pfauter milling machines used for sale

Gear Hobbing Machine Pfauter P 400 With interchangeable wheels

Gear hobbing machine horizontal Pfauter P160 With accessories

The machine is in good technical condition, testing is possible by prior arrangement.

power capacity: 0 kW tool adaptor: 0 total power requirement: 0 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Three milling heads for different machines of the brand Pfauter-Gleason are available. 1) Milling head for Gleason Genesis 130H. 2) Milling head for Pfauter P200, without counter bearing. 3) Milling head for Pfauter PE250. An on-site inspection is possible.

Generating Grinding Machine Grinding Machine Gleason Pfauter G320 CNC + Promot Automation Hersteller [manufacturer]: Gleason Pfauter G320 + with Promot Automation handling unit Type [ type]: G 320 Control unit: Siemens 840 Incl. control panel Baujahr[construction year]: 10/2001 Module [ ]: 0.5-7.0 Min. workpiece diameter [ ]: 10 mm Max. workpiece diameter [ ]: 380 mm Number of teeth [ ]: 10-600 Vertical carriage stroke "Z" [ ]: 200mm Horizontal carriage stroke "X" [ ]: 230mm Tangential carriage stroke (SHIFTING) "Y" [ ]: 135mm Swivel angle clamping head "A" [ ]: +-45° Tailstock tip stroke [ ]: 125mm tangential slide stroke – dressing [ ]: "V" 180mm radial carriage stroke – dressing [ ]: "U" 110mm Rotation speed – grinding wheel in progress [ ]: 3000rpm max - infinitely variable Egg speed - linear axes [ ]: 10000 mm/min Max. table rotation speed [ ]: 240 RP ...

Gear hobbing machine PFAUTER 1200mm, modul 12, with change gears

Gear hobbing machine vertical Pfauter P251 With accessories

Pfauter RS 2 With accessories

max. wheel diameter: 3000 mm gear width: 1200 mm max. module: 30/40 min. module: 2 table diameter: 2500 mm table load capacity: 400 kN hob dia. - max.: 450 x 500 mm milling spindle speeds: 10 - 165 U/min hob length max.: 500 mm tip circle diameter: 2050 mm tooth helical angle min/max: 0 - 45 ° center distance betw. workpiece-tool min/max.: 150 - 1750 mm milling slide swivelling: 50 Grad distance table / counter stay: 1050 - 2050 mm shifting: 300 mm workpiece weight: 40 t table bore diameter: 800 mm depth of hole: 1100 mm main drive motor: 37 kW min. workpiece diameter: 290 mm min. number of teeth: Wälzfräsen 20 min. number of teeth: Formfräsen 2 taper: MK 100 feeds axial: 1 - 1800 mm/min radial feed: 1 - 500 mm/min feed: Tangential 1 - 450 mm/min rapid traverse: 1875 / 530 / 470 mm/min electrics - voltage/frequency: 380 / 50 V/Hz control: Siemens Sinumerik 3M total power requirement: ...

amount: 36 STK. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter:300 mm gear width:110 mm max. module:6 weight of the machine ca.:10,5 t

Infeed and outfeed chain conveyor, with tool holders, chip conveyor, hydraulic unit and air conditioning.

max. wheel diameter:180 mm gear width: mm max. module:4 total power requirement:14 kW weight of the machine ca.:8 t slide travel axial ( Z-axis ):300 mm work piece - max.:490-640 mm

max. wheel diameter:275 mm gear width:58 mm max. module:8 min. module:0,5 weight of the machine ca.:10 t max. number of teeth:200 min. number of teeth:5

max. wheel diameter: 630 mm gear width: 375 mm max. module: 10 clamping table: 550 mm table hole: 125 mm milling spindle speeds infinitely variable: 62 - 390 U/min taper: MORSE 5 axial-feeds: 0,40 - 6,80 mm/U radial feeds: 0,10 - 1,76 mm/U dist. cutter spindle - workpiece spindle: 50 - 425 mm no. of teeth: min. 8 milling cutter dia. x width: 192 / 215 mm shifting: 200 mm main drive motor: 7,5 kW total power requirement: 21 kVa weight of the machine ca.: 8,2 t Main features: -Universal hob head with tangential movement -Automatic shifting -Automatic dwell attachment -Hydraulic clamping in table -Pressure reduce valve for outer steady -Magnetic swarf conveyor Accessory: 1 set of tools for operating and maintenance 1 set differential gears, module 1,75 1 set indexing change gears module 2,5 1 change gear cabinet The data for this ad was created with ModulMWS - the software solution of Lo ...

