ermak presses used for sale

pressure: 60.0 t chamfer lenght: 1270 mm distance between columns: 1000 mm column arm: 410 mm ram stroke speed: 160 mm/sec work speed: 10.0 mm/sec return speed: 165 mm/sec work stroke: 275 mm dayligth: 530 mm table height: 900 mm table width: 90.0 mm back stop - adjustable: max. 800 mm oil volume: 150 ltr. voltage: 400 V engine output: 7.5 kW Weight: 4320 kg range L-W-H: 2250 x 1960 x 2750 mm Demonstration/demo machine () From our showroom (like new) With very few operating hours -------------------------------------------------- CNC press brake with special equipment Version ERGO - knee room for the operator flexible articulated arm mount for the controller increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA-66T graphic/touch screen 2D graphi ...

pressure: 175 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 12.0 mm/min return speed: 190 mm/sec work stroke: 275 mm dayligth: 550 mm oil volume: 300 ltr. table height: 900 mm table width: 90.0 mm voltage: 400 Volt total power requirement: 15.0 kW weight: 9800 kg range L-W-H: 4150 x 2150 x 2800 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot tool R ...

pressure: 200 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 250 mm ram stroke speed: 100 mm/sec return speed: 75,0 mm/sec work speed: 7,0 mm/min work stroke: 180 mm dayligth: 415 mm oil volume: 200 ltr. table height: 900 mm voltage: 400 Volt range L-W-H: 4450x2050x2650 mm Furnishing: - DELEM - CNC control model DA-58T - controlled axes: Y1 - Y2 and X - FIESSLER AKAS - laser protection in front of the machine - Deer foot upper tool - Universal die block - manual table crowning - Safety device: light barrier behind the machine - 2 front support arms - SIEMENS - electrical system - BOSCH / HOERBIGER hydraulic system - CE mark / declaration of conformity - Operating manual: machine and control - Safety manual: press brakes The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 400 t chamfer lenght: 4100 mm distance between columns: 3550 mm column arm: 510 mm ram stroke speed: 110 mm/sec work speed: 8.4 mm/sec return speed: 130 mm/sec work stroke: 375 mm dayligth: 650 mm table height: 1000 mm table width: 240 mm back stop - adjustable: max. 800 mm oil volume: 400 ltr. voltage: 400 Volt total power requirement: 30.0 kW weight: 26409 kg range L-W-H: 5450 x 2650 x 3470 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 ...

Pressure:175 t chamfer lenght:4100 mm distance between columns:3600 mm column arm:410 mm ram stroke speed:180 mm/sec return speed:135 mm/sec working speed:10 mm/sec work stroke:275 mm oil volume:200 l dayligth:550 mm table height:900 mm table width:90 mm total power requirement:15 kW weight of the machine ca.:12000 kg dimensions of the machine ca.:5100 x 2150 x 2850 mm

sheet width: 3100 mm plate thickness: 10 mm cutting angle: 2 ° down holder: 14 Stück no. of strokes: 13 Hub/min throat: 350 mm oil volume: 260 l total power requirement: 22 kW weight of the machine ca.: 10.550 kg dimensions of the machine ca.: 4000x2250x2050 mm Domestic equipments: - Hydraulic swing cut sheet metal shears - Touch screen controller with digital display for backgauge - automatic kerf adjustment via the control - Backgauge control 1000 mm travel with recirculating ball screws - Vibration cutting machine with kerf adjustment - 2 support arms - 1 side stop - Photocell behind the machine - Cutting length limit - cut line lighting - Chrome steel knife - Ball rolls in the table - hinged finger guard with limit switch - Footswitch - CE mark / Declaration of Conformity - Bed instructions in German The data for this ad was created with ModulMWS - the software solution of LogoTe ...

sheet width: 3100 mm plate thickness: 6 mm voltage: 380 V control: CYBELEC CybTouch down holder: 14 Stück cutting angle: 1,2 ° total power requirement: 11 kW weight of the machine ca.: 5700 kg dimensions of the machine ca.: 4000x2100x1640 mm Accessories / equipment: - CYBELEC Cybtouch touch screen controller - NC controller for backgauge, gap adjustment, number of pieces, cutting length - 1 side stop with scale, T-groove and tilting cam - 2 front support arms - cut line lighting - Cutting gap adjustment - Cutting length limit - Folding finger guard with limit switch - motorized back gauge 1.000 mm travel - Ball screws - Photocell behind the machine - Ball rolls in the table - SIEMENS electrical system - BOSCH / HOERBIGER hydraulic system - Footswitch - CE mark / Declaration of Conformity - Operating manual: Machine and control in German The data for this ad was created with ModulMWS  ...

sheet width: 3100 mm plate thickness: 6 mm voltage: 380 V control: CYBELEC CybTouch down holder: 14 Stück cutting angle: 1,2 ° total power requirement: 11 kW weight of the machine ca.: 6.300 kg dimensions of the machine ca.: 4000x2100x1640 mm Equipment: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Quantity Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom. can be folded up at max. Traverse path, for longer cuts - 1x side stop - 2x front support arms - Ball casters in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - fo ...

