klingelnberg milling machines used for sale

Complete production line for bevel gears, consisting of 6 bevel gear milling machines Klingelnberg BF 201 including orders for contract work for sale Technical data Diameter: 240 mm Module: 10 mm Tooth width: 60 mm Dimensions: 2.3 x 2 x 1.7 m Machine weight: approx. 6,700 kg Information and data are non-binding, subject to prior sale Special features: Complete production line consisting of 6 machines with the following accessories: - Bevel gear machine - 1x interchangeable gear set - 1x test block - Mounts (proportionate) - Knife set (proportionate) - Documentation (1xOriginal / data set) Furthermore, contract gear orders could follow, catalogue goods and special bevel gear sets according to customer specifications, complete volume approx. 8,000 components / year. Asking price of the seller 18.000.- VB / per machine

Circulation cutter from Klingelberg

Klingelnberg ZW 301 Gear Measuring Machine Weight 750 kg

Key data: 450

The Klingelnberg PEK 300 H bevel gear testing machine is designed for universal single-flank rolling testing of bevel gears and crown gears. Here, gears can be measured and graphically evaluated by means of single-flank rolling testing. These test methods are particularly suitable for determining defects in the gear geometry such as concentricity and axial running properties, rolling deviations or pitch errors. Here, a practical installation situation of a gear outside the gearbox is simulated under real load conditions and then evaluated. Deviations in the gear geometry, machining errors due to defective tools and damage to the gears can thus be detected and eliminated even before assembly. The following parameters can be measured here: » Single-flank deviations Fi', fi', fl', fk' » Crossing, Runout Roundness (Option) » Carrying diagram with digital camera » Pit ...

Key data: 540

The Klingelnberg GKP 90 bevel gear testing machine was designed as a universal machine and is used by manufacturers of gears and transmission technologies, for the process of noise and contact pattern tests on bevel gears and hypoid gears. Technical data Diameter: 540 (400) mm Hypoid: ±50 mm mm Pinion spindle Dm: 90 mm mm Dimensions: 1,800 x 1,800 x 1,600 m Machine weight: approx. 2,800 kg Information and data are non-binding, subject to prior sale Special features: The machine is intended for noise and contact pattern tests on bevel and hypoid gears of all gears. By simulating operating conditions, applying different speeds and changing the load states for drive and outlet, the optimal installation distance for standstill can be determined. Digital actual value display for 2 axes Stepless speed adjustment via frequency converter Electrically fused and acceptable ...

max. wheel diameter: 1600 mm gear width: 250 mm max. module: 20 min. module: 1,5 base circle dia. - max.: 1450 mm base circle dia. - min.: 150 mm specimen weight from/to: 4000 kg feeler adjustment movement - parallel: 1400 mm max.helical angle: 0 - 90 ° wheel diameter with counterstay: 1000 mm feeler adjustment movement - parallel: 800 mm centre height: 1150 mm electrics - voltage/frequency: 400 / 50 V/Hz dimensions of the machine ca.: 2,8 x 2,4 x 2,3 m total power requirement: 2 kW weight of the machine ca.: 3 t Universal Involute and Helix Testing Machine - modernized 1995 Machine is suitable for measuring all individual tooth data on straight and helical spur gears, and shaping and shaving cutters. Following tooth data can be tested: Tooth flanks, Involute base circle dia. and pressure angle, Profile c ...

max. wheel diameter: 275 mm gear width: 55 mm max. module: 6 min. module: 1 Control: 840 C Siemens total power requirement: 100 kW weight of the machine ca.: 16,7 t dimensions of the machine ca.: 5,2 x 2,3 x 2,4 m m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 275 mm gear width: 55 mm max. module: 6 min. module: 1,5 control: Sinumerik 840C tooth width: 5,5 mm spiral angle: 0/60 ° max. number of teeth: 120 min. number of teeth: 5 transmission ratio max.: 1:10 transmission ratio min.: 1:1 spindle speeds: max. 110 mm blade head turning speeds: 20-110 1/min total power requirement: 100 kW weight of the machine ca.: 16700 kg dimensions of the machine ca.: 5200x2300x2400 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 0-200 mm max. module: 25 min. module: 0,5 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: --- mm gear width: --- mm max. module: --- min. module: --- Control: --- total power requirement: --- kW weight of the machine ca.: --- t dimensions of the machine ca.: --- m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 160 - 1.600 mm gear width: 250 mm max. module: 20 min. module: 1,5 total power requirement: 1 kW weight of the machine ca.: 3 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 2500 mm gear width: 0 mm max. module: 34 min. module: 1 total power requirement: ca. 15 kW weight of the machine ca.: 15 t dimensions of the machine ca.: 4,20 x 2,00 x 2,90 m Extra große ZR-Prüfmaschine, Gegenhalter The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 275 mm max. module: 6 min. module: 1,5 Control: SINUMERIK 840 C tooth width: 5,5 mm spiral angle: min. 0 / max. 60 ° max. number of teeth: 120 min. number of teeth: 5 ratio of transmission: 1:10 min. ratio of transmission: 1:1 work piece spindle speed: max. 110 U/min blade head turning speeds: 20 - 110 U/min total power requirement: 100 kW weight of the machine ca.: 16,7 t dimensions of the machine ca.: 5,20 x 2,30 x 2,40 m Internal deburring device U axis / Q spindle chip conveyor coolant device Electrostatic air purifier ELBARON no tools No workpiece clamping device The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 500 mm Hypoid adjustment: ±70 mm axial cross angle: 90 ° Distance Y-: 150 - 350 mm Distance Z-axis: 120 - 340 mm turning speed range - stepless: 0 - 5000 U/min max. torque on the spindle: 57 Nm Cone: 99,2 mm Pull-in force Tool clamping: 23000 N Braking torque max.: 93 Nm total connected load: 20 kVA total power requirement: 15 kW weight of the machine ca.: 6 t dimensions of the machine ca.: 2,35 x 2,24 x 2,5 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 400 mm gear width: mm max. module: Control: total power requirement: kW weight of the machine ca.: 4 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 600 mm gear width: 450 , 600 mm module: distance gear spindle / pinion head: 40 - 450 mm distance pinion spindel head / gear head: -160 - 600 mm axis adjustment +/-: 60 mm spindle turning speed - stepless: 1 - 2120 U/min spindle bore: 130 mm taper in main spindle: MK 60 total power requirement: 30 kW weight of the machine ca.: 6,6 t dimensions of the machine ca.: 2,8 x 1,8 x 2,1 m Bevel gear testing machine, 2 flank testing! The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 300 mm max. module: 8 min. module: 0,7 Control: SINUMERIK 840 D min/max. pitch cone angle: - 90 / + 90 ° workpiece spindle - bore: 127 mm grinding wheel diameter: 50 - 230 mm spindle speeds (infinitely variable): 7.500 U/min work piece spindle speed: 700 U/min total power requirement: 146 kW weight of the machine ca.: 21 t dimensions of the machine ca.: 9,5 x 3,6 x 3,1 m Measuring probefor tooth gap(integrated on the grinding head) External grinding spindle cooling system ELBARON oil mist extraction (integrated in the machine) Hoffmann coolant filter system Was used for the serial production of spiral-toothed ring gears No clamping devices No grinding wheels / grinding wheel flanges No dressing wheels The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 500 mm gear width: 200-400 mm module: 12 turning speeds: 0-3250 U/min bracke pressure: bis max. 95 Nm inner taper: Konus #39 Control: Fanuc 16 total power requirement: 15 kW weight of the machine ca.: 6 t dimensions of the machine ca.: 2.350 x 2.240 x 2.500 mm HIGHLY FLEXIBLE TESTING OF HARD, FINISHED AND GREEN SPIRAL BEVEL AND HYPOID GEAR SETS The T 60 bevel gear testing machine is a CNC testing machine with three linear axes for the fully automatic hard and soft testing of spiral bevel and hypoid gear sets with a 90° axis angle. It offers versatile objective and subjective testing options with speeds up to 3,250 min and braking torques up to max. 95 Nm. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

