baykal sheet metal working used for sale

BAYKAL HNC 4110 hydraulic guillotine shears built in 2019 in Turkey are designed for precision cutting of workpieces with a maximum thickness of 10 mm. The machining process is performed by extremely precise cutting knives with adjustable gap between blades. The all-steel construction combined with a powerful hydraulic system additionally ensure the highest stability and machining performance. The BAYKAL HNC 4110 guillotine shears have been in use for a small amount of time – so far they have worked only 560 hours. The total weight of the machine is 15400 kg. Technical specifications of the BAYKAL HNC 4110 guillotine shears - HMI panel: SIEMENS SIMATIC HMI - maximum sheet metal length: 4060 mm - maximum sheet metal thickness (Rm

BAYKAL APHS 31440 CNC hydraulic press brake was built in 2020 in Turkey by BAYKAL MAKINA SANAYI VE TICARET A.Ş. The machine, designed for machining sheet metal with a maximum length of 3100 mm, is distinguished by its high precision, efficiency and reliability. Throughout its entire service life, the machine was used for only 43 hours. Thanks to full electronic synchronisation with proportional valve technology, the installed CNC control constantly monitors and corrects the parallelism of the beam. The use of this solution maximises the accuracy and repeatability of the bending workpieces. The workspace, in turn, is protected by the FIESSLER AKAS laser safety system, which automatically stops the machine if the laser beam is interrupted. All this is complemented by a design made from high-grade ST44-2 steel, which maintains maximum stability during even the most intensive challenges. ...

BAYKAL RGS 3150x3 electromechanical guillotine shears were built in 2007 in Turkey by BAYKAL MAKINA SANAYI VE TICARET A.Ş. The machine, distinguished by its high precision, is used for cutting of sheet metal with a maximum thickness of 3 mm. The machining process is performed by means of quality cutting knives with an adjustable gap between blades. The all-steel design, combined with a powerful electromechanical system, guarantees the highest cutting performance during even the most intensive challenges. The workspace is additionally protected by high-end light curtains made by FIESSLER ELEKTRONIK. All this makes the offered BAYKAL RGS guillotine shears an excellent choice for any industrial plant. Technical specifications of the BAYKAL RGS 3150x3 guillotine shears - maximum sheet metal thickness (Rm

The machine is in good technical condition, after prior agreement it is possible to test it. - Nominal forming force: 120 t Working length: 3106 mm CNC control Delem (graphic 2D programming) Automatic calculation of bending sequence and collision detection Back gauge X axis with 2× manually adjustable stop fingers CNC electromotive height adjustment of the back gauge (R axis) CNC electrically controlled table deflection Upper tool adapter ROLLERI Equipment and accessories: - Front protective device (tilting door) - Rear protective device (sliding door) - 1× freely movable two-hand / foot control - Operating instructions including CE declaration

Offer 22408 Specifications: - max. working width 3050 mm - max. cutting capacity St 40 10 mm - Projection 270 mm -Cutting angle° - Cutting gap adjustment by hand - Number of hydraulic hold-downs 16 pcs - Mechanical backgauge 20 - 650 mm - Front angle stop + support arms - Stroke rate depending on cutting angle and cutting length 7 - 12 per/min - Hydraulic drive 400 V / 22 kW - Table height approx. 820 mm - Space requirements incl. back gauge, without front support arms -ca. W 3850 x H 2000 x D 2000 mm - Weight approx. 8500 kg - With: - E-foot switch - Cutting line illumination

Cutting lenght 6100 mm Cutting thickness 16 mm

Offer 24295 Specifications: - max. working width 3050 mm - max. cutting capacity St 40 16 mm - Projection 270 mm - Cutting angle 2.4 ° - Cutting gap adjustment by hand - Number of hydraulic hold-downs 16 pcs - Motor back gauge with positioning control 20 - 1000 mm - Front angle stop + support arms - Stroke rate depending on cutting angle and cutting length 7 - 18 rpm - Hydraulic drive 400 V / 30 kW - Table height approx. 820 mm - Space required including back gauge, without front support arms -ca. W 4000 x H 2400 x D 2400 mm - Weight approx. 14500 kg - with: - E-foot switch - Cutting Line Illumination - - Cutting Length Selection - Rear area protection with light barrier

Key data: 160 t, 3700 mm

Control Delem ... DA - 56 s Thrust... 160t Bending length... 3700mm controlled axes ... 4 Drive... Hydraulic Max. ram stroke... 260mm Main engine power ... 15kW Machine weight ... 10700kg L x W x H ... 4750x1850x2660mm The machine is in good condition, possible to test under power.