sheet width: 3100 mm plate thickness: 13 mm thickness at Niro-steel: 8 mm control: CYBELEC CybTouch down holder: 14 Stück cutting angle: 2,0° ° no. of strokes: 11 Hub/min voltage: 380 V total power requirement: 22 kW weight of the machine ca.: 12.100 kg dimensions of the machine ca.: 4000x2240x2235 mm Accessories / equipment: - CYBELEC-CybTouch control panel with digital display for backgauge - hydr. Cutting gap adjustment via control - 1 side stop - 4 front lifting arms - cut line lighting - Cutting gap adjustment - Cutting length limit - Ball rolls in the table - motorized back gauge 1.000 mm travel with recirculating ball screws,    automatically start at the end of the stop - Shear knives for stainless steel cuts as standard - Photocell behind the machine - SIEMENS electrical system - BOSCH / HOERBIGER hydraulic system - Footswitch - Operating instructions in German The data f ...

sheet width: 3100 mm plate thickness: 10 mm cutting angle: 2 ° down holder: 14 Stück no. of strokes: 13 Hub/min throat: 350 mm oil volume: 260 l control: CYBELEC CybTouch 8 total power requirement: 22 kW weight of the machine ca.: 10.550 kg dimensions of the machine ca.: 4000x2250x2050 mm Domestic equipments: - Hydraulic swing cut sheet metal shears - Touch screen controller with digital display for backgauge - automatic kerf adjustment via the control - Backgauge control 1000 mm travel with recirculating ball screws - Vibration cutting machine with kerf adjustment - 2 support arms - 1 side stop - Photocell behind the machine - Cutting length limit - cut line lighting - Chrome steel knife - Ball rolls in the table - hinged finger guard with limit switch - Footswitch - CE mark / Declaration of Conformity - Bed instructions in German The data for this ad was created with ModulMWS - the ...

ERMAK CNC HVR 3100 x 13 hydraulic guillotine shears built in Turkey in 2008, are designed for cutting workpieces made of among others mild steel or stainless steel. The metal sheet with a maximum length of 3100 mm and a maximum thickness of 8 mm (plain steel) or 13 mm (stainless steel), is held during machining by 14 hydraulic clamps. The angle of the cutting blade can be freely adjusted in the range from 0.5° to 2.0°. Full control over the operation of the CNC HVR 3113 machine is guaranteed by the control panel located on the guillotine shears body with installed CYBELEC DNC 60 CNC controller, allowing programming of many different machining processes. The guillotine shears is equipped with among others new cutting blades and a foot control pedal, making the operator’s work much more comfortable and simple. The total weight of the machine is 13400 kg. The total weight of the mach ...

ERMAK HGS 2600 X 6 guillotine shears built in 2006 in Turkey are designed for cutting sheet metal with a maximum thickness of 6 mm. The machine performs this process using precise cutting knives with an option to adjust the gap between the blades. The simple design, with an efficient drive system, further ensures trouble-free operation throughout its lifetime, while maintaining the highest cutting quality. The ERMAKSAN HGS 2606 guillotine shears weighs 5000 kg. Technical specifications of the ERMAK HGS 2600 X 6 guillotine shears - maximum workpiece thickness: 6 mm - maximum workpiece length: 2600 mm - number of strokes: 20/min - oil tank capacity: 150 l - motor power: 11 kW - power supply: 380 V - dimensions (L x W x H): 3395 x 1880 x 1550 mm - weight of machine: 5000 kg

ERMAK GMR 2600 X 4 mechanical guillotine shears were built in 2007 in Turkey by ERMAKSAN MAKINA SANAYI TIC. LTD. ŞTI. The machine, designed for precision cutting of workpieces with a maximum thickness of 4 mm, offers high reliability, precision and efficiency. The machining process is performed by high alloy steel cutting knives with adjustable gap between blades. Automatic hold-down system, in turn, prevent the sheet metal from sliding during machining, ensuring uninterrupted production of repeatable parts. Moreover, the operator’s daily work is facilitated by the convenient foot switch control and the intuitive NC control, which allows the creation of machining programmes in just a few steps. The GMR 2600 X 4 guillotine shears weighs 3750 kg. Technical specifications of the ERMAK GMR 2600 X 4 guillotine shears - NC control - maximum workpiece length: 2600 mm - maximum workpiec ...

ERMAK RPP 1270X30 punching machine was built in 2013 in Turkey by ERMAKSAN MAKINA SANAYI VE TIC. AŞ. The machine, which is distinguished by its high productivity and precision, is used in the machining of thin sheet metal with a maximum thickness of 6.35 mm. All machining processes are performed on a large brush table by a reliable working head, which operates with a maximum force of 30 tonnes. The brush table prevents scratches and nicks on the sheet metal surface during material feed, and also significantly reduces noise level. All this is complemented by a FANUC CNC control with an intuitive interface that allows advanced machining programmes to be created in just a few steps. The ERMAK RPP 12730 CNC punching machine weighs 11000 kg. It is also possible to purchase Metalix CAD/CAM software at an additional cost of 10500 EUR net. Technical specifications of the ERMAK RPP 1270X30 ...

