dmg mori milling machines used for sale

x-travel: 500 mm y-travel: 450 mm z-travel: 400 mm control: Siemens 840D total power requirement: 13/9 kW weight of the machine ca.: 4,7 t dimensions of the machine ca.: 3,4 x 2,5 x 2,2 m Brand DMG Mori Seiki Machine no F652 Type DMU 50 Ecoline Control Siemens 840D Year of make 2012 Table width 500 mm Table diameter 630 mm ø Table adjustable in degrees X 500 mm Y 450 mm Z 400 mm Spindle taper SK40 Speed minimum 20 RPM Speed maximum 10.000 RPM Maximum table load 200 kg Chip transport Machine size 3.400 x 2.500 x 2.200 mm Machine weight 4.700 kg Tool magazine positions: 30 B-as: -5/+110 ° C-as: 360 ° Engine power: 13/9 Kw The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Cross650 mmLongitudinal735 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools90 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.12400 KgNC swivel rotary table integrated in rigid tableType of Measuring system Direct measuring systemTable surface 800 x 650 (Ø 650) mmCentre bore 50 mmMaximum load (table centre) 600 KgSlot width 14 mmNumber of Slots 9Rotation Speed 5. Axis 20 rpm5. Axes (swivelling range) +120/-120 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeRot ...

GeneralUniversal Machining Centre in monoBLOCK construction - MPC Machine Protection Control; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal750 mmCross650 mmVertical560 mmTechnical DataDrive power (100% DC)25 kWDrive power (40% DC)35 kWTorque (100% DC)86 NmTorque (40% DC)130 NmSpeed range- 20000 rpmSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmMiscellaneousClamping SystemHSK-A 63 Floor space/WeightWeight approx.12300 KgNC swivel rotary tableTable surface 800 x 650 (Ø 650) mmCentre bore 50h6 mmMaximum load (table centre) 600 KgDirect measuring systemDir ...

GeneralUniversal machining centre; Control: Siemens 840D-Powerline ShopMill Classic Technical DataRapid traverse longitudinal/transverse/vertical60/60/60 m/minFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minWorking area 1Longitudinal1250 mmCross1000 mmVertical1000 mmMiscellaneousClamping SystemHSK-A 63 Tool changerType of magazineChain ApplicationUniversal Tool changer planehorizontal Type of gripperDouble gripper Automatic swivel milling headUniversal head: automatic changeover from vertical to horizontal machiningProd. package 40 bar/23 l/minProduction package 40 bar/23 l/min / 580 psi/6 gallon/min (theoretical pump performance) tank 900 l, rotating clear-view window, scraper flight conveyor coolant through spindle centre form ADNC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 1000 x 800 mmTool magazine,chain, 60 pockets ...

GeneralUniversal machining centre; Control: Siemens 840D-Powerline ShopMill Classic Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Cross1000 mmLongitudinal1250 mmVertical1000 mmMiscellaneousClamping SystemHSK-A 100 Tool changerApplicationUniversal Type of magazineChain Tool changer planehorizontal Type of gripperDouble gripper Automatic swivel milling headUniversal head: automatic changeover from vertical to horizontal machiningProd. package 40 bar/23 l/minCoolant through spindle centre form AD 40 bar/23 l/min / 580 psi/6 gallon/min (theoretical pump performance) clear-view rotating window Multi-jet unit at universal head, switchable from coolant to air (max. 6 bar / 90 psi) (6 water jets, 4 air jets) pumpNC rotary table with pallet changerType of Measuring system Direct measuring  ...

GeneralUniversal machining centre New DMG MORI Design; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal400 mmCross400 mmVertical375 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightDimensions (L x W x H)6,21 x 6,58 x 2,69 (6,21 x 7,38 x 2,69) mWeight approx.7200 KgDie and Mold Package linearDie and Mold Package linear Dynamic package V-type Eagle timing belt for Z axisPackage Mill / TurnPackage Mill / Turn (only available for Siemens 840D solutionline) NC-Mill-turn table 450x450 mm / 17.7x17.7 in rounded down to d460 mm / 18.1 in C ...

GeneralHSC-Precision Centre - Active chiller for main spindle and linear drives - Active chiller for electrical cabinet - Direct absolute measuring system with air purge - Coolant-airblast changeover - MPC (Machine Protection Control); Control: 3D-control Heidenhain iTNC 530 HSCI Technical DataSpindle taperHSK-E 50 Feed rate longitudinal/transverse/vertical1-80000/1-80000/1-80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minWorking area 1Cross580 mmLongitudinal450 mmVertical460 mmTool changerType of magazineChain ApplicationVertical Type of gripperDouble gripper Number of tools30 Rigid tableRigid table, clamping area 460 x 600 mm / 18,11 x 23,62 inch Loading weight max. 600 kg / 1322 lbsSpindle speed up to 40,000rpm with Shaft CoolingSpindle speed 20 up to 40,000 rpm within shaft cooling for tool taper HSK-E50 DIN 69893 AC-Main drive with 19,5/15 kW (100/40%DC) 14,5 ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1Drive power (100% DC) 14,5 kWDrive power (40% DC) 20,3 kWSpeed range 20 - 15000 rpmTorque (40% DC) 121 NmTorque (100% DC) 84 NmSpindle taper HSK-A 63Clamping System HSK-A 63Tool clamping for HSK-A63Tool clamping HSK-A63 according DIN 69893 (incl. adaptation working spindle and tool magazine)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working plane transformationTool magazine 60 ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal550 mmVertical420 mmCross450 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1 SK40 suitable for BIG-PLUS® toolsDrive power (100% DC) 14,5 kWDrive power (40% DC) 20,3 kWTorque (100% DC) 84 NmTorque (40% DC) 121 NmSpeed range 20 - 15000 rpmSpindle taper SK40 Tool holder DIN ISO 7388-1-AClamping System DIN ISO 7388-3-A, ADToolchanger with set up station for tool loadingNumber of tools 30NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working plane transformat ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1 SK40 suitable for BIG-PLUS® toolsDrive power (100% DC) 14,5 kWSpeed range 20 - 15000 rpmTorque (40% DC) 121 NmTorque (100% DC) 84 NmDrive power (40% DC) 20,3 kWSpindle taper HSK-A 63Clamping System HSK-A 63Tool clamping for HSK-A63Tool clamping HSK-A63 according DIN 69893 (incl. adaptation working spindle and tool magazine)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working p ...

GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 KgSlot width 14 mmNumber of Slots 5Spindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmTool magazine, cha ...

GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 KgSlot width 14 mmNumber of Slots 5Spindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmTool magazine, cha ...

GeneralHorizontal universal machining center; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal650 mmCross700 mmVertical950 mmCabineFull protection cabinMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Taper cleaning brushesTaper cleaning unit with rotating brushes for spindle taper HSKNC swivel rotary table DirectDriveNC swivel rotary table direct drive Table plate: d 650 mm / 25.6 in 1 x T-slot 14 H7 / 0.55 H7 (alignment groove, table centre) 8 x T-slot 14 H12 / 0.55 H7 (clamping grooves) Permissible load: 600 kg / 1,323 lbs Rotary-axis: 80 min-1 direct drive Swivel-aKinematics a ...

Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minGeneralHorizontal 5-axis universal machining centre; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal850 mmCross900 mmVertical1150 mmCabineFull protection cabinMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Taper cleaning brushesTaper cleaning unit with rotating brushes for spindle taper HSKNC swivel rotary table DirectDrive CNC swivel rotary table direct drive C-axis with pallet carrier Permissible load: 800 kg / 1,760 lbs C-axis: 80 min-1 direct drive A-axis: 15 min-1 single drive Rotation C axis: endlessly turning Swivel range A axis: +120°/-120° (replacement of base machKi ...

GeneralHorizontal machining centre - Horizontal milling head; Control: CELOS with Siemens 840D sl Operate Technical DataRapid traverse longitudinal/transverse/vertical60/60/70 m/minFeed rate longitudinal/transverse/vertical60000/60000/70000 mm/minWorking area 1Longitudinal800 mmCross1050 mmVertical900 mmCabineFull protection cabinDirect measuring systemDirect path measuring systemNC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 630 x 630 mmRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmNumber of Slots 5Slot width 14 mmMaximum load (table centre) 900 KgCentre bore 50 mm4. Axes (swivelling range) 360 x 0,001 degreePackage recirculation ballscrew spindlePackage recirculating ballscrew spindle X-,Z-axis:max. feed speed: 60.000 mm/min Y-axis: max. feed speed: 70.000 mm/min (basic machine without linear drive X-, Y-, Z-axis)Motor ...

GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Working area 1Longitudinal560 mmVertical600 mmCross600 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMiscellaneousClamping SystemDIN ISO 7388 CabineFull protection cabinNC rotary table with pallet carrierNC rotary table with pallet carrier permissible load 500 kg / 1,100 lbs (no indexing table 360 x 1° in basic machine)Table surface 400 x 400 mmMaximum load (table centre) 500 Kg4. Axes (swivelling range) 360 x 0,001 degreeTool magazine, chain Vert., 60 pocketsTool magazine Vertical chain magazine with 60 tool pockets SK 40 or optional chosen spindle tapersMotor spindle SK 40 18,000 rpmMain drive: Integrated motor spindle SK 40 Spindle speed max. 18,000 rpmDrive power (100% DC) 28 kWDrive power (40% DC) 34 kWSpi ...

GeneralVertical Machining Centres; Control: DMG MORI SLIMline® Multi-Touch control CharacteristicsTable surface900 x 560 mmMaximum load (table centre)600 KgDrive power (100% DC)9 kWSpeed max.12000 rpmDrive power (40% DC)13 kWDimensions (L x W x H)3,03 x 3,49 x 2,94 (5,8 x 5,5 x2,94) mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z600/560/510 mmSpindle taperSK 40 DIN 69871 Max. torque82 NmTool Magazine with30 PositionsTorque (100% DC)54 NmWeight approx.5200 KgDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable data exchange between the IoTconnector and CELOS APPs such as the NETservice. The integrated firewall with automatic updates ensures the hSafety Package for Power FailureSafety Package for Power ...

GeneralTwo spindle turning/milling centre with - Main and counter spindle; Control: CELOS with Siemens 840D sl Operate Tool holder 2Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.4000 rpmPower max. (40% DC)10 kWTool magazineNumber of tools24 Max. tool length230 mmMax. tool diameter80 mmMax. tool weight7 KgTurning-milling spindleSpindle taperHSK-A 63 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22,5 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking moment1000 NmSwivelling range+/-110 degreeSlide 3Longitudinal stroke1200 mmSlide 2Longitudinal stroke1200 mmTransverse stroke195 mmSlide 1Transverse stroke490 mmLongitudinal stroke1200 mmY axis, vertical+/- 100 mmHeadstock, rightClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWDri ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmMax. Turning Length1200 mmTurning diameter500 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 ...

Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length1200 mmBar diameter max.65 mmGeneral- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Work spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 ...

GeneralCNC Swiss type lathe with Fanuc control; Control: FANUC 310 iTB Working areaTurning diameter33 mmSpecial equipmentHinged belt chip conveyor with Discharge height 1200 mm Aut. bar feeder IEMCA BOSS 545/32 E, max_ L=3200 mm, incl. guide channel diam. 18 mm

GeneralIntegrated Mill Turn Center; Control: Control F31iB5 with CELOS CharacteristicsSwing- Ø, max.700 mmMilling spindle upper side1 Bar diametre80 mmSpeed max.4000 rpmMax. Turning Length1530 mmMax machining diameter670 mmDrive power tool spindle5,5/3,7 kWDrive power milling spindle28/23 kWDrive power main spindle18,5/15 kWMovements X / Z200/1542 mmLower Turret10 PositionsNumber of Toolmagazine positions38 Speed max.12000 rpmSlewability of B-Axis±120 degreeMovements X / Z / Y675/1562/300 (±150) mmWeight approx.18500 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and p(Left Spindle) through-spindle hole dia. 91 mm, 4,000min-1 (STD)(Left Spindle) Through-spindle Hol ...

GeneralUniversal machining centre; Control: Siemens 840D-Powerline ShopMill Classic Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal1250 mmCross1000 mmVertical1000 mmMiscellaneousClamping SystemHSK-A 63 Tool changerApplicationUniversal Type of magazineChain Tool changer planehorizontal Type of gripperDouble gripper Automatic swivel milling headUniversal head: automatic changeover from vertical to horizontal machiningProd. package 40 bar/23 l/minCoolant through spindle centre form AD 40 bar/23 l/min / 580 psi/6 gallon/min (theoretical pump performance) clear-view rotating window Multi-jet unit at universal head, switchable from coolant to air (max. 6 bar / 90 psi) (6 water jets, 4 air jets) pumpNC rotary table with pallet changerType of Measuring system Direct measuring s ...

GeneralUniversal machining centre; Control: 3D Control Siemens 840D powerline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal1250 mmCross1000 mmVertical1000 mmMiscellaneousClamping SystemHSK-A 100 Tool changerApplicationUniversal Type of magazineChain Tool changer planehorizontal Type of gripperDouble gripper Automatic swivel milling headUniversal head: automatic changeover from vertical to horizontal machiningProd. package 40 bar/23 l/minCoolant through spindle centre form AD 40 bar/23 l/min / 580 psi/6 gallon/min (theoretical pump performance) clear-view rotating window Multi-jet unit at universal head, switchable from coolant to air (max. 6 bar / 90 psi) (6 water jets, 4 air jets) pumpNC rotary table with pallet changerType of Measuring system Direct measuring system ...

GeneralVertical machining center in C-frame-design New DMG MORI Design Direct Measuring system X,Y,Z; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minWorking area 1Cross520 mmLongitudinal650 mmVertical475 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 TableTable surface 960 x 570 mmMaximum load (table centre) 800 KgSlot width 14 mmNumber of Slots 5Distance between T-Slots 100 mmSpindle speed 20.000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Tool magazine 60 pockets HSK-A63Tool magazine 60 pockets HSK-A63 Chain magazine with pockets and with double gripper, incl. manually direct t ...