max. wheel diameter: 130 mm gear width: 25 mm max. module: 4 min. module: 0,5 Control: Siemens 840 D strokes - infinitely variable: 500-2500 Hub/min stroke: 30 mm work-spindle diameter: 85 mm total power requirement: 49 kW weight of the machine ca.: 11,5 t dimensions of the machine ca.: 6,4x4,5x4,4 m Counterhold without center hydraulically operated counter arm and Linear guides. For automatic ring loader, with 4 stations The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 4400 mm gear width: 645 mm max. module: 35 Control: Siemens main drive motor: 37 kW table diameter: 2500 mm max.helical angle: +/- 30 ° workpiece weight: 40000 kg total power requirement: 142 kVA weight of the machine ca.: 75 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 150 mm gear width: mm max. module: 4 min. module: control: Sinumerik 840 D table diameter: 140 mm maximum axial offset: 200 mm milling tool taper: ISO 40 diameter of hob: max. 130 mm cutter length max.: 220 mm milling spindle speeds (infinitely variable): 300 - 1200 U/min shifting: max. 170 mm milling head -swivable +/-: 45 ° feed speeds: 1 - 1500 mm/min rapid travel speed: 3000 m/min workpiece magazin: Stück max. workpiece diameter: im Magazin: 150 mm total power requirement: 50 kW weight of the machine ca.: 8,5 t dimensions of the machine ca.: 4,7 x 3,6 x 2,6 m Condition: ready for operation: Video(s) available on our website.: Electric 400 Volt: Used gear hobbing machine, Pfauter, completely overhauled in 2023 by the specialist company SerWeMa. There is another identical machine available, but the spindle needs to be overhauled. If you are interested, you ca ...

max. wheel diameter: 160,175 mm gear width: 355 mm max. module: 4,5 spindle bore: 75 mm centre distance: 410 mm min. number of teeth: 2, 3 cutter diameter max.: 115 mm cutter length max.: 105 mm axis distance between cutter and workpiece - max.: 138 mm axis distance between cutter and workpiece - min.: 30 mm milling head -swivable: 120 ° milling spindle speeds: 70 - 400 U/min axial-feeds: 0,25 - 4,0 mm/U radial feeds: 0,09 - 1,5 mm/U total power requirement: ca. 9,5 kW weight of the machine ca.: 3,5 t dimensions of the machine ca.: 1730x1400x1440 mm Equipment/accessories: - Interchangeable wheels - Milling arbors - Clamping devices - Documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Max. Pitch circle diameter External gearing: 300 mm Max. Pitch circle diameter internal gearing: 300 mm Max. Outer diameter of workpiece (equipment): 450 mm max. module: 6 gear hobbing width -max.: 100 mm Max. Helix angle (with tool Ø 125 mm): +/- 45 ° strokes - infinitely variable: 130 - 1300 Hub/min workpiece weight: 1000 kg Minimum distance table top - tool spindle: -55 / +300 mm Maximum distance table top - tool spindle: 200 mm Maximum distance table top - tool spindle: 350 mm Manual Upright side shift: +/- 25 mm Manual swivelling angle of the tool spindle: +/- 0,5 ° Max. Tool speed: 15 UpM Max. Workpiece speed: 27 UpM Max. Tool diameter: 7 Zoll voltage: 400 V frequency: 50 Hz Max. Line power: 70 A total power requirement: 48 kW weight of the machine ca.: 11 t dimensions of the machine ca.: 4,27 x 3,11 x 2,87 m control: Siemens Sinumerik 840 C table hole: 40 mm taper in main spind ...

max. machining diameter: 3200 mm max. workpiecediameter: 3200 mm axial slide way: 2200 mm control: Siemens Sinumerik 840 D table diameter: 2500 mm boring diameter: 800 mm max. load: 40.000 kg table rotation speed: 2 U/min grinding head: grinding head - swivable: +45 / - 45 ° turning speed range - grinding wheel: 270 - 2700 U/min tip circle diameter: min. 1500 mm grinding spindel dia.: 100 mm Max. grinding wheel diameter: 450 mm Dressing diameter: min. 250 mm Planing width: min. 80 mm Fast feed speed: axial: 10 m/min Fast feed speed: radial: 3 m/min max. depth of profile: 100 mm tail stock: tailstock travel: 1410 mm total power requirement: 225 kVA weight of the machine ca.: 46 t dimensions of the machine ca.: 14,5 x 9,95 x 6,1 m Gear Profil-Grinding Machine - CNC Control Siemens 840D - Tailstock - Dressing Unit - Oil Mist suction - Coolant The data for this ad was created with Modul ...

max. wheel diameter: 100 mm gear width: 26 mm max. module: 31 min. module: 0,1 Control: Siemens 840 D SL total power requirement: 45 kW weight of the machine ca.: 7 t dimensions of the machine ca.: 4x3x2,5 m Gleason 100S gear shaping machine for the production of internally and externally toothed cylindrical gears and other cylindrical workpiece circumference regularly occurring profiles and moulds as well as for the production of profiles using the single part process. Technical data: Nominal workpiece diameter 100 mm Largest circumferential diameter 150 mm Machine nominal module approx. 3 mm (Guide value depending on the respective machining task.) Shaping spindle stroke speed range 0 - 3,000 1/min Stroke position adjustment range (manual) 20 mm Largest toothing width 26 mm Smallest pitch height of the hydrostatic inclined guide 400 mm Smallest/largest distance between tool axis - 20/+ ...

A Pfauter vertical CNC gear hobbing machine is available. Modules min./max.: 1/3, max. workpiece diameter: 150mm, max. tooth width: 150mm, milling head tilt: +/-45°, milling cutter axis-table axis distance: 10mm-160mm, table diameter: 160mm, table bore: 63mm. Tool holder: SK40, max. cutter diameter: 130mm, max. cutter length: 220mm, speed: 600rpm, feed: 1500mm/min, tangential path: 170mm, rapid traverse: 3m/min. Machine dimensions X/Y/Z: approx. 4000mm/3000mm/2500mm, weight: approx. 6500kg. On-site inspection is possible.