Key data: 3100 mm, 6 mm

Hinged backgauge, manual cutting gap adjustment, lighting, cutting length adjustment, Machine is repaired, checked, cleaned by a professional and is then fully functional. Test run is carried out. Sheet width: 3100 mm Sheet thickness steel: 6.0 mm Sheet thickness front: 4.0 mm Colour: grey/blue Total power requirement: 11 kW Machine weight: 900 kg Dimensions: 4000 x 2150 x 1640 mm Cutting gap adjustment: 0.05 -0.80 mm Hold-down: 14 Stroke rates per minute approx.: 19 stroke/min Cutting Angle: 1.2 Adjustable back gauge Back gauge: 1000 mm Machine number: SN20080583

sheet width: 3100 mm plate thickness: 6,0 mm thickness at Niro-steel: 4,0 mm distance between columns: 3100 mm down holder: 14 Stück oil volume: 150 ltr. cutting angle: 1,2 ° no. of strokes: 18 Hub/min control: CYBELEC CybTouch total power requirement: 11,0 kW weight: 6300 kg range L-W-H: 4.000 x 2.100 x 1.640 mm -------------------------------------------------- electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment -------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Quantity Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom. Can be fol ...

sheet width: 3100 mm plate thickness: 13.0 mm thickness at Niro-steel: 8.0 mm down holder: 14 Stück no. of strokes: 11 - 20 Hub/min oil volume: 310 ltr. cutting angle: 0.05 - 2.0 ° throat: 350 mm table height: 900 mm total power requirement: 22.0 kW weight of the machine ca.: 13400 kg range L-W-H: 5.110 x 2.570 x 2.400 mm Current new price approx. 80.000 Euro Special price upon request - in checked conditions - machinevideo - https://www.youtube.com/watch?v=K4ymYMIJ7_Y ----------------------------------------------------------- Robust electro-hydraulic CNC sheet metal shear with slide guides Includes CYBELEC DNC 60 CUT control system Includes CNC electro-hydraulic cutting gap adjustment Includes CNC electro-hydraulic cutting angle adjustment ---------------------------------------------------------- Equipment: - CNC electro-hydraulic guillotine shear with slide guides - Includes C ...

sheet width: 3100 mm plate thickness: 6,0 mm distance between columns: 3.100 mm down holder: 14 Stück no. of strokes: 16 - 24 Hub/min oil volume: 150 ltr. cutting angle: 0,5 - 1,5 ° thickness at Niro-steel: 4,0 mm column arm: 350 mm engine output: 11,0 kW weight of the machine ca.: 7.060 kg range L-W-H: 4100 x 2200 x 2190 mm -------------------------------------------------- electr. / hydraulic CNC guillotine shears - guided by a backdrop with CYBELEC CNC touch screen control with electr. / hydr. Cutting gap and cutting angle adjustment -------------------------------------------------- Furnishing: - CNC guiding guillotine shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Number of pieces Cutting length limitation Material preselection, including s ...

sheet width: 3100 mm plate thickness: 13,0 mm thickness at Niro-steel: 8,0 mm down holder: 14 Stück no. of strokes: 11 - 20 Hub/min oil volume: 310 ltr. cutting angle: 0,05 - 2,0 ° throat: 350 mm table height: 900 mm total power requirement: 22,0 kW weight of the machine ca.: 13.300 kg range L-W-H: 5.110 x 2.570 x 2.400 mm -------------------------------------------------- heavy electr. / hydraulic CNC guillotine shears - guided by a backdrop with CYBELEC CNC touch screen control with electr. / hydr. Cutting gap and cutting angle adjustment -------------------------------------------------- Furnishing: - CNC guillotine guiding shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Number of pieces Cutting length limitation Material preselection, includi ...

pressure: 175 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 180 mm/sec return speed: 135 mm/sec work speed: 10,0 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 90,0 mm oil volume: 200 ltr. voltage: 400 Volt total power requirement: 15,0 kW weight: 11.950 kg range L-W-H: 5100 x 2150 x 2850 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA-58T graphics / touchscreen 2D graphic programming 15 high definition color TFT screen Bending sequence calculation Product programming and display in real size USB interface - Motorized backgauge with R-axis, on recirculating ball spindles - ...

sheet width: 3100 mm plate thickness: 13,0 mm thickness at Niro-steel: 8,0 mm down holder: 14 Stück no. of strokes: 11 Hub/min oil volume: 310 ltr. cutting angle: 2,0 ° throat: 350 mm table height: 900 mm total power requirement: 22,0 kW weight of the machine ca.: 12200 kg range L-W-H: ca. 4100 x 2300 x 2235 mm -------------------------------------------------- heavy electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment -------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Number of pieces Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom ...

sheet width: 3100 mm plate thickness: 10,0 mm thickness at Niro-steel: 6,0 mm down holder: 14 Stück no. of strokes: 13 Hub/min oil volume: 260 ltr. cutting angle: 2,0 ° throat: 350 mm engine output: 22,0 kW back stop - adjustable: 1.000 mm weight: 10.575 kg. range L-W-H: 4,05 x 2,5 x 2,17 m -------------------------------------------------- heavy electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment -------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Quantity Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom. Can be folded up at max.trav ...

