schuler sheet metal working used for sale

Sheet thickness iron: 0.75mm, sheet thickness steel: 0.5mm, working width: 780mm, stroke rate: 135/min. An on-site inspection is possible.

Schuler PE4s 50/800 High Speed Press Manufacturer: Schuler Type: PE4s 50/800 High-speed press 61/21 600/3 Pressing force: 50 t Projection: 800 mm Stroke rate /min: 125-300 Plunger stroke: 40 mm Kohler unwinding reel 500.1 M We sell a large number of paternosters. The devices are in operation until 30.06.2021. After the purchase, there are also the documents for it From 01.07.21 the devices are ready for collection. Dismantling and transport by the buyer. Location is Hildesheim The dismantling, loading, as well as transport can alternatively be offered by us. In addition to about 50 paternosters, countless other machines are available. After purchase, the amount is due within 7 working days. Please also note our other offers. Have fun browsing and buying.

Capacity: 50 ton Projection: 225 mm Stroke: 320 p/min Large table: 500 x 800 mm

Fully Automated Forging Hammer Line (2023) SCHULER KG H 6.3 B (63 KJ) Line Description The complete line consists of the following machines: ‍ Tilting Device, Stahlmann Step Conveyor, Stahlmann Cold conveyor belt Conductive Heating System, Stahlmann, E89, 2023 Transfer Gripper Hot Conveyor Belt with Lifting Device 2 Forging robot, Kuka, KR 30-3F, 2010 Safety Fence with Safety Doors Short-Stroke Die Forging Hammer, Schuler, KG H 6.3 B, 2023 Discharge / Extraction Robot, Kuka, KR 150/2, 2010 Output Station, Stahlmann, 2010 ‍ ‍ Technical Details ‍ (2023) Short-Stroke Die Forging Hammer SCHULER KGH 6.3B ‍Machine identification data Name: Short-Stroke Die Forging Hammer Model: KGH 6.3B Machine number: 119820 Year of manufacture: 2023‍ Operational parameters Working capacity max. 63 kJ Max. impact frequency 98/min Max. usable impact rate  ...

Specifications: Capacity 63 tons Stroke rate 140 h/min Projection 250 mm Plunger stroke 8-100 mm Table , WxD approx. 700 x 480 mm Installation height approx. 400 mm

Specifications: Capacity 63 tons 2 strokes 105 rpm and 140 rpm large projection 450 mm ! Plunger stroke 8-100 mm Plunger adjustment approx. 70 mm Table , WxD approx. 700 x 780 mm Plunger, W x D approx. 450 x 280 mm

pressure: 63 t throat: 315 mm stroke: 8-100 mm no. of strokes: 140 Hub/min ram - range of adjustment: 63 mm table surface area: 1200x630 mm ram surface: 800x315 mm hole in the table: Ø 110 mm table height: 820 mm tool hole in ram: Ø 50 mm dayligth: 335 mm total power requirement: 7,5 kW weight of the machine ca.: 5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 63 t throat: 440 mm stroke: 8-100 mm no. of strokes: 65 Hub/min ram - range of adjustment: 63 mm table surface area: 720x750 mm ram surface: 440x280 mm hole in the table: Ø 240 mm table height: 830 mm tool hole in ram: Ø 40 mm weight of the machine ca.: ca. 5,0 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

End mill, shank mill, milling cutter -Four-cutter -Roughing end mill -Diameter: 16 mm -Usable length: 20 mm -Type: HSSE -Quantity: 17 pieces -Sale: only complete set -Weight: 4 kg

Pressure total: 600 ton Ram stroke: 762 mm Slide adjustment: 406 mm Shut height (stroke down, adjustment up): 1322 mm Free frontal opening L-R: 3700 mm Table surface area : 3350 x 2134 mm Slide area: 3350 x 2134 mm Die cushion capacity in table: 180 ton Die cushion stroke: 305 mm Ejector in ram: 60 ton Ejector stroke in ram: 230 mm Number of strokes: 16 s.p.m. Required power: 90 kW Weight of machine approx.: 185 ton

Radius cutter, finger cutter, end mill, milling cutter -Six-cutter -Finish cutter -Shaft: Ø 25 mm -Diameter: 32 mm -Usable length: 70 mm -Angle: 60° -Type: HSS -Quantity: 4 pieces -Sale/Price: complete -Weight: 4 kg

End mill, roller cutter, milling cutter, disc cutter, slot cutter -Manufacturer: Schuler, end mill cutters, disc cutters -Type: 125Wx12x32 HSS K10 -Hole: Ø 32 mm -Quantity: 1x milling cutter available -Dimensions: Ø 125 x 12 mm -Weight: 0.5 kg