Diameter: 0 mm Width: 0 mm Bore: mm Tangential head for gear hobber RS 2 - also available: Tangential head for gear hobber RS 00 ! The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 350 mm gear width: 350 mm max. module: 8 min. module: total power requirement: 7,5 - 22 kW weight of the machine ca.: t dimensions of the machine ca.: m Gear hobber with gear shaping device, 2-cut cycle The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 900 mm gear width: 500 mm max. module: 1 min. module: 10 total power requirement: 16 kW weight of the machine ca.: 8.500 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 330 mm gear width: - mm max. module: 7 min. module: 0,5 Control: Siemens 840 C total power requirement: 72 kVA weight of the machine ca.: 11,7 t dimensions of the machine ca.: m We offer a Pfauter model G 320 gear grinding machine for sale numerical control on 8 axes for the machining of gears with straight and helical toothing, with rolled profile for enveloping cuts, the one Worm profile disc used. Technical specifications: CNC control Siemens 840 C Controlled axes: X Radial axis Y Tangential Shift Z Vertical axis A Workhead rotation B Worm rotation during processing C Table rotation U Radial axis dresser V Tangential axis dresser Module 0.5 – 7.0 Minimum workpiece diameter 10 mm Maximum workpiece diameter 330 mm Number of teeth 10 - 600 Vertical carriage thrust Z 200 mm Horizontal grinding wheel - carriage stroke X 230 mm Tangential slide stroke Y 135 mm Angle o ...

max. wheel diameter: 2800 mm gear width: - mm max. module: 20/30 min. module: Control: Siemens 840 D total power requirement: 40 kW weight of the machine ca.: 50 t The machine has only a few working hours and is like new. With internal milling head. Note: If you require an external milling head, we can offer it separately. - The price of the new machine of this caliber is 2.3 million Euro. - With minimal operating hours, the machine is essentially new. - It is one of Gleasons largest machines - It has the possibility of dry or wet milling, and internal and external gearing. - The machine underwent a comprehensive manufacturers inspection in July 2023 and is in impeccable working order. - Machine is currently partially assembled to allow potential buyers to verify all functionalities. If you wish to see the machine in operation, we have two identical machines running in our produc ...

max. wheel diameter: --- mm gear width: --- mm max. module: --- min. module: --- total power requirement: --- kW weight of the machine ca.: --- t dimensions of the machine ca.: --- m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 900 mm y-travel: 300 mm z-travel: 1000 mm control: Siemens Sinumerik 840D max. workpiece diameter: 1600 mm max. module: 20 mm tip circle diameter: 350 mm Milling arbour diameter: 375 mm Total closing value: 80 kVa weight of the machine ca.: 33,5 t dimensions of the machine ca.: 10,530 x 6,375 x 4,680 m Feed rate: - X-axis 1 to 3000 mm/min - Y-axis 1 to 3000 mm/min - Z-axis 1 to 4000 mm/min Spindle speeds in rpm: - Tool 26 to 265 - Workpiece table 0 to 8 Equipment/accessories: - M 2 motor milling head - Milling mandrels - Oil cooler - Technical documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

workpiece diameter nominal: 2400 mm max. workpiece diameter: 2800 mm max. module: 30 mm control: Siemens Sinumerik 840 D dividing plate diameter: 2200 mm table diameter: 2500 mm Table hole Diameter / depth: 800 / 875 mm max. table load: 40000 kg Table rpm: 4,5 min-1 clamping length max.: 375 mm clamping diameter max.: 350 mm cutter diameter max.: 2800 mm Cutter arbor cone: HSK-B160 swivelling range milling head: + 30/-45° Distance Cutter - Workpiece: 615 / 1600 mm weight of the machine ca.: 57 t Slide drives: - Feed & rapid traverse speed: - axial 4000 mm/min - radial 3000 mm/min - tangential 3000 mm/min Equitment/Accessories: - IFK2 internal milling head - Milling arbor with spacers - chip conveyor - Oil mist extraction - technical Documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Wheel diameter: 160mm, max. wheel width: 355mm, module range: 0.5-4.5, max. cutter diameter: 115mm, max. cutter length: 105mm, cutter head swivel range: 120°, speed: 400rpm, distance between centers: 410mm. Machine dimensions X/Y/Z: approx. 2000mm/1500mm/2000mm, weight: approx. 3500kg. An on-site inspection is possible.

max. wheel diameter: 250 mm gear width: 242 mm max. module: 4 min. module: 0,5 table diameter: 250 mm table bore diameter: 68 mm milling cutter dia. x width: 130 x 130 mm spindle stroke - max.: 110 mm min. number of teeth: 6 center distance betw. workpiece-tool min/max.: 10 - 210 mm milling spindle speeds (infinitely variable): 80 - 500 U/min feeds axial: 0,32 - 4 mm/WU radial feed: 0,05 - 1,6 mm/WU feeds - tangential: 0,16 - 2 mm/WU Control: LAUER PCS table diameter: 250 mm table hole: 62 mm milling cutter dia. x width: 130 x 130 mm total power requirement: 16 kVa weight of the machine ca.: 3,6 t dimensions of the machine ca.: 2,8 x 2,4 x 1,9 m Machine ideal for electrical retrofitting Equipped with: - LAUER PCS NC control - Siemens Simatic S5 PLC - Loading device/magazine for workpiece size max. 140 mm Ø - Shifting - 2-cut cycle The data for this ad was created with ModulMWS - the s ...