pressure: 100 t chamfer lenght: 2600 mm distance between columns: 2200 mm column arm: 410 mm ram stroke speed: 200 mm/sec work speed: 9.5 mm/sec return speed: 155 mm/sec work stroke: 275 mm dayligth: 530 mm table height: 900 mm table width: 90.0 mm oil volume: 150 ltr. voltage: 400 Volt total power requirement: 7.5 kW weight: 6850 kg range L-W-H: 3750 x 1950 x 2800 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA 53T (touchscreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Upper deer foot tool with PS 135.8 ...

pressure: 220 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 185 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 930 mm table width: 200 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 18.5 kW weight: 11286 kg Dimensions (HxWxD): 4550 x 2250 x 2850 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot ...

pressure: 175 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 12.0 mm/sec return speed: 190 mm/sec work stroke: 275 mm dayligth: 550 mm oil volume: 300 ltr. table height: 900 mm table width: 90.0 mm voltage: 400 Volt total power requirement: 15.0 kW weight: 12100 kg range L-W-H: 5.100x2.150x2.850 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot tool R ...

pressure: 135 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 200 mm/sec work speed: 12.0 mm/sec return speed: 190 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 15.0 kW weight: 10800 kg range L-W-H: 5100 x 2100 x 2850 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot tool Roleri 135.85.R08, Sy ...

pressure: 220 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 185 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 160 mm back stop - adjustable: max. 800 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 18.5 kW weight: 14000 kg range L-W-H: 5150 x 2250 x 3000 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 ...

table length: 4000 mm table width: 2000 mm burner heads: Precitec Procutter x-axis: 4050 mm z-axis: 150 mm y-axis: 2050 mm total power requirement: 18,0 kW weight of the machine ca.: 18.150 kg dimensions of the machine ca.: 12430 X 5664 X 2310 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 220 t chamfer lenght: 3760 mm distance between columns: 3250 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 160 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 160 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 18.5 kW weight: 12906 kg range L-W-H: 5100 x 2250 x 2900 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA 58T (TouchScreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Upper deer foot tool with PS 135 ...

pressure: 320 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 410 mm ram stroke speed: 140 mm/sec work speed: 10.5 mm/sec return speed: 150 mm/sec work stroke: 375 mm dayligth: 650 mm table height: 900 mm table width: 240 mm oil volume: 400 ltr. voltage: 400 Volt total power requirement: 30.0 kW weight: 17082 kg Dimensions (HxWxD): 4550 x 2450 x 3200 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot ...

pressure: 40.0 t chamfer lenght: 1270 mm distance between columns: 1050 mm column arm: 350 mm dayligth: 387 mm work stroke: 170 mm table height: 850 mm back stop - adjustable: 800 mm adjustment speed: 230 mm/min ajustment speed: 140 mm/sec working feed: 10.0 mm/sec return speed: 170 mm/sec total power requirement: 5.5 kW weight of the machine ca.: 3220 kg dimensions of the machine ca.: 2150 x 1650 x 2300 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA 58T (TouchScreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by C ...

pressure: 160 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 250 mm ram stroke speed: 90.0 mm/sec work speed: 7.5 mm/sec return speed: 80.0 mm/sec work stroke: 160 mm dayligth: 395 mm table height: 900 mm back stop - adjustable: max. 800 mm oil volume: 200 ltr. voltage: 400 Volt total power requirement: 11.0 kW weight: 7524 kg range L-W-H: 4250 x 1900 x 2550 mm Furnishing: - DELEM CNC control model DA-66T graphic/touch screen 2D graphical programming 17 TFT color screen with high resolution Bending sequence calculation Product programming and real size display USB interface intuitive, graphical entry of profiles Automatic calculation of features: tool safety zones, Press force, bending tolerance, crown setting, stretched Length, embossing force, flattening, automatic rounding calculation Radius programming Graphic tool and product library Collision mo ...

pressure: 80.0 t chamfer lenght: 2600 mm distance between columns: 2200 mm column arm: 250 mm ram stroke speed: 90.0 mm/sec work speed: 7.5 mm/min return speed: 60.0 mm/sec work stroke: 160 mm dayligth: 380 mm table height: 900 mm oil volume: 150 ltr. voltage: 400 Volt weight: 5227 kg range L-W-H: 3750 x 1950 x 2400 mm Furnishing: - DELEM - CNC control model DA-58T - controlled axes: Y1 - Y2 and X - AKAS laser in front of the machine - manual crowning - Upper tool, deer foot - Lower tool, die block with 4Vs - SICK light barrier behind the machine - 2 front support arms - SIEMENS - electrical system - BOSCH / HOERBIGER hydraulic system - CE mark / declaration of conformity - Operating manual: machine and control - Safety manual: press brakes The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 160 t chamfer lenght: 3760 mm distance between columns: 3250 mm column arm: 250 mm ram stroke speed: 90.0 mm/sec work speed: 7.5 mm/min return speed: 80.0 mm/sec work stroke: 160 mm dayligth: 395 mm table height: 900 mm oil volume: 200 ltr. voltage: 400 Volt weight: 8514 kg range L-W-H: 4910 x 1900 x 2550 mm Furnishing: - DELEM - CNC control model DA-58T - controlled axes: Y1 - Y2 and X - SICK light barrier in front of the machine - Upper tool, deer foot - Lower tool, die block with 4Vs - manual table crowning - SICK light barrier behind the machine - 2 front support arms - SIEMENS - electrical system - BOSCH / HOERBIGER hydraulic system - CE mark / declaration of conformity - Operating manual: machine and control - Safety manual: press brakes The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 175 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 135 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 90.0 mm oil volume: 200 ltr. voltage: 400 Volt total power requirement: 15.0 kW weight: 9450 kg range L-W-H: 4250 x 2150 x 2800 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA-58T graphic/touch screen 2D graphical programming 15 TFT color screen with high resolution Bending sequence calculation Product programming and real size display USB interface - Motorized backgauge with R-axis, on ball screws - X = 800 mm R =  ...

