spinner lathes used for sale

Turning Diameter 400 mm Turning Lenght 650 mm With C ,Y axes and subspindle Control Unit Fanuc 31i Can be inspected under power

Control SIEMENS Swing diameter over bed 350 mm Turning diameter 180 mm Distance between centers 500 mm Spindle speed 4000 min-1 Tailstock Multifix Accessories

SPINNER TTC 300- 52 SMMCY CNC Lathe YOM 2012 Twin-opposed-spindle, twin-turret lathe Control FANUC 31iT Swing diameter 400 mm Max. turning dia ~200-250 mm Max. turning length 400 mm Travels: X1 180 mm, X2 110 mm, Z 450 mm, Y +40/-40 mm Rapid traverse: X1 15 m/min, X2 15 m/min, Z 24 m/min, Y 15 m/min With C-axis Main Spindle 1: Motor spindle with water cooling With hollow shaft measuring system for C-axis drive mounted directly on the spindle shaft Spindle bore 52 mm Spindle speed 0-5000 rpm/ 19 kW Performance Pmax 23,5 kW Torque 150 Nm Spindle nose A6/DIN Sub-Spindle 2: Motor spindle with water cooling With hollow shaft measuring system for C-axis drive mounted directly on the spindle shaft Can be moved on a slide to take over spindle 1 Spindle speed 0-7000 rpm/ 8 kW Performance Pmax 13,8 kW Torque 189 Nm Spindle nose 100 mm Turret 1: At the top of the ...

Key data: 400 mm, 250 mm

This machine is sold on behalf of the customer. Technical data: Manufacturer: Spinner Type: TC300-52 SMMCY Year of Make: 2010 Control: Siemens 840D SL Travel: X1 180 mm X2 110 mm Z 450 mm Y +40/-40 mm Turning length: 400 mm Turning diameter: 250/200 mm Swing diameter: 400 mm Working Spindle 1 Speed: 5,000 rpm Torque: 96/121 Nm Power: 15/19 kW Bar Passage: 52 mm Working spindle 2 Speed: 7,000 rpm Torque: 38 Nm Power: 6 kW Tool turret 1 and 2 Number of stations: 12x Recording: VDI 25 Max. speed AGW: 6,000 rpm Power: 8/2.6 kW Dimensions and weight Dimensions: 2,200 x 2,000 x 2,000 mm Weight: approx. 4,600 kg Condition Condition: Used Other equipment and accessories included: Parts Conveyor Belt High Pressure Pump Chip conveyor Interface for bar feeders 3-jaw chuck on sub-spindle and main spindle

Key data: 32 mm

Manufacturer: Spinner Type: PD-CNC IB-TMC-V3 Year of Make: 2008 Control: Siemens 840D ShopTurn Travels: X 400 mm, Z 400 mm, Q 400 mm Switch-on hours: (Information to follow) Working spindle Spindle speed: 8,000 rpm Spindle passage: 32 mm Tool/movement Tool holder: VDI 20 Tool turret: 12-speed Number of tools driven: 6 Dimensions and weight Dimensions: 2,500 mm x 1,400 mm x 1,700 mm Weight: 2,300 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: programmable tailstock Preparation for interface for bar feeders

Table clamping area: 600 x 1300 mm Travel x/y/z: 810/580/560 mm Spindle holder: SK 40 ISA Spindle speeds: 8000 rpm Number of toolslots: 40 pieces Feeds: 24000 mm/min Spindle drive: 25 kW electr. Connection: 380/400 V kW Space requirement: 3200 x 2500 x 2900 mm Weight: 9000 kg Control: SIEMENS 810 EN

X Travel 1100 mm Y Travel 610 mm Z Travel 610 mm Spindle speed 10.000 Rpm Controller Siemens 840 Dsl

CNC lathe, brand Spinner, TypeTC67H-MC, YEAR 1999 with chip conveyor, underlays, various tools. The price is net.

This 3-axis SPINNER TC 52 MC was manufactured in 2007. It features a robust design with optional equipment including a bar feeder, parts catcher, and a turret with driven tools. The machine is equipped with a collet chuck for clamping and a dust extraction system for efficient operation. If you are looking to get high-quality turning capabilities, consider the SPINNER TC 52 MC horizontal turning machine we have for sale. Contact us for further details.

This 3-axis SPINNER VC810 was manufactured in 2004. It features an X-axis travel of 810 mm, Y-axis travel of 610 mm, and Z-axis travel of 610 mm. The machine is equipped with a maximum spindle speed of 8,000 rpm and an automatic pick-up tool changer with a capacity of 24 tools. If you are looking to get high-quality machining capabilities, consider the SPINNER VC810 vertical machining centre we have for sale. Contact us for further details.

This 3-axis SPINNER TC 800 110 MC was manufactured in 2009. It features a collet chuck for clamping and includes a dust extraction system. Optional equipment includes a bar feeder, parts catcher, turret with driven tool, chip conveyor, and tailstock. If you are looking to get high-quality turning capabilities, consider the SPINNER TC 800 110 MC horizontal turning machine we have for sale. Contact us for further details.