Hydraulic press line for deep drawing and forming processes with multiple presses and automated part handling. Manufacturer: Fritz Müller / Schuler Machine Type: Hydraulic Press Line / Heat Press Number of presses: 6 Press 1 Type: BZE 1200 – 35.1.1 Year of Make: 1972 Press force: 12000 kN Press 2 Type: ZE 800 – 35.1.1 Year of Make: 1969 Press force: 8000 kN Press 3 Type: ZE 800 – 35.1.1 Year of Make: 1969 Press force: 8000 kN Press 4 Type: ZE 800 – 35.1.1 Year of Make: 1969 Press force: 8000 kN Press 5 Type: ZE 800 – 35.1.1 Year of Make: 1969 Press force: 8000 kN Press 6 Type: ZE 800 – 40.3.1 Year of Make: 1993 Press force: 8000 kN Max. workpiece size: 3500 x 2200 mm Tool weight max.: 32000 kg Material thickness: 0.5 – 2.5 mm Max. drawing depth: 430 mm Documentation: No digital data available Drawings: Some available as ink draw ...

SCHULER HYDRAP SH 630 - 1.6 x 1.3 (2005) Total weight 74,000 kg Rated force 6,300 kN Max. stroke length 600 mm Mounting height 900 mm Closes quickly 500 mm/s Max. working speed 23 mm/s Min. working speed 51 mm/s Base and tool max. (xH) 2,280 x 1,200 mm Base and tool min. (xH) 1,250 x 600 mm Tool height min. 300 mm Total tool weight max. 2,500 kg Total tool weight max. 5,000 kg Permissible eccentric hydraulic press load left right Permissible eccentric load front rear 490 kNm 250 kNm Installed power 295 kW Rated current 565 A Voltage 400 V Frequency 50 Hz Operating hydraulic pressure 278 bar Total oil volume 5.185 l Oil type HLP 68 in accordance with DIN 51524

sheet width: 5 mm plate thickness: 1000 mm distance between columns: mm total power requirement: 4 kW weight of the machine ca.: 2,8 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

material width:320 mm coil weight:2,6 t material thickness:0,5 - 2,0 mm coil internal diameter:400 - 510 mm coil external diameter:1200 mm no. of straightening rolls:7 straightening roll diameter:50 mm number of draw-in rolls:2 band speed:0 - 30 m/min power capacity:1,5 kW weight:1,5 t

nominal force:100 t stroke:320 mm no. of strokes:35 /min distance between columns:360 / 250 mm Distance table/ram, max. stroke up, adjustment up:500 mm table surface area:320 x 450 mm table height over floor:660 mm ram surface:250 x 280 mm spindle diameter:125 mm power capacity:3,0 kW weight:4,5 t Dimensions (WxDxH):2,0 x 1,6 x 3,1 m

pressure: 25 t throat: 200 mm stroke: 8 - 80 mm no. of strokes: 180 Hub/min distance table/ram: 330 mm table surface area: 550 x 400 mm hole in the table: 60 mm table height over floor: 800 mm table height over floor: 800 mm passage to the back: 200 mm ram surface: 355 x 220 mm ram adjustment: 50 mm power capacity: 2,5 kW total power requirement: kW weight of the machine ca.: 2,5 t dimensions of the machine ca.: 1,2 x 1,8 x 2,4 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CONTROLS   PLC SIEMENS S7 PRESS DESIGN   drive system: knuckle-joint   frame design: H-frame, monoblock   openings in uprights: yes   number of suspensions: 2   feedstock transport direction: left to right PRESS FORCES   total force (nominal): 315 to   nominal work capacity: 38 kNm PRESS TABLE   table surface (left-right): 2000 mm   table surface (front-back): 1200 mm   thickness of bolster plate: 200 mm SLIDE   slide force: 315 to   table surface (left-right): 1995 mm   table surface (front-back): 1100 mm   stroke: 160 mm   stroke rate (max.): 80 /min SLIDE (MECHAN. PRESS)   slide adjustment: 140 mm   stroke rate (min.): 20 /min   stroke rate (max.): 80 /min   main drive power: 90 kW TOOL ASSEMBLY DIMENSIONS   shut height (stroke down, adjustment up), BDC: 555 mm   distance between columns (H-frame): 2060 mm   passline opening (free passa ...

An electric guillotine shear L. Schuler (Göppingen) is available. Working width: 1000mm, max. sheet thickness iron/steel: 2.5mm/2mm, flywheel speed: 100rpm, power requirement: 4HP. An on-site inspection is possible.