GeneralTwo spindle turning/milling centre with - Main and counter spindle; Control: CELOS with Siemens 840D sl Operate Tool holder 2Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.4000 rpmPower max. (40% DC)10 kWTool magazineMax. tool length230 mmNumber of tools24 Max. tool diameter80 mmMax. tool weight7 KgTurning-milling spindleSpindle taperHSK-A 63 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22,5 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking moment1000 NmSwivelling range+/-110 degreeSlide 3Longitudinal stroke1200 mmSlide 2Longitudinal stroke1200 mmTransverse stroke195 mmSlide 1Longitudinal stroke1200 mmTransverse stroke490 mmY axis, vertical+/- 100 mmHeadstock, rightClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWDri ...

GeneralVertical-Machining centre Stealth Design; Control: CELOS with Heidenhain TNC 640 Technical DataRapid traverse longitudinal/transverse/vertical42/42/42 m/minFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minWorking area 1Cross700 mmLongitudinal1450 mmVertical550 mmIntegrated motor spindle speedMASTER®Integrated motor spindle speedMASTER® At speeds > 18.000 min-1, the use of tools with dual contact system (BIG-PLUS®) is stipulated.Drive power (100% DC) 25 kWDrive power (40% DC) 35 kWTorque (100% DC) 86 NmTableTable surface 1760 x 750 mmClamping System DIN ISO 7388-3-ADSpindle taper SK40 Tool holder DIN ISO 7388-1-ASpeed range - 20000 rpmTorque (40% DC) 130 NmSlot width 14 mmMaximum load (table centre) 1500 KgNumber of Slots 7Distance between T-Slots 100 mmCabin roofCabin roof In sheet steel design Open and close via front doorSpecial equipmentClamping pneuma ...

GeneralVertical-Machining centre Stealth Design; Control: CELOS X with Siemens 840D SL Operate CharacteristicsTable surface1460 x 750 mmMaximum load (table centre)1500 KgTool Magazine with40 PositionsMovement X / Y / Z1150/700/550 mmRapid feed X / Y / Z42/42/42 m/minWeight approx.12900 KgSpindle speed 20 - 12,000 rpm SK50, 288NmSpindle speed 20 - 12.000 rpm SK50 for tool taper according to DIN ISO 7388-1-A50 with power 44/32 kW // 59.0/42.9 hp with torque 288/187 Nm (40/100% DC) (differently from standard)Tool magazine 40 pocketsTool magazine 40 pockets SK50 chain magazine with pockets and double gripper, incl. manually direct loading into the tool magazineCoolant-air blast change-overCoolant - Air-blast changeover external switchable via M-FunctionAir blast through spindle centreAir blast through spindle centre activated by M function, maintained air with low oil rateInternal coolant su ...

GeneralVertical machining center in C-frame-design New DMG MORI Design Direct Measuring system X,Y,Z; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minWorking area 1Longitudinal650 mmCross520 mmVertical475 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools30 TableTable surface 960 x 570 mmMaximum load (table centre) 800 KgSlot width 14 mmNumber of Slots 5Distance between T-Slots 100 mmSpindle speed 15,000 rpm, 200 NmMotor spindle speedMASTER® SK 40 Spindle speed 20 - 15,000 min-1 Output 46 kW / 30 kW (62 hp / 40 hp) Torque 200 Nm / 130 Nm (148 ft lbs / 96 ft lbs) (40 / 100 % duty cycle) BIG-PLUS® tools possibleTool magazine 30 pockets SK40Tool magazine 30 pockets SK40 Chain magazine with pockets and with double gripper,  ...

CharacteristicsTable surface1460 x 750 mmMaximum load (table centre)1500 KgTool Magazine with30 PositionsMovement X / Y / Z1150/700/550 mmRapid feed X / Y / Z42/42/42 m/minWeight approx.12900 KgGeneralVertical-Machining centre Stealth Design; Control: CELOS X with Siemens 840D SL Operate Spindle speed 15,000 rpm, 200 NmMotor spindle speedMASTER® SK 40 Spindle speed 20 - 15,000 min-1 Output 46 kW / 30 kW (62 hp / 40 hp) Torque 200 Nm / 130 Nm (148 ft lbs / 96 ft lbs) (40 / 100 % duty cycle) BIG-PLUS® tools possibleTool magazine 30 pockets SK40Tool magazine 30 pockets SK40 Chain magazine with pockets and with double gripper, incl. manually direct loading into the tool magazineCoolant-air blast change-overCoolant - Air-blast changeover external switchable via M-FunctionAir blast through spindle centreAir blast through spindle centre activated by M function, maintained air with low oil rat ...

GeneralVertical Machining Centres; Control: DMG MORI SLIMline® Multi-Touch control CharacteristicsMaximum load (table centre)800 KgDimensions (L x W x H)3,3 x 2,7 x 2,94 mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z800/560/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with30 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmTable surface1100 x 560 mmWeight approx.5550 KgDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SysteminlineMASTER® spindle 12.000 rpminlineMASTER® spindle 12.000 rpm Spindle speed range 20 to 12.000 rpm Tool Taper SK40 DIN69871 with BIG PLUS inteface Tool clamping according to DIN69872 Power: 13kW (40% DC) / 9kW (100% DC) Torque: 83 Nm (40% DC) / 57 Nm (100% DC) bearings oil-air lubrSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872NC-D ...

General2 spindles automatic lathe - 2 cross slides - Main and counter spindle - Y axis on slide 1 - Y axis on slide 2 - C axis on main spindle - C axis on counter spindle - Chip tank with coolant system and coolant pump - Part unloading chute; Control: Numeric control Fanuc 32i Working areaBar diameter max.20 mmCounter spindle collet cleaningCounter spindle collet cleaning with coolantChanging kit from steady to sliding headstockChanging kit from steady to sliding headstock including application bush type Dunner B260 and bush-spindle syncronismAdditional charge for belt type chip conveyorAdditional charge for belt type chip conveyor, compatible with shaft-unloading-device Specific chip removol systems (for example: scraping blades chip conveyors, with additional filtering systems) are recommended in case of short chip material machininOil mist filter for emulsion or oilOil mist filter fo ...

GeneralVertical Machining centre; Control: DMG MORI ERGOline IV HEIDENHAIN TNC 7 CharacteristicsTable surface900 x 600 mmTool Magazine with60 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z30/30/30 m/minAC main driveSpindle speed range 20 to 15.000 rpm AC main drive:20/14,5 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemProduction Package 20 bar with chip conveyorProduction Package 20 bar with chip conveyor Option includes: - Internal coolant supply 20 bar - Chip conveyor (scraper type) with tank capacity: 200 l(left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - External electronic handwheAir coolant internal (through spindle centre)Air Coolant Internal (through spindle centre) switchable via M-Function maintained air wi ...