Key data: 3100 mm, 6 mm

Max. cutting length ... 3100mm Max. sheet thickness ... 6mm Drive... Hydraulic Main engine power ... 11kW Number of strokes ... 20/min Machine weight... 5500kg L x W x H ... 3900x2560x1560mm The machine is in good condition, possible to test under power,

sheet width: 3060 mm plate thickness: 6 mm no. of strokes: 20 Hub/min stroke: 750 mm Motor Capacity: 11 kW oil volume: 160 l weight of the machine ca.: 5.500 kg dimensions: 3860 x 2560 x 1560 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3060 mm plate thickness: 6.0 mm thickness at Niro-steel: 4.0 mm distance between columns: 3100 mm down holder: 16 Stück no. of strokes: 20 Hub/min oil volume: 160 ltr. cutting angle: 1.6 ° Control: ELGO Number of working hours: ~ 1.100 h total power requirement: 11.0 kW weight: 5250 kg range L-W-H: 3800 x 1940 x 1560 mm from a maintenance workshop with only approx. 1.100 operating hours () Equipment: - electro-hydraulic swing beam shears - ELGO NC control unit for electric back stop Input of target/actual position value possible - NC electro-motoric back stop travel path of back stop X = 750 mm back stop ball screw with no play travel speed 100 mm/sec - electric cutting length limitation cutting length limitation to increase the number of strokes/min. - manual cutting gap adjustment, via eccentric - tip operation with push buttons on the control panel on the left - ...

sheet width: 3060 mm plate thickness: 8.0 mm thickness at Niro-steel: 6.0 mm distance between columns: 3100 mm down holder: 16 Stück no. of strokes: max. 10 - 15 Hub/min oil volume: 160 ltr. cutting angle: 1.6 ° back stop - adjustable: 6.0 - 750 mm Control: ELGO P9521 total power requirement: 18.5 kW weight: 6300 kg range L-W-H: 3900 x 2300 x 1630 mm Features: - Robust electro-hydraulic swing beam shear - ELGO digital display model P9521, for electric backgauge Backgauge travel X = 750 mm Backgauge-free ball screw drive Travel speed 100 mm/s - 1x stable side stop With T-slot, flip-stop, and millimeter scale - 2x stable front support arms - Electric cutting length limiter Cutting length limiter to increase the stroke rate/min. - Manual cutting gap adjustment Centrally operated on the right side stand - Front support plates - Front finger/interference guard - Inching operation with ...

BAYKAL BPS3006 plasma cutting machine was built in 2020 in Turkey by BAYKAL MAKINA SANAYI VE TICARET A.Ş. The machine is designed for precision plasma cutting of sheet metal and tubes. The machining process is performed on a large work table with a length of 6000 mm and a width of 3000 mm with an extraction system. This system is integrated with an industrial filtration unit, which removes any contamination generated during the cutting process on an ongoing basis. The plasma torch with an anti-collision system and automatic height adjustment is in turn powered by a powerful HYPERTHERM plasma source of the highest energy efficiency. The innovative True Hole cutting technology for mild steel ensures significantly better hole quality than was ever possible with the use of plasma. All this is complemented by extensive equipment, consisting of, among others, an intelligent CNC control and au ...

pressure: 180 t chamfer lenght: 3110 mm distance between columns: 2600 mm column arm: 410 mm ajustment speed: 100 mm/sec working feed: 10.0 mm/sec return speed: 80.0 mm/sec back stop - adjustable: max. 750 mm stroke: 260 mm dayligth: 460 mm table height: 880 mm oil volume: 210 ltr. operating pressure: max. 240 bar control: DELEM total power requirement: 15.0 kW weight of the machine ca.: 11.200 kg. range L-W-H: 4250 x 2000 x 2800 mm Current new price approx. 85.000 euros Special price on request Features: - Electro-hydraulic CNC press brake - With DELEM CNC control model DA 66W” 2D graphic programming Automatic bend sequence calculation and collision detection High-quality LCD screen (TFT) Swivel control panel, front left - CNC-controlled axes: Y1 + Y2 + X + R + CNC crowning - CNC electric motor-driven backgauge (X axis) with 2x manually adjustable stop fingers - CNC electric mo ...

The machine is in good technical condition, after prior agreement it is possible to test it. Baykal HNC 3100/13 hydraulic sheet shears controlled by PLC. Steel 13mm Stainless steel 8mm Cutting length 3070mm Cutting angle 0.5-2.5 degrees Weight 13t

pressure: 35.0 t chamfer lenght: 1250 mm distance between columns: 1070 mm piston stroke: 150 + 60 mm column arm: 410 mm table height: 800 mm dayligth: 470 mm working feed: 10.0 mm/sec return speed: 70.0 mm/sec table width: 140 mm Control: ELGO NC Number of working hours: ~ 9.600 h oil volume: 80.0 l operating pressure: max. 240 bar voltage: 380 V total power requirement: 4.0 kW weight: 2200 kg range L-W-H: 1800 x 1450 x 2150 mm Well maintained condition With only approx. 9.600 operating hours () Features: - Robust NC-controlled hydraulic press brake - With ELGO NC control unit P8822” Positioning of the backgauge (X axis) Positioning of the depth adjustment (Y1+Y2 axis) Swiveling control panel, front left - NC electric motorized backgauge (X axis) With 2x stop fingers, manually adjustable (R+Z axis) - 1x split set of pointed tools - top - 1x rotatable Multi-V die block - Side saf ...