Press force: 250kN, ram stroke: 8mm-80mm, stroke rate: 180/min, installation height: 310mm, table dimensions X/Y: 550mm/400mm, ram dimensions X/Y: 355mm/220mm, machine dimensions X/Y/Z: approx. 1100mm/1400mm/2300mm, weight: approx. 2500kg. An on-site inspection is possible.

bushing cut-off diameter range 8-18 mm number of dies 5 number of stations (incl. cut off) 6 shaft length under head 120 mm cutting length 140 mm output - pieces/min 60-170 press power 100 to

Pressure total: 800 ton Ram stroke: 700 mm Slide adjustment: 600 mm Shut height (stroke down, adjustment up): 1475 mm Free frontal opening L-R: 3700 mm Free lateral opening F-B: 2300 mm Table surface area : 3600 x 2200 mm Slide area: 3500 x 2070 mm Die cushion capacity in table: 150 ton Die cushion stroke: 250 mm Die cushion pad area: 2780 x 1570 mm Ejector in ram: 60 ton Ejector stroke in ram: 150 mm Number of strokes: 7 - 21 s.p.m. Required power: kW Height over floor approx.: 9510 mm Weight of machine approx.: 260 ton

Pressure total: 1200 ton Ram stroke: 600 mm Slide adjustment: 600 mm Shut height (stroke down, adjustment up): 1600 mm Free frontal opening L-R: 4550 mm Table surface area : 4500 x 2700 mm Slide area: 4500 x 2700 mm Die cushion capacity in table: 225 ton Die cushion stroke: 200 mm Number of strokes: 9 s.p.m. Height over floor approx.: 9000 mm Weight of machine approx.: 344 ton

pressure: 200 t nominal power: 2000 kN stroke length max.: 1700 mm working feed: 50 mm/sec weight of tools max.: 50000 kg voltage: 400 V table-size: 4.800 x 2.400 mm total power requirement: 99 kW weight of the machine ca.: 113 t dimensions of the machine ca.: m passage width: mm stroke: mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Pressure total: 1200 ton Ram stroke: 600 mm Slide adjustment: 500 mm Shut height (stroke down, adjustment up): 1250 mm Free frontal opening L-R: 3550 mm Table surface area : 3500 x 2700 mm Slide area: 3500 x 2700 mm Die cushion capacity in table: 240 ton Die cushion stroke: 250 mm Ejector in ram: 95 ton Ejector stroke in ram: 150 Number of strokes: 10 - 16 s.p.m. Height over floor approx.: 9000 mm Weight of machine approx.: 280 ton

pressure: 1.000 t nominal power: 10.000 kN stroke length max.: 1.650 mm working feed: 62 mm/sec weight of tools max.: 40.000 kg voltage: 400 V total power requirement: 420 kW weight of the machine ca.: 254 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Pressure total: 800 ton Ram stroke: 700 mm Slide adjustment: 600 mm Shut height (stroke down, adjustment up): 1500 mm Free frontal opening L-R: 3800 mm Free lateral opening F-B: 1450 x 1100 mm Table surface area : 3500 x 1900 mm Slide area: 3500 x 1900 mm Die cushion capacity in table: 150 ton Die cushion stroke: 250 mm Die cushion pad area: 2780 x 1570 mm Number of strokes: 7 - 18 s.p.m. Required power: 120 kW Height over floor approx.: 9510 mm Weight of machine approx.: 260 ton

plate thickness: 4,0 mm roll diameter: ca. 120 mm throat: 450 mm total power requirement: kW weight of the machine ca.: 0,48 t dimensions of the machine ca.: 1,3 x 0,8 x 1,8 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Pressure total: 250 ton Ram stroke: 70 / 250 mm Slide adjustment: 160 mm Ejector in ram: 20 ton Ejector stroke in ram: 10 mm Shut height (stroke down, adjustment up): 520 mm Free lateral opening F-B: 1.300 mm Table surface area : 1.600 x 1.600 mm Slide area: 1.600 x 1.600 mm Number of strokes: 0 - 50 s.p.m. Required power: 33 kW Height over floor approx.: 5.500 mm Weight of machine approx.: 58 ton Roll feeder Material width: 1250 mm Material thickness: 0,3 - 1,6 mm Control: Siemens S7

material width: 650 mm coil weight: 15 t material thickness: 16 mm The year of construction is estimated, the system is as good as new The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

band width:1050 mm plate thickness:8 mm number of rolls:8 DECOILER:. - design : single coil :. - sheet width max:1050 mm - sheet width (min):150 mm - max. weight of coil:22 to - max. diameter of coil:2000 mm - min. internal diameter of coil:570 mm FEEDERS:. - feeder: type : roll feeder :. - sheet width max:1050 mm - sheet thickness max:150 mm LEVELER UNIT:. - sheet width max:1050 mm - sheet width (min):150 mm - sheet thickness max:8 mm - sheet thickness (min):2.5 mm - number of leveler rolls:8 - diameter of leveler rolls:96 mm - distance between leveler rolls:104 mm - diameter of feed rolls:160 mm - feed velocity min.:2 m/min - feed velocity max.:43.5 m/min ELECTRICAL SPECIFICATIONS:. - mains voltage:400 V - mains frequency:50 Hz Technical description : Sheet metal unrolling and straightening system for thick sheet metal up to 8 mm, consisting of: - LAWECO COIL LOA ...