voltage: 110 - 230 V frequency range: 50 - 60 Hz Power connection: 0,5 kVA Dimensions (HxWxD): 1000 x 800 x 1750 mm weight: 150 kg Measuring machine for bar knives. Equipment/accessories: -Measuring tools -Clamping devices -Computer -Monitor -Printer -Cabin -Technical documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding diameter: mm grinding length: mm max. module: 0 min. module: 0 total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

z-travel: 200 mm Clamping diameter of the cutter heads: max. 550 mm Max. permissible cutter head weight: 150 kg Mounting plate diameter for cutter heads: 360 mm Mounting cone for cutter heads Nominal diameter: 500 mm weight of the machine ca.: 2,3 t dimensions of the machine ca.: 2 x 1,5 x 2,03 m Cutter Head Set-Up- and -Measuring Machine In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in dry milling, high gear cutting quality and a long service life can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing devic ...

max. wheel diameter:5 - 260 mm gear width:400 mm max. module:15 min. module:0,5 gear hobbing diameter - internal:30 mm max. helix angle:> 85 ° Aussenverz. max. helix angle:> 45° Innenverz. Testing Range vertical:400 mm dist. between centers:5 - 600 mm table diameter:260 mm max. table load:100 kg speeds:30 1/min total power requirement:1,6 kVA weight of the machine ca.:900 kg dimensions of the machine ca.:200 x 1300 x 2150 mm CNC Gear Tester in good condition, out of OEM Test Lab. For measuring of spur and helical toothing, additional of rotationally symetric parts as true running, coaxiality, axial runout, etc. with tool changer ( 4 nos.)

Usable for the: Milling and engraving labeling, marking Drilling, cutting Dosing and much more. (Applications require optional accessories) inclusive: Design software ConstruCAM 3D Control software KinetiC-NC incl. CAM software Estlcam Multi-zone vacuum table with recessed T-nuts sliding Control panel including step control manual central lubrication The offer here is a CNC milling machine with the above-mentioned accessories (without further ado possibly shown on the photos accessories). For operation, a milling motor is also required, which can optionally be purchased from us. echnische data: External dimensions LxWxH: 1650x1440x1950 mm Weight: approx. 650 kg Clamping surface XxY: 930x630 mm Travel XxYxZ: 900x600x200 mm (optional 300/400 mm in Z-axis) Width linear guides X,Y,Z: 20 mm Repeatability: 0.01 mm Reverse play: appr ...

Work facilitation through basic equipment The basic equipment includes, for example, an ergonomic control panel, which contains the stepper motor control and an industrial PC with touch function. Software (CAD/CAM, control software, operating system Win 10 Pro) are already pre-installed. Thus, the CNC milling machine can be operated conveniently and conveniently. A multi-zone vacuum table ensures a comfortable, fast clamping of workpieces and a strong hold during milling. Furthermore, the machine is equipped with a manual central lubrication, which makes it easier for you to grease and increases the service life of the CNC milling machine. Various applications The most diverse materials can be processed on our T-Rex, whether plastic, wood, metal or stone, nothing is impossible. Whether engraving, milling, cutting, drilling, dosing, gluing, etc., no wishes remain unfulfille ...