pressure: 35.0 t chamfer lenght: 1250 mm distance between columns: 1095 mm stroke - stepless adjustable: 215 mm column arm: 410 mm table height: 800 mm dayligth: 455 mm working feed: 10.0 mm/sec return speed: 56.0 mm/sec work height max.: ca. 875 mm Control: DM 51 Number of working hours: ~ 13.300 h oil volume: 80.0 l operating pressure: max. 240 bar voltage: 380 V total power requirement: 4.0 kW weight: 2500 kg range L-W-H: 1700 x 1450 x 2250 mm Features: - Robust CNC-controlled hydraulic press brake - With DELEM CNC control unit DM 51” Positioning of the backgauge (X axis) Positioning of the depth adjustment (Y1+Y2 axis) Program + tool storage possible Swiveling control panel, front left - CNC electric motor-driven backgauge (X axis) - CNC electric motor-driven height adjustment of the stop (R axis) - 2x manually adjustable stop fingers - 1x split set of deer foot tools - top - 1 ...

pressure: 180 t chamfer lenght: 3100 mm distance between columns: 2550 mm throat: 310 mm stroke: 200 mm ajustment speed: 80.0 mm/sec working feed: 10.0 mm/sec return speed: 58.0 mm/sec dayligth: 385 mm table width: 240 mm work height max.: 885 / 1050 mm oil volume: 180 ltr. total power requirement: 15.0 kW weight of the machine ca.: 9850 kg. range L-W-H: 4200 x 1750 x 2450 mm from a maintenance workshop well-maintained condition () - in checked condition - machine video - https://www.youtube.com/watch?v=o_t9BBMsNNs Equipment: - simple, conventional electro-hydraulic press brake with torsion shaft for parallelism of the upper beam - electric back stop, with ball screws (X axis) with 4x manually adjustable stop fingers fine adjustment via handwheel at the front, with analog position display - electro-motor adjustment of the immersion depth (Y1 + Y2 axis) with digital position display ...

A hydraulic CNC plate shear Baykal is available. Cutting length: 3060mm, max. sheet thickness (St42): 10mm, operating pressure: 260bar, stroke rate: 12/min. Machine dimensions X/Y/Z: approx. 4000mm/2600mm/2000mm, weight: approx. 9600kg, control system: Delem DAC 310. Documentation available. On-site inspection is possible.

This Baykal BPH 1503 + Hypertherm HPR 130 Plasma Cutting machine Machine was manufactured in the year 2012 and has 18000 production hours. It is equipped with a Baykal control unit.

pressure: 035 t chamfer lenght: 1250 mm distance between columns: 1070 mm piston stroke: 150 + 60 mm column arm: 410 mm table height: 800 mm dayligth: 470 mm working feed: 10.0 mm/sec return speed: 70.0 mm/sec table width: 140 mm Control: ELGO NC Number of working hours: ~ 9.600 h oil volume: 80.0 l operating pressure: max. 240 bar voltage: 380 V total power requirement: 4.0 kW weight: 2200 kg range L-W-H: 1800 x 1450 x 2150 mm Well maintained condition With only approx. 9.600 operating hours () Features: - Robust NC-controlled hydraulic press brake - With ELGO NC control unit P8822” Positioning of the backgauge (X axis) Positioning of the depth adjustment (Y1+Y2 axis) Swiveling control panel, front left - NC electric motorized backgauge (X axis) With 2x stop fingers, manually adjustable (R+Z axis) - 1x split set of pointed tools - top - 1x rotatable Multi-V die block - Side saf ...

This Baykal HNC 3100x13 shearing machine was manufactured in 2009. It features a cutting capacity for St 42 at 13 mm and a cutting length of 3060 mm. Main voltage is 380/50/3 with a robust 30 kW motor. The machines substantial weight of 13000 kg ensures stability and precision in operation. For more information about this shearing machine, please reach out to us.

The machine is in good technical condition, testing is possible after prior agreement. Pressing force: 35 tons • Working length: 1250 mm • Control system: CNC (precise adjustment of angles and stops) • Condition: Fully functional, currently not connected. Main advantages: • High accuracy: Stable frame and precise positioning for high-quality bending. • Compact dimensions: Ideal solution even for smaller workshops and operations. • Accessories: The sale includes the equipment visible in the photos.