pressure:40 t throat:220 mm stroke:8 / 88 mm table pass:ø- abgesetzt 225/200 mm ram head dimension:400 x 250 mm distance table/ram:228 mm stroke adjustable from - to:30 - 140 mm ram adjustment:63 mm thickness of bolster:80 mm no. of strokes:70 Hub/min total power requirement:5,5 kW weight of the machine ca.:2600 kg dimensions of the machine ca.:1100 x 1300 x 2300 mm Documents:vorhanden

pressure:125 t stroke:25 fix mm no. of strokes:70 - 700 /min distance between columns:1150 mm distance table/ram, max. stroke up, adjustment up:400 mm table surface area:1150 x 1000 mm hole in the table:900 x 220 mm side window:650 mm ram surface:990 x 850 mm ram adjustment:60 mm material width:250 mm material thickness:2,5 mm power requirement:46,5 kW weight:29,5 t roll feed:mechanical, Schuler, WK 8-250

pressure:063 t throat:450 mm stroke:8 - 100 mm no. of strokes:65 /min distance table/ram, max. stroke up, adjustment up:415 mm table surface area:720 x 800 mm hole in the table:280/250 mm table height over floor:800 mm passage to the back:290 mm ram surface:450 x 280 mm ram adjustment:63 mm power requirement:7,5 kW weight:4,7 t dimensions (WxDxH):1,3 x 2,0 x 2,65 m clutch:pneumatisch overload protection in ram:mechanisch

pressure:100 t throat:315 mm stroke:30 - 160 mm no. of strokes:40 /min distance table/ram, max. stroke up, adjustment up:460 mm table surface area:910 x 680 mm Hole in the table:400 mm table height over floor:800 mm passage to the back:400 mm ram surface:630 x 400 mm ram adjustment:80 mm power requirement:7,5 kW weight:7,5 t dimensions (WxDxH):1,7 x 2,0 x 3,0 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical ram counterbalance:pneumatic

pressure:3500 t stroke:900 mm Distance table / ram, stroke down:1000 mm distance table / ram, stroke up:1900 mm table surface area:3150 x 2150 mm ram surface:3150 x 2150 mm Total Weight of Tool max.:30,0 t Weight of Tool Top Part max.:20,0 t speed down:400 mm/s working speed:0,9 - 9,2 mm/s Hydraulic Operating Pressure:280 bar oil volume:5500 l rated current:760 A voltage:400 V frequency:50 Hz power requirement:425 kW weight:231,0 t

Pressure:080 t throat:280 mm stroke:20 - 120 mm no. of strokes:42 - 125 /min distance table/ram, max. stroke up, adjustment up:510 mm table surface area:700 x 560 mm hole in the table:280 mm table height over floor:800 mm passage to the back:320 mm ram surface:560 x 350 mm ram adjustment:72 mm Weight:5,2 t Dimensions (WxDxH):1,6 x 1,6 x 2,6 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical

pressure:025 t throat:200 mm stroke:8 - 80 mm no. of strokes:60 - 180 /min distance table/ram, max. stroke up, adjustment up:330 mm table surface area:560 x 400 mm hole in the table:150 mm table height over floor:800 mm passage to the back:240 mm ram surface:355 x 220 mm ram adjustment:50 mm weight:3,0 t dimensions (WxDxH):1,0 x 1,4 x 2,2 m infinitely variable drive:Stöber overload protection in ram:mechanical NEW electrical controls:Pilz

pressure:025 t throat:200 mm stroke:8 - 80 mm no. of strokes:180 /min distance table/ram, max. stroke up, adjustment up:330 mm table surface area:550 x 400 mm hole in the table:60 mm table height over floor:800 mm passage to the back:200 mm ram surface:355 x 220 mm ram adjustment:50 mm power requirement:2,7 kW weight:2,5 t dimensions (WxDxH):1,2 x 1,8 x 2,4 m overload protection in ram:mechanical