Work facilitation through basic equipment The basic equipment includes, for example, an ergonomic control panel, which contains the stepper motor control and an industrial PC with touch function. Software (CAD/CAM, control software, operating system Win 10 Pro) are already pre-installed. Thus, the CNC milling machine can be operated conveniently and conveniently. A multi-zone vacuum table ensures a comfortable, fast clamping of workpieces and a strong hold during milling. Furthermore, the machine is equipped with a manual central lubrication, which makes it easier for you to grease and increases the service life of the CNC milling machine. Various applications The most diverse materials can be processed on our T-Rex, whether plastic, wood, metal or stone, nothing is impossible. Whether engraving, milling, cutting, drilling, dosing, gluing, etc., no wishes remain unfulfille ...

Usable for the: Milling and engraving labeling, marking Drilling, cutting Dosing and much more. (Applications require optional accessories) inclusive: Design software ConstruCAM 3D Control software KinetiC-NC incl. CAM software Estlcam Multi-zone vacuum table with recessed T-nuts sliding Control panel including step control manual central lubrication The offer here is a CNC milling machine with the above-mentioned accessories (without further ado possibly shown on the photos accessories). For operation, a milling motor is also required, which can optionally be purchased from us. Technical specifications: External dimensions LxWxH: 1970x2150x1950 mm Weight: approx. 950 kg Clamping surface XxY: 1230x1320 mm Travel XxYxZ: 1200x1300x200 mm (optional 300/400 mm in Z-axis) Width linear guides X,Y,Z: 20 mm Repeatability: 0.01 mm Reve ...

Milling holders with milling cutters and drills mostly SK40, total 25 parts

Good condition Auction-ID: A7-45427-206

End mill, end mill, cutter, shell cutter, milling head, angle cutter, shell angle cutter, angle end mill, prism cutter -Angle milling cutters: Attachment angle milling cutters, prism milling cutters -Type: Ø85 x 35 mm -Hole: Ø 27 mm -Quantity: 1x milling cutter available -Dimensions: Ø 85 x 35 mm -Weight: 0.8 kg

Operating voltage: 400 v Ma.Nr.: 41636 HEIDENHAIN positioning and control TNC 131 / 135 Complete Dokunnetation (operating instructions, technical plans) exists. Errors excepted!

Table clamping surface: 600 x 1100 mm traverse path x: 800 mm traverse path y: 450 mm traverse path z: 500 mm Quill stroke: by hand approximately 50 mm of spindle speeds: 63-3150 rpm stufenl feeds. adjustable: 0,1-1500 mm / min rapid traverse: x/y/z 4.5/2,6/3 m / min. Supply: 380 V, 5.5 kW space: 3000 x 2500 x 2030 mm weight: 4000 kg

Table size: 500 x 1200 mm traverse path x: 1000 mm stroke y: 550 mm traverse path z: 600 mm spindle retainer: ISO 40 spindle speeds: 60-2700 rpm spindle drive: 10 kW Electr. Supply: 380 V, 20 kVA kW space: 3200 x 2800 x 2650 mm weight: 7.3 t

Table clamping surface: 500 x 1000 mm stroke x: 630 mm traverse path y: 500 mm traverse path z: 460 mm Quill stroke: hand 45 mm spindle retainer: ISA 40 spindle speeds: 31.5-3150 rpm stufenl feeds. adjustable: 1-3000 mm / min rapid traverse: x/y 6 / z 4 m/min. Supply: 380 V, 6/8 kW space: 1800 x 2120/2600 x 2020 mm weight: 3100 kg

Universal milling machine. Hure head. Table size: 2000x480mm. Longitudinal travel: 1700mm. Cross travel: 400mm. Vertical travel: 575mm. ISO50. Motor power: 20cv. Weight: 5500Kgs. Dimensions: 2550x2380x2680.

Table clamping surface: 630 ø mm traverse path x: 600 mm traverse path y: 450 mm traverse path z: 500 mm Quill stroke: hand 80 mm spindle retainer: ISO 40 spindle speeds: 20-3150 rpm stufenl feeds. adjustable: 1-3000 mm / min rapid traverse rate: 4 m / min. Connection: 380V kW space: 2000 + 850 x 2000 x 2000 mm weight: 3300 kg

Stroke x: 600 mm traverse path y: 400 mm traverse path z: 400 mm spindle retainer: ISO 40 spindle speeds: 80-4000 rpm stufenl feeds. adjustable: 0,1-1500 mm / min rapid traverse: x & y/z 4/2.5 m / min. Supply: 380 V, 16 kVA kW space: 2450 x 2200 x 1900 mm weight: 2250 kg

Universal milling machine. Table size: 1400mmx300mm. Longitudinal travel: 1200mm. Cross travel: 320mm. Vertical travel: 500mm. ISO40. Hure head. Speeds: 12. (40-1800rpm). Motor power: 7Kw.

Drilling capacity in steel: 32 mm Drilling capacity in cast: 40 mm Cutter head milling max.: 80 mm Projection: 220 mm Spindle speed: (12) 75-3200 RPM Spindle retainer: MK 4 Quill stroke: 125 mm Table size: 800 x 240 mm Travel (x / y): 555 / 225 mm Milling head swiveling: - 90 ° to + 90 ° Distance from spindle / table: 60-485 mm Head height: 425 mm T - slot size: 14 mm S1 motor power output 100%: 1,1 / 1,5 kW (400 V) Motor power S6 40%: 1.5 / 2.2 kW (400 V) Machine dimensions (W x D x H) : 1140 x 770 x 1500 mm Approximate weight: 287 kg without stand Features: Quick and easy change of speed using the gear selector switch Versatile application possibilities such as drilling, milling, thread cutting, … High running smoothness by polished, running in an oil bath gear gears Right - and the link run device for thread cutting Quill adjustment by means of ...