Control: SIEMENS table surface area: 160 mm weight of the machine ca.: 10 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: mm gear width: mm max. module: 0 min. module: 0 total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: mm gear width: mm max. module: 0 min. module: 0 total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cone distance min./max.: 0-108 mm Pitch angle min/max: 5°/84° Control: GE Fanuc Series 0-GC Pitch diameter (1:1 ratio): 152 mm pitch diameter (10:1 ratio): 216 mm Diametral pitch (finest/coarsest): 1.3/8.5 Mod. Face width gear wheel max.: 35 mm Knife spindle - Speed range: 41-121 U/min working spindle speed range: 0-33.33 U/min weight: 9025 kg dimensions of the machine ca.: 2707 x 2720 x 2200 mmxmmxmm Equipment/accessories: -Knife -Chip conveyor -Technical documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

PFAUTER RS 00 - Gear hobbing machine -Max. wheel diameter 250mm -Max. tooth width 160mm -Max. module 2.5 - 3mm -Approx. 65 change wheels + built-in change wheels in the machine - Table diameter approx. 200mm -Milling cutter speeds 200 - 1200 rpm -Digital display -Tangential milling device -Interchangeable wheels -Documentation -Machine enclosure Dimensions: LxWxH 1.6x1x1.7 meters / Weight 1800 kg

This 5-axis Gleason PFAUTER G320 CNC + Promot Automation was manufactured in 2001. It features a Siemens 840 control unit, a maximum workpiece diameter of 380 mm, and a module range of 0.5-7.0. The system includes Promot Automation handling, a robotics system, and a cooling belt system. If you are looking to get high-quality gear grinding capabilities consider the Gleason PFAUTER G320 CNC machine we have for sale. Contact us for more information about this machine.

max. wheel diameter: 160 mm gear width: 355 mm max. module: 4,5 min. module: 0,5 centre distance: 450 mm total power requirement: 11 kW weight of the machine ca.: 3,8 t dimensions of the machine ca.: 2x17,1,6 m Wheel diameter - max. 160.175 mm Wheel width 355 mm Module - max. 4.5 Spindle bore 75 mm Center distance 410 mm Number of teeth - min. 2, 3 Cutter diameter max. 115 mm Cutter length max. 105 mm Center distance between milling cutter and workpiece - max. 138 mm Center distance between milling cutter and workpiece - min. 30 mm Milling head - swivels 120 ° Milling cutter speeds 70 - 400 rpm Axial feeds 0.25 - 4.0 mm/rev Radial feeds 0.09 - 1.5 mm/rev Total power requirement approx. 9.5 kW Machine weight approx. 3.5 t Space requirement approx. 1730x1400x1440 mm Equipment/accessories: - Changing wheels - milling arbors - Clamping device Dra8M7 - documentation The data for this ad wa ...

max. wheel diameter:200 mm gear width:250 mm max. module:3 min. module:0,5 total power requirement:45 kW weight of the machine ca.:8,5 t dimensions of the machine ca.:4,4 x 2,4 x 2,7 m Machine out of prototype production Without automation

max. wheel diameter:130 mm gear width:170 mm max. module:3 min. module:0,5 total power requirement:48 kVA weight of the machine ca.:9 t dimensions of the machine ca.:7,64 x 3,14 x 3,25 m For technical data, see PDF-File enclosed

max. wheel diameter: mm gear width: mm weight of the machine ca.:7000 kg dimensions of the machine ca.:9130 x 3895 x 3450 mm max. top circle diameter:80 mm max. length of teeth cutting:170 mm Total length:240 mm taper diameter:32 mm slide travel radial ( X-axis ):100 mm slide travel tangential ( Y-axis ):160 mm axial movement Z-axis:300 mm/min workpiece spindle - bore:45 mm electr. connected load:44 kVA

max. wheel diameter:200 mm gear width:50 mm max. module:6 table diameter:168,14 mm boring diameter:65,532 mm weight of the machine ca.:11 t table turning speeds:0-1.000 U/min length of stroke min./max.:0-70 mm no. of strokes:180-1.800 Stück This machine can be used to make tandler gears. However, for helical gearing, a helical guide is also required.

max. wheel diameter:80/120 mm max. module:2,5 max. top circle diameter:65 mm :22 mm :140 mm :120 mm slide travel axial ( Z-axis ):320/400 mm Dimensions (L/W/H):3270 x 3240 x 2020 mm weight of the machine ca.:6 t P60 - The compact all-rounder for wheels, shafts and worms The P60 is the smallest machine in the Gleason line of horizontal hobbing machines. The all-rounder not only mills spur gears with all rollable profiles, but is also the optimal solution for machining steering pinions and worms. with automatic loading system, extraction unit, chip conveyor, with balancing device with 2 tailstocks, with Artec process monitoring system, type CTM-BT1.1

Usable for the: Milling and engraving labeling, marking Drilling, cutting Dosing and much more. (Applications require optional accessories) inclusive: Design software ConstruCAM 3D Control software KinetiC-NC incl. CAM software Estlcam Multi-zone vacuum table with recessed T-nuts sliding Control panel including step control manual central lubrication The offer here is a CNC milling machine with the above-mentioned accessories (without further ado possibly shown on the photos accessories). For operation, a milling motor is also required, which can optionally be purchased from us. echnische data: External dimensions LxWxH: 1650x1440x1950 mm Weight: approx. 650 kg Clamping surface XxY: 930x630 mm Travel XxYxZ: 900x600x200 mm (optional 300/400 mm in Z-axis) Width linear guides X,Y,Z: 20 mm Repeatability: 0.01 mm Reverse play: appr ...