CNC press brake Type: APH-S 3106×120 Manufacturer: Baykal Year: 2005 Control: Delem DA 66W (graphical 2D programming) Press force: 120 t Working length: 3100 mm Automatic calculation of the bending sequence and collision detection X-axis rear stop with 2x manually adjustable stop fingers CNC electromotoric rear stop height adjustment (R axis) CNC electrically controlled table deflection ROLLERI upper tool adapter Equipment and accessories: Front protection device (hinged door) Rear protection device (sliding door) 1× freely movable two-handed / foot control User manual including CE declaration Machine in good condition, fully functional, under power Find more here - / Contact us at -

sheet width: 3060 mm plate thickness: 6.0 mm thickness at Niro-steel: 4.0 mm distance between columns: 3100 mm down holder: 16 Stück no. of strokes: max. 10 - 15 Hub/min oil volume: 160 ltr. cutting angle: 1.6 ° back stop - adjustable: 6.0 - 750 mm Control: ELGO P9521 total power requirement: 18.5 kW weight: 6300 kg range L-W-H: 3900 x 2300 x 1630 mm Features: - Robust electro-hydraulic swing beam shear - ELGO digital display model P9521, for electric backgauge Backgauge travel X = 750 mm Backgauge-free ball screw drive Travel speed 100 mm/s - 1x stable side stop With T-slot, flip-stop, and millimeter scale - 2x stable front support arms - Electric cutting length limiter Cutting length limiter to increase the stroke rate/min. - Manual cutting gap adjustment Centrally operated on the right side stand - Front support plates - Front finger/interference guard - Inching operation with ...

sheet width: 3060 mm plate thickness: 6,0 mm distance between columns: 3060 mm : max. 730 mm cutting angle adjustment: ja ° cutting gap adjustment: ja mm connected load: 11,0 kW weight of the machine ca.: 5,1 t dimensions of the machine ca.: 4,0 x 260 x 2,55 m Hydraulic guillotine shear with - ELGO control for backgauge - Cutting gap adjustment - Cutting length adjustment - Cutting line illumination - Side gauge - 2 support brackets The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Qty. 1 Second-hand Sendzimir reversing cold rolling mill Mfc.: Waterbury Farrel Type: WZS- Reversing - Sendzimir Rolling Mill type: ZR – 23M – 31”, reversing Z”, 1 – 2 – 3 – 4 Built: 1977 Modernised in 1991 Capacity: approx. 50 000 T/annum Strip width: 370 – 740 mm Strip tension: controlled up to 10 Tons Thickness: Entry: 3.5 mm Exit: 0.20 mm Speed: 183 – 368 m/min. Min. exit thickness of material M70-A: 0.04 mm Last pass from 0.12 to 0.04 mm Qty. 1 Second-hand roll grinder Mfc.: Landis Type: L-28A Roll dia.: 40-100 mm Roll length: up to 1500 mm Qty. 15 Containers

Qty. 1 Second-hand aluminium strip production plant Entry Material: Aluminium Scrap – HD666, AA5050, 2.5-3.0% Mg Final product: Aluminium strip (can stock) Width: 220 mm Thickness: 0.15 – 1.0 mm Mfc.: De Winter, Thermcon, Fata Hunter, Fröhling, Nederman, Burghardt & Schmidt, Siemens Built: 1984, 1999, 2000, 2002, 2014, 2015 Scope of supply: Melting Furnace Tilting Casting Furnace Block Caster 5 Stand Hot Rolling Mill 6 Stand Cold Rolling Mill Hot Gas Filter Slitter Welding Machine Treatment Furnace Quenching Unit Shear

Qty. 1 Second-hand strip rolling mill Mfc.: United Engineering Type: 4-Hi Built: Strip Width: 393 mm (15.5”) Thickness Entry: 4 mm (0.16”) Exit: 1.2 mm (0.05”) Mill Speed: 405 m/min. (1330 Fpm) Strip Tension: 2670 kg (5875 Lbs) Coil ID 406 mm (16”) Coil OD 1448 mm (57”) Coil weight: 3180 kg (7000 lbs)

material width: 300 mm material thickness: 2,0 mm : max. 90° Grad weight: 12 Kg dimensions: 400 x 250 x 100 m Combined sheet metal working machine with: - Bending, tool widths 25 - 50 - 75 - 75 - 105 mm. - Rolls, roll diameter 38 mm - scissors, max. 1015 x 1mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

guillotine shears AG TS 2 Working thickness 2mm Adjustable stop Hold Length 1.80 m Width 1 m Height 1.40 m Weight 300 kg

Line Salvagnini S4 P4 Year 2001/2003 S4 30 + P4 2220 + MD with unloading robot. Working line, regular assistance performed by the manufacturer

Hydraulic Shear HACO HS 3010 Capacity: 3000 x 10 mm Back gear gauge travel: 1000 mm Year of construction: 1983 Manual adjustment of the clearance between blades Cutting angle: 1° to 3° Voltage: 380 V Dimensions (L x W x H): 4000 x 2100 x 2200 mm Weight: approx 8 T

LASER PRIMA INDUSTRIE Mod. 2D/3D DOMINO Year 2006 1500x3000 2.5 kw 22,000 working hours Visible in operation No loading and unloading