Standard ALB ear performance: 30 mm Thread cutting performance: M 20 (option) Thread: M 12 Spindle: MK 3 or SK 30 (option) Quill stroke: 100 mm Longitudinal / cross travel: 350/160 mm Distance spindle/cross table: 80 to 450 mm Table area: 600 x 240 mm Column diameter: 110 mm Total height: Max 1,920 mm Weight: 340 kg Motor pole shift bar: 0.8/1.5 kW Spindle speeds, continuous, selectable: 10 spindle speeds: 80-1,400 rpm 10 spindle speeds: 120-2,160 rpm 10 spindle speeds: 160-2,800 RPM Facilities: A versatile, accurate and handy drilling milling machine. The quiet-running drive and a perfect clamping of Quill guarantee good surfaces when milling. The headstock can be swung out. The stage is precise and precisely adjustable. Pitch 0.05 mm. clamping device for both axes. Full motor protection. Machine incl. Cabinet.

Table clamping surface: 500 x 1600 mm table movement x: 1220 mm table movement y: 500 mm table movement z: 500 mm spindle retainer: SK 50 spindle speeds: 56-2800 rpm feeds longitudinal & cross: 10-1800 mm / min feed vertically: 2.5-450 mm / min. Supply: 400 V, 16 kVA kW space: 2000 x 2250 x 2150 mm weight: 4500 kg

Machine type milling machine - universal brand HURON type MU 5 year 1975 control type conventional storage France country of origin France delivery immediately cargo base camp, free truck Technical details x way 1300 mm y path 700 mm z-way 550 mm table size 1500 x 460 mm spindle speeds 15-2500 RPM spindle retainer for SK 40 feed range x - direction 1,6-820 mm / min feed Empire z-direction 1,6-820 mm / min rapid traverse X + Z - axes 2.8 m/min rapid traverse y - direction of 2.8 m / m in power - spindle motor 10 kW total power 14 kW machine weight approx. 4.6 t additional information good condition with 3 axis of DIGITAL HEIDENHAIN SK 40 BUILT IN 1975

Universal milling machine with automatic movement ram. Table size: 1600mmx320mm. Longitudinal travel: 1200mm. Cross travel: 300mm. Vertical travel: 600mm. ISO50. Hure head. Equipped with DRO Fagor.

Universal tool-feeding machine, used universal milling machine, used Type FU 250 x 1000/2 Fabr. WMW Auerbach Built: 1988 Table size/ table: 1130 x 255 mm Laengsmotion/ longit. move: X 690 mm Horizontal movement/ horiz. Move: Y 190 mm Vertical movement/ Vert. move : Z 360 mm Tool holder/taper: ISO 40 Spindle speeds R+L infinitely/ speeds of spindle ( left/right) 56 - 2800 rpm. Pre-shot stepless all axes X, Y and Z/ feeds all axis 10 - 630 mm/min / 250 mm/min Drive power/ load 3.8 kW Weight: 2 t Specification: Vertical head,shock head

Table size: 460 x 800 mm stroke x: 485 mm traverse path y: 385 mm traverse path z: 380 mm Quill stroke: by hand approximately 70 mm spindle speeds: 50-3150 rpm stufenl feeds. adjustable: 2-1000 mm / min rapid traverse rate: 2 m / min. Port: 3.7/4,4 kW space: 2100 x 1650 x 1730 mm weight: 1850 kg

Vertical machining center Cincinnati Millacron Traverse path x 1270 mm Y: travel 660 mm Z: travel 660 mm CNC control: Acramatic 850SX Table size: 1,370 x 660 mm Table load: 910 kg Rapid traverse x/Y/Z: 15,000 mm / min. Spindle speeds: 60-8,000 rpm. Spindle recording: ISO 40 Distance from spindle - table min/max: 150/880 mm Tool changers: 21 items Equipped with:-cooling device -Hand Council operation -Complete instructions Country of origin: England Spindle motor: 9 kW Machine weight: 8.000 kg Machine WxDxH: 3,600 x 2.900 x 3.000 mm

CNC toolmill cover FP 3 NC Dialog 11 Used machine (very good) Control type Cnc Built 1990 Hours K.a. Dimensions 1800x1700x2000 Weight 2000 kg Location Haiger Description Universal tool milling machine of the brand lid suitable for tooling, fixture construction, training as well as mold making • Travel distances: 400x400x400mm • Control: Dialog 11 Technical data • Control CNC Dialog 11 • Table 600x400mm • Longitudinal path (X,Y,Z axis) 400x400x400mm • Tool changer no • Tool holder: ISO 40 • Vertical spindle speeds: 31.5-3150rpm • Feeds 2-3600mm/min • Connection 50 Hz 3x 380V • Spindle motor 3.4KW

Lid FP 4 MA Used machine (Very good) Control type CNC Built in 1990 Operating hours n/a Price 8,000 net plus VAT Dimensions 2500x2000x2500 Weight 1800 kg Location Haiger Description Universal tool ingescent machine of the brand lid suitable for tooling, fixture construction, training as well as mold making Travel: 465x385x380mm Control: Contour 2 Technical data Technical data: Lid FP4 MA (527) Built in 1992 Control CNC Hand / Contour 2 Table 800x465mm Laengsweg (X,Y,Z axis) 465x385x380mm Tool changer no Tool holder: ISO 40 Vertical spindle speeds: 31.5-3150rpm Vorschuebe 2-4000mm/min Connection 50 Hz 3x 380V Spindle motor 4KW Machine weight approx. 1900kg Dimensions 2800x2000x2500mm