Pressure:250 t stroke:30 mm no. of strokes:60 - 500 /min Distance between columns:1500 mm distance table/ram, max. stroke up, adjustment up:390 mm table surface area:1580 x 1100 mm hole in the table:1270 x 300 mm table height over floor:1470 mm side window:600 mm ram surface:1500 x 900 mm ram adjustment:100 mm material width:500 mm material thickness:0,5 - 1,5 mm coil weight:6,5 t coil internal diameter:420 - 560 mm coil external diameter:1500 mm power capacity:45,0 kW Weight:44,0 t Dimensions (WxDxH):3,3 x 1,8 x 4,5 m clutch:pneumatisch ram adjustment:motorisch double decoiler:LH 2-1,5-500 straightening machine:R 500 roll feed:mechanisch; Schuler, WK 8-500

pressure:160 t throat:400 mm stroke:30 - 200 mm no. of strokes:50 /min distance table/ram, max. stroke up, adjustment up:600 mm table surface area:1000 x 770 mm table height over floor:810 mm hole in the table:360 mm Passage to the back:450 mm ram surface:710 x 450 mm ram adjustment:110 mm power requirement:15,0 kW weight:10,5 t Dimensions (WxDxH):1,7 x 2,0 x 3,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:hydraulic overload protection in ram:mechanical ram counterbalance:pneumatic

pressure:063 t throat:250 mm stroke:8 - 100 mm Stroke rate:60 - 160 / min Distance table/ram, max. stroke up, adjustment up:415 mm Table surface area:710 x 500 mm Hole in the table:250 / 280 mm Table height above floor:800 mm Passage to the back:290 mm Ram surface:450 x 280 mm Ram adjustment:63 mm Weight:4,3 t Dimensions (WxDxH):1,5 x 1,7 x 2,7 m infinitely variable drive:PIV clutch:pneumatic overload protection in ram:mechanical

pressure:063 t throat:250 mm stroke:8 - 100 mm Stroke rate:47 - 140 / min Distance table/ram, max. stroke up, adjustment up:415 mm Table surface area:710 x 480 mm Hole in the table:280 / 250 mm Table height above floor:800 mm Passage to the back:290 mm Ram surface:450 x 280 mm Ram adjustment:63 mm Weight:4,0 t Dimensions (WxDxH):1,5 x 1,6 x 2,7 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 infinitely variable drive:PIV clutch:pneumatic overload protection in ram:mechanical

pressure:600 t distance between columns:3640 mm stroke:350 mm no. of strokes:11 - 44 /min Distance table/ram, max. stroke up, adjustment up:1550 mm table surface area:3600 x 2500 mm sliding table:3600 x 2500 mm ram surface:3600 x 2500 mm Side window:2200 mm ram adjustment:400 mm material width coil line:500 - 1950 mm Material thickness at 1200 mm material width:0,6 - 2,5 mm Material thickness at 1850 mm material width:0,6 - 2,0 mm Material thickness at 1950 mm material width:0,6 - 1,75 mm Coil weight:35,0 t coil internal diameter:610 mm coil external diameter:900 - 1900 mm no. of straightening rolls:13 straightening roll diameter:50 mm Stack height:400 mm stacking dimensions - station 1+2 (L x W):150-2000 x 250-2000 mm stations:2 power requirement:112,0 + 35,0 kW Weight:390,0 t Dimensions (WxDxH):7,3 x 5,1 x 15,0 m Height above floor:9,1 m Height below floor:5,9 m clutch-/ brake combinat ...

Qty. 1 Second-hand Sendzimir reversing cold rolling mill Mfc.: Waterbury Farrel Type: WZS- Reversing - Sendzimir Rolling Mill type: ZR – 23M – 31”, reversing Z”, 1 – 2 – 3 – 4 Built: 1977 Modernised in 1991 Capacity: approx. 50 000 T/annum Strip width: 370 – 740 mm Strip tension: controlled up to 10 Tons Thickness: Entry: 3.5 mm Exit: 0.20 mm Speed: 183 – 368 m/min. Min. exit thickness of material M70-A: 0.04 mm Last pass from 0.12 to 0.04 mm Qty. 1 Second-hand roll grinder Mfc.: Landis Type: L-28A Roll dia.: 40-100 mm Roll length: up to 1500 mm Qty. 15 Containers

Qty. 1 Second-hand aluminium strip production plant Entry Material: Aluminium Scrap – HD666, AA5050, 2.5-3.0% Mg Final product: Aluminium strip (can stock) Width: 220 mm Thickness: 0.15 – 1.0 mm Mfc.: De Winter, Thermcon, Fata Hunter, Fröhling, Nederman, Burghardt & Schmidt, Siemens Built: 1984, 1999, 2000, 2002, 2014, 2015 Scope of supply: Melting Furnace Tilting Casting Furnace Block Caster 5 Stand Hot Rolling Mill 6 Stand Cold Rolling Mill Hot Gas Filter Slitter Welding Machine Treatment Furnace Quenching Unit Shear