This 3-axis SPINNER VC450 was manufactured in 2014. It features an X-axis travel of 450 mm, Y-axis travel of 400 mm, and Z-axis travel of 400 mm. The machine includes a robust table size of 770 x 410 mm and a maximum table load of 200 kg. If you are looking to get high-quality machining capabilities, consider the SPINNER VC450 vertical machining center we have for sale. Contact us for further details.

This 3-axis SPINNER VC 1020 CNC machining centre was manufactured in 2002. It features impressive travels of X 1020 mm, Y 610 mm, and Z 610 mm, along with a spindle speed of 8000 rpm. The machine includes a chip conveyor, coolant tank with paper filter, and internal coolant supply. If you are looking to get high-quality machining capabilities, consider the SPINNER VC 1020 machine we have for sale. Contact us for further details.

turning length:140 mm dimensions of the machine ca.:4 x 2 x 1,9 m

Ref. -No.: 10304 Manufacturer: SPINNER Year of construction: 2007 Type of control: CNC Control: Siemens 840 D with SHOP Mill Storage location: Halberstadt Country of origin: Germany X-Travel: 1100 mm Y-Travel: 610 mm Z-Travel: 610 mm B-Axis: 0.001 prepared for 4 th axis ° Main spindle drive power: 25 kW Main spindle speed range: 6000 RPM Table surface: 1200 x 600 mm Table Load: 1000 kg Tool Taper: SK 50 Numbers Of Tools In Magazin: 24 axes: 4 Rapid Traverse X-Axis: 18 m / min Rapid Travel Y-Axis: 18 m / min Rapid Traverse Z-Axis: 15 m / min Main Drive: 25 kW Weight Of The Machine Ca.: 8 t Further information: - additional 4 axis (Dividing head)

Table size 900x400 mm X Travel 750 mm Y, Travel 450 mm Z Travel 450 mm Spindle speed 12.000 rpm Controller Siemens 840D Sl Spindle taper SK40 Number of tools in magazine 24 Can be tested under power

Key data: 500 mm, 700 mm, 3500 1/min

Make: Spinner Model : TC 110 SMCY Control Siemens 840 D ShopTurn Year of construction 2006 Specifications: Turning diameter 500 mm Circulation diameter 690 mm Turning length 900 mm Y-axis -55/+65 mmmm C-axis 0.001° Spindle passage main spindle 110 mm Spindle passage counter spindle 66 mm Main spindle motor 28 kw High-speed main spindle 3200 rpm. Counter spindle speed 5000 rpm. Rapid traverse x/y/z 24 m/min. Sauter Star Revolver VDI 50 Number of stations 12-fold Driven tools 12 Speed driven tools 4000 rpm. Machine weight approx. 7800 kg Dimensions set-up (L x W x H) with chip conveyor 5500 x 2200 x 1800 mm Accessories: automatic pick-up device Measuring arm Bar feeder preparation Conveyor 3D Renishaw Probe Coolant gun Increased coolant pump Hainbuch Collet Chuck for Main Spindle 3 Jaw chuck counter spindle Various tool holders Documentation

1 CNC lathe spinner type CNC TC82 Fanuc 1998 2 CNC machining machine (miling) Stama type CNC 014 Fanuc 2000 3 CNC BAZ milling machine AXA type VHC 2-M Haidenhain 1999 4 CNC lathe (lathe) Takisawa type TS 20 Fanuc 1985 5 CNC Drawing Machine (lathe) Unitec Type UT6 Siemens 2008 6 CNC lathe (lathe) spinner type TC 108 Fanuc 2003 Note: Machine parameters must be fed into item 1, but otherwise works perfectly. Pos. 2 also works single-wall, but a heat sensor must be replaced

BAZ Spinner VZ 750 Year of construction: 2011 Hours : 6910 Spindle hours: 5114 Control Type: Fanuc OIMD-Alpha-Drive-HV-Technology Accessories: Chip conveyor Equipment: SK 40 Tool Pack

General Manufacturer: Spinner Type: SB 32-V4 Year of Make: 2016 Control: Fanuc Series 32i Model B Travels: X 250 mm Z 285 mm Switch-on hours: 46,318 h Spindle Spindle speed: 8,000 rpm Spindle Passage: 32 mmin Dimensions and weight Dimensions: 2,100 mm x 800 mm x 1,600 mm Weight: approx. 1,500 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: C-axis Preparation Interface Bar Feeder Linear Tool Carriers Collet chuck

Key data: 2 mm, 810 mm, 700 mm

General Manufacturer: Spinner Type: MVC1600-B Year of Make: 2006 Switch-on hours: 30,240 h Control: Siemens 810D ShopMill Travels: X 1,600 mm Y 810 mm Z 700 mm Spindle Speed: 6,000 rpm Power: 25 kW Tool holder: SK50 Tool Changer Number of stations: 24-fold with double arm Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Conveyor Blow-out device for spindle High-pressure system IKZ 26 bar Preparation 4th axis Preparation of workpiece probes

Inv. Num. : 8226 Type: VC 810 Producer: Spinner Created: 2005 Parameters: Control system: Siemens Work table length: 1000 mm Work table width: 600 mm Maximum vertical spindle speed: 8000 1/min X-axis travel: 800 mm Y-axis travel: 600 mm Travel Z-axis: 510 mm Machine height: 2600 mm Machine length: 2400 mm Machine width: 2200 mm Machine weight: 6000 kg