Description x-path: 300 mm y-way: 150 mm z-way: 340 mm Clamping area: 600 x 210 mm T-slots: 5 T - slot width: 12 mm Speed range - vertical: 250 - 2000 rpm Speed range - horizontal: 40 - 315 rpm Speed levels working spindle: 8 Feed range: 10 - 500 mm/min Feed levels: 8 Pinolene stroke: 60 mm Spindle holder: SK 40 Total power requirement: 1.7 kW Machine weight approx.: 0.8 t Space requirement approx.: 0.90 x 1.10 x 1.55 m Universal tool milling machine in very good condition, vertical head rotatable +/- 90° incl. drill pin with stroke 60 mm, horizontal spindle, automatic feed in X and Z direction, universal swivel table, turning and tilting range+/- 30°, swivel range+/- 90°, separate control cabinet + main switch incl. digital display (new)

Lid FP 1 in very nice condition x-path: 300 mm y-way: 150 mm z-way: 340 mm Clamping area: 600 x 210 mm T-slots: 5 T - slot width: 12 mm Speed range - vertical: 250 - 2000 rpm Speed range - horizontal: 40 - 315 rpm Speed levels working spindle: 8 Feed range: 10 - 500 mm/min Feed levels: 8 Pinolene stroke: 60 mm Spindle holder: SK 40 Digital display Z-502 Total power requirement: 1.7 kW Machine weight approx.: 0.8 t Space requirement approx.: 0.90 x 1.10 x 1.55 m Universal tool milling machine in good condition, vertical head rotatable +/- 90° incl. drill pin with stroke 60 mm, horizontal spindle, automatic feed in X and Z direction, universal swivel table, turning and tilting range+/- 30°, swivel range+/- 90°, separate control cabinet + main switch

A used S O R A L U C E CNC driving stand milling and drilling center FS 16000 Built in 2000 MAIN TECHNICAL DATA: Travel: Longitudinal (X): mm 16000 Senkr. (Z): mm 1600 Cross (Y): mm 1500 Milling and drilling spindle: Tool holder: ISO 50, DIN 69871 Auto. Tool tension: clamping force 15000 N Tightening bolt: DIN 69872 Form B (BT50) Spindle speeds: Special speeds: rpm 20-3000 Feeds: Feed range: mm/min 2-5000 Rapids: X-axis: mm/min 12000 Y- and Z-axis mm/min 15000 The machine is equipped with: - HEIDENHAIN control TNC 426 M. - Operator's platform in the X-direction with sliding door and Viewing windows against chip flight and splashing water. - Operator's console swivels mounted on the stage. - Automatic thermal expansion compensation of the Milling sliders. - Automatically indexing milling head. This milling head enables the fully automatic m ...

Qty.1 Second-hand milling (scalping) line Mfc.: Torrington Type: 30" Slap Miller Speed: 500 rpm – 18 fpm Capacity: 1,9 m/dk

Universal milling machine. Table size: 1200mmx320mm. Longitudinal travel: 950mm. Cross travel: 300mm. Vertical travel: 500mm. ISO40. Hure head. DRO Fagor.

Table size: 440 x 1200 mm table movement x: 950 mm table movement y: 250 mm table movement z: 475 mm spindle retainer: ISA 40 spindle speeds: 40-1800 rpm feeds longitudinal & cross: 16-630 mm / min feed vertically: 5.6-224 mm / min. Supply: 380 V, 7.5 kVA kW space: 2150 x 2000 x 2100 mm weight: 2400 kg

Control cabinet for MAHO 600 - MAHO had manual transmission damage and was therefore exploited. - Are also other parts in stock. Please inquire! Good condition fully functional can be visited and tried out on site. Shipping also abroad. Sightseeing: Basically, I would like to point out that the article, in order to avoid misunderstandings, can be viewed before the purchase and tested under electricity. Please ask questions before buying to avoid ambiguity. For general questions or an appointment for a viewing, I can be reached at any time at the telephone number below or above. Errors in the description and prior sale excepted. VAT will be shown separately on my invoices. Shipping with freight forwarder.

Vertical Milling Machine RAMBAUDI type RAMMATIC 600 Travel X 1260 mm Travel Y 690 mm Travel Z 600 mm Numerical Command NUM 1060 Cone SA 50 Table size 2000 x 600 mm Year of construction 1991 Voltage 380 V Depth 2500 mm Total height 4000 mm Weight approx 9 T

Vertical Milling Machine Droop & Rein type FS130 Travel X 2000 mm Travel Y 1000 mm Travel Z 1000 mm Spindle SA 50 Sensitive spindle exit: 200 mm Rotation from 31,5 to 1600 RPM Table size 2400 x 1070 mm Year of construction 1976 Throat depth 950 mm Head Tilt head Spindle motor 22 kW Scale HEIDENHAIN 3 axes New electrical panel in 2006 Voltage 380 V Width 3500 mm Depth 4700 mm Total height 4500 mm Weight 26 T

Special price for stock goods! Only while stocks last! Drilling-milling machine: Bernardo Type/Model: FM 45 HSV with digital display Condition: new Drilling capacity in steel: 32 mm Drilling capacity in cast iron: 40 mm Knife head milling cutter max.: 80 mm Projection: 220 mm Spindle speed: (12) 75 – 3200 rpm Spindle holder: MK 4 Pinole stroke: 120 mm Pinole feed: (3) 0.10 / 0.18 / 0.26 mm/U Table size: 800 x 240 mm Travel (x / y): 555 / 205 mm Milling head swivel: -60° to +60° Distance spindle / table: 60 – 485 mm Height adjustment milling head: 425 mm T-slot size: 14 mm Motor output power S1 100%: 1.1 / 1.5 kW (400 V) Motor input power S6 40%: 1.5 / 2.2 kW (400 V) Machine dimensions (W x D x H): 1140 x 770 x 1500 Weight approx.: 308 kg without base Characteristics: - High-torque 2-stage motor, speed range 75 - 3200 rpm - Double-sided swivelling m ...