Work facilitation through basic equipment The basic equipment includes, for example, an ergonomic control panel, which contains the stepper motor control and an industrial PC with touch function. Software (CAD/CAM, control software, operating system Win 10 Pro) are already pre-installed. Thus, the CNC milling machine can be operated conveniently and conveniently. A multi-zone vacuum table ensures a comfortable, fast clamping of workpieces and a strong hold during milling. Furthermore, the machine is equipped with a manual central lubrication, which makes it easier for you to grease and increases the service life of the CNC milling machine. Various applications The most diverse materials can be processed on our T-Rex, whether plastic, wood, metal or stone, nothing is impossible. Whether engraving, milling, cutting, drilling, dosing, gluing, etc., no wishes remain unfulfille ...

Work facilitation through basic equipment The basic equipment includes, for example, an ergonomic control panel, which contains the stepper motor control and an industrial PC with touch function. Software (CAD/CAM, control software, operating system Win 10 Pro) are already pre-installed. Thus, the CNC milling machine can be operated conveniently and conveniently. A multi-zone vacuum table ensures a comfortable, fast clamping of workpieces and a strong hold during milling. Furthermore, the machine is equipped with a manual central lubrication, which makes it easier for you to grease and increases the service life of the CNC milling machine. Various applications The most diverse materials can be processed on our T-Rex, whether plastic, wood, metal or stone, nothing is impossible. Whether engraving, milling, cutting, drilling, dosing, gluing, etc., no wishes remain unfulfille ...

Usable for the: Milling and engraving labeling, marking Drilling, cutting Dosing and much more. (Applications require optional accessories) inclusive: Design software ConstruCAM 3D Control software KinetiC-NC incl. CAM software Estlcam Multi-zone vacuum table with recessed T-nuts sliding Control panel including step control manual central lubrication The offer here is a CNC milling machine with the above-mentioned accessories (without further ado possibly shown on the photos accessories). For operation, a milling motor is also required, which can optionally be purchased from us. Technical specifications: External dimensions LxWxH: 1970x2150x1950 mm Weight: approx. 950 kg Clamping surface XxY: 1230x1320 mm Travel XxYxZ: 1200x1300x200 mm (optional 300/400 mm in Z-axis) Width linear guides X,Y,Z: 20 mm Repeatability: 0.01 mm Reve ...

Milling holders with milling cutters and drills mostly SK40, total 25 parts

End mill, end mill, cutter, shell cutter, milling head, angle cutter, shell angle cutter, angle end mill, prism cutter -Angle milling cutters: Attachment angle milling cutters, prism milling cutters -Type: Ø85 x 35 mm -Hole: Ø 27 mm -Quantity: 1x milling cutter available -Dimensions: Ø 85 x 35 mm -Weight: 0.8 kg

Operating voltage: 400 v Ma.Nr.: 41636 HEIDENHAIN positioning and control TNC 131 / 135 Complete Dokunnetation (operating instructions, technical plans) exists. Errors excepted!

Table clamping surface: 600 x 1100 mm traverse path x: 800 mm traverse path y: 450 mm traverse path z: 500 mm Quill stroke: by hand approximately 50 mm of spindle speeds: 63-3150 rpm stufenl feeds. adjustable: 0,1-1500 mm / min rapid traverse: x/y/z 4.5/2,6/3 m / min. Supply: 380 V, 5.5 kW space: 3000 x 2500 x 2030 mm weight: 4000 kg

Table size: 500 x 1200 mm traverse path x: 1000 mm stroke y: 550 mm traverse path z: 600 mm spindle retainer: ISO 40 spindle speeds: 60-2700 rpm spindle drive: 10 kW Electr. Supply: 380 V, 20 kVA kW space: 3200 x 2800 x 2650 mm weight: 7.3 t

Universal milling machine. Hure head. Table size: 2000x480mm. Longitudinal travel: 1700mm. Cross travel: 400mm. Vertical travel: 575mm. ISO50. Motor power: 20cv. Weight: 5500Kgs. Dimensions: 2550x2380x2680.

Table clamping surface: 500 x 1000 mm stroke x: 630 mm traverse path y: 500 mm traverse path z: 460 mm Quill stroke: hand 45 mm spindle retainer: ISA 40 spindle speeds: 31.5-3150 rpm stufenl feeds. adjustable: 1-3000 mm / min rapid traverse: x/y 6 / z 4 m/min. Supply: 380 V, 6/8 kW space: 1800 x 2120/2600 x 2020 mm weight: 3100 kg

Table clamping surface: 630 ø mm traverse path x: 600 mm traverse path y: 450 mm traverse path z: 500 mm Quill stroke: hand 80 mm spindle retainer: ISO 40 spindle speeds: 20-3150 rpm stufenl feeds. adjustable: 1-3000 mm / min rapid traverse rate: 4 m / min. Connection: 380V kW space: 2000 + 850 x 2000 x 2000 mm weight: 3300 kg

Stroke x: 600 mm traverse path y: 400 mm traverse path z: 400 mm spindle retainer: ISO 40 spindle speeds: 80-4000 rpm stufenl feeds. adjustable: 0,1-1500 mm / min rapid traverse: x & y/z 4/2.5 m / min. Supply: 380 V, 16 kVA kW space: 2450 x 2200 x 1900 mm weight: 2250 kg

Universal milling machine. Table size: 1400mmx300mm. Longitudinal travel: 1200mm. Cross travel: 320mm. Vertical travel: 500mm. ISO40. Hure head. Speeds: 12. (40-1800rpm). Motor power: 7Kw.