GeneralVertical Machining centre; Control: DMG MORI ERGOline X Multi-Touch control CharacteristicsTable surface900 x 600 mmTool Magazine with60 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z42/42/42 m/minSpindle speed range 20 to 12.000 rpmSpindle speed range 20 to 12.000 rpm AC main drive:13/9 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemProduction Package 20 bar with chip conveyorProduction Package 20 bar with chip conveyor Option includes: - Internal coolant supply 20 bar - Chip conveyor (scraper type) with tank capacity: 200 l(left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - External electronic handwheAir coolant internal (through spindle centre)Air Coolant Internal (through spindle centre) switchable via M-Func ...

GeneralUniversal Machining Centre Vertical headstock Tool change system double gripper NC-Swivel rotary table with pallet carrier 3 pallets 500 mm x 500 mm / 19.7 in x 19.7 in T-slots according to DIN 55201-A2 linear pallet changer coolant tank 500 l / 132 gallon chip conveyor with netting band filter integrated, coolant ring jet; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmFloor space/WeightWeight approx.18300 KgDirect measuring systemDirect path measuring systemCabineFull protection cabinNC swivel rotary table with pallet carrierTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 500 KgMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000  ...

GeneralVertical Machining centre; Control: DMG MORI ERGOline IV Multi-Touch CharacteristicsTable surface900 x 600 mmTool Magazine with30 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z30/30/30 m/minAC main driveSpindle speed range 20 to 15.000 rpm AC main drive:20/14,5 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemProduction Package 40 barProduction Package 40 bar Option includes: - Internal coolant supply 40 bar; - Tank capacity: 600l with papertype filter; - Chip conveyor (scraper type) with tank capacity: 200 l (left) - Bed flushing via M-Function - Coolant spray gun for swarf removal -Tool clamping buttons on the headstockTool Clamping and Unclamping Buttons placed on the Headstock CoverAir coolant internal (through spindle centre)Air Coola ...

GeneralVertical Machining centre; Control: Control SIEMENS ERGOline IV CharacteristicsTable surface1400 x 600 mmTool Magazine with60 PositionsMovement X / Y / Z1100/600/510 mmRapid feed X / Y / Z30/30/30 m/minAC main driveSpindle speed range 20 to 15.000 rpm AC main drive:20/14,5 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemProduction Package 20 bar with chip conveyorProduction Package 20 bar with chip conveyor Option includes: - Internal coolant supply 20 bar - Chip conveyor (scraper type) with tank capacity: 220 l (left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - External electronic handwhAir coolant internal (through spindle centre)Air Coolant Internal (through spindle centre) switchable via M-Function maintained air with low o ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmMax. Turning Length1200 mmBar diameter max.65 mmTurning diameter500 mmWork spindle (left)Diametre of spindle nose170h5 mmSpindle noseFlat flange Spindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 ...

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataRapid traverse longitudinal/transverse/vertical40/40/40 m/minFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.14500 KgMotor spindle 20,000 rpmMotor spindle speedMASTER® SK 40 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Tool magazine, chain vert., 60 pocketsTool magazine Vertical chain magazine basic with 60 magazine pockets SK 40 or optionally chosen spindle taper ...

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataRapid traverse longitudinal/transverse/vertical40/40/40 m/minFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.14500 KgNC swivel rotary table integrated in rigid tableType of Measuring system Direct measuring systemTable surface 800 x 650 (Ø 650) mmCentre bore 50 mmMaximum load (table centre) 600 KgSlot width 14 mm5. Axes (swivelling range) +120/-120 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between ...

GeneralHighly productive compact machining centres; Control: Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical1-60000/1-60000/1-60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross420 mmVertical380 mmMiscellaneousClamping SystemMAS 403 - 45° Floor space/WeightDimensions (L x W x H)1,65 x 2,34 x 2,5 (1,65 x 2,95 x 2,55) mWeight approx.4100 KgSpindle speed up to 24,000 r.p.m. BT30Spindle 24,000rpm with tool taper BT30 JIS B 6339 (MAS 403-45°) AC-Motor 20 / 4 KW (max. / 100% ED) Watercooling Spindle and Spindle motor via heat exchanger (fan)TableTable surface 840 x 420 mmMaximum load (table centre) 300 KgSlot width 14 mmNumber of Slots 2Clamping grid M 12, 100 x 100 mmTool clamping for BBT 30 (Big+)Tool taper BBT 30 - Big+ Pull stud MAS 403 - 45°Tool magazine 25 placesTool magazine 25 places (suita ...

GeneralVertical Machining Centre - Direct Measuring System X, Y, Z - Coolant air-blast changeover external switchable via M-Function; - Thermal compensation - DMG MORI NETservice; Control: DMG MORI ERGOline X Multi-Touch control Siemens CharacteristicsMovement X / Y / Z800/600/510 mmType of magazineChain Tool Magazine with30 PositionsClamping SystemDIN 69872 Spindle taperSK 40 DIN 69871 Drive power (40% DC)20 kWDrive power (100% DC)14,5 kWSpeed max.15000 rpmRapid feed X / Y / Z42/42/42 m/minTable surfaceØ 800 x 620 mmMovement C-Axis360 degreeMovement B-Axis(-15/+110) degreeType of gripperDouble gripper Production Package 20 bar with chip conveyorProduction Package 20 bar with chip conveyor Option includes: - Internal coolant supply 20 bar; - Chip conveyor (scraper type) with tank capacity: 205 l (left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - External electr ...

GeneralVertical Machining centre; Control: DMG MORI ERGOline IV Multi-Touch CharacteristicsTable surface900 x 600 mmTool Magazine with30 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z30/30/30 m/minAC main driveSpindle speed range 20 to 15.000 rpm AC main drive:20/14,5 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemTouch Probe Heidenhain TS 460Touch Probe HEIDENHAIN for workpiece measuring Option includes: - TS 460 Touch probe with optical signal transmission - measuring cycles - calibration ring - case for equipmentTouch probe Heidenhain TT160Touch Probe HEIDENHAIN for tool length and diameter measurement Option includes: - TT160 probe for tool measurement - measuring cycles with tool breakage monitoring - calibration tool Note: Additionally to ...

