TOS VARNSDORF wh used machines

This 5-axis TOS Varnsdorf WHN130 was manufactured in 2007. It features a horizontal boring and milling machine with a table size of 1800 × 1800 mm and a spindle diameter of 130 mm. The machine includes a rotary table and is controlled by an NCT-104 system. Consider the opportunity to buy this TOS Varnsdorf WHN130 boring machine. Contact us for more information.

bore capacity in steel (diameter):- mm throat:- mm bore stroke:- mm x-axis:1.800 mm y-axis:1.600 mm z-axis:1.250 mm w-axis:630 mm max. table load:5.000 kg table length:1.400 mm table width:1.600 mm spindle diameter:105 mm spindle turning speed range:3.300 U/min numbers of positions in the tool changer:40 internal coolant system feed:40 bar Splash guard around rotary table Chip Conveyor Oil cooling unit (chiller) Touch probe Renishaw RMP60 Upgrades in 2024 and 2025 Retrofit of X and Z axis ball screws at producer ? KSK Kurim CZ New linear scales Heidenhain in X and Z axis including cabling retrofit of Z axis - new Biplast V lining on guideways, hand scraped Biplast lining on Z axis new TOS Varnsdorf parts for tool clamping and automatic tool changer arm Overhaul of X, Z and Y axis feed motors at authorized Siemens service (new bearings and sensor) New Siemens hand wheel

X=3500mm Y=2000mm Z=1250mm W=800mm H=360° spindle 130 mm, ISO 50, max. 1600 rpm table 1600 x 1800 mm with a load of 12000 kg with Siemens electric and CNC Heidenhain TNC 415B Oil cooled: Schimpke. Dismantled. The machine has been used very little = in very good technical condition.

spindle diameter: 130 mm x-travel: 4000 mm y-travel: 3000 mm z-travel: 2000 mm w-axis: 800 mm table:: 1800 x 2500 table load: 20 t feed range: 4 - 5000 mm/min spindle turning speed range: 10 - 3000 U/min spindle taper ISO: 50 spindle motor: 37 kW rapid traverse: 10 m/min Control: Heidenhain iTNC 530 total power requirement: 70 kW weight: 39 t range L-W-H: 8,5 x 8,6 x 5,5 mm equipped with - CNC control Heidenhein iTNC 530 & handwheel - 60-fold tool changer (ISO 50) - NC rotary table 1800 x 2500mm, 20t - IKZ and external coolant supply 20bar - chip conveyor - spindle support The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 130 mm x-travel: 3500 mm y-travel: 2500 mm z-travel: 1600 mm w-axis: 800 mm b-axis: 360 ° table:: 1800 x 2200 table load: 25 t feed range: 10000 mm/min spindle turning speed range: 10 - 3000 U/min spindle taper ISO: 50 spindle motor: 37/46 kW rapid traverse: 10 m/min Control: Heidenhain TNC 640 total power requirement: 70 kW weight: 38 t range L-W-H: 8,5 x 8,6 x 5,5 mm Equipped with: - Heidenhein iTNC 640 CNC control & HR 510 handwheel - HUI 50 automatic milling head - 40-position tool changer (ISO 50) - B-axis in rotary table - Heidenhain optical scales - NC rotary table - Coolant system with paper belt filter, Coolant through Spindle 20bar - Chip conveyor - Heidenhain TS 460 measuring probe - Movable operating platform - Pfannenberg oil cooler - Central lubrication ca 4450h Spindle Hours The data for this ad was created with ModulMWS - the software solution of Logo ...

spindle diameter: 130 mm x-travel: 3500 mm y-travel: 2000 mm z-travel: 1250 mm w-axis: 800 mm b-axis: 360 ° table:: 1800 x 2200 spindle turning speed range: 3000 U/min feed range: 4 - 3000 mm/min table load: 12 t spindle taper ISO: 50 spindle motor: 37 kW rapid traverse: 10 m/min Control: Heidenhain iTNC 530 b-axis: 360 ° total power requirement: ca 70 kW weight: 36 t range L-W-H: 8 x 8 x 3,5 m equipped with: - CNC control Heidenhein iTNC 530 & handwheel - clamping table 1800 x 2200mm, 12t -- full B-axis with 360,000 positions - coolant - IKZ 20bar & extern cooling - BLUM TC 60 Taster - without chip conveyor ca 11500 Spindle Hours The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel:3500 mm y-travel:2500 mm z-travel:1250 mm bore spindle speeds:2500 U/min table load:12 t dia. of rotary table:1800 x 2200 mm numbers of positions in the tool changer:60 Lifting operator platform External tool cooling Spindle clamping support