DOOSAN DNM 4500 CNC milling machine built in Germany in 2019 is used for drilling, milling or threading workpieces weighing up to 600 kg. Machining is performed in the X,Y,Z axes on a working table with dimensions (L x W) of 1000 x 450 mm. The vertical machining centre characterised by excellent precision and exceptional machining quality, will satisfy even the most demanding customers. Noise and vibrations occurring during machining are reduced thanks to the use of a high-performance direct drive spindle operating at speeds in the range from 80 to 8000 revolutions per minute. The tool magazine can store up to 30 tools, and they are changed in a very short time of just 1.2 seconds. The machining centre is also equipped with among others, through-spindle coolant, a lubrication system and an extremely efficient and reliable FANUC 0iMF CNC controller, ensuring full control of the mill ...

Mikron C Axis Machine Table - with Heidenhain control 430 - Siemens server motor - Table: 60 x 110 cm - 4th axis, diameter: 50 cm - Weight: 650 kg Good condition fully functional can be visited and tried out on site. Shipping also abroad. Sightseeing: Basically, I would like to point out that the article, in order to avoid misunderstandings, can be viewed before the purchase and tested under electricity. Please ask questions before buying to avoid ambiguity. For general questions or an appointment for a viewing, I can be reached at any time at the telephone number below or above. Errors in the description and prior sale excepted. VAT will be shown separately on my invoices. Shipping with freight forwarder.

2130 2x3 M 3D CNC milling plotter built in 2014 in China, is used for machining workpieces in the X,Y and Z axes. Machining is performed on the machine’s vacuum table with dimensions (L x W) of 3000 x 2100 mm, by using a rotary head. The applied electro-spindle with a power of 4.5 kW, is distinguished by its extreme reliability and speed reaching up to 18000 rpm, allowing the desired result to be obtained in a very short time. The CNC milling machine is controlled by a hand-held terminal connected to the WEIHONG NK105 G2 CNC controller. This solution makes the machine’s operation much easier to handle and allows every function to be used. The machining centre is also equipped with among others: an EMI filter to attenuate high-frequency electromagnetic interference and a PANASONIC MDME102GCGM axis servo motor. Technical specifications of the 2130 2×3 M CNC milling machine - wo ...

2 piece F. 17.3 2 piece F. 17.34 Milling machines with double head (duplex), with counter holder for horizontal milling

Milling Machine MAHO MH 700 C CNC- 5 axis CNC- Phillips 432 X/Y/Z- 700/450/500 mm B axis CNC Universal table 820x480 mm 5th axis- CNC/NC dividing head ISO 40 spindle adapter Quill stroke of spindle 100 mm Universal table: -swiveling of the Horizontal X/Z axis 30 degrees -swiveling of the vertical Y axis 360 degrees Spindle speeds infinitely variable 20-3150 rpm

VISION WIDE VB-2016 5-AXIS CNC gantry milling machine was manufactured in 2013 in Taiwan. The machine performs precision machining of heavy workpieces in three or even five axes, once the automatic swivel head is mounted to the vertical spindle. The machine’s top-quality cast-iron structure is rigid and resistant to bending stress, thus perfectly dampening the vibrations and oscillations generated during machining. The VISION WIDE VTEC VB 2016 CNC gantry milling machine centre is equipped with safety guards fitted around the entire machine with sliding doors that open flush with the X-axis travel. Inside, there is a large work table with a length of 2000 mm and a width of 1300 mm, which is supported along the entire length of the longitudinal travel and guided by two sliding guideways, making it possible to machine heavy workpieces even when the table is unevenly loaded. Two scre ...

SERON 1315 EXPERT CNC milling machine built in Poland in 2017 is new and has never been used. The machine designed and manufactured with attention to the smallest details, is used for precision machining of a wide range of materials such as mild metals, plastics, carbon, wood, wood-like panels and glass. All vibrations and deformations during the milling process are eliminated by the high-quality ribbed steel construction with a T-slot table made of aluminium profiles, with a length of 1500 mm and a width of 1300 mm. The workspace is additionally equipped with a special PVC overlay to protect the table cover while cutting the workpieces through. At the end of the table there is a six-position linear magazine with an automatic tool correction sensor. The 1315 EXPERT machine axes are driven by highly dynamic and precise brushless AC servo drives with back pressure, equipped with serv ...

Table size: 254 x 1100 mm Table movement x: machine. u. v. hand 682 mm Table movement y: hand 380 mm Table movement z: hand 457 mm Milling head swiveling to: +/-90 or +/-45 ° Spindle retainer: ISO 40 Spindle speeds: 70-2300 rpm Quill feeds: 0.038 â 0.152 mm / min Spindle drive: 380 V, 2.2 kW Space: 1600 x 1600 x 2150 mm Weight: 1420 kg

Table surface: 300 x 1300 mm Table movement x: 950 mm Table movement y: 220 mm Table movement z: 400 mm Spindle intake: MK 5 Spindle speeds: 25-1200 rpm Prests lengthwise & across: 7.5-635 mm/min Presens vertical: 3-250 mm/min Electr. Connection: 380 V, 7.5 kW Space requirement: 1670 x 1500 x 1750 mm Weight: 2600 kg

x-280 ,y- 200 , Z 315 , Table dimensions 380x380/250x500 A lot of writings,much more than pictured

Universal tool milling machine DECKEL FP 1 with 3 axis active digital display Heidenhain TNC 113 Year of construction: 1987 Travel: X 300 Y 160 Z 340 Speed range: 40 – 2000 rpm With the following accessories: Universal table 600 mm x 250 mm clamping surface Movable vertical milling head Extendable drill quill Infinitely variable feed via potentiometer 1 machine vice 1 counter holder with counter bearing 1 pc. milling mandrel long 0 22 mm Various tool holders S 22 x 2 Bellows Z Axis Machine light Automatic central lubrication pump Chip collection plate Coolant system Operating instructions THE MACHINE IS IN VERY GOOD CONDITION