table length: 3000 mm table width: 1500 mm laser capacity in Watt: 4.000 Watt x-axis: 3050 mm z-axis: 150 mm y-axis: 1550 mm burner heads: Precitec HPSSL total power requirement: 22,0 kW weight of the machine ca.: 14.200 kg range L-W-H: 10.360 x 5.110 x 2.310 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 60,0 t square edge steel: 35,0 mm round bar steel: 40,0 mm L-beam: 120x120x12 mm punching cross-cut in cmm: Ø28 in 15 / Ø38 in 11 mm throat: 220 mm flat steel: 200x20 / 300x15 mm blade length: 317 mm oil volume: 45,0 ltr. work height max.: 940 / 1140 mm strokes per minute: max. 26 work stroke: 55,0 mm total power requirement: 4,0 kW weight of the machine ca.: 1425 kg. Dimensions (HxWxD): 1510 x 590 x 1570 mm Furnishing: - Support table at the hole punch - Support table on the square notcher - foot switch - Bed. Instructions - CE declaration + MUBEA - punch and die holder The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3100 mm plate thickness: 6,0 mm thickness at Niro-steel: 4,0 mm down holder: 14 Stück no. of strokes: 20 Hub/min cutting angle: 1,2 ° control: CYBELEC CybTouch work height max.: 800 mm oil volume: 150 ltr. total power requirement: 11,0 kW weight: 5500 kg range L-W-H: 4.000 x 2.410 x 1.640 mm ------------------------------------------------- electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment ------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Quantity Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom. Can be folded up at ma ...

sheet width: 2600 mm plate thickness: 8,0 mm thickness at Niro-steel: 5,0 mm down holder: 12 Stück no. of strokes: 18 Hub/min oil volume: 200 ltr. cutting angle: 1,5 ° engine output: 15,0 kW weight of the machine ca.: 6.300 kg range L-W-H: 3525 x 2350 x 1700 mm ------------------------------------------------- electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment ------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Quantity Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom. Can be folded up at max.travel, for longer cuts - 1x side stop - 2 ...

sheet width: 4100 mm plate thickness: 10,0 mm thickness at Niro-steel: 6,0 mm down holder: 28 Stück no. of strokes: 18 Hub/min oil volume: 260 ltr. cutting angle: 0,5 - 2 ° control: CYBELEC Cybtouch engine output: 22,0 kW back stop - adjustable: 1000 mm range L-W-H: 6100 x 2580 x 2460 mm weight: 15.100 kg. -------------------------------------------------- electr. / hydraulic CNC guillotine shears - guided by a backdrop with CYBELEC CNC touch screen control with electr. / hydr. Cutting gap and cutting angle adjustment -------------------------------------------------- Furnishing: - CNC guillotine guillotine shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Number of pieces Cutting length limitation Material preselection, including sheet thickness  ...

sheet width: 3100 mm plate thickness: 10.0 mm thickness at Niro-steel: 6.0 mm down holder: 14 Stück no. of strokes: 13 Hub/min cutting angle: 2.0 ° throat: 350 mm back stop - adjustable: 1000 (+) mm oil volume: 260 ltr. engine output: 22.0 kW weight: 10.575 kg range L-W-H: 4100 x 2400 x 2170 mm Demonstration/demo machine () from our exhibition (like NEW) with very few operating hours -------------------------------------------------- heavy electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment -------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Number of pieces Cutting length limitation Material preselection, including sheet thickness Cutting line ligh ...

sheet width: 4100 mm plate thickness: 6,0 mm thickness at Niro-steel: 4,0 mm down holder: 18 Stück no. of strokes: 15 Hub/min oil volume: 150 ltr. cutting angle: 1,2 ° control: CYBELEC Cybtouch back stop - adjustable: 1000 mm work height max.: 800 mm engine output: 11,0 kW weight: 8.100 kg. range L-W-H: 5000 x 2410 x 1650 mm ------------------------------------------------- electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment ------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Quantity Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom. C ...