CharacteristicsTable surface900 x 600 mmTool Magazine with60 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z42/42/42 m/minGeneralVertical Machining centre; Control: DMG MORI ERGOline IV HEIDENHAIN TNC 7 Spindle speed range 20 to 12.000 rpmSpindle speed range 20 to 12.000 rpm AC main drive:13/9 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemProduction Package 80 barProduction Package 80 bar Option includes: - Internal coolant supply 80 bar - Tank capacity: 600l with papertype filter - Chip conveyor (scraper type) with tank capacity: 200 l (left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - EActive cooling systemActive cooling system for selected mechanical components in order to increase machine thermal stabilityAir coola ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaTurning diameter500 mmSwing diameter over guide ways500 mmMax. Turning Length1200 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-12000 rpmDrive power (100% ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length1200 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-12000 rpmDrive power (100% ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmMax. Turning Length1200 mmTurning diameter500 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle diametre on front bearing130 mmSpindle bore87 mmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking moment8 ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmBar diameter max.65 mmMax. Turning Length1200 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperCapto C6 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22 kWTorque ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length1200 mmBar diameter max.75 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS X with HEIDENHAIN TNC7 Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1 SK40 suitable for BIG-PLUS® toolsDrive power (100% DC) 14,5 kWDrive power (40% DC) 20,3 kWTorque (100% DC) 84 NmTorque (40% DC) 121 NmSpeed range 20 - 15000 rpmSpindle taper HSK-A 63Toolchanger with set up station for tool loadingNumber of tools 30Clamping System HSK-A 63IoTconnectorIoTconnector The IoTconnector allows the use of online services of DMG MORI (e.g. NETservice)NETserviceNETservice Qualified support by Internet-based remote diagnosticsMessenger V4Messenger V4 Clear presentation of the machine live status.Service AgentService Agent Overview of  ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 100 mm - B-axis ±110° with pneumatic locking - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 5 bar; 20l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor - USB interface, Ethernet interface; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length750 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWTorque (100% DC)280 NmSpeed range- 5000 rpmDrive power (40% DC)32 kWMax. torque (40% DC)360 NmC-Axis Speed-5000 rpmTorque of C-Axis (holding torque)280 NmT ...

Control CNC: HEIDENHAIN iTNC530 Axes X-axis travel mm: 200 Y-axis travel mm: 220 Z-axis travel mm: 280 C-axis degrees: 360º A-axis degrees: -15º max.130º Work Table Table dimensions mm: ø200 Maximum workpiece weight kg: 15 Spindle Spindle speed rpm: 42.000 Cooling Cooling through the spindle bar: 40 Tool System Tool holder: HSK-E32 Tool magazine slots: 60 Max. tool diameter mm: ø50 Max. tool length mm: 200 Chip-to-chip time s: 10 Equipment Automation LM100 (EROWA ITS72, 5 levels of 9 positions); 10 kg maximum manipulation Electronic handwheel Chip conveyor Infrared probe High-pressure pump NC rotary tilting table Rated power kVA: 40

GeneralUniversal milling machine with duoblock construction; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal800 mmCross1050 mmVertical850 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minTool changerApplicationUniversal Tool changer planehorizontal Type of magazineWheel Type of gripperDouble gripper Number of tools123 Coolant supply ICSCoolant supply: coolant through spindle centre form AD 40 bar/23 l/min(theoretical pump performance) rotating clear-view window Multi-jet unit at universal head, switchable from coolant to air (max. 6 bar, 6 water jets, 4 air jets) pump output (theoreticChip removalChip removal: 2 worm conveyors in the machine bed convey into a chip conveyor (scraper flight conveyor), with interval control, placed at right angles. discharge height: 950 mm /  ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length1200 mmBar diameter max.75 mmFloor space/WeightDimensions (L x W x H)5,86 x 2,07 x 2,3 mWeight approx.12000 KgTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking moment850 NmWork spindle (left)Spindle noseFlat flange Di ...

Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length1200 mmBar diameter max.65 mmGeneral- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Work spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle speed-12000 rpmSpindle  ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length1200 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-12000 rpmDrive power (100% ...

Key data: 750 mm, 650 mm, 560 mm

Universal CNC Machining Center Manufacturer: DMG Mori Type DMU75 Monoblock Year of manufacture 2014 IBN 2015 Control Heidenhain iTNC530 Control a 23.075h Engine a 22.287h Program run 12.946h Operating hours 12.891h Travels X/Y/Z 750/650/560mm Table size 800 x 650mm Table load 600kg C-axis b-axis -120° + 120° Tool holder HSK63 60 Compartment Tool Magazine IKZ 40bar Blum Wireless Push Button Electronic Handwheel HR410 Belt filter system 500l Motor power 35kW Torque 130/86/0 Machine is in a used very good condition. Geometrically very good. Without vice, without tool holders

GeneralUniversal Machining Centre Vertical headstock Tool change system double gripper NC-Swivel rotary table with pallet carrier 3 pallets 500 mm x 500 mm / 19.7 in x 19.7 in T-slots according to DIN 55201-A2 linear pallet changer coolant tank 500 l / 132 gallon chip conveyor with netting band filter integrated, coolant ring jet; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmFloor space/WeightWeight approx.17800 KgDirect measuring systemDirect path measuring systemCabineFull protection cabinPackage Mill / Turn HSK-A 63Package Milling / Turning: Upgrade NC-swivel rotary table to Milling - Turning / direct drive Pallet C-axis d 630 mm / 24.9 in Speed C-axis 1.000 rpm Integrated balancing sensor  ...

GeneralVertical Machining Centres; Control: DMG MORI SLIMline® Multi-Touch control CharacteristicsTable surface900 x 560 mmDimensions (L x W x H)3,03 x 3,49 x 2,94 (5,8 x 5,5 x2,94) mMovement X / Y / Z600/560/510 mmRapid feed X / Y / Z30/30/30 m/minSpindle taperSK 40 DIN 69871 Tool Magazine with60 PositionsMax. torque82 NmTorque (100% DC)54 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmMaximum load (table centre)600 KgWeight approx.5300 KgDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable data exchange between the IoTconnector and CELOS APPs such as the NETservice. The integrated firewall with automatic updates ensures the hProduction Package 40 barProduction Package 40 bar Optio ...

GeneralVertical Machining Centres; Control: Control F0iMF CharacteristicsTable surface1400 x 560 mmDimensions (L x W x H)3,19 x 2,76 x 2,94 (3,82 x 3,58 x 3,01) mRapid feed X / Y / Z36/36/30 m/minMovement X / Y / Z1100/560/510 mmSpindle taperBT 40 Tool Magazine with60 PositionsDrive power (25% DC)15 kWDrive power (100% DC)11 kWSpeed max.12000 rpmMaximum load (table centre)1000 KgWeight approx.5500 KgStandard spindle 12,000 min-1, 15/ 11 kWStandard Spindle 12,000 min-1, 15/ 11 kW Spindle speed: 12,000 min-1 Output: 15/13/11 kW (20/17.33/15 HP) (25%ED/30min/cont) Torque: 119/70/57 Nm (87.76/51.62/42.04 ft·lbf) (25%ED/30min/cont)Spindle Taper 7/24 Taper #40/ Grip MAS Spindle Taper 7/24 Taper #40/ Grip MAS This specification uses the spindle No. 40 7/24 taper / Grip MAS tool holder. The grip type and retention knob type of ATC are specified separately.Retention Knob: Special (Center-Throug ...