Inv. Num. : 8228 Type: TC-42 Producer: Spinner Created: 2004 Parameters: Control system: Siemens Max. machining length: 500 mm Maximum turning diameter over bed: 400 mm Maximum main spindle power: 12 kW Maximum spindle speed: 4500 1/min Spindle bore: 42 mm Equipment: Powered tools

Inv. Num. : 8227 Type: U-620 Producer: Spinner Created: 2011 Parameters: Control system: Siemens Number of axles: 5 pieces X-axis travel: 620 mm Y-axis travel: 520 mm Travel travel Z-axis: 460 mm Maximum vertical spindle speed: 10000 1/min

Inv. Num. : 8242 Type: VC 560 Producer: Spinner Created: 2007 Parameters: Control system: Siemens Work table length: 650 mm Work table width: 480 mm Maximum vertical spindle speed: 6000 1/min X-axis travel: 560 mm Y-axis travel: 400 mm Travel Z axis: 400 mm Cone: SK 40 Number of all tools: 16 pieces Equipment: Cooling

X,Y,Z Travels 630,530,465 mm Spindle speed 18.000 rpm Tool holder SK40 Number of tools 32 Controller Heidenhain iTNC 530 With Tool and workpiece measuring probe With chip conveyor

Control Heidenhain TNC 620 V2 Travel X/Y/Z 760/480/480 mm Speed 12000 rpm. Tool magazine for 24 tools SK40 Table size 900x410 mm Conveyor

Specifications: Manufacturer: Spinner Type: SB-CNC Year of Make: 1998 Control: Siemens 840D Travels: X 250 mm Z 285 mm Switch-on hours: 32,156 h Main spindle: Spindle speed: 5,000 rpm Spindle passage: 42 mm Tool holder: Tool holder: Multifix A on linear beam Dimensions and weight Dimensions: 2,100 mm x 800 mm x 1,600 mm Weight: approx. 1,500 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Collet chuck Interface for bar feeders The machine has a headstock elevation of 10 mm.

turning diameter: max. 250 mm turning length: max. 900 mm control: FANUC SERIE 0-T turning spindle: Durchlass 75mm chuck diameter: 250 mm turning speeds: 0-3700 U/min transmission ratio: 2 tool numbers: 12 feed speeds: X/Z 15/20 mm/min quill stroke: 100 mm diameter of quill: 110 mm tool adaptor: MK 4 coolant tank: 130 l weight - pallet system: 5500 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 32 mm, 8000 1/min

Specifications: Manufacturer: Spinner Type: SB 32-V4 Year of Make: 2017 Control: Fanuc Series 32i Model B Travels: X 250 mm Z 285 mm Switch-on hours: 39,131 h Spindle Spindle speed: 8,000 rpm Spindle passage: 32 mm Dimensions and weight Dimensions: 2,100 mm x 800 mm x 1,600 mm Weight: approx. 1,500 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: C-axis Preparation Interface Bar Feeder Linear Tool Carriers Collet chuck

Specifications: Manufacturer: Spinner Type: SB 32-V4 Year of Make: 2017 Control: Fanuc Series 32i Model B Travels: X 250 mm Z 285 mm Switch-on hours: 39,616 h Spindle Spindle speed: 8,000 rpm Spindle passage: 32 mm Dimensions and weight Dimensions: 2,100 mm x 800 mm x 1,600 mm Weight: approx. 1,500 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: C-axis Preparation Interface Bar Feeder Linear Tool Carriers Collet chuck

Specifications: Manufacturer: Spinner Type: SB 32-V4 Year of Make: 2017 Control: Fanuc Series 32i Model B Travels: X 250 mm Z 285 mm Switch-on hours: 39,889 h Spindle Spindle speed: 8,000 rpm Spindle passage: 32 mm Dimensions and weight Dimensions: 2,100 mm x 800 mm x 1,600 mm Weight: approx. 1,500 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: C-axis Preparation Interface Bar Feeder Linear Tool Carriers Collet chuck

Key data: 32 mm, 8000 1/min

Specifications: Manufacturer: Spinner Type: SB 32-V4 Year of Make: 2015 Control: Fanuc Series 32i Model B Travels: X 250 mm Z 285 mm Switch-on hours: 52,356 h Spindle Spindle speed: 8,000 rpm Spindle passage: 32 mm Dimensions and weight Dimensions: 2,100 mm x 800 mm x 1,600 mm Weight: approx. 1,500 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: C-axis Preparation Interface Bar Feeder Linear Tool Carriers Collet chuck

General Manufacturer: Spinner Type: TTC300 65SMMCY Control: Siemens 840D SL ShopTurn Year of Make: 2015 Travel X1 / X2 / Z / Y: 180 / 110 / 450 / +40-40 mm Rapid traverse X1 / X2 / Z / Y: 15 / 15 / 15 / 24 m/min Turning Spindle 1 Speed: 4,000 rpm Chuck size: 250 mm Spindle passage: 52 mm Spindle power S1 / S6: 21 / 27 kW Torque S1 / S6: 201 / 258 Nm Turning spindle 2 Speed: 7,000 rpm Chuck size: 130 mm Spindle power S1 / S3: 6 / 8.5 kW Torque S1 / S3: 49 / 68 Nm Revolver Number of tools: 12 + 12 (BMT45) Rotating Tools: 12+12 (BMT45) Speed: 6,000 rpm Power S1 / S3: 2.3 / 3.5 kW Torque S1 / S3: 7 / 11 Nm Dimensions and weight Dimensions: 2,700 mm x 1,900 mm x 2,165 mm Weight: 5,100 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: IKZ 50 bar with belt filter system Parts Conveyor Belt w ...