Qty. 1 Second-hand strip rolling mill Mfc.: United Engineering Type: 4-Hi Built: Strip Width: 393 mm (15.5”) Thickness Entry: 4 mm (0.16”) Exit: 1.2 mm (0.05”) Mill Speed: 405 m/min. (1330 Fpm) Strip Tension: 2670 kg (5875 Lbs) Coil ID 406 mm (16”) Coil OD 1448 mm (57”) Coil weight: 3180 kg (7000 lbs)

material width: 300 mm material thickness: 2,0 mm : max. 90° Grad weight: 12 Kg dimensions: 400 x 250 x 100 m Combined sheet metal working machine with: - Bending, tool widths 25 - 50 - 75 - 75 - 105 mm. - Rolls, roll diameter 38 mm - scissors, max. 1015 x 1mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

guillotine shears AG TS 2 Working thickness 2mm Adjustable stop Hold Length 1.80 m Width 1 m Height 1.40 m Weight 300 kg

Hydraulic Shear HACO HS 3010 Capacity: 3000 x 10 mm Back gear gauge travel: 1000 mm Year of construction: 1983 Manual adjustment of the clearance between blades Cutting angle: 1° to 3° Voltage: 380 V Dimensions (L x W x H): 4000 x 2100 x 2200 mm Weight: approx 8 T

LASER PRIMA INDUSTRIE Mod. 2D/3D DOMINO Year 2006 1500x3000 2.5 kw 22,000 working hours Visible in operation No loading and unloading

Mechanical Shear BOMBLED type 9G Capacity: 2500 mm x 4 mm Manual Back gear gauge travel: 500 mm Supplied with 2 front length stops Voltage: 380 V Dimensions (L x W x H): 4000 x 1500 x 1500 mm Weight: approx 4,5 T

Sheet metal processing system P 315 / 1991 105327 Ai P4-1812+HPT 2015 + R51 272/ 1991 S4.30 / 1998 Find more here - / Contact us at -

55 ton multi station

Auction-ID: A1-40976-10

Auction-ID: A1-40976-11

Manufacturer: Bystronic Model: BLT 4000 Year of Manufacture: 2001 Type of Machine : C02 Laser Find more here - / Contact us at -

Inv. Num. : 8739 Type: TS 3006 Producer: HACO Created: 2004 Parameters: Maximum cutting length: 3000 mm Maximum cutting thickness: 6 mm

Inv. Num. : 8740 Type: VR 13-31 Producer: EHT Generated: Parameters: Maximum cutting length: 3100 mm Maximum cutting thickness: 13 mm

Manufacturer: SATO Model: DHDS 3100 Year of Manufacture: 2017 Estimated operating hours: 16,000 hours - Plasma cutting system with table and extraction system. - Cutting area: 2 x 6 meters. - Equipped with plasma unit and 2 oxy-fuel torches. Find more here - / Contact us at -

Manufacturer: Amada Model: LST 3015-M2 Year of Manufacture: 2011 Power Required: 4 kVA Noise Level: 70 dB(A) Weight: 1950 kg Operating Hours: 30,000 hours Pallet Capacity: - Maximum sheet size: 3050 x 1525 x 25 mm - Maximum load: 920 kg Amada 4 kW laser cutting system including shuttle table and extraction system. Operated in single-shift production, no maintenance backlog. Find more here - / Contact us at -

00905 Designation of the scissors system Manufacturer: Finnpower Model SG6 12.13 Year of construction 2008 Operating hours: (as of Feb 2026) 42,340 h Power on time 6462131min Running time 2540410min Alarm time 2187771min Control Finnpower ICP1 Machine weight 28,000 kg Punching force 300 kN Cutting force 250 kN Max. operating pressure 300 bar Note: Tapping unit without function The SG6 turbine is currently connected to an LP6 Finnpower plant. The SG6 is converted into a stand-alone machine. So that the SG6 can also work independently on its own. The SG6 scissors are also currently connected to a Night Train storage system together with the LP6. (the LP6 layout and Night Train storage system will be dismantled on March 30, 2026) SG6 12 13 3 x 400 V 50 Hz 3 x 80 A Lcu 25 kA Condition Good condition Dismantling March 30, 2026

older Gebr. Lever shears on base frame Technical data Knife length 500 mm Cutting range approx. 3-4 mm Dimensions 800 x 170 x 1300 mm dto. incl. base frame 1300 x 600 x 1780 mm Remarks / Accessories: Underframe, small damage to the knife Maschinenladen Oeben GmbH Krahnendonk 116 D-41066 Mönchengladbach Phone: + 49 2161 662701 maschinenladen.de InfoMachine Shop