GeneralTwo-spindle turning centre with - 2 cross slides - 2 turrets with 12 positions each (all driven) - main spindle and counter-spindle - 2 C-axis - 2 tool drives - Y-axis on slide 1 - chip conveyor - workpiece-unloading; Control: Fanuc 31i Working areaBar diameter max.50 mmTransport beltTransport belt for finished workpieces outside the machineDMG MORI NETSERVICEDMG MORI NETSERVICE Qualified support by Internet-based remote diagnosticsIoT connectorDMG MORI IoTconnector The IoTconnector allows the use of online services of DMG MORI (e.g. NETSERVICE or MESSENGER on ADAMOS)Special equipmentAdditional bar capacity for main spindle from Ø 50 mm to Ø 65 mm (max. 5.500 RPM) Additional charge for cooling on turret (upgrade to) 50 bar instead of 25 bar

GeneralPrecision centre - Linear drive package - Active cooling for spindle, linear drives and electrical cabinet - Frame temperatur control - Direct measuring system - Chiptray, coolant/airblast changing - Full cabin including 2nd door; Control: 3D-control Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical1-80000/1-80000/1-80000 mm/minSpindle taperHSK-A 63 Rapid traverse longitudinal/transverse/vertical80/80/80 m/minWorking area 1Longitudinal650 mmCross600 mmVertical380 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools120 Floor space/WeightDimensions (L x W x H)7,28 x 6,63 x 3 mWeight approx.9600 KgRigid tableRigid table clamping area 850 x 600 mm // 33,46 x 23,62 inch loading weight max. 700 kg // 1543,23 lbsSpindle speed up to 28,000rpm Shaft CoolingSpindle speed 20 up to 28,000 rpm within shaft cooling inclusive MPC Machi ...

GeneralUniversal Milling Machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross520 mmVertical475 mmTechnical DataType of main driveAC Drive power (100% DC)16 kWDrive power (40% DC)21 kWSpeed range20 - 15000 rpmSpindle taperHSK-A 63 Clamping SystemHSK-A 63 Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgDirect measuring systemDirect path measuring systemSpindle speed 15,000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 15,000 min-1 Output 21 kW / 16 kW (28 hp / 21.5 hp) Torque 111 Nm / 85 Nm (82 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 630 x 500mm / 24.8 x 19.6 in swivel range -35 to +110° ...

GeneralHSC-Precision Centre - Active chiller for main spindle and linear drives - Active chiller for electrical cabinet - Direct absolute measuring system with air purge - Coolant-airblast changeover - MPC (Machine Protection Control); Control: CELOS X with HEIDENHAIN TNC7 Technical DataSpindle taperHSK-E 50 Feed rate longitudinal/transverse/vertical1-80000/1-80000/1-80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minTool changerApplicationVertical Type of magazineChain Type of gripperDouble gripper Number of tools60 Working area 1Longitudinal450 mmCross580 mmVertical460 mmSpecial equipmentFischer spindle 40,000 rpm with wave cooling 5-axis design Tool magazine 60 places HSK-E50 Production package high chip volume with IKZ (chip conveyor, rinsing gun, rotating viewing panel, AR flushing, IKZ 40 bar/600 1) Oil Mist Separator AFS BlowinSpecial equipmentPreparation aut ...

Working area 1Longitudinal700 mmCross420 mmVertical380 mmGeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMain driveDrive power (100% DC) 6 kWDrive power (40% DC) 8,5 kWClamping System ISO 7388-3 - JD30Spindle taper BT 30Speed range 20 - 10000 rpmTorque (40% DC) 48 NmTorque (100% DC) 41 NmIntegrated swivel rotary table simultaneousIntegated swivel rotary table 5-Axis simultaneous mode! Torque drives incl. direct measuring in A- and C-Axis Swivel range A-Axis -120 / + 100 degrees Max. load C-axis 100kg Table diameter C-Axis d290mm Inclusive Software package Sinumerik Mdynamics 5-axRotary joint, 4 channelsRotary joint for integrated swivel rotary table with torque drives 4- channe ...

GeneralUniversal machining centre New DMG MORI Design; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal400 mmCross400 mmVertical375 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightDimensions (L x W x H)6,21 x 6,58 x 2,69 (6,21 x 7,38 x 2,69) mWeight approx.7200 KgPackage Mill / TurnPackage Mill / Turn NC-Mill-turn table 450x450 mm / 17.7x17.7 in rounded down to d460 mm / 18.1 in C-axis direct drive, speed max.1,200 rpm Integrated balancing system Motorspindle 20-20,000 rpm power 35/25 kW (40/100% ED) tool taper HSK-A63 according D ...

GeneralUniversal Milling Machines; Control: DMG MORI SLIMline® Multi-Touch control Working area 1Longitudinal500 mmCross450 mmVertical400 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minFloor space/WeightDimensions (L x W x H)3,15 x 2,86 x 2,71 (4,14 x 2,91 x 2,71) mWeight approx.5000 KgSwivel Rotary Table Powered B/C AxesSwivel Rotary Table Powered B/C Axes with automatic hydraulic clamping Electronic angle indication (B&C Axes) and Working Plane transformation For positioning only!Mode for positioning only5. Axes (swivelling range) -5/+110 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeDistance between T-Slots 63 mmNumber of Slots 7Slot width 14 mmMaximum load (table centre) 200 KgTable surface Ø 630 x 500 mmType of Measuring system Direct measuring systemDirect measuring system ...

Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal650 mmCross700 mmVertical950 mmGeneralHorizontal universal machining center; Control: CELOS with Siemens 840D sl Operate CabineFull protection cabinMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Taper cleaning brushesTaper cleaning unit with rotating brushes for spindle taper HSKNC swivel rotary table DirectDriveNC swivel rotary table direct drive Table plate: d 650 mm / 25.6 in 1 x T-slot 14 H7 / 0.55 H7 (alignment groove, table centre) 8 x T-slot 14 H12 / 0.55 H7 (clamping grooves) Permissible load: 600 kg / 1,323 lbs Rotary-axis: 80 min-1 direct drive Swivel-aKinematics a ...

GeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Working area 1Longitudinal350 mmCross420 mmVertical380 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMain driveDrive power (100% DC) 6 kWDrive power (40% DC) 8,5 kWTorque (100% DC) 41 NmTorque (40% DC) 48 NmSpeed range 20 - 15000 rpmSpindle taper BT 30Clamping System ISO 7388-3 - JD30ToolchangertoolchangerTableTable surface 740 x 420 mmNumber of tools 15Type of magazine WheelMaximum load (table centre) 400 KgPreparation NC-Devider EA510 indirectPreparation 4.th axis Lehmann EA 510.L indirect measuring System Attention: Customer specific optimisations and adjustments are not part of delivery!Chip removal package with chip conveyorChip removal package with chip conveyor conte ...

GeneralVertical Machining Centre; Control: 3D control Heidenhain iTNC 530 Technical DataFeed rate longitudinal/transverse/vertical1-90000/1-90000/1-90000 mm/minRapid traverse longitudinal/transverse/vertical90/90/90 m/minWorking area 1Longitudinal885 mmCross600 mmVertical600 mmMiscellaneousClamping SystemHSK-A 63 Colour Floor space/WeightDimensions (L x W x H)4,9 x 4,3 x 3,2 mWeight approx.12000 KgCabineFull protection cabinDMC 75 V linear in 5-axes-versionAdditional price DMC 75V linear in 5-axes-version - motion in X=885mm und Z=600mm - spindle speed up to 18.000rpm, - tool-taper HSK-A 63, - swiveling range B-axis +10° to -110°, - swiveling speed B-axis 50rpm, - max. torque 750Nm / 553ft/lbs - clampiTool magazine 150 pocketsTool magazine 150 pockets Tower type magazine Only available for HSK Tool holders. (differently from standard)Number of tools 150Preparation measuring probe TS640 ...