Key data: 280 mm, 500 mm

Turning lenght 500 mm Turning diameter 280 mm Controller Fanuc 32i 12 stations VDI30 tool holder

A CNC milling machine Spinner is available. Travel X/Y/Z: 760mm/460mm/460mm, table dimensions X/Y: 900mm/410mm, max workpiece weight: 350kg, tool stations: 24, max tool weight: 8kg, max tool length: 200mm, speed: 12000rpm, max tool diameter: 80mm, tool holder: SK40. Machine dimensions X/Y/Z: approx. 2600mm/1600mm/2850mm, weight: approx. 4000kg. Including automation and robot M10. Documentation available. An on site inspection is possible.

A lathe (Universal Turning Solution) is offered, control: Fanuc, tool turret: 12-station, tailstock, 3-jaw chuck. Tool setting arm: Renishaw HPRA. Inspection is possible by arrangement.

Offered is a CNC lathe (sub-spindle, milling/C-axis, Y-axis). Equipped with bar feeder for balls 120mm, incl. Fanuc six-axis robot M-16iB with R-30iA control for automated loading and unloading as well as a bunker for raw material supply. Machine is operational. Inspection possible by prior arrangement.

General Manufacturer: Spinner Type: TC800-110-MCY Year of Make: 2009 Control: Siemens 840D SolutionLine Travel: X 360 mm Z 900 mm Y -55/+65 mm Switch-on hours: 22,551 h Working spindle Speed: 3,200 rpm Power: 28/35 kW Torque: 175/875 Nm Tool/movement Tool holder: VDI40 Tool turret: 16-speed Condition Condition: Used Functional: tested and fully functional Other equipment and accessories included: C-axis for spindle incl. software option "Transmit" Hydraulic hollow clamping cylinder Electrical interface for connecting rod feeds 840D-SL Software Package "Turning with Shoturn" Tool monitoring 840D-SL 3D Simulation of the Precast Part Tailstock Chip conveyor High Pressure Pump Double filter Mahle Parts catcher V2 TC800 Clamping force control via differential pressure for main spindle

Inv. Num. : 8904 Type: SB-CNC Producer: SPINNER Created: 1999 Parameters: Maximum turning length: 250 mm Maximum turning diameter: 285 mm Spindle diameter: 42 mm Maximum spindle speed: 8000 1/min Weight: 1500 kg

This SPINNER VC 450 Vertical Machining center was manufactured in the year 2014 in Germany. The machine has a spindle speed of 15000 rpm and a spindle motor power of 16 kW.

This 2-axis SPINNER TC 600-65MC horizontal turning machine was manufactured in 2017, featuring a Siemens 840D control system and a 16-position indexing turret. It includes a main spindle with a speed of up to 4,000 rpm and a power of 24 kW. The machine offers a swing diameter over bed of 425 mm and a maximum turning diameter of 310 mm. Consider the opportunity to buy this SPINNER TC 600-65MC horizontal turning machine. Contact us for more information about this machine.

This SPINNER PD-CNC was manufactured in 2006. A reliable horizontal turning machine, it offers solid performance for your machining needs. Consider the opportunity to buy this SPINNER PD-CNC horizontal turning machine. Contact us for more information.

This SPINNER JCL-75/1000-TC 82 was manufactured in 2003. A robust horizontal turning machine featuring a max turning diameter over bed of 555 mm and over carriage of 350 mm. It includes a 12-station turret with a VDI 40 tool interface and a spindle motor power of 30 kW. Consider the opportunity to buy this SPINNER JCL-75/1000-TC 82 horizontal turning machine. Contact us for more information about this machine.

This SPINNER TC46-COMPACT was manufactured in 1999. A robust horizontal turning machine, it offers reliable performance for precision machining. Ideal for those looking to enhance their turning capabilities. Contact us for more information.

This SPINNER TTS 42 Lathe was manufactured in the year 2020 in Germany and has 25585 production hours. It is equipped with a Fanuc Series 31i-MODEL B control unit. The machine has a spindle speed of 7000 rpm. See tech specs file as PDF (German) attached for more details.

This SPINNER MT 350/750 was manufactured in 2001. A reliable horizontal turning machine, it offers solid performance for various machining tasks. Consider the opportunity to buy this SPINNER MT 350/750 horizontal turning machine. Contact us for more information.

This 3-axis SPINNER VC 750 was manufactured in 2013. Ideal for precision CNC milling, this machine offers robust performance and reliability. Consider the opportunity to buy this SPINNER VC 750 CNC milling machine. Contact us for more information.

This 3-axis SPINNER MVC 1600-N was manufactured in 2016. Ideal for precision machining, this vertical machining centre ensures reliable performance and durability. Consider the opportunity to buy this SPINNER MVC 1600-N vertical machining centre. Contact us for more information.