Drilling capacity in steel: 32 mm Drilling capacity in cast: 40 mm Cutter head milling max.: 80 mm Projection: 220 mm Spindle speed: (12) 75-3200 RPM Spindle retainer: MK 4 Quill stroke: 125 mm Table size: 800 x 240 mm Travel (x / y): 555 / 225 mm Milling head swiveling: - 90 ° to + 90 ° Distance from spindle / table: 60-485 mm Head height: 425 mm T - slot size: 14 mm S1 motor power output 100%: 1,1 / 1,5 kW (400 V) Motor power S6 40%: 1.5 / 2.2 kW (400 V) Machine dimensions (W x D x H) : 1140 x 770 x 1500 mm Approximate weight: 287 kg without stand Features: Quick and easy change of speed using the gear selector switch Versatile application possibilities such as drilling, milling, thread cutting, … High running smoothness by polished, running in an oil bath gear gears Right - and the link run device for thread cutting Quill adjustment by means of ...

Standard ALB ear performance: 30 mm Thread cutting performance: M 20 (option) Thread: M 12 Spindle: MK 3 or SK 30 (option) Quill stroke: 100 mm Longitudinal / cross travel: 350/160 mm Distance spindle/cross table: 80 to 450 mm Table area: 600 x 240 mm Column diameter: 110 mm Total height: Max 1,920 mm Weight: 340 kg Motor pole shift bar: 0.8/1.5 kW Spindle speeds, continuous, selectable: 10 spindle speeds: 80-1,400 rpm 10 spindle speeds: 120-2,160 rpm 10 spindle speeds: 160-2,800 RPM Facilities: A versatile, accurate and handy drilling milling machine. The quiet-running drive and a perfect clamping of Quill guarantee good surfaces when milling. The headstock can be swung out. The stage is precise and precisely adjustable. Pitch 0.05 mm. clamping device for both axes. Full motor protection. Machine incl. Cabinet.

Table clamping surface: 500 x 1600 mm table movement x: 1220 mm table movement y: 500 mm table movement z: 500 mm spindle retainer: SK 50 spindle speeds: 56-2800 rpm feeds longitudinal & cross: 10-1800 mm / min feed vertically: 2.5-450 mm / min. Supply: 400 V, 16 kVA kW space: 2000 x 2250 x 2150 mm weight: 4500 kg

Machine type milling machine - universal brand HURON type MU 5 year 1975 control type conventional storage France country of origin France delivery immediately cargo base camp, free truck Technical details x way 1300 mm y path 700 mm z-way 550 mm table size 1500 x 460 mm spindle speeds 15-2500 RPM spindle retainer for SK 40 feed range x - direction 1,6-820 mm / min feed Empire z-direction 1,6-820 mm / min rapid traverse X + Z - axes 2.8 m/min rapid traverse y - direction of 2.8 m / m in power - spindle motor 10 kW total power 14 kW machine weight approx. 4.6 t additional information good condition with 3 axis of DIGITAL HEIDENHAIN SK 40 BUILT IN 1975

Universal tool-feeding machine, used universal milling machine, used Type FU 250 x 1000/2 Fabr. WMW Auerbach Built: 1988 Table size/ table: 1130 x 255 mm Laengsmotion/ longit. move: X 690 mm Horizontal movement/ horiz. Move: Y 190 mm Vertical movement/ Vert. move : Z 360 mm Tool holder/taper: ISO 40 Spindle speeds R+L infinitely/ speeds of spindle ( left/right) 56 - 2800 rpm. Pre-shot stepless all axes X, Y and Z/ feeds all axis 10 - 630 mm/min / 250 mm/min Drive power/ load 3.8 kW Weight: 2 t Specification: Vertical head,shock head

Universal milling machine with automatic movement ram. Table size: 1600mmx320mm. Longitudinal travel: 1200mm. Cross travel: 300mm. Vertical travel: 600mm. ISO50. Hure head. Equipped with DRO Fagor.