Mechanical Shear BOMBLED type 9G Capacity: 2500 mm x 4 mm Manual Back gear gauge travel: 500 mm Supplied with 2 front length stops Voltage: 380 V Dimensions (L x W x H): 4000 x 1500 x 1500 mm Weight: approx 4,5 T

Sheet metal processing system P 315 / 1991 105327 Ai P4-1812+HPT 2015 + R51 272/ 1991 S4.30 / 1998 Find more here - / Contact us at -

55 ton multi station

Auction-ID: A1-45793-102

v.v. euroklemming Auction-ID: A1-45793-116

Manufacturer: Bystronic Model: BLT 4000 Year of Manufacture: 2001 Type of Machine : C02 Laser Find more here - / Contact us at -

Manufacturer: Morn Laser Condition : New Model: GH-S3015 GH-Series Type of Machine : High Speed Full Cover Fiber Laser Cutting Machine Condition : New Advantages: - High speed cutting efficiency - Safe and clean production - Zoned smoke exhaust system - High speed double platform exchanging Parameters: - Laser Power: 3000W / 6000W - Cutting Area: 3100 × 1600 mm Find more here - / Contact us at -

Manufacturer: Morn Laser Condition : New Model: MT-6000 N-6 Series Type of Machine : High Speed Tube Fiber Laser Cutting Machine Advantages: - Fast loading - High precision - Saves labor costs Parameters: - Laser Power: 3000W / 6000W - Tube Length: 6m / 9m Find more here - / Contact us at -

Manufacturer: Morn Laser Type of Machine : PROFILE STEEL LASER CUTTING MACHINE Condition : New Model : MT-H4510 / MT-H50120 HD Series Advantages: - Stable cutting of large-size profile steel - High-precision bevel cutting Parameters: - Profile Steel Processing Range (Customizable): 450×1000mm / 500×1200mm - Laser Power: 12000W–20000W Find more here - / Contact us at -

Manufacturer: Morn Laser Type of Machine : HEAVY DUTY TUBE LASER CUTTING MACHINE Conditon : New Models: MT-6000 / MT-9000 / MT-12000 X Series & L Series Advantages: - Intelligent 4-chuck technology - Truly zero tailing - Auto loading and unloading system Parameters: - Laser Power: 1500W – 20000W - Tube Diameter: Ø20mm–160mm / 200mm / 350mm / 500mm - Tube Length: Standard 6m / 9m / 12m Find more here - / Contact us at -

Inv. Num. : 8739 Type: TS 3006 Producer: HACO Created: 2004 Parameters: Maximum cutting length: 3000 mm Maximum cutting thickness: 6 mm

Inv. Num. : 8740 Type: VR 13-31 Producer: EHT Generated: Parameters: Maximum cutting length: 3100 mm Maximum cutting thickness: 13 mm

- Cutting size: 1350 mm wide x 600 mm high - With motor: 7.5 hp (5.5 kW)

Manufacturer: SATO Model: DHDS 3100 Year of Manufacture: 2017 Estimated operating hours: 16,000 hours - Plasma cutting system with table and extraction system. - Cutting area: 2 x 6 meters. - Equipped with plasma unit and 2 oxy-fuel torches. Find more here - / Contact us at -

Manufacturer: Amada Model: LST 3015-M2 Year of Manufacture: 2011 Power Required: 4 kVA Noise Level: 70 dB(A) Weight: 1950 kg Operating Hours: 30,000 hours Pallet Capacity: - Maximum sheet size: 3050 x 1525 x 25 mm - Maximum load: 920 kg Amada 4 kW laser cutting system including shuttle table and extraction system. Operated in single-shift production, no maintenance backlog. Find more here - / Contact us at -

00905 Designation of the scissors system Manufacturer: Finnpower Model SG6 12.13 Year of construction 2008 Operating hours: (as of Feb 2026) 42,340 h Power on time 6462131min Running time 2540410min Alarm time 2187771min Control Finnpower ICP1 Machine weight 28,000 kg Punching force 300 kN Cutting force 250 kN Max. operating pressure 300 bar Note: Tapping unit without function The SG6 turbine is currently connected to an LP6 Finnpower plant. The SG6 is converted into a stand-alone machine. So that the SG6 can also work independently on its own. The SG6 scissors are also currently connected to a Night Train storage system together with the LP6. (the LP6 layout and Night Train storage system will be dismantled on March 30, 2026) SG6 12 13 3 x 400 V 50 Hz 3 x 80 A Lcu 25 kA Condition Good condition Dismantling March 30, 2026

older Gebr. Lever shears on base frame Technical data Knife length 500 mm Cutting range approx. 3-4 mm Dimensions 800 x 170 x 1300 mm dto. incl. base frame 1300 x 600 x 1780 mm Remarks / Accessories: Underframe, small damage to the knife Maschinenladen Oeben GmbH Krahnendonk 116 D-41066 Mönchengladbach Phone: + 49 2161 662701 maschinenladen.de InfoMachine Shop

