coolant system - counter Holder - change Gears - The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning length: 3.000 mm greates pass round over bed: 810 - 760 mm swing diameter over slide rest: 740 mm control: SIEMENS - 840 C max. turning diameter: 800 mm turning diameter over slide: 740 mm travel -x2 axis: 875 mm travel -z2 axis: 3.700 mm CNC Turning- and Milling Center | NILES-SIMMONS - N40 MC / 3000 equipped with a well as travelling lynette and tailstock. Additional equipment: - Centering points, - Jaw sets, - Clamping jaws, The machine is in a well-maintained condition and can be inspected at any time under power. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: N-40 | N 40 | N40MC3000 | N40MC The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

tip circle diameter: 650/800 mm workpiece length - max.: 1100 mm max. module: 20 (25) mm min. module: 0,5 mm control: Siemens Sinumerik 840 D total connected load: 62 kVA helical angle: -45 / + 120 ° weight of the machine ca.: 10 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning length: 1.300 mm spindle diameter: 120 mm spindle bore: 38 mm control: SIEMENS - 840 D numbers of positions in the tool changer: 12 tool taper: VDI 30 CNC Turning- and Milling Center | NILES-SIMMONS - N10 equipped with Y-axis, turret for driven tools, steady rest, and tailstock. The machine is in well-maintained condition. For further technical details, please refer to the attached offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: N-10 | N 10 | N10/2 | N10-2 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 270 mm turning length: 630 mm control: SIN840D swing over bed: 400 mm swing diameter over slide rest: 220 mm longitudinal slide -travel: 745 mm cross slide - travel: 200 mm turning speeds: 10 - 4.000 U/min power capacity at 100 % load: 15,00 kW spindle head DIN 55026 - Size: 6 spindle bore: 62 mm chucking diameter: max. 315 mm feed x-axis: 1 - 12.000 mm/min rapid traverse X-axis: 12,00 m/min Feed z- axis: 1 - 20.000 mm / min. rapid traverse Z-axis: 20,00 m/min tailstock quill taper MT: 3 quill stroke: 112 mm quill pressure: 10,00 kN tool turret with 12 work positions: tool taper DIN 69880: Ø 30 mm Tool drive speed max.: 4.000 1/min total power requirement: 37,00 kW weight of the machine ca.: 4,00 t dimensions of the machine ca.: 4,00 x 2,75 x 2,30 m With SIEMENS SINUMERIK 840D control system, turret with driven tools, C-Axis, tailstock, chip conveyor, various tool hol ...

turning length: 4.500 mm greates pass round over bed: 810 - 760 mm swing diameter over slide rest: 740 mm control: SIEMENS - 840 C max. turning diameter: 800 mm turning diameter over slide: 740 mm travel -x2 axis: 875 mm travel -z2 axis: 5.200 mm CNC Turning- and Milling Center | NILES-SIMMONS - N40 MCT 4500 equipped with a turret for driven tools as well as NC steady rest and tailstock. Additional equipment: - Centering points, - Jaw sets, - Clamping jaws, The machine is in a well-maintained condition and can be inspected at any time under power. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: N-40 | N 40 | N40MCT4500 | N40MCT The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 1250 mm turning diameter over slide rest: 1250 mm turning length: 9000 mm turning speeds: U/min faceplate: 1300 mm 3-jaw chuck: 500 mm steady: 2 centre distance: 10.000 mm bed width: 1250 mm turning dia. in gap: 1600 mm total power requirement: 54 kW weight of the machine ca.: 33 t dimensions of the machine ca.: m Multifix steel holder with inserts The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look  ...

turning diameter: 820 mm turning length: 4500 mm control: Siemens Si 840 D sl total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m New purchase price in the year 2022 EUR 1.2 million Time recording from Feb. 2025 Operating hours = 16085 h Main spindle = 616 h Milling spindle = 369 h CNC control Siemens Sinumerik Si 840D sl Max. center distance 4500 mm Working height 1375 mm X-axis travel -15…+725 mm Y-axis travel -245…+4756 mm Swing diameter over cross slide 780 mm Swing diameter over bed 820 mm C-axis, smallest increment +/-0.001° Main spindle A15 with BVG, 3135 N,/2000 rpm Spindle head DIN 55026 Form A 15 Max. speed 3000 rpm Max. torque 3135 Nm Drilling/milling unit Milling power (40/100% duty cycle) 36.5/29.8 kW Torque up to 1110 rpm (40/100% duty cycle) 328/261 Nm Max. spindle speed 5000 rpm Swivel range (B-axis) -105…+95° Vertical travel  ...

turning diameter: 820 mm turning length: 6000 mm control: Siemens Si 840 D sl total power requirement: 155 kW weight of the machine ca.: 65 t dimensions of the machine ca.: 16350 x 3700 x 3850 m Purchase price EUR 1.550.000 Time recording from Feb. 2025 Operating hours = 38601 h Main spindle = 1958 h Milling spindle = 1760 h CNC control Si 840D sl Working area 6000 mm Working height 1390 mm Swing diameter over bed slide/bed 820 mm X-axis travel +850 -25 mm Z-axis travel 6820 mm C-axis, smallest increment +/-0.001° Workpiece spindle Spindle head according to DIN 55026 A15 Bathing through 160 mm Front diameter Bearing 240mm 2-stage gearbox, infinitely variable programmable Drive power at 100/60% duty cycle: 78/87kW Speed ranges: 2 Speed range I: 10-501 rpm Speed range II: 10-1750 rpm Torque I, 60% duty cycle: 8000 Nm Torque II, 60% duty cycle: 2308 Nm C-axis Holding torque with backlash-f ...