CNC toolmill cover FP 3 NC Dialog 11 Used machine (very good) Control type Cnc Built 1990 Hours K.a. Dimensions 1800x1700x2000 Weight 2000 kg Location Haiger Description Universal tool milling machine of the brand lid suitable for tooling, fixture construction, training as well as mold making • Travel distances: 400x400x400mm • Control: Dialog 11 Technical data • Control CNC Dialog 11 • Table 600x400mm • Longitudinal path (X,Y,Z axis) 400x400x400mm • Tool changer no • Tool holder: ISO 40 • Vertical spindle speeds: 31.5-3150rpm • Feeds 2-3600mm/min • Connection 50 Hz 3x 380V • Spindle motor 3.4KW

Lid FP 4 MA Used machine (Very good) Control type CNC Built in 1990 Operating hours n/a Price 8,000 net plus VAT Dimensions 2500x2000x2500 Weight 1800 kg Location Haiger Description Universal tool ingescent machine of the brand lid suitable for tooling, fixture construction, training as well as mold making Travel: 465x385x380mm Control: Contour 2 Technical data Technical data: Lid FP4 MA (527) Built in 1992 Control CNC Hand / Contour 2 Table 800x465mm Laengsweg (X,Y,Z axis) 465x385x380mm Tool changer no Tool holder: ISO 40 Vertical spindle speeds: 31.5-3150rpm Vorschuebe 2-4000mm/min Connection 50 Hz 3x 380V Spindle motor 4KW Machine weight approx. 1900kg Dimensions 2800x2000x2500mm

Description x-path: 300 mm y-way: 150 mm z-way: 340 mm Clamping area: 600 x 210 mm T-slots: 5 T - slot width: 12 mm Speed range - vertical: 250 - 2000 rpm Speed range - horizontal: 40 - 315 rpm Speed levels working spindle: 8 Feed range: 10 - 500 mm/min Feed levels: 8 Pinolene stroke: 60 mm Spindle holder: SK 40 Total power requirement: 1.7 kW Machine weight approx.: 0.8 t Space requirement approx.: 0.90 x 1.10 x 1.55 m Universal tool milling machine in very good condition, vertical head rotatable +/- 90° incl. drill pin with stroke 60 mm, horizontal spindle, automatic feed in X and Z direction, universal swivel table, turning and tilting range+/- 30°, swivel range+/- 90°, separate control cabinet + main switch incl. digital display (new)

Table size: 460 x 800 mm stroke x: 485 mm traverse path y: 385 mm traverse path z: 380 mm Quill stroke: by hand approximately 70 mm spindle speeds: 50-3150 rpm stufenl feeds. adjustable: 2-1000 mm / min rapid traverse rate: 2 m / min. Port: 3.7/4,4 kW space: 2100 x 1650 x 1730 mm weight: 1850 kg

Vertical machining center Cincinnati Millacron Traverse path x 1270 mm Y: travel 660 mm Z: travel 660 mm CNC control: Acramatic 850SX Table size: 1,370 x 660 mm Table load: 910 kg Rapid traverse x/Y/Z: 15,000 mm / min. Spindle speeds: 60-8,000 rpm. Spindle recording: ISO 40 Distance from spindle - table min/max: 150/880 mm Tool changers: 21 items Equipped with:-cooling device -Hand Council operation -Complete instructions Country of origin: England Spindle motor: 9 kW Machine weight: 8.000 kg Machine WxDxH: 3,600 x 2.900 x 3.000 mm

Lid FP 1 in very nice condition x-path: 300 mm y-way: 150 mm z-way: 340 mm Clamping area: 600 x 210 mm T-slots: 5 T - slot width: 12 mm Speed range - vertical: 250 - 2000 rpm Speed range - horizontal: 40 - 315 rpm Speed levels working spindle: 8 Feed range: 10 - 500 mm/min Feed levels: 8 Pinolene stroke: 60 mm Spindle holder: SK 40 Digital display Z-502 Total power requirement: 1.7 kW Machine weight approx.: 0.8 t Space requirement approx.: 0.90 x 1.10 x 1.55 m Universal tool milling machine in good condition, vertical head rotatable +/- 90° incl. drill pin with stroke 60 mm, horizontal spindle, automatic feed in X and Z direction, universal swivel table, turning and tilting range+/- 30°, swivel range+/- 90°, separate control cabinet + main switch

A used S O R A L U C E CNC driving stand milling and drilling center FS 16000 Built in 2000 MAIN TECHNICAL DATA: Travel: Longitudinal (X): mm 16000 Senkr. (Z): mm 1600 Cross (Y): mm 1500 Milling and drilling spindle: Tool holder: ISO 50, DIN 69871 Auto. Tool tension: clamping force 15000 N Tightening bolt: DIN 69872 Form B (BT50) Spindle speeds: Special speeds: rpm 20-3000 Feeds: Feed range: mm/min 2-5000 Rapids: X-axis: mm/min 12000 Y- and Z-axis mm/min 15000 The machine is equipped with: - HEIDENHAIN control TNC 426 M. - Operator's platform in the X-direction with sliding door and Viewing windows against chip flight and splashing water. - Operator's console swivels mounted on the stage. - Automatic thermal expansion compensation of the Milling sliders. - Automatically indexing milling head. This milling head enables the fully automatic m ...

Qty.1 Second-hand milling (scalping) line Mfc.: Torrington Type: 30" Slap Miller Speed: 500 rpm – 18 fpm Capacity: 1,9 m/dk

Universal milling machine. Table size: 1200mmx320mm. Longitudinal travel: 950mm. Cross travel: 300mm. Vertical travel: 500mm. ISO40. Hure head. DRO Fagor.