Manufacturer: Durma Model: MS 2003 Type: Guillotine shear Year of Manufacture: 2014 Find more here - / Contact us at -

Auction-ID: A1-41998-12

500m^2 , thickness of 0.75

Angular table for lid milling machine Clamping flat 900x530mm 8 St T-hooks Never used

In 2020, the machine was extensively overhauled for 7000 €. Proof available. Processes: - Chamfering 60° - Longitudinal turning up to a maximum of 40 mm - Centering drilling Workflow fully automatic: - Tensioning, feeding to - Rapid traverse forward - Work feed - Dwell time for cutting - Rapid traverse back - Relax, feed on Specifications: workpiece diameter approx. 80 mm workpiece diameter 6kt-SW 70 mm min. workpiece diameter round and 6kt 10 mm min. workpiece length 450 mm Speed range infinitely variable Level I/Stage II = 51-306/102-612 Electrical equipment 220/380 V, 50 Hz Motor power main motor kW 1.3/1.8 Engine power Coolant motor kW 0.07 Required air pressure 6-8 bar Weight approx. 520 kg Dimensions: L 1520 mm x W 610 mm x H 1350 mm Roller conveyor

BIHLER GRM100 multislide punching and forming machine, Made in Germany. Machine re-engineered in year 2010 originally by Bihler, updated with servo motor, pump, rewired, new control, etc. Equipped with 4x forming slides and 18 ton press station. Gripper feed on right-hand side with straightener. Max width of strip 100 mm. Max wire diameter 10 mm. Standard feed length 250 mm max. Max operating speed 135 strokes per minute approx. Servo motor. Touch screen control. Air clutch. Weight cca. 6000 kg. Power supply 400/480V, 50 Hz. On stock more Bruderer, Schaal, and Mabu high speed presses. Also Ideal flash butt welding machines.

Prepared for CNC control Siemens 840 DSL Precision turntable make EIMELDINGEN with aerostatic axial bearings Specifications Table diameter 5,600 mm Total height approx. 1,230 mm Centering bore Ø 250H7X 25 mm Permissible transport load 30,000 kg Holding torque of the table clamping 2,400 daNm Table speed 0.002 – 2 min Net weight approx. 30,000 kg Operating voltage 380 V, 50 Hz. 3 phases Control voltage 24V Positioning accuracy (without control errors) ± 1" Plan accuracy 0.02 mm Axial running accuracy 0.01 mm Concentricity deviation of the centering bore 0.01 mm Resolution of the displacement measuring systems 0.0001°

Work platform, platform TALL ESCOPE No. 512 Load capacity: 115 kg Platform height: 2900 - 4400 mm Dimensions: 3600 x 1000 x 2000 mm Weight: 92 kg used, tested !

Machine is in good technical condition, a visit and a test run are possible by prior arrangement.

Schroeder & Bauer WB 32-1 Universal Wire and Strip Bending Machine Wire feeder Plain text display Compression Force Monitoring Wire straightener Bosch Stripping Devices Bracket and brush motor with mounted tool W32/1-32 Soundproof booth Fäßerb CU wire with stamped parts Switchboard Item condition: very good Description of the manufacturer, deviations possible. You purchase the machine as shown in the pictures. Complete plant closure, large selection of mezzanines, pallet racks, shelving racks, paternosters. High Quality Industrial Machinery, Lathes, Grinding Machines, Hand Machinery Suppliers in China More items - new and used - can be found in our shop! International shipping costs on request!

- Hersteller: HURCO - Model/Typ.: BMC4020HT/M - Baujahr: 1997 - MFG.No.: 029 Verfahrwege: - X-Achse: ~ 1020 mm - Y-Achse: ~ 510 mm - Z-Achse: ~ 610 mm - Steuerung: Ultimax 3 Hauptspindel: - Hauptspindel: max. Drehzahl 8.000 U/min - Hauptspindel Leistung: 15 kW - Werkzeugaufnahme: SK 40 Arbeitstisch: - Tischaufmaße 1220 x 510 mm - max. Tischbelastung ca. 700 kg - Werkzeugwechsler: - Anzahl der Werkzeugplätze 24 Stück - max. Werkzeugdurchmesser 100mm - max. Werkzeuglänge 300mm - max. Werkstückhöhe 250mm (bei einer Werkzeuglänge von 300mm) - max. Werkzeuggewicht 7,0 kg - Maschinengewicht ca. 5,6 to - Standort: demontiert, am Lager D-32825 Blomberg