EXTRON L610 CNC vertical machining center was built in 2008 in Taiwan. Distinguished by its extensive machining capabilities, high precision and reliable components, the machine is ideal for every production facility, even during the most intensive and demanding challenges. The high-quality design with sliding doors additionally efficiently dampens any vibrations and ensures maximum process stability. The EXTRON L 610 milling center machines workpieces on a large T-slot table using reliable tools placed in a 20-position head and a powerful spindle rotating at a maximum speed of 8000 rpm. All process parameters are programmed in the intuitive FANUC Series 0i-MC CNC control with many useful features that minimise the operator’s need to operate the machine. The EXTRON machining center weighs 5750 kg. Technical data of the EXTRON L610 CNC milling machine - CNC controller: FANUC Seri ...

Bearing number 1105-02690 Machine type Milling machine - Universal Make HERMLE Type UWF 1000 Built in 1988 Control type CNC Storage location FRANCE Country of origin Germany Delivery time SOFORT Freight base EXW Technical details x-way 700 mm y-way 630 mm z-way 500 mm Control heidenhain 355 Tool holder SK 40 (DIN 69871) Table clamping area: 1000 x 490 mm Spindle speed Gear stage 1 25 - 400 rpm. Spindle speed Gear stage 2 401 - 1260 rpm Spindle speed Gear stage 3 1261 - 4200 rpm Feed 5 m/min Rapid speed 10 m/min Swivel of the milling head + / - 90 ° Pinole diameter 110 mm Pinole stroke 95 mm Total power requirement 18 kW Machine weight approx. 5 t Information with full cabin coolant device Sale takes place without clamping equipment approx. 8500h switch-on hours

Milling machine 4-axis (15995740874) DMG Milltap 700 (2015) Spindle 24,000 1/min NC parts apparatus Lehmann EA-510. L Tool magazine 25 places Renishaw Measurement Kit Rinsing gun Milling machine 5-axis (15995747284) DMG Milltap 700 (2015) Spindle 24,000 1/min Swivel rotary tables 5-axis simultaneous operation Clamping pneumatics 1-circuit Tool magazine 25 places 40 bar IKZ Conveyor Rinsing gun Renishaw Measurement Kit Milling machine 5-axis (15995765944) DMG Milltap 700 (2018) Spindle 10,000 1/min Swivel rotary tables 5-axis simultaneous operation Clamping pneumatics 1-circuit Tool magazine 25 places 40 bar IKZ Conveyor Renishaw Measurement Kit Automatic front door Automation interface including automation door on the right Milling machine 5-axis (15995734744) + WH3 (770200062R) DMG Milltap 700 (2014) Spindle 10,000 1/min Swivel rotary  ...

Technical data: Fixed angular table: Fixed angular table clamping area: 800 x 400 mm Max table load: 200 kg Working spindle: Tool holder horizontally and vertically: ISO 40 Power of the main drive motor / 100% ED: 2.2 kW Vertical milling head: Speed range, tiered: (12) 50 - 2000 rpm Drill pinole, stroke: 100 mm Swivel range: +/- 90° Travel: X-axis automatic/man.: 385/400 mm Y-axis automatic/man.: 185/200 mm Z-axis automatic/man.: 365/380 mm Feeds: Feed range: 0-650 mm/min Number of feeds: infinitely adjustable Rapid response: 1000 mm/min Characteristics: - Machine accuracy according to DIN 8615 - 3-axis digital displays FAGOR® Innova (option) - Spindle run max. 0.005 mm, incl. test protocol according to DIN 8615 (rolling bearing SKF®/NSK®) - Vertical milling head can be swivelled out for horizontal milling (without d ...

Vertical -consol milling machine, used    Vertical -milling machine, used Make/make: WMW HECKERT Type/ model: FQS 400 Year built: 1978 Control type / control: conventional   x-way: 1190 mm   y-way: 530 mm z-way: 540 mm Table size/ table: 1600 x 400 mm Spindle power/ spindle power: 11kW Tool holder/tool taper: ISO 50 Speeds/ speeds: 28 - 1400 rpm Feeds: 16- 800 mm/min Total power requirement: 21 kW Machine weight: 4.8 t

Blade length 205 mm Max cutting performance Sheet R = 42 kg / mm2 4 mm Sheet R = 70 kg / mm2 3 mm Engine power 3 kW Number of beats / minutes 50 min Table dimension 625 x 954 mm Capacity of the oil tank 25 l Weight 500 kg The setting between the blades is fully automatic. Standard: - 1 set of knives at 30 ° (mounted on the machine) - 1 stop switch - 1 general circuit breaker - 1 stop adjustable and adjustable every 15° - Fill the first oil - Manual with installation and maintenance instructions and service keys.

x-400,y-330,z-350,angle table 630x335,SK 40, 40-6,000 rpm,measuring probe

Table clamping area: 310 x 1400 mm Table movement x: 950 mm Table movement y: approx. 325/345 mm Table movement z: approx. 500 mm Spindle speeds: 20 - 1500 rpm Feeds longitudinally and transversely: 18 - 620 mm/min Feeds vertical: 18 - 620 mm/min electr. Connection: 380 V kW Space requirement: 1900 x 1600 x 1750 mm Weight: approx. 1500 kg

Table clamping area: 560 x 240 mm x-way: 300 mm y-way: 275 mm z-way: 200 mm Spindle holder: ISO 40 Spindle speeds: 40 - 2000 rpm Operating voltage: 380 V Total power requirement: 1.5 kW Space requirement: 1200 x 1100 x 1700 mm Weight: approx. 750 kg