pressure: 60.0 t chamfer lenght: 2100 mm distance between columns: 1700 mm column arm: 410 mm ram stroke speed: 160 mm/sec work speed: 10.0 mm/sec return speed: 165 mm/sec work stroke: 275 mm dayligth: 530 mm table height: 900 mm table width: 90.0 mm oil volume: 150 ltr. voltage: 400 Volt total power requirement: 7.5 kW weight: 5640 kg range L-W-H: 3250 x 1960 x 2750 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA 53T (touchscreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Upper deer foot tool with PS 135 ...

sheet width: 2100 mm plate thickness: 6,0 mm ST 42 thickness at Niro-steel: 4,0 mm VA cutting angle: 1,2 Grad no. of strokes: 28 Hub/min oil volume: 150 ltr. down holder: 11 Stück control: CYBELEC CybTouch engine output: 11,0 kW back stop - adjustable: 1.000 mm table height: 800 mm weight: 4.500 kg range L-W-H: 3.010 x 2.100 x 1.640 mm ------------------------------------------------- electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment ------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Quantity Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws ...

pressure: 220 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 160 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 160 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 18.5 kW weight: 13800 kg range L-W-H: 5150 x 2250 x 3000 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA-58T graphics / touchscreen 2D graphic programming 15 high definition color TFT screen Bending sequence calculation Product programming and display in real size USB interface - Motorized backgauge with R-axis, on recirculating ball spindles - X ...

sheet width: 3100 mm plate thickness: 6,0 mm thickness at Niro-steel: 4,0 mm distance between columns: 3100 mm no. of strokes: 18 Hub/min down holder: 14 Stück oil volume: 150 ltr. cutting angle: 1,2 ° control: CYBELEC CybTouch total power requirement: 11,0 kW weight: 6300 kg range L-W-H: 4.000 x 2.100 x 1.640 mm -------------------------------------------------- electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment -------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Number of pieces Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom. Ca ...

sheet width: 3100 mm plate thickness: 6,0 mm distance between columns: 3.100 mm down holder: 14 Stück no. of strokes: 16 - 24 Hub/min oil volume: 150 ltr. cutting angle: 0,5 - 1,5 ° thickness at Niro-steel: 4,0 mm column arm: 350 mm engine output: 11,0 kW weight of the machine ca.: 7.060 kg range L-W-H: 4,1 x 2,2 x 2,19 m -------------------------------------------------- electr. / hydraulic CNC guillotine shears - guided by a backdrop with CYBELEC CNC touch screen control with electr. / hydr. Cutting gap and cutting angle adjustment -------------------------------------------------- Furnishing: - CNC guillotine guillotine shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Number of pieces Cutting length limitation Material preselection, including s ...

pressure: 320 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 140 mm/sec work speed: 10.5 mm/sec return speed: 150 mm/sec work stroke: 375 mm dayligth: 650 mm table height: 900 mm table width: 220 mm oil volume: 400 ltr. voltage: 400 Volt total power requirement: 30.0 kW weight: 22064 kg Dimensions (HxWxD): 5350 x 2450 x 3150 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot ...

pressure: 40.0 t chamfer lenght: 1270 mm distance between columns: 1000 mm column arm: 200 mm stroke: 100 mm dayligth: 308 mm ajustment speed: 150 mm/sec working feed: 1-10 mm/sec return speed: 100 mm/sec table width: 100 mm table height: 900 mm control: DNC 60 PS oil volume: 100 l voltage: 400 V total power requirement: 5.5 kW weight of the machine ca.: 2750 kg Equipment: - CNC electro-hydraulic press brake - CYBELEC DNC 60 PS CNC control Swiveling control panel, front left Tool & program library - CNC electro-motorized backgauge (X-axis) X-axis travel = 800 mm 2x manually adjustable backgauge fingers (R+Z axes) Backgauge on ball screws - CNC controlled axes Y1 - Y2 - X - Rehfuß upper tool system A with quick-change clamping Additional crowning device in the tool holder - 4V universal die block with 60 mm die shoe - 2x sliding material/support arms (Sliding System) - BOSCH/HOERBI ...

This ERMAK EPP 1270 x 30 was manufactured in 2010. It features a punching force of 30 tons, a capacity of 6 mm, and can deliver up to 700 strokes per minute. The machine has a motor power of 11 kW and an oil capacity of 300 liters. Dimensions are 4000 mm in width, 4250 mm in length, and 2330 mm in height. Contact us for more information about this machine.

This 4-axis ERMAK CNC HAP 3100x200 was manufactured in 2007. A robust hydraulic press with a press capacity of 200 tons and a bending length of 3100 mm. It operates with an Ermak ER70 CNC control system and has a motor power of 15 kW. Ideal for heavy-duty bending tasks. Machine dimensions are 4550 × 2250 × 2850 mm, weighing 11,000 kg. Contact us for more information about this machine.

pressure: 135 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 135 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 90.0 mm control: ModEva 12S oil volume: 200 ltr. voltage: 400 Volt total power requirement: 11.0 kW weight: 8800 kg range L-W-H: 4250 x 2150 x 2800 mm current new price approx. 80.000 euros special price on request - in checked conditions - machinevideo - https://www.youtube.com/watch?v=ALo1SpWfnTk --------------------------------------------------------- SPEED BEND electro-hydraulic press brake with : increased installation height increased cylinder stroke increased throat depth --------------------------------------------------------- Equipment: - CNC electro-hydraulic press brake - CYBELEC ModEva 12S CNC control unit High-resolution screen  ...