Table size: 440 x 1200 mm table movement x: 950 mm table movement y: 250 mm table movement z: 475 mm spindle retainer: ISA 40 spindle speeds: 40-1800 rpm feeds longitudinal & cross: 16-630 mm / min feed vertically: 5.6-224 mm / min. Supply: 380 V, 7.5 kVA kW space: 2150 x 2000 x 2100 mm weight: 2400 kg

Control cabinet for MAHO 600 - MAHO had manual transmission damage and was therefore exploited. - Are also other parts in stock. Please inquire! Good condition fully functional can be visited and tried out on site. Shipping also abroad. Sightseeing: Basically, I would like to point out that the article, in order to avoid misunderstandings, can be viewed before the purchase and tested under electricity. Please ask questions before buying to avoid ambiguity. For general questions or an appointment for a viewing, I can be reached at any time at the telephone number below or above. Errors in the description and prior sale excepted. VAT will be shown separately on my invoices. Shipping with freight forwarder.

Vertical Milling Machine RAMBAUDI type RAMMATIC 600 Travel X 1260 mm Travel Y 690 mm Travel Z 600 mm Numerical Command NUM 1060 Cone SA 50 Table size 2000 x 600 mm Year of construction 1991 Voltage 380 V Depth 2500 mm Total height 4000 mm Weight approx 9 T

Vertical Milling Machine Droop & Rein type FS130 Travel X 2000 mm Travel Y 1000 mm Travel Z 1000 mm Spindle SA 50 Sensitive spindle exit: 200 mm Rotation from 31,5 to 1600 RPM Table size 2400 x 1070 mm Year of construction 1976 Throat depth 950 mm Head Tilt head Spindle motor 22 kW Scale HEIDENHAIN 3 axes New electrical panel in 2006 Voltage 380 V Width 3500 mm Depth 4700 mm Total height 4500 mm Weight 26 T

Special price for stock goods! Only while stocks last! Drilling-milling machine: Bernardo Type/Model: FM 45 HSV with digital display Condition: new Drilling capacity in steel: 32 mm Drilling capacity in cast iron: 40 mm Knife head milling cutter max.: 80 mm Projection: 220 mm Spindle speed: (12) 75 – 3200 rpm Spindle holder: MK 4 Pinole stroke: 120 mm Pinole feed: (3) 0.10 / 0.18 / 0.26 mm/U Table size: 800 x 240 mm Travel (x / y): 555 / 205 mm Milling head swivel: -60° to +60° Distance spindle / table: 60 – 485 mm Height adjustment milling head: 425 mm T-slot size: 14 mm Motor output power S1 100%: 1.1 / 1.5 kW (400 V) Motor input power S6 40%: 1.5 / 2.2 kW (400 V) Machine dimensions (W x D x H): 1140 x 770 x 1500 Weight approx.: 308 kg without base Characteristics: - High-torque 2-stage motor, speed range 75 - 3200 rpm - Double-sided swivelling m ...

Mikron C Axis Machine Table - with Heidenhain control 430 - Siemens server motor - Table: 60 x 110 cm - 4th axis, diameter: 50 cm - Weight: 650 kg Good condition fully functional can be visited and tried out on site. Shipping also abroad. Sightseeing: Basically, I would like to point out that the article, in order to avoid misunderstandings, can be viewed before the purchase and tested under electricity. Please ask questions before buying to avoid ambiguity. For general questions or an appointment for a viewing, I can be reached at any time at the telephone number below or above. Errors in the description and prior sale excepted. VAT will be shown separately on my invoices. Shipping with freight forwarder.

2130 2x3 M 3D CNC milling plotter built in 2014 in China, is used for machining workpieces in the X,Y and Z axes. Machining is performed on the machine’s vacuum table with dimensions (L x W) of 3000 x 2100 mm, by using a rotary head. The applied electro-spindle with a power of 4.5 kW, is distinguished by its extreme reliability and speed reaching up to 18000 rpm, allowing the desired result to be obtained in a very short time. The CNC milling machine is controlled by a hand-held terminal connected to the WEIHONG NK105 G2 CNC controller. This solution makes the machine’s operation much easier to handle and allows every function to be used. The machining centre is also equipped with among others: an EMI filter to attenuate high-frequency electromagnetic interference and a PANASONIC MDME102GCGM axis servo motor. Technical specifications of the 2130 2×3 M CNC milling machine - wo ...

2 piece F. 17.3 2 piece F. 17.34 Milling machines with double head (duplex), with counter holder for horizontal milling

Milling Machine MAHO MH 700 C CNC- 5 axis CNC- Phillips 432 X/Y/Z- 700/450/500 mm B axis CNC Universal table 820x480 mm 5th axis- CNC/NC dividing head ISO 40 spindle adapter Quill stroke of spindle 100 mm Universal table: -swiveling of the Horizontal X/Z axis 30 degrees -swiveling of the vertical Y axis 360 degrees Spindle speeds infinitely variable 20-3150 rpm

VISION WIDE VB-2016 5-AXIS CNC gantry milling machine was manufactured in 2013 in Taiwan. The machine performs precision machining of heavy workpieces in three or even five axes, once the automatic swivel head is mounted to the vertical spindle. The machine’s top-quality cast-iron structure is rigid and resistant to bending stress, thus perfectly dampening the vibrations and oscillations generated during machining. The VISION WIDE VTEC VB 2016 CNC gantry milling machine centre is equipped with safety guards fitted around the entire machine with sliding doors that open flush with the X-axis travel. Inside, there is a large work table with a length of 2000 mm and a width of 1300 mm, which is supported along the entire length of the longitudinal travel and guided by two sliding guideways, making it possible to machine heavy workpieces even when the table is unevenly loaded. Two scre ...