This 3-axis SPINNER VC 450 was manufactured in 2011. It features a Fanuc 0i-MD control unit, X/Y/Z travels of 450/400/400 mm, and a rapid traverse rate of 36 m/min. The spindle operates at up to 15,000 rpm with a power of 7.5 kW. It includes a 24-tool changer, linear guideways, and a chip conveyor. If you are looking to get high-quality milling capabilities consider the SPINNER VC 450 machine we have for sale. Contact us for more information.

This 4-axis SPINNER H630 horizontal machining center was manufactured in 2012. Ideal for precision engineering, it offers robust construction and reliability for various machining tasks. Consider the opportunity to buy this SPINNER H630 horizontal machining center. Contact us for more information.

This SPINNER TC 82 -MC was manufactured in 1998. A robust horizontal turning machine featuring a Siemens Sinumerik control system, it offers a max turning diameter of 400-520 mm and length up to 1100 mm. With a spindle speed of 3750 rpm and a 12-position VDI 40 turret with live tooling, its ideal for precise turning tasks. Dimensions are 4200 × 2000 × 2100 mm. Contact us for more information about this machine.

Key data: 850 mm, 510 mm, 510 mm

General Manufacturer: Spinner Type: VC 850 Year of Make: 2021 Control: Siemens 840DE ShopMill Travel X/Y/Z: X 850 mm Y 510 mm Z 510 mm Working spindle Spindle speed: 18,000 rpm Tool holder: HSK63 Tool changer: 32-fold Voltage Operating voltage: 3x400V +/-10% Power frequency: 50Hz (+/-2%) Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Direct measuring systems in X/Y/Z Multifunction handheld operator Chip conveyor Preparation of standard probes

This 3s SPINNER VC 560s was manufactured in 2007. It is a CNC Milling Machine featuring a 3-axis configuration, prepared for a 4th axis (included but not installed). The machine is operational and comes complete with all tooling and a tool cabinet. With a maximum spindle speed of 12,000 rpm and rapid traverse of 48 m/min, consider the opportunity to buy this SPINNER VC 560 vertical machining centre. Contact us for further details.

Key data: 850 mm, 510 mm, 510 mm

General Manufacturer: Spinner Type: VC 850 Year of Make: 2022 Control: Siemens 840DE ShopMill Travel X/Y/Z: X 850 mm Y 510 mm Z 510 mm Working spindle Spindle speed: 18,000 rpm Tool holder: HSK63 Tool changer: 32-fold Voltage Operating voltage: 3x400V +/-10% Power frequency: 50Hz (+/-2%) Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Direct measuring systems in X/Y/Z Multifunction handheld operator Chip conveyor Preparation of standard probes

This 3-axis SPINNER MT 500/1000 AT was manufactured in 2000. It features an X-axis travel of 210 mm, and Z-axis travel of 930 mm. The machine includes a robust table size of 520 x 900 mm with a load capacity of 400 kg. If you are looking to get high-quality machining capabilities, consider the SPINNER MT 500/1000 AT machine we have for sale. Contact us for further details.

This 5-axis SPINNER U5-2520 was manufactured in 2016. It features an impressive X-axis travel of 2660 mm, Y-axis travel of 520 mm, and Z-axis travel of 460 mm. The machine is equipped with a spindle speed of 10,000 rpm and an automatic tool changer with 2x52 positions. If you are looking to get high-quality machining capabilities, consider the SPINNER U5-2520 vertical machining centre we have for sale. Contact us for further details.

General Manufacturer: Spinner Type: Microturn LT Year of construction: 2024 Control: Siemens One Travels: X 600 mm Z 350 mm Y +/- 50 mm Switch-on hours: 4,587 h Work spindle hybrid bearing Speed: 10,000 rpm Tool/movement Tool holder: BMT45 with Y-axis Tool turret: 12-speed Condition Condition: Used Functional: tested and fully functional Other equipment and accessories included: High-precision motor spindle with a circular shape deviation and 1um Power Chuck Röhm KFD-HS 125 Power Chuck SMW Autoblok BH-D 165-46-3-A05 Various owners and AGW High-pressure system 70 bar including fine filter Chip conveyor Spindle coolers

A CNC vertical machining center Spinner is available. Travel X/Y/Z: 650mm/450mm/460mm, table dimensions X/Y: 710mm/450mm, max. table load: 500kg, speed: 8000rpm, tool holder: SK40, tool positions: 24, rapid traverse: 24m/min, feed: 10m/min, positioning accuracy: +/-0.01mm, repeatability: +/-0.005mm. Machine dimensions X/Y/Z: approx. 2400mm/2100mm/2600mm, weight: approx. 9500kg, control: Fanuc. Without vise and dividing head. The spindle was recently renewed and the hydraulic pump is currently being renewed. The rotary table is leaking oil. Documentation available. An on-site inspection is possible.

turning diameter: 250 mm turning length: 600 mm control: FANUC Series 31i-Model A total power requirement: 23 kW weight of the machine ca.: 7,7 t dimensions of the machine ca.: 2.880 x 2.130 x 1.990 mm m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