Manufacturer: Morn Laser Type of Machine : INTELLIGENT THREE-CHUCK TUBE FIBER LASER CUTTING MACHINE Condition : New Models: MT-6000 / MT-9000 / MT-12000 X Series & L Series Advantages: - Innovative 3-chuck technology - One-click clamping technology - Extremely short tailing Parameters: - Laser Power: 1500W – 20000W - Tube Diameter: φ20mm – 160mm / 200mm / 350mm / 500mm - Tube Length: Standard 6m / 9m / 12m

Fully automatic sheet dispenser PAL-Cut 800 The Palcut 800 cuts paper quickly and precisely into intermediate sheets of the desired length, directly from the roll. Fully automatic sheeter PAL-Cut 800 sheet dispenser, which cuts intermediate layers quickly and precisely in the desired length. The sheet dispenser is suitable for continuous operation in an automatic palletizing system and for companies with high sheet consumption. The Palcut 800 works with rollers of max. 800 mm width. Type designation: PAL-Cut 800 Length: 1853 mm Width: 1380 Height: 1739 for roll width up to: 800 mm Mounting height: 1,368 mm Working speed: 480 pcs/h Power connection: 220 V, 0.18 kW Operating mode: fully automatic Weight: 370 kg Link PAL-Cut 800 More items - new and used - can be found in our shop! International shipping costs on request!

Angular table for lid milling machine Clamping flat 900x530mm 8 St T-hooks Never used

In 2020, the machine was extensively overhauled for 7000 €. Proof available. Processes: - Chamfering 60° - Longitudinal turning up to a maximum of 40 mm - Centering drilling Workflow fully automatic: - Tensioning, feeding to - Rapid traverse forward - Work feed - Dwell time for cutting - Rapid traverse back - Relax, feed on Specifications: workpiece diameter approx. 80 mm workpiece diameter 6kt-SW 70 mm min. workpiece diameter round and 6kt 10 mm min. workpiece length 450 mm Speed range infinitely variable Level I/Stage II = 51-306/102-612 Electrical equipment 220/380 V, 50 Hz Motor power main motor kW 1.3/1.8 Engine power Coolant motor kW 0.07 Required air pressure 6-8 bar Weight approx. 520 kg Dimensions: L 1520 mm x W 610 mm x H 1350 mm Roller conveyor

BIHLER GRM100 multislide punching and forming machine, Made in Germany. Machine re-engineered in year 2010 originally by Bihler, updated with servo motor, pump, rewired, new control, etc. Equipped with 4x forming slides and 18 ton press station. Gripper feed on right-hand side with straightener. Max width of strip 100 mm. Max wire diameter 10 mm. Standard feed length 250 mm max. Max operating speed 135 strokes per minute approx. Servo motor. Touch screen control. Air clutch. Weight cca. 6000 kg. Power supply 400/480V, 50 Hz. On stock more Bruderer, Schaal, and Mabu high speed presses. Also Ideal flash butt welding machines.

Prepared for CNC control Siemens 840 DSL Precision turntable make EIMELDINGEN with aerostatic axial bearings Specifications Table diameter 5,600 mm Total height approx. 1,230 mm Centering bore Ø 250H7X 25 mm Permissible transport load 30,000 kg Holding torque of the table clamping 2,400 daNm Table speed 0.002 – 2 min Net weight approx. 30,000 kg Operating voltage 380 V, 50 Hz. 3 phases Control voltage 24V Positioning accuracy (without control errors) ± 1" Plan accuracy 0.02 mm Axial running accuracy 0.01 mm Concentricity deviation of the centering bore 0.01 mm Resolution of the displacement measuring systems 0.0001°

Work platform, platform TALL ESCOPE No. 512 Load capacity: 115 kg Platform height: 2900 - 4400 mm Dimensions: 3600 x 1000 x 2000 mm Weight: 92 kg used, tested !

Machine is in good technical condition, a visit and a test run are possible by prior arrangement.

Schroeder & Bauer WB 32-1 Universal Wire and Strip Bending Machine Wire feeder Plain text display Compression Force Monitoring Wire straightener Bosch Stripping Devices Bracket and brush motor with mounted tool W32/1-32 Soundproof booth Fäßerb CU wire with stamped parts Switchboard Item condition: very good Description of the manufacturer, deviations possible. You purchase the machine as shown in the pictures. Complete plant closure, large selection of mezzanines, pallet racks, shelving racks, paternosters. High Quality Industrial Machinery, Lathes, Grinding Machines, Hand Machinery Suppliers in China More items - new and used - can be found in our shop! International shipping costs on request!