sheet width: 3100 mm plate thickness: 6 mm rear stop: 1000 mm cutting angle: 1,2 ° down holder: 14 Stk no. of strokes: 18 Hub/min oil volume: 150 l total power requirement: 11 kW dimensions of the machine ca.: 3900 x 1900 x 1600 mm weight: 5500 kg Equipment: - Hydraulic swing cut shears - ELGO control system - Electric backgauge 1000 mm - Manual cutting gap adjustment - Cutting length limitation - Ball rollers in the table - 2x front support arms - 1x front side stop with scale - Front finger guard, hinged - Rear safety device (protective grille + light barrier) - Foot switch - Operating instructions The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Hydraulic press manufactured in 2006. This ERMAK CNC HAP 3100x300 features a pressing force of 300 tons and a bending length of 3100 mm. It is equipped with a high-precision Cybelec CNC control system and a robust steel frame construction, making it suitable for large and thick sheet metal bending. If you are looking to get high-quality bending capabilities, consider the ERMAK CNC HAP 3100x300 machine we have for sale. Contact us for further details.

ERMAK GMR 2600 X 4 mechanical guillotine shears were built in 2009 in Turkey by ERMAKSAN MAKINA SANAYI TIC. LTD. AŞ. The machine is designed for precision cutting of workpieces with a maximum length of 2600 mm and a thickness of 4 mm. The machining process is performed by means of cutting knives made of high-alloy steel, distinguished by their excellent cutting quality and high wear resistance. Thanks to the adjustable gap between the blades, it is possible to precisely adjust the cutting parameters to the type and thickness of the material being machined. In addition, along the cutting line there are material hold-downs which effectively hold the workpiece in place during machining. Daily operation is facilitated by the convenient foot switch control and the intuitive NC control system, enabling rapid programming of all the necessary parameters. All this is complemented by an extremely ...

Force of pressure: 75 t projection: 300 mm table size: 620 x 800 mm Durchfalloch in the table: 225 x 325 mm table adjustment: 175 mm plunger surface: 180 x 475 mm slide adjustment: 80 mm stroke adjustment: 16-140 mm stroke rate: 90 / min drive motor: 380 V, 3 kW space: 1700 x 1200 x 2500 mm weight: 3300 kg

; in order

Force of pressure: 63 t table size: 610 x 800 mm throat depth: 350 mm stroke: 200 mm Electr. Supply: 380 V, 15 kW space: 1800 x 920 x 2440 mm weight: 3940 kg

Capacity: 50 ton Projection: 225 mm Stroke: 320 p/min Large table: 500 x 800 mm

Pressing force: 40 t table size: 670 x 470 mm plunger surface: 670 x 470 mm clearance between the pillars: 620/470 mm gr. Height: 740 mm Preß speed: 20 mm / s rapid traverse: 50 mm ejector force: 3T Electr. Supply: 380 V, 9.5 kW space: 2200 x 1875 x 3000 mm weight: 2400 kg

Force of pressure: 30 to piston stroke: 150 mm table width: 185 mm passage (S): 530 mm bore (F): distance of 140 mm cylinders - table (F1): distance 150 mm cylinder - table (F2): 1030 mm cylinder movable (M): 200 mm width (A): (B depth of 800 mm): 700 mm height 1 (C): 1775 mm height 2 (D): 1805 mm weight: 162 kg

Force of pressure: 50T piston stroke: 200 mm table width: 260 mm passage (S): 730 mm bore (F): distance 205 mm cylinder - table (F1): distance 75 mm cylinder - table (F2): 1050 mm cylinder movable (M): 240 mm width (A): 1040 mm depth (B): 800 mm height 1 (C): 1835 mm height 2 (D): 1880 mm weight approx.: 287 kg

Pneumatic press 2643 Assembly through pivot table outside the working area With protective cage and release only with a retracted swing table Table size: 10 cm x 10 cm

Pneumatic press with foot-tripping

FRICTION BELT FOR SCREW PRESS DIRECT FROM THE MANUFACTURER! Description: -Chrome leather friction belt for screw presses, riveted, new! -Dimensions: 530 mm i. diameter x 50 mm high x 18 mm thick ON request make we the friction belts regarding to your sizes! For all machine types like SMS Hasenclever Berrenberg, Schuler, Weingarten, Vaccari, via, Mecolpress, Osterwalder... We deliver worldwide! We confirm best service and short delivery times.

With the universal hand punch NPR-20 can both on the front page as also Center of the punch be punched, so may here A4 sheet at any point are processed. The punch is suitable for cutting of printed materials in the Office, in the printer or in the copy shop. With a Nutmesser can A4 sheets are grooved. The NPR-20 is suitable for all cutting work, which can be with the NPR-10 through out. A countertop if necessary Additionally facilitates the stamping work

A roll punching press for stamping is available up to A3. The die is pulled under the roll.