GeneralUniversal milling and turning machining centre with duoBLOCK construction; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal800 mmCross1050 mmVertical850 mmTool changerApplicationUniversal Type of magazineWheel Tool changer planehorizontal Type of gripperDouble gripper Number of tools123 Uni milling head with controlled B axis HSK-A 63Universal milling head with controlled B axis HSK-A 63 Continuously positioning universal milling head (B axis) with integrated motor spindle for 5 axes positioning and simultaneous machiningNC mill-turn table with palletNC mill-turn table with pallet number of T-slots: - 1x cross slot 14 H7 / 0.55 H7 - 12x star slots 14 H11 / 0.55 H11 / 22.5° max. table speed milling operation: 30 rpm turning o ...

Working areaTurning diameter500 mmDistance between spindles1435 mmMax. Turning Length1100 mmGeneralTurning/milling center with turning length 1100 mm - mounting HSK-A 63 DIN 69893 - B-axis ±120 - Y-axis ±100 mm - 60-fold chain magazine - Absolute, direct path measuring systems in X-, Y- and Z-axis - Hydraulically movable tailstock with foot pedal - Double switch filter - Electric handwheel - DMG MORI IoT connector - Clamping pressure adjustment on the control - 5-axis simultaneous machining; Control: CELOS X with Siemens SINUMERIK ONE Main drive 1Drive power (100% DC)14 kWDrive power (40% DC)17 kWSpeed range- 5000 rpmTorque (100% DC)275 NmMax. torque (40% DC)345 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-15000 rpmDrive power (40% DC)22,5 kWDrive power (100% DC)19 kWTorque (100% DC)85 NmTorque (40% DC)120 NmFloor space/WeightDimensions (L x W x H)5,77 x 2,33  ...

GeneralTurning/milling center with turning length 1100 mm - mounting HSK-A 63 DIN 69893 - B-axis ±120 - Y-axis ±100 mm - 60-fold chain magazine - Absolute, direct path measuring systems in X-, Y- and Z-axis - Hydraulically movable tailstock with foot pedal - Double switch filter - Electric handwheel - DMG MORI IoT connector - Clamping pressure adjustment on the control - 5-axis simultaneous machining; Control: CELOS X with Siemens SINUMERIK ONE Working areaTurning diameter500 mmDistance between spindles1435 mmMax. Turning Length1100 mmMain drive 1Drive power (100% DC)14 kWDrive power (40% DC)17 kWSpeed range- 5000 rpmTorque (100% DC)275 NmMax. torque (40% DC)345 NmFloor space/WeightDimensions (L x W x H)5,77 x 2,33 x 2,51 mWeight approx.10000 KgTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-15000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22,5 kWTorque (100% ...

GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Working area 1Longitudinal560 mmCross600 mmVertical600 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minCabineFull protection cabinDirect measuring systemDirect path measuring systemNC rotary table with pallet carrierNC rotary table with pallet carrier permissible load 500 kg / 1,100 lbs (no indexing table 360 x 1° in basic machine)Tool magazine, chain Vert., 60 pocketsTool magazine Vertical chain magazine with 60 tool pockets4. Axes (swivelling range) 360 x 0,001 degreeMaximum load (table centre) 500 KgTable surface 400 x 400 mmMotor spindle 18,000 rpmMain drive: Integrated motor spindle incl. active coolingSpindle taper CAT 40Speed range - 18000 rpmTorque (40% DC) 110 NmTorque (100% DC) 84 NmDrive power (40% DC) ...

GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Working area 1Cross600 mmLongitudinal560 mmVertical600 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minCabineFull protection cabinDirect measuring systemDirect path measuring systemNC rotary table with pallet carrierNC rotary table with pallet carrier permissible load 500 kg / 1,100 lbs (no indexing table 360 x 1° in basic machine)Tool magazine, chain Vert., 60 pocketsTool magazine Vertical chain magazine with 60 tool pockets4. Axes (swivelling range) 360 x 0,001 degreeMaximum load (table centre) 500 KgTable surface 400 x 400 mmMotor spindle 18,000 rpmMain drive: Integrated motor spindle incl. active coolingSpindle taper CAT 40Speed range - 18000 rpmTorque (40% DC) 110 NmTorque (100% DC) 84 NmDrive power (40% DC) ...

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.14500 KgDirect measuring systemDirect path measuring systemCabineFull protection cabinChip removalChip removal: manual, from the chip troughCoolant supplyCoolant supply: Multi-jet strip at spindle head, switchable from coolant to air (max. 6 bar / 90 psi, 6 water jets, 6 air jets) Pump capacity: 70 l/min / 18 gallon/min (theoretical pump performanc ...

GeneralUniversal milling and turning machining centre with duoBLOCK construction; Control: CELOS X with HEIDENHAIN TNC7 Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal800 mmCross1050 mmVertical850 mmTool changerApplicationUniversal Type of magazineWheel Tool changer planehorizontal Type of gripperDouble gripper Number of tools123 NC mill-turn table with palletNC mill-turn table with pallet number of T-slots: - 1x cross slot 14 H7 / 0.55 H7 - 12x star slots 14 H11 / 0.55 H11 / 22.5° max. table speed milling operation: 30 rpm turning operation: 780 rpm integrated balancing sensor Pallet changer for 2 palletsType of Measuring system Direct measuring systemTable surface Ø 800 x 630 mmCentre bore 50 mmMaximum load (table centre) 1400 Kg4. Axes (swivelling range) 360 x 0,00 ...

GeneralHorizontal Machining Centre in travelling column construction; Control: 3D Control Siemens 840D solutionline operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/70000 mm/minRapid traverse longitudinal/transverse/vertical60/60/70 m/minWorking area 1Longitudinal630 mmCross800 mmVertical850 mmPackage recirculation ballscrew spindlePackage recirculating ballscrew spindle X-,Z-axis:max. feed speed: 60.000 mm/min Y-axis: max. feed speed: 70.000 mm/min (basic machine without linear drive X-, Y-, Z-axis)Main driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range -12000 rpmSpindle taper HSK-A 63CabineFull protection cabinDirect measuring systemDirect path measuring systemNC rotary table with pallet changerTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 Kg4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS X with Siemens SINUMERIK ONE Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minNC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working plane transformationTool clamping for HSK-A63Tool clamping HSK-A63 according DIN 69893 (incl. adaptation working spindle and tool magazine)Tool magazine 60 pocketsTool magazine 60 places HSK-A63 Vertical chain with double gripper incl. set up station for tool loadingChip removal package with cabin roofSwarf removal package chip conveyor Coolant - air-blast changeover Swarf con ...