1 x Universall tool-feeding machine Lid FP 4 Built: c.1970 Very robust and rare conventional machine in good condition. Technical data: Travel: X: 700 Y: 400 Z: 450 mm Spindle speeds: 31.5 - 1,600 rpm (18 levels) Tool holder: ISO 40 Pinole stroke: 115 mm Feed in X/Y/Z Feed range: X/Y/Z 5 - 500 mm/min (infinitely adjustable) Rapid response: X/Y: 10 - 500 mm/min Z: 5 -250 mm/min (18 levels) swivel handling table Clamping area: 860 x 500 mm Accessories: 1 x horizontal counter bearing 5 x horizontal frond spine Bftj7cazem 10 x vertical fraes aufnahme 36 x tension tension ingesheis from 0.5 - 18 mm 0.5 mm rising 5 x Direct clamping pliers D: 12/14/16/18/20 mm 1 x machine vice Manual various distance rings and accessories for milling machines complete documentation The machine can be inspected at our warehouse under electricity. A 3-axis digital ...

Milling machine from a training workshop in very good condition Manufacturer lid Type FP1 Active

Universal tool milling machine, used universal milling machine, used Type FU 315 - V/2 Fabr. WMW Heckert Built: 1979 Table size/ table: 1250 x 315 mm Laengsmotion/ longit. move: X: 850 mm Horizontal movement/ horiz. Move: Y: 270 mm Vertical movement/ Vert. move : Z 355 mm Tool holder/taper: ISO 50 Spindle speeds R+L infinitely/ speeds of spindle ( left/right) 28 - 1400 rpm. Pre-shot stepless all axes X, Y and Z/ feeds all axis 10 - 630 mm/min / 250 mm/min Drive power/ load 3.8 kW Weight: 2 t

Mikron Milling Machine WF2/35 - Width: 120 cm - Depth: 140 cm - Height: 180 cm Good condition, fully functional, can be viewed and tried out on site. Shipping also abroad. Sightseeing: Basically, I would like to point out that the article can be viewed and tested under power before purchase in order to rule out misunderstandings. Please ask questions before purchasing to avoid confusion. If you have any general questions or would like to make an appointment for a viewing, I can be reached at any time on the telephone number below or above. Errors in the description and prior sale excepted. VAT is shown separately on my invoices. Shipping with forwarding agent.

XYZ SMX 5000 CNC bed milling machine was built in 2016 in the UK. The machine for precision machining of workpieces with a maximum weight of 850 kg is made from a uniform cast iron, which guarantees excellent rigidity and stability during even the most intensive machining. The enclosed workspace includes a large work table with a length of 1930 mm and a width of 355 mm, a reliable spindle and a tilting work head. All this is complemented by a CNC control with integrated CAD functions, which significantly simplifies everyday machining. The XYZ Machine Tools SMX 5000 CNC milling machine weighs 3570 kg. Technical specifications of the XYZ SMX 5000 milling machine - feed in the X/Y/Z axis: 1500/600/580 mm - rapid traverse in X,Y,Z axis (CNC): 6.3 m/min - rapid traverse in X,Y,Z axis: 3.8 m/min - work table dimensions (L x W): 1930 x 355 mm - maximum workpiece weight: 850 kg - number ...

ATMSolutions ATMS 1325 CNC milling machine built in 2017 in Poland is designed for the production of both small and large parts made of e.g. aluminium, plastic or wood. The machine on offer is like new, it has never worked after a trial run. The machining process is performed on a large vacuum table using a powerful, water-cooled spindle. The steel frame, by increasing the overall rigidity, makes it possible to achieve unprecedented precision and accuracy in machining, removing any vibration and deformation. In addition, the X and Y axes are equipped with trapezoidal guides with gear drives with bevel teeth, thanks to which excellent dynamics and feed repeatability are achieved. This is complemented by an intuitive CNC control with professional CAM software that supports G-CODE and .nc commands. The ATMS 1325 CNC milling machine weighs 1000 kg. Technical specifications of the ATMSo ...

Deckel Maho DMG DMU 70eVolution 5Axis simultaneous Machining center CNC Hersteller [manufacturer]: DMG Deckel Maho Type [ type]: 70eVolution Control unit: Heidenhain iTNC 530 Incl. handwheel Baujahr[construction year]: 12/2006 - Renewed/renewed spindle - IKZ integrated cooling system for water 40bar and air (both possible) Travel X/Y/Z 750/600/520 mm B-axis 0 to 180° degrees C-axis n x +-360° degrees Table load up to 350kg Spindle speed range 20 to 18,000 1/min. Tool holder SK 40 DIN 69871 Weight [weight]: 10.000kg Full documentation is available. Inspection under power can be done at short notice. We will be happy to answer any further questions you may have. Tel. 017621834834Price, from stock here plus VAT Condition: good - ready for demonstration Delivery: from stock - as seen Payment: purely net - upon receipt of invoice Prior sale, errors excepted.  ...

Universal milling machine vertically / horizontally from a training workshop Manufacturer Hermle Type FW801 Tool holder SK40 automatic feed in three axes Digital display in three axes Machine technically in very good condition under electricity ready for demonstration Technical data: Travel: x=350mm y=150mm z=220mm Spindle speeds from 50 to 3,150 rpm can be infinitely variable Feed speed infinitely adjustable via rotary pot from 10 to 5,000 mm/min, aisle Special price Used milling machine Hermle FW 801

- travel range: X= 485, Y= 385, Z= 380 mm - table size: 800 x 460 mm - tool holder: SK 40 - dimensions LxWxH: 2440 x 1800 x 2100 mm - weight: ca. 2.000 kg