For sale is a high-quality CNC turning-milling center spinner TC77-SMCY with Siemens Sinumerik control. The machine is equipped with: Y-axis C-axis Sub-spindle powered tools Chip conveyor extensive tool package Technical data: Bar passage 77 mm 12-speed VDI50 turret Main spindle ASA 8 Sub-spindle ASA 6 Speed up to 4000 rpm Turning diameter approx. 500–690 mm Turning length approx. 800–900 mm Y-axis ±60 mm Main and sub-spindle Weight approx. 6000–7000 kg Nloc Egsy Uwmws S Rrgob

This 4-axis SPINNER TC800 was manufactured in 2009. It features a radial turret and is equipped with Siemens control, ensuring reliable operation. With approximately 1,000 operating hours, this machine has been barely used. If you are looking to get high-quality turning capabilities, consider the SPINNER TC800 horizontal turning machine we have for sale. Contact us for further details.

General Manufacturer: Spinner Type: VC750-XL Year of Make: 2019 Control: Siemens 840DE SolutionLine V2 Travel: X 950 mm Y 460 mm Z 460 mm Rapid traverse: 36 m/min Working spindle Speed: 12,000 rpm Power: 11 kW (S6/40%) Tool/movement Tool taper: size 40 according to DIN 69871-A Tightening bolts: according to DIN 69872-A Tool changer: 32-fold Condition Condition: Used Functional: tested and fully functional Other equipment and accessories included: Multi-function control panel with handwheel and integrated display Chip Conveyor V2 VC750-XL Preparation for high-pressure flushing High-pressure flushing 22 bar (additional tank) Blow-out device for spindle taper Compressed air cooling nozzle on the headstock Option package "Shopmill programming" Preparation of interface for Blum infrared probe TC50/TC52/TC54-20 Linear guide in all three axes Splash protection ...

This 5-axis SPINNER U5-1530 was manufactured in 2021. It features an impressive X-axis travel of 1530 mm, Y-axis travel of 530 mm, and Z-axis travel of 465 mm. The machine includes a fixed rigid table combined with a 2-axis rotary/tilt table, enhancing its versatility. If you are looking to get high-quality machining capabilities, consider the SPINNER U5-1530 vertical machining centre we have for sale. Contact us for further details.

x-travel: 760 mm y-travel: 460 mm z-travel: 460 mm control: TNC 620 Heidenhain Main spindle:: turning speed range - main spindle: max. 12.000 min/-1 power capacity - main spindel: 14 / 10 kW Torque: 89 / 63,7 Nm tool taper: SK 40 work table:: table surface area: 900 x 410 mm max. table load: 350 kg T-slots: 4x Tool-Presetter:: number of toolpositions: 24 pos. max. tool diameter: 130 mm max. tool length: 200 mm max. tool weight: 8,0 kg feeds:: rapid traverse ( X / Y / Z ): 36 m/min total power requirement: 20 kVA weight of the machine ca.: 3,3 t dimensions of the machine ca.: 3,0 x 2,5 x 2,9 m Documents: digital Chip-Tray: Automatic Tool Changer: Coolantsystem: interface 4. axis: work light: test probe: Blum TC 50 elektr. hand wheel: integriert / integrated Tailstock: TTS-125 indexing attachment: CNC Machiningcenter Vertical SPINNER - VC 750 The data for this ad was created wi ...

A CNC horizontal machining center by Spinner is offered, equipped with a twin spindle and two dual tool changers. Travel X/Y/Z: 1000mm/850mm/850mm, distance from spindle center to pallet front face: 100-950mm, distance from spindle nose to table surface: 150-1100mm, rapid traverse X/Y/Z: 32m/min, pallet size: 2×630×630mm, max. pallet load: 1000kg, distance to table: 360mm, table top height above floor: 993mm, door opening: 1200mm, table threads: M16, spindle A: tool interface 1/2: SK40/SK50, max. speed 1/2: 10000rpm/6000rpm, power S1 1/2: 22kW/22kW, power S3 1/2: 26kW/26kW, max. torque S1 1/2: 139Nm/556Nm, max. torque S3 1/2: 164Nm/656Nm, tool stations 1/2: 60/40, max. tool diameter 1/2: 80mm/115mm, max. tool weight 1/2: 8kg/20kg, control: Fanuc 0i. Machine dimensions X/Y/Z: 5970mm/3470mm/3362mm, weight: approx. 23000kg. Documentation available. Inspection by appointment possible.

A CNC vertical machining center is offered. Travel X/Y/Z: 1000mm/500mm/570mm, table dimensions X/Y: 1200mm/500mm, max. workpiece weight: 800kg, distance from spindle nose to table: approx. 120-690mm, tool holder: SK40, max. spindle speed: 10000rpm, tool magazine: 24, max. tool diameter: approx. 80mm, max. tool length: approx. 300mm, max. tool weight: approx. 7kg, rapid traverse X/Y: 24m/min, rapid traverse Z: 20m/min, positioning accuracy: approx. 8-12µm, control: Heidenhain TNC 620. Machine dimensions X/Y/Z: approx. 2700mm/2550mm/2770mm, machine weight: approx. 5100kg. Inspection possible by appointment.