turning diameter: 315 mm turning length: 1000 mm control: Siemens type: Sinumerik 802 D turning diameter over slide: 160 mm spindle hollow: 52 mm Tool changer: 12 turning speeds: 30-3300 U/min chip conveyor: total power requirement: kW weight of the machine ca.: 6 t dimensions of the machine ca.: m Machine has been overhauled Die techn. Daten sind Hersteller- bzw. Betreiberangaben und daher für uns unverbindlich. Einen Zwischenverkauf behalten wir uns vor, es gelten ausschließlich unsere Geschäfts- und Verkaufsbedingungen. Über uns mehr als 400 eigene Maschinen im Lager über 15.000 m² Lagerfläche, Krankapazität 70 t mehr als 10.000 Artikel Zubehör für Ihre Werkstatt Sie wollen Maschinen Produktionslinien oder Ihren Betrieb verkaufen, dann sprechen Sie uns an. Weitere Angebote finden Sie auf unserer Webseite. Besichtigungen sind nach Absprache möglich. Wir freuen uns auf Ihre ...

control: Numeriksteuerung CNC 700 K total power requirement:28 KVA weight of the machine ca.:7,8 t dimensions of the machine ca.:6610 x 2280 x 2235 mm work height max.:1060 mm greates pass round over bed:305 mm spindle bore:82 mm Documents:vorhanden

swing diameter:260 mm control:840 D SIEMENS turning speeds:3.500 1/min spindle drive:36 / 28 kW chucking diameter:260 mm travel -x axis:900 mm travel -z axis:400 mm turret head:12 Pos. tool holder:VDI 40 rapid power traverse in X-and Z direction:100 / 30 m/min dimensions of the machine ca.:5,3 x 2,4 x 3,31 m CNC vertical lathe with 2 spindles, 2x RÖHM power chucks dia. 315mm,

turning diameter:300 mm swing diameter:350 mm turning height:275 mm x-axis:925 mm z-axis:250 mm clamping chuck diameter:200 mm Feed speed:30 m/min. total power requirement:45 kW weight of the machine ca.:7 t Machine was used just from time to time in the last years - very good condition! with CNC SIEMENS 840 D 12-station turret head with driven toolings workpiece in and out conveyor belt coolantattachment and chip conveyor diverse accessories

Offer 24178 Specifications: - Center height 250 mm - Center width 2000 mm - larger circulation – Ø over bed 490 mm - via flat sleds approx. 300 mm - Spindle bore 72 mm - Pick-up cone of the tailstock quill MK 5 - Travel of the tailstock quill 260 mm - Spindle speeds 25 - 1160 rpm -Feeds - Travel of the cross slide 200 mm - Travel of the upper slide 115 mm - Drive 380 V / 5.5 kW - with: - Tailstock, 3-jaw lining, bezel - Steel holder, moving center punch, - Chip tray - Space requirement approx. W 3500 x H 1500 x D 1300 mm - Weight approx. 3000 kg

Offer 24177 Specifications: - Tip height 180 mm - Center width 1000 mm - larger circulation – Ø over bed 355 mm - via flat sleds approx. 200 mm - Spindle bore 36 mm - Pick-up cone of the tailstock quill MK 5 - Travel of the tailstock quill 260 mm - Spindle speeds 18 - 1800 rpm -Feeds - Travel of the cross slide approx. 200 mm - Travel of the upper slide approx. 115 mm - Drive 400 V / 5.8 kW - with: - Tailstock, 3-jaw lining, bezel - Steel holder, moving center punch, - Chip tray - Space requirement approx. W 2500 x H 1500 x D 1200 mm - Weight approx. 2100 kg

Inv. Num. : 8986 Type: DH-250/4 Producer: WMW Created: 1983 Parameters: Length: 3400 mm Width: 2100 mm Height: 1600 mm Weight: 4800 kg

Facing and Centering machine WMW FZWD 600x900.

see picture for data. Table hoehen-adjustable. mass approx.: 1.55 x 0.8 x 2.1 m high

Universal tool-feeding machine, used universal milling machine, used Type FU 250 x 1000/2 Fabr. WMW Auerbach Built: 1988 Table size/ table: 1130 x 255 mm Laengsmotion/ longit. move: X 690 mm Horizontal movement/ horiz. Move: Y 190 mm Vertical movement/ Vert. move : Z 360 mm Tool holder/taper: ISO 40 Spindle speeds R+L infinitely/ speeds of spindle ( left/right) 56 - 2800 rpm. Pre-shot stepless all axes X, Y and Z/ feeds all axis 10 - 630 mm/min / 250 mm/min Drive power/ load 3.8 kW Weight: 2 t Specification: Vertical head,shock head