Force of pressure: 100 t projection: 350 mm table size: 690 x 840 mm Durchfalloch in the table: 160 mm table adjustment: slide area: 450 x 600 mm slide adjustment: 80 mm stroke adjustment: 8-100 mm stroke rate: 60 / min drive motor: 380 V, 5.5 kW space: 1850 x 1850 x 2650 mm weight: 6800 kg

With the universal hole punch NPR-20 can both on the front page as also Center of the punch be punched, so may here A4 sheet at any point are processed. The punch is suitable for cutting of printed materials in the Office, in the printer or in the copy shop. With a Nutmesser can A4 sheets are grooved. The NPR-20 is suitable for all cutting work, which can be with the NPR-10 through out. A countertop if necessary Additionally facilitates the stamping work.

Pneumatic multi function press Operating pressure 6-8 bar Weight 106 kg dimensions 0.70 x 0.38 x 1.05 m Comments: Multi function punch air consumption 18 l per stroke, pneumatic punching operation via foot switch tripping

Tech. Data Nominal press force 1000 kN at maximum stroke adjustment - commute 6.5 mm 1250 kN at maximum stroke adjustment - commute 3.5 mm Strokes with endurance 125/83/63 Hube/min Usable stroke rate 50 50 38 / min. Throat depth 320 mm, clamp 380 mm Stroke adjustment 10-120 mm, Stosselverstellung 80 mm Stosselflaeche 800 x 320 mm, recording journal 50 / 85 Tabletop table top hole, 900 x 630 mm 230 mm, Durchfalloch in the table 300 / 400 x 250 mm Drive - 7,5 / 5,5 kW Bulk 1350 x 2080 x 2780 mm, Btto 8900 kg

Pressure: 65 tons -Stroke: 140 mm -Table size: 720 x 600 mm -Plunger surface: 500 x 300 mm -Tappet adjustment: 80 mm -Strokes: 20-40 per min. -. Weight: 6000 kg -Dimensions (L x W x H): height 3.1 m -Clamping hole ø 60 x 80 mm More info on request

Table 1750 x 920 mm, fixed stroke 101 mm, see pictures and description,; All right

various hand spindle presses small More: Foot pendulum press Jantsch

Transfer press KRUPP PST-A 160 built in 1980. Technical data of the KRUPP PST-A 160 press: - nominal pressure: 160 tons - cutting force grade 1: 400 KN - force between stands: 1200 KN - number of working steps including cutting stage: 11 - distance between stands: 200 mm - slider stroke: 210 mm - drawing depth: 70 mm - range of jumps, infinitely adjustable: 15-75 / min. - production range of jumps with repeatability of its setting: 25-75 / min. - number of actuation movements: 15-25 / min. - a usable work resource for a jump in the range of 25-75 strokes per minute. : 20,000 J - maximum load on a single step: 500 KN - maximum load of a single step using inserts: 630 KN - maximum width of the tape: approx. 340 mm - maximum diameter of the cut: 120 mm - minimum diameter of the pattern: 30 mm - distance between stands: 2450 mm - height of tool building at the lower posi ...

FRICTION BELT DIRECT FROM THE MANUFACTURER! Description: -Chrome leather friction belt for screw press, riveted, new! -Dimensions: 530 mm i.diameter x 50 mm high x 18 mm thick ON request make we the friction belts regarding to your sizes! For all machine types like SMS Hasenclever Berrenberg, Schuler, Weingarten, Vaccari, via, Mecolpress, Osterwalder... We deliver worldwide!

Technical data: -Compressive force 100 t -Throat 320 mm -Wide stand below the Guide 400 mm -Table size approx. 850 x 610 mm -Discontinued diarrhea hole in the table 335 / 300 mm -thickness of the table clamping plate 90 mm -gr. Height approx. 300 mm -Plunger area 600 x 335 mm -Adjustable height of the RAM 80 mm -Stroke adjustment 10-130 mm -Emissions er hub in the RAM 32 mm -Speed continuous operation approx. 56 / min -Drive 400 V / 11 kW -Space requirement approx. B H 1900 x 2800 X 2200 mm -Weight approx. 9000 kg Starring:-UVV press backup controller PREVENTA -Hydr. + pneumatically actuated clutch -LUTEX auxiliary braking system -Central lubrication

Pressure capacity: 8000 kg Maximum cutting area - 200 mm2 for material strength 40 kg / mm2 Horizontal radius 200 mm Clearance between the side walls 160 mm Fixed hub 35 mm Pin hole in the Stossel 38 x 60 mm Adjustability of the Stossels 70 mm Weight of 400 kg of the Presse Operating instructions The machine is located in the new value. State, probably never in use. Control actuator Stober

Universal - NPR-55U Stanze Knee lever punch -Punching of paper, cardboard and plastics. -for simple stamping -The cutting blades can be recorded from the shaft -The cutting blades can be created also not attached just under the pressure plate. -The pictured tools are not part of the offer.

Hydraulic glue press with heating base, infinitely variable temperature setting, stuffenlose setting of the adhesive holding time, Power: 5 kW, 380 v 50 Hz; Two-hand operation.

Pneumatic pin press for printed circuit boards

Pneumatic pin press for printed circuit boards

Hand lever press to push pins in printed circuit boards