Table drilling unit W 100 A Manufacturer: TOS Varnsdorf overhauled: 20125 Spindle diameter ... 100mm Axis X ... 1600mm Axis Y ... 1120mm Spindle speed ... 7-1120 rpm. Axis W ... 900mm Axis Z ... 1250mm ISO 50 Max table load ... 3000kg L x W x H ... 6710 x 3450 x 3000mm Machine weight ... 14000kg Main Engine Power... 11kW Total power demand ... 17kVA Clamping table area ... 1250 x 1250mm Flat disc diameter... 600mm Max circulation diameter ... 900mm The machine is possible to test under electricity, with one-year warranty.

Key data: 130 , 3500 , 2000

CNC SIEMENS 840D X-axis (longitudinal) 3500 mm Y-axis (transverse) 2000 mm Z-axis (vertical) 1250 mm Table length 1800 mm Table width 1800 mm Maximum workpiece weight 12000 kg Spindle diameter 130 mm Maximum spindle speed 800 rpm Magazzino utensili 52 posti Spindle motor 37 kW Year of revision 2005 ------------------- Length x width x height 7200 × 7800 × 4900mm Weight 32000 kg

Year of manufacture: 1992 / G: 2025 Spindle diameter ... 100mm Axis X ... 1500mm Axis Y ... 1250mm Spindle speed ... 7-1120 rpm Axis W Axis Z ... 1800mm ISO 50 Turntable diameter ... 1200x1200mm The machine is in good condition, possible to test under power.

Travel X/Y/Z/W: 1000mm/900mm/800mm/710mm, speed: 1400rpm, spindle diameter: 90mm, table dimensions: 1250mm/1250mm, max. table load: 3000kg, motor power: 7.5kW. X/Y dimensions: approx. 5500mm/7500mm, weight: approx. 11000kg, control: Newall DP700. Documentation available.

Key data: 100 mm, 1600 mm, 1120 mm

Spindle diameter ... 100mm Axis X ... 1600mm Axis Y ... 1120mm Spindle speed ... 0-1120 rpm Axis W ... 900mm Axis Z ... 1250mm Spindle holder ... ISO 50. Clamping table surface ... 1250 x 1250mm Main engine power ... 11kW Max. workpiece weight ... 3000kg Total power requirement ... 15kVA L x W x H ... 6710 x 3450 x 3000mm Machine weight ... 14000kg The machine is in good condition, possible to test under power.

Key data: 100 mm, 1600 mm, 1120 mm

Spindle diameter ... 100mm Axis X ... 1600mm Axis Y ... 1120mm Spindle speed ... 0-1120 rpm Axis W ... 900mm Axis Z ... 1250mm ISO 50 Clamping table surface ... 1250 x 1250mm Main engine power ... 11kW Max. workpiece weight... 3000kg Total power requirement ... 15kVA L x W x H ... 6710 x 3450 x 3000mm Machine weight ... 14000kg The machine is in good condition, possible to test under power in our warehouse.

spindle diameter: 100 mm x-travel: 1600 mm y-travel: 1120 mm z-travel: 1250 mm table surface area: 1250 x 1250 mm spindle taper: ISO 50 spindle turning speed range: 7,1 - 1120 U/min faceplate turning speed range: 7,1 - 224 U/min faceplate diameter: 600 mm table load: 4000 kg main drive motor: 11 kW max. travel of spindle: 900 mm total power requirement: 15 kVA weight of the machine ca.: 14,5 t dimensions of the machine ca.: 6 x 3,1 x 3,1 m Overhauled/Modernized in 2003 - DRo Heidenhain - Faceplate with slide The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 100 mm x-travel: 1600 mm y-travel: 1120 mm z-travel: 1250 mm table surface area: 1250 x 1250 mm spindle taper: ISO 50 spindle turning speed range: 7,1 - 1120 U/min faceplate turning speed range: 7,1 - 224 U/min faceplate diameter: 600 mm table load: 4000 kg main drive motor: 11 kW max. travel of spindle: 900 mm total power requirement: 15 kVA weight of the machine ca.: 14,5 t dimensions of the machine ca.: 6 x 3,1 x 3,1 m - DRo Heidenhain - Faceplate with slide The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

- 3 axis TESLA NS 114  digital read out - Tailstock - Face plate 800 mm - Distance faceplate to boring bar rest 2800 mm - Max. diameter off facing 900 mm - Under power inspection possible