Fully automatic sheet dispenser PAL-Cut 800 The Palcut 800 cuts paper quickly and precisely into intermediate sheets of the desired length, directly from the roll. Fully automatic sheeter PAL-Cut 800 sheet dispenser, which cuts intermediate layers quickly and precisely in the desired length. The sheet dispenser is suitable for continuous operation in an automatic palletizing system and for companies with high sheet consumption. The Palcut 800 works with rollers of max. 800 mm width. Type designation: PAL-Cut 800 Length: 1853 mm Width: 1380 Height: 1739 for roll width up to: 800 mm Mounting height: 1,368 mm Working speed: 480 pcs/h Power connection: 220 V, 0.18 kW Operating mode: fully automatic Weight: 370 kg Link PAL-Cut 800 More items - new and used - can be found in our shop! International shipping costs on request!

specifications: Max sheet width 3,000 mm Max sheet thickness at max yield strength 240 N/mm2 when bending to max. sheet width 35 mm when rounding Bend length 2.2 x S Max passage between rollers 145 mm Roller diameter upper roller 552 mm Underroller 532.4 mm Side rollers 400 mm Number of rollers 4 Powered rollers 2 top and bottom roller Drive of the rollers hydraulically Arrangement of the rollers symmetrically Rotation speed of the rollers 2-4 m/min Adjustable rollers 3 Type of adjustment of the rollers hydraulically Adjustment speed lower roller 0-200 mm/min. Side rollers 0-700 mm/min. Brake of the rollers pneumatic Actuation of the folding bearing hydraulically Operating voltage 3 x 380 V / 50 Hz Display device of the roll positions 4 x optical/analog Weight of the machine approx. 42 to Area 2.71 x 6.4 m Height 3.12 m

Year 1996, CE norm, complete instructions, control Delem, machine in TOP condition with warranty, more details on request

Key data: 300 , 4

Bandwidth - up to 460 mm Band thickness - 0,5-4 mm Motor drive - 6 kW together with Reel 1.5 T - non-powered

MAX 20 X 1600

Sheet thickness aluminium: 1.00 mm Due to the bevel cut, the X-Cut machine can not only cut straight strips in the longitudinal and transverse directions, the automated bevel cut opens up many new possibilities for cutting the different surfaces quickly and accurately. Saves up to 90% of the time Up to 60 degrees angle adjustment in both directions Intuitive operation thanks to touchscreen and calculation aids Thanks to optimized software, cutting trapezoidal surfaces, triangular surfaces and other surfaces for standing seam roofs and wall cladding is no problem Due to the fully automated bevel cutting and the versatility and accuracy of the software, a high level of time savings can be achieved during production in the company and also during installation on the construction site Automatic operation: Enter the desired length and the number of pieces to be cut automatically. Tota ...

Capacity , ton: 800 Stroke, mm: 320 Strokes/min: 20 Shut height, mm: 900 Bed to ram adjustment stroke, mm: 320 Bed dimensions, mm: 2500x1600 Main drive motor power, kW: 75 Overall dimensions, mm: 4220x3500x8356 Weight, ton: 96,6

Beam claw, sheet metal clamp, sheet metal claw, beam clamp, sheet metal gripper, material gripper, material gripper, profile steel gripper, plate gripper -Sheet metal clamp: clamping range up to 85 mm -Load capacity: kg -Dimensions: 300/80 / H330 mm -Weight: 13 kg

Beam claw, sheet metal clamp, sheet metal claw, beam clamp, sheet metal gripper, material gripper, material gripper, profile steel gripper, plate gripper -Sheet metal claw: clamping range up to 30 mm -Load capacity: kg -Dimensions: 250/100 / H460 mm -Weight: 20 kg

Hydraulic mobile tin hole punch for e.g. control cabinet construction and control construction Manufacturer Alfra Type SKP-1 Punches holes of max 140mm diameter in 3mm sheet metal Round, square and rectangular stamps possible. Punch punch punch tin punch drill tin hole drill monocut gap-plate-hole, hand hydraulics, ball bearing screw, Klauke Alfra Special price

Beam claw, sheet metal clamp, sheet metal claw, beam clamp, sheet metal gripper, material gripper, material gripper, profile steel gripper, plate gripper -Sheet metal claw: clamping range up to 35 mm -Load capacity: 4 t -Dimensions: 230/110 / H450 mm -Weight: 22 kg

NC - controlled mechanical sheet metal panel scissors in backdrop cutting design, maximum cutting length 1,050 mm, maximum cutting capacity 4 mm steel sheet/ST40, cutting angle 1.5°, NC - controlled rear stop with 1,000 mm travel range - automatic removal of the stop rail at sections lower than 1,000 mm - optionally available with a foldable sheet support at the rear stop or a conveyor belt with upliftrs, drive power 5 kW, weight approx. 2,500 kg