A CNC vertical machining center is offered. Travel X/Y/Z: 1000mm/500mm/570mm, table dimensions X/Y: 1200mm/500mm, max. workpiece weight: 800kg, distance from spindle nose to table: approx. 120-690mm, tool holder: SK40, max. spindle speed: 10000rpm, tool magazine: 24, max. tool diameter: approx. 80mm, max. tool length: approx. 300mm, max. tool weight: approx. 7kg, rapid traverse X/Y: 24m/min, rapid traverse Z: 20m/min, positioning accuracy: approx. 8-12µm, control: Heidenhain TNC 620. Machine dimensions X/Y/Z: approx. 2700mm/2550mm/2770mm, machine weight: approx. 5100kg. Inspection possible by appointment.

Key data: 250 mm, 400 mm

Technical data: Manufacturer: Spinner Type: TC300-52 SMMCY Year of Make: 2012 Control: Siemens 840D SL Travel: X1 180 mm X2 110 mm Z 450 mm Y +40/-40 mm Turning length: 400 mm Turning diameter: 250/200 mm Swing diameter: 400 mm Switch-on hours: (Information to follow) Working Spindle 1 Speed: 5,000 rpm Torque: 96/121 Nm Power: 15/19 kW Bar Passage: 52 mm Working spindle 2 Speed: 7,000 rpm Torque: 38 Nm Power: 6 kW Tool turret 1 and 2 Number of stations: 12x Recording: VDI 25 Max. speed AGW: 6,000 rpm Power: 8/2.6 kW Dimensions and weight Dimensions: 2,200 x 2,000 x 2,000 mm Weight: approx. 4,600 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Parts Conveyor Belt High Pressure Pump Chip conveyor Interface for bar feeders 3-jaw chuck on sub-spindle and main spindle

x-travel: 650 mm y-travel: 500 mm z-travel: 530 mm control: Siemens type: 840D Shopmil table surface area: . mm size of pallet: 800x500 mm workpiece weight: . kg Tool changer: 24 Fach spindle taper ISO: SK 40 Spindle capacity: KW turning speeds: 60-8000 U/min feed: 30 m/min total power requirement: kW weight of the machine ca.: 5 t dimensions of the machine ca.: 4000x5000x3000 mm Workpiece width: Max. 550 mm Workpiece length: Max. 1300 mm Workpiece height: Max. 600 mm The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please conta ...

3 machining centers 1 x BAZ Spinner H 500 BJ 2012 1 BAZ Spinner H 630 BJ 2014 1 BAZ Wemas VZG 5A BJ 2019

turning diameter: 310 mm turning length: 600 mm control: Sinumerik 810 D PL Siemens turning diameter over bed: 425 mm Main spindle: turning speed range - main spindle: 500 - 4.500 min/-1 max. Torque: 280 Nm power capacity - main spindel: 16,5 kW Spindle diameter: 100 mm C-Axis: 360 ° chucking diameter: 210-52 mm spindle bearing diameter: 120 mm clamping cylinder: 65 mm Bar feed: max. 65 / (52) mm spindle nose: A8 DIN 55026 axis stroke:: x-axis: 230 mm z-axis: 740 mm rapid traverse X-axis: 15 m/min rapid traverse Z-axis: 24 m/min turret:: tool positions turret: 12 pos. driven statition: 12 pos. tool taper: VDI 30 DIN 69880 Spindle speed driven tools: 6.000 min -1 power capacity - driven tools: 3,7 kW max. Torque: 9,5 Nm tail stock: dia. of quill: MK 4 80 mm quill stroke: 120 mm tailstock adjustment: 475 mm tension force: 500 daN total power requirement: - kW weight of the machine ca. ...

x-travel: 1520 mm y-travel: 520 mm z-travel: 460 mm Control: Siemens 840D turning speeds: 12.000 U/min tool change unit: 32-fach tool taper: SK 40 0: 19 kW rapid traverse: 32 m/min B-axis (table): +110 / -90 ° total power requirement: kW weight of the machine ca.: 10,5 t dimensions of the machine ca.: 3,5x2,6x3,0 m 5 axes simultaneous machining - CNC control Siemens 840D - 32-position tool changer (SK 40) - Blast air through spindle - Internal coolant supply 80 bar - Automatic door - Rotary and tilting table: 650x540mm, 500kg - Fixed table: 920x540mm approx. 5000h running hours The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 400 mm turning length: 730 mm control: FANUC 21i rapid traverse: 15/24 mm/min spindle turning speed range: 4000 U/min spindle motor: 19 kW x-axis: 240 mm z-axis: 640 mm rapid travel (x and z-axis): 18 /24 m/min spindle bore: 66 mm tailstock quill taper MT: 5 tailstock quill stroke: 120 mm total power requirement: 50 kVA weight of the machine ca.: 5,5 t dimensions of the machine ca.: 3 x 1,7 x 1,8 m - CNC control FANUC 21i-TB (with Manual Guide I) - hydraulic hollow clamping cylinder - 12-position tool turret, driven tools 4000 rpm, 2.8 kW - Tool monitoring - SMW Autoblok KNCS N225-65 chuck - C-axis (with disk brake for milling operation, Transmit software for end face machining and cylinder interpolation for shell machining) - B-axis - Tailstock (MK 5) - Chip conveyor - Coolant system with high-pressure pump - Parts catcher - Radial and axial milling heads Translated wi ...