- Hersteller: HURCO - Model/Typ.: BMC4020HT/M - Baujahr: 1997 - MFG.No.: 029 Verfahrwege: - X-Achse: ~ 1020 mm - Y-Achse: ~ 510 mm - Z-Achse: ~ 610 mm - Steuerung: Ultimax 3 Hauptspindel: - Hauptspindel: max. Drehzahl 8.000 U/min - Hauptspindel Leistung: 15 kW - Werkzeugaufnahme: SK 40 Arbeitstisch: - Tischaufmaße 1220 x 510 mm - max. Tischbelastung ca. 700 kg - Werkzeugwechsler: - Anzahl der Werkzeugplätze 24 Stück - max. Werkzeugdurchmesser 100mm - max. Werkzeuglänge 300mm - max. Werkstückhöhe 250mm (bei einer Werkzeuglänge von 300mm) - max. Werkzeuggewicht 7,0 kg - Maschinengewicht ca. 5,6 to - Standort: demontiert, am Lager D-32825 Blomberg

Length approx. 3.2 meters; 13 mm lip Auction-ID: A1-45793-114

length 2050 mm; hydraulic top clamp from Baps (Euro) to Bystronic RF Auction-ID: A1-45793-117

Length 3615 mm; V45 die Auction-ID: A1-45793-113

V6 30 degree T mold set; length approx. 3.1 meters Auction-ID: A1-45793-118

specifications: Max sheet width 3,000 mm Max sheet thickness at max yield strength 240 N/mm2 when bending to max. sheet width 35 mm when rounding Bend length 2.2 x S Max passage between rollers 145 mm Roller diameter upper roller 552 mm Underroller 532.4 mm Side rollers 400 mm Number of rollers 4 Powered rollers 2 top and bottom roller Drive of the rollers hydraulically Arrangement of the rollers symmetrically Rotation speed of the rollers 2-4 m/min Adjustable rollers 3 Type of adjustment of the rollers hydraulically Adjustment speed lower roller 0-200 mm/min. Side rollers 0-700 mm/min. Brake of the rollers pneumatic Actuation of the folding bearing hydraulically Operating voltage 3 x 380 V / 50 Hz Display device of the roll positions 4 x optical/analog Weight of the machine approx. 42 to Area 2.71 x 6.4 m Height 3.12 m

MAX 20 X 1600

Sheet thickness aluminium: 1.00 mm Due to the bevel cut, the X-Cut machine can not only cut straight strips in the longitudinal and transverse directions, the automated bevel cut opens up many new possibilities for cutting the different surfaces quickly and accurately. Saves up to 90% of the time Up to 60 degrees angle adjustment in both directions Intuitive operation thanks to touchscreen and calculation aids Thanks to optimized software, cutting trapezoidal surfaces, triangular surfaces and other surfaces for standing seam roofs and wall cladding is no problem Due to the fully automated bevel cutting and the versatility and accuracy of the software, a high level of time savings can be achieved during production in the company and also during installation on the construction site Automatic operation: Enter the desired length and the number of pieces to be cut automatically. Tota ...

Year 1996, CE norm, complete instructions, control Delem, machine in TOP condition with warranty, more details on request

Key data: 300 , 4

Bandwidth - up to 460 mm Band thickness - 0,5-4 mm Motor drive - 6 kW together with Reel 1.5 T - non-powered

lechrichter, used,       sheet leveller, used,   Type: UBR 10 x 2000 /1-16 Manufacturer / make: WMW Gotha max. sheet width: 2000 mm max. sheet thickness ( St 50): 10 mm    min. sheet thickness / min. sheethickness: 3 mm   Number of straightening rollers: 13 rollers / rollers Directionroller Diameter/diameter of     straihgtening rollers: 145 mm Directional speed / speed of straightening: 16 m / min Bale length / convexity length of rollers: 2330 mm Center distance of directional rollers/ distance b/n rollers centers: 150 mm Support roller diameter / diameter of bottom rollers: 290 mm Number of bottom rollers 21/24 Number of supports (top/bottom): 3 /3 Lifting speed of the traverse / speed   ...

Capacity , ton: 800 Stroke, mm: 320 Strokes/min: 20 Shut height, mm: 900 Bed to ram adjustment stroke, mm: 320 Bed dimensions, mm: 2500x1600 Main drive motor power, kW: 75 Overall dimensions, mm: 4220x3500x8356 Weight, ton: 96,6

Hydraulic mobile tin hole punch for e.g. control cabinet construction and control construction Manufacturer Alfra Type SKP-1 Punches holes of max 140mm diameter in 3mm sheet metal Round, square and rectangular stamps possible. Punch punch punch tin punch drill tin hole drill monocut gap-plate-hole, hand hydraulics, ball bearing screw, Klauke Alfra Special price

NC - controlled mechanical sheet metal panel scissors in backdrop cutting design, maximum cutting length 1,050 mm, maximum cutting capacity 4 mm steel sheet/ST40, cutting angle 1.5°, NC - controlled rear stop with 1,000 mm travel range - automatic removal of the stop rail at sections lower than 1,000 mm - optionally available with a foldable sheet support at the rear stop or a conveyor belt with upliftrs, drive power 5 kW, weight approx. 2,500 kg