Key data: 100 mm, 1600 mm, 1120 mm

Spindle diameter ... 100mm Axis X ... 1600mm Axis Y ... 1120mm Spindle speed ... 0-1200 rpm Axis W ... 900mm Axis Z ... 1250mm Spindle mount... ISO 50. Clamping table surface... 1250 x 1250mm Max. table load ... 3000kg Main engine power ... 11kW L x W x H ... 6710 x 3450 x 3000mm Machine weight ... 14 000kg The machine is in good condition, possible to test under power.

spindle diameter:100 mm x-travel:1250 mm y-travel:1100 mm z-travel:950 mm spindle turning speed range:2500 U/min Rotary-table:1100 x 1000 mm table surface area:1000 x 1100 mm tool clamping:69871 DIN spindle stroke:630 mm spindle taper:SK50 total power requirement:22/34 kW max. workpiece weight:3000 kg weight of the machine ca.:13000 kg

Control system Heidenhain TNC 415 Spindle diameter 130 mm Tapered hollow spindle ISO 50 Spindle speed range 10 to 1500 rpm Table transverse (X): 3500 mm Rolling headstock stand for (Y): 2000 mm Longitudinal displacement rack (W): 1250 mm Eject working spindle (Z): 800 mm Table load 12 000 kg Machine weight: 36 000 kg

TOS WHN 130 MC used machine Specifications System Heidenhain TNC 426 Working range Spindle diameter 140 [mm] Taper in the spindle ISO 50 Table transverse adjustment (X) 3000 [mm] Vertical headstock adjustment (Y) 2000 [mm] Vertical travel (Z) 1250 [mm] Spindle stroke (W) 560 [mm] 2X Clamping surface 1800 x 1600 [mm] Speed range 10 - 2500 [rpm] Main motor output 37,0 [kW] Max. workpiece weightƒ 8000 [kg] Accessories Tool changer for 60pcs Tool cooling Chip conveyor

Key data: 130 mm, 3000 mm, 2000 mm

Inv. Num. : 6957 Type: WHN 13 Produzent: TOS Erzeugt: 1976 Parametern: Arbeitstischlänge: 1800 mm Arbeitstischbreite: 1800 mm Maximale Tischbelastung (gleichmäßig): 120.000 kg Verfahrwege X-Achse: 3000 mm Verfahrwege Y-Achse: 2000 mm Verfahrwege Z-Achse: 800 mm Spindeldurchmesser: 130 mm DRO

Inv. Num. : 7260 Type: WHN 13.4 A Producer: TOS Created: 1986, GO 2003 Parameters: Control system: MEFI CNC 859 Work table length: 1800 mm Work table width: 1600 mm Maximum table load (uniform): 12 t Maximum spindle speed: 1098 1/min X-axis travel: 3000 mm Y-axis travel: 2000 mm Z-axis travel: 800 mm W-axis travel: 1250 mm Spindle diameter: 130 mm Cone: ISO 50 Machine height: 3900 mm Machine length: 6200 mm Machine width: 5930 mm Machine weight: 32 t

Control Heidenhain TNC 355 Spindle diameter Ø 130 mm Horizontal Spindle Travel (W) 800 mm Taper ISO 50 P.D.B. Table 1,600 x 1,800 mm Max. load 12 Ton Cross travel (X) 3,500 mm Vertical travel headstock (Y) 2,000 mm Longitudinal travel (Z) 1,250 mm RPM 5 – 1,100 kW 32 Volts 400 Cycles 50

1x CNC Table Boring Machine Manufacturer: TOS Type: WHQ Year of Make:1997 Control: Heidenhain TNC 426 in 5-axis X-axis 2000mm Y-axis 1400mm Z-axis 1250mm W-axis. 710 mm B-axis 360 degrees Spindle diameter : 112mm Spindle mount: ISO 50 Spindle speed max: 2000 rpm Table clamping surface: 1400x 1600mm Tool changer: 60 places Chip Conveyor: Yes

spindle diameter: 130 mm x-travel: 3500 mm y-travel: 2500 mm z-travel: 1250 mm w-axis: 800 mm b-axis: 360 ° spindle turning speed range: 1000 U/min transmission ratio: 4 Control: Heidenhain type: 355 table surface area: 1800x2200 mm Table load: 12000 kg spindle taper ISO: 50 width of T-slots: 22 mm T-slot - distance: 160 mm Feed: 1-6000 mm/min table rotating: 1,5 U.min-1 total power requirement: 80 KVA weight of the machine ca.: 36 t dimensions of the machine ca.: 7,7x7,2x4,9 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