turning diameter: 120 mm turning length: 380 mm control: Fanuc 18 iTB max. swing diameter: 300 mm : : 8000 min/-1 : 7,5 kW : 26 Nm spindle nose: 100 mm spindle passage: 32 mm A-Axis: : 8000 min/-1 : 5,5 kW : 23 Nm spindle nose: 100 mm spindle passage: 32 mm : : 12 pos. tool taper: VDI 16 Sub Spindle: x-axis: 400 mm z-axis: 400 mm feeds:: rapid traverse: 12 m/min total power requirement: 20 kW weight of the machine ca.: 2,3 t dimensions of the machine ca.: 2,8 x 2 x 1,7 m 2022 New glass scale Heidenhain and replacement of smaller parts, new FANUC CNC Keyboard CNC - Ultra precision turning centre (X-, Z-, E-, C-Axe) - CNC control Fanuc 18iTB - Main and counter spindle - SAUTER tool turret 16-fold (0.5.480.510) VDI 16 - Linear tool slide - automatic doors - Chip tray - Coolant system with fine filter (high Pressure Pump) - 3 jaw chucks - Various clamping devices/pressure collets - Vari ...

SPINNER VC-560 ist ein 3-Achsen-Bearbeitungszentrum, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Tisch 650×410 mm mit 3 T-Nuten 14 mm, Tischlast 250 kg; Verfahrwege X 560 mm, Y 410 mm, Z 410 mm. Spindelaufnahme SK40, Drehzahl stufenlos 0–12.000 min-¹; Eilgang 48 m/min; Werkzeugmagazin 24 Plätze (Ø Werkzeug max 77 mm, mit freien Nachbarplätzen 125 mm, L 200 mm, Wechsel 1,3 s). Netz 3×400 V 50 Hz, Gesamtleistung 20 kVA, Druckluft 6 bar. Kühlmitteleinheit 250 l. Gewicht ~5500 kg; Abmessungen 2400×1800×2500 mm. Ermöglicht enge Toleranzen; geeignet für Automobil, Luftfahrt, Medizintechnik, Uhrmacherei, Maschinenbau Technische Daten ohne Gewähr

SPINNER VC-560 is a 3-Achsen Bearbeitungszenter, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Tisch 650x410 mm, 3 T-Nuten 14 mm, max. Werkstückgewicht 250 kg; Verfahrwege X560 Y410 Z410 mm. Spindel SK40, 0–12.000 U/min (stufenlos), Eilgang 48 m/min. Magazin 24 Plätze, Werkzeug-Ø max. 77 mm (125 mm bei freien Nachbarplätzen), Länge 200 mm, Werkzeuggewicht max. 5 kg, Werkzeugwechsel 1,3 s. Anschluss 3x400 V 50 Hz, Gesamtleistung 30 kW; Maschinengewicht ca. 4000 kg; Abmessungen L3000 x B2000 x H2500 mm. Erreicht enge Toleranzen; geeignet für Automotive, Luftfahrt, Medizintechnik, Uhrmacherei und Maschinenbau Technische Daten ohne Gewähr

SPINNER TC 32-MC ist eine CNC Drehmaschine, die Präzision, hohe Genauigkeit und Zuverlässigkeit in der Drehbearbeitung bietet. Arbeitsvermögen: 3 Achsen, Schwingdurchmesser über Bett 290 mm, maximale Drehlänge 245 mm, maximaler Drehdurchmesser 120 mm, Spindeldurchlass 32 mm; Revolver 12 Positionen mit 6 festen und 6 angetriebenen Werkzeugen; Verfahrwege X 96 mm, Z 245 mm. Technische Hauptdaten: Spindeldrehzahl bis 6000 t/min, Anschluss 50 Hz 3x 400 V, Maschinengewicht ca. 1400 kg, Abmessungen L 1750 x B 1100 x H 1730 mm. Zubehör: Lademagazin Typ Botteron jdb. Erreicht enge Toleranzen; geeignet für Automotive, Luft- und Raumfahrt, Medizintechnik und Maschinenbau Technische Daten ohne Gewähr

BAZ Spinner H500 BJ 2012

BAZ Spinner H630 BJ 2014

Manufacturer: SPINNER Model No.: PD-CNC Year: 2006 Condition: Used Stock number: 9421 Control system: SIEMENS Sinumerik Maximum turning diameter: 120 mm Maximum length of travel in the X-axis: 400 mm Maximum feed rate in the Z-axis: 400 mm Max. rod diameter: 32 mm Spindle speed: 8000 1/min Length: 2300 mm Width: 1200 mm Height: 1700 mm Weight: 2300 kg

Manufacturer: SPINNER Model No.: TC-32-MC Year: 1999 Condition: Used Stock number: 9422 Control system: SIEMENS Sinumerik Maximum turning length: 245 mm Maximum turning diameter: 120 mm Maximum turning diameter over bed: 290 mm Maximum length of travel in the X-axis: 96 mm Max. travel length of the Z-axis: 245 mm Maximum spindle speed: 6000 1/min Length: 1750 mm Width: 1100 mm Height: 1730 mm Weight: 1400 kg