GeneralVertical Machining Centres; Control: DMG MORI SLIMline® Multi-Touch control CharacteristicsTable surface1400 x 560 mmDimensions (L x W x H)6,31 x 4,8 x 2,94 mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z1100/560/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with30 PositionsMax. torque82 NmTorque (100% DC)54 NmDrive power (40% DC)13 kWMaximum load (table centre)1000 KgDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5850 KgSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Preparation 4th axis EA 510.L indirect (Siemens)Preparation for rotary table (4th axis) Lehmann EA-510.L with indirect measuring system Option includes: - Electrical and pneumatic preparation - Software preparation to work with rotary table - Cycle TRACYL which allows to define contour on the cylinDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive air purge for meas ...

GeneralVertical Machining Centres; Control: DMG MORI SLIMline Multi-Touch Control CharacteristicsMaximum load (table centre)1000 KgDimensions (L x W x H)3,93 x 3,49 x 2,94 (6,3 x 5,5 x 2,94) mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z1100/560/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with30 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmTable surface1400 x 560 mmWeight approx.6050 KgSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Air coolant internal (through spindle centre)Air Coolant Internal (through spindle centre) switchable via M-Function maintained air with low oil rateTropical PackageTropical Package Option includes: - Active Cooling Unit for Electrical Cabinet - Additional Ventilator for Control Panel Recommended from 35°C to max. 45°C environmental temperatureDirect measuring system ...

GeneralHorizontal machining center; Control: Control F31iB with CELOS CharacteristicsSpeed max.-20000 rpmDimensions (L x W x H)3,08 x 4,79 x 2,86 mMax. tool length550 mmSpindle taperBT 40 Tool Magazine with60 PositionsRapid feed X / Y / Z60/60/60 m/minMovement X / Y / Z730/730/880 mmPalett changer with2 PalletMax. work piece height1000 mmMax. work piece diameter800 mmMaximum load (table centre)500 KgSwivelling range360x1 degreeTable size500x500 mmDrive power (40% DC)26 kWDrive power (100% DC)18,5 kWWeight approx.12000 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and pHigh-speed spindle 20,000 min-1, 37/ 26/ 18.5 kWHigh-Speed Spindle 20,000 min-1, 37/26/18.5 kW Motor ...

General- partial hollow clamping device (hydraulic), - C-axis and spindle brake (hydr.) - upper compound slide with turning-/ milling spindle, with hydraulic locking reception HSK-A63, DIN 69893 - Y-axis ±210 mm - B-axis ±120º interpolating, Torque motor - tool magazine 36-fold disc magazine, ergonomic front load - absolute, direct measuring systems in X-, Y-, Z1-axis - cooling pump 6 bar;20 l/min, - USB-interface, Ethernet-interface; Control: CELOS X with Siemens 840D SL Operate Working areaSwing diameter over guide ways700 mmTurning diameter700 mmDistance between spindles3360 mmClamping chuck diameter max.630 mmBar diameter max.125 mmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-20000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22,5 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking moment1700 NmMain drive 1Drive power (100% DC)40 kWSpeed range- 2 ...

GeneralMulti-Axis Machine; Control: Control F31iB with CELOS CharacteristicsMax machining diameter320 mmMax. Turning Length300 mmSpeed max.6000 rpmSpindle speed 2nd Spindle max.6000 rpmMovements X / Z210/810 mmWeight approx.8000 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and pGuide bushGuide Bushing If the bar material diameter is smaller than the spindle diameter, place an duracon bushing inside the spindle to prevent vibrations. (including the guide spacer) The customer should machine the guide bushing to the required diameter asLeft Spindle) KITAGAWA 8in. Hollow Chuck B208A521B (SK-OP)(Left Spindle) KITAGAWA 8in. Hollow Chuck B208A521B Three-jaw hydraulic chuck ...

GeneralCTX beta 1250 4A Two spindle turning centre with - partial hollow clamping device for main spindle and counter spindle internal diameter of draw tube Ø67 mm (2.63 in) x 700 mm (27.55 in) deep - 2 C-axes and spindle brakes (hydr.) - 2 12 fold Sauter star turrets reception VDI 40, DIN 69880-40 with precision interface (Trifix) and tool drive connection/drive acc. DIN 5480 - Y-axis, slide I - counter spindle slide; Control: CELOS X with Siemens 840D SL Operate Headstock, leftClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle diametre on front bearing130 mmSpindle bore87 mmDrive power (100% DC)25 kWTorque (100% DC)280 NmSpeed range0-5000 rpmC-Axis Speed2000 rpmHeadstock, rightClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWC-Axis Speed2000 rpmTorque (100% DC)280 NmSlide 1Longitudina ...

GeneralTravelling column machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal3000 mmCross1100 mmVertical1050 mmFeed drives:Feed rate X / Y / Z42000/42000/42000 mm/minRapid feed X / Y / Z42/42/42 m/minNC-swivel head (B-axis)Controlled NC-swivel milling head (B-axis) with clamping in position. Continuously positioning NC swivel milling head with integrated motor spindle for 4/5 axes positioning and simultaneous machining. Swivel torque: 3,300 / 2,300 Nm // 2,433 / 1,696 ftDynamic package for DMF 300|11 linearDynamic package for DMF 300|11 linear Linear motor X-axis with 80 m/min // 262.48 ft/min Rapid speed XYZ 80 m/min // 262.48 ft/min Acceleration XYZ 8 m/s² // 26.25 ft/s² Active cooling for Linear motorToolchanger with twin-grippertoolchanger with twin-gripperType of magazine ChainNumber of tools 40CabineFull protection cabinPackage Mill / Turn 20,000 rpm, H ...

x-travel: 2.600 mm y-travel: 700 mm z-travel: 700 mm Control: SIEMENS SINUMERIC 840D table-size: 2.900x700 mm table weight: 2.150 Kg tool adaptor: SK 40 DIN 69872 workpiece length - max.: 300 mm workpiece weight: 6 kg workpiece dia.: 80/130 mm : 30 fach main drive: 18,4/14 kW speed: 14.000 mm/min rapid traverse: 40 m/min feed: 40 m/min Machine on: 18.859 h Spindle hours: 5.666 h internal coolant system feed: 40 Bar/600 l Chip coveyor: inkl. total power requirement: 55 kW weight of the machine ca.: 14.520 kg dimensions of the machine ca.: 10.280 x 7.230 x 3.042 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

GeneralCNC Turning Centre with C axis and tool drive; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways700 mmTurning diameter410 mmTransverse stroke300 mmLongitudinal stroke850 mmMax. Turning Length800 mmClamping chuck diameter max.315 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Spindle bore87 mmDiametre of spindle nose170h5 mmSpindle diametre on front bearing130 mmTool holder 1Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.-6000 rpmPower max. (40% DC)10 kWMain drive 1Drive power (100% DC)25 kWTorque (100% DC)280 NmSpeed range25 - 5000 rpmAccuracy at point stopping0,01 degreeFloor space/WeightDimensions (L x W x H)3,99 x 2,69 x 1,99 mWeight approx.6500 KgTechnologie cycle alternating speedTechnology cycle for the application of an alternating speed for vibration sensitive s ...