Beam claw, sheet metal clamp, sheet metal claw, beam clamp, sheet metal gripper, material gripper, material gripper, profile steel gripper, plate gripper -Sheet metal clamp: clamping range up to 85 mm -Load capacity: kg -Dimensions: 300/80 / H330 mm -Weight: 13 kg

Beam claw, sheet metal clamp, sheet metal claw, beam clamp, sheet metal gripper, material gripper, material gripper, profile steel gripper, plate gripper -Sheet metal claw: clamping range up to 30 mm -Load capacity: kg -Dimensions: 250/100 / H460 mm -Weight: 20 kg

Beam claw, sheet metal clamp, sheet metal claw, beam clamp, sheet metal gripper, material gripper, material gripper, profile steel gripper, plate gripper -Sheet metal claw: clamping range up to 35 mm -Load capacity: 4 t -Dimensions: 230/110 / H450 mm -Weight: 22 kg

sheet width: 1050 mm plate thickness: 1 mm roll diameter: 56 mm dimensions of the machine ca.: 1600 x 700 x 1050 mm Domestic equipments: - Upper roller can be swung out manually The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Sheet metal clamp, sheet metal claw, beam clamp, beam claw, sheet metal gripper, material gripper, material gripper -with chain: 1.3 m -Span width: 44 to 70 mm -Load capacity: 6300 kg -Dimensions: 300/460/H120 mm -Weight: 30 kg

VERRINA CLR 216 X 4050 Sheet metal round bending machine Double roller with 4 rollers and double pressure Year of manufacture 1979 Capacity 4000 mm x 16 mm Roll length 4050 Roll diameter side rolls 370mm top & bottom roll 410mm Roll rise and fall 370mm Input 400/3/50 Hz 52 kW Rolling speed 2.9 / 3.9 / 6.8 meters per minute Control control panel Equipped with hydraulic drop, safety cable hoist Length 9000mm Width 2350 mm Height 2400 mm Net weight approx. approx. 29,500 kg

Sheet metal clamp, sheet metal claw, beam clamp, beam claw, sheet metal gripper, material gripper, material gripper -Sheet metal claws -Span: 0 to 40 mm -Load capacity: 9000 kg -Number: 1x terminal available -Weight: 28 kg

Sheet metal clamp, sheet metal claw, beam clamp, beam claw, sheet metal gripper, material gripper, material gripper -Sheet metal claws -Span: 0 to 55 mm -Load capacity: 9000 kg -Number: 2x terminals available Price: per piece -Weight: 28 kg/piece

sheet width: 2100 mm plate thickness: 13 mm pre-bending: 10 mm upper roll diameter: 230 mm lower roll diameter: 210 mm side roll diameter: 190 mm total power requirement: 7,5 kW weight of the machine ca.: 4.620 kg dimensions of the machine ca.: 4150x1400x1300 mm Accessories / equipment: - Conical bending device - induction hardened rolls - digital display for side rollers - Machine made of steel construction - Separate control panel - two speeds - all rollers on ball bearings - Folding and support bearing from the top roller is actuated from the control panel. When the folding bearing is opened, the roller moves automatically upwards. - Conical adjustment of the rollers via control panel - Central rollers are via hydraulic motor and rotary reduction gear driven. (Top and bottom rollers) - Calibration The data for this ad was created with ModulMWS - the software solution of LogoTech oHG ...

sheet width: 1050 mm plate thickness: 3,3 mm pre-bending: 3,0 mm roll diameter: 90 mm min. dia.: 130 mm total power requirement: 1,1 kw weight of the machine ca.: 570 kg dimensions of the machine ca.: 2100 x 800 x 1130 mm Domestic equipments: - Asymmetrical 3-roll round bending machine with motor drive - Upper roller swung out - Conical bending device - Main engine with brake device Additional equipment: - motorized rear roller adjustment - Digital display for back roller - induction hardened rolls The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 1250 mm plate thickness: 5,5 mm pre-bending: 5,0 mm roll length: 1280 mm min. dia.: 210 mm roll diam. toproll: 140 mm weight: 1365 kg range L-W-H: 2.020 x 900 x 1.200 mm Standard features: - Central rollers via electric motor, planetary reduction gear and Gear drive driven - Swivel top roller - Main engine with brake device - Conical bending device - Mobile controller and foot pedal - CE mark / Declaration of Conformity Additional equipment: - motorized rear roller adjustment - Digital display for back roller - induction hardened rolls The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Sheet metal clamp, sheet metal claw, beam clamp, beam claw, sheet metal gripper, material gripper, material gripper -Sheet metal claws -Span: 0 to 50 mm -Load capacity: 9000 kg -Weight: 32 kg
