Water coolers NATIONAL LAB ProfiCool Genius PCGE 250

Item condition: fully functional/ maintained
Availability: immediately
Cooling capacity: 17.4 kW +8°C refrigerant outlet and +32°C ambient temperature
Cooling water recooler: mains connection 3-phase
Power supply: 400V/3Ph/50Hz ±5%.
Power consumption: 9440 W
Max. current consumption: 17.4 A
Cold transfer temperature: +0 - 25°C
Weight: 250 kg
Ambient Temp.: -15 / +40°C
Cooling capacity: 24,000 W
Dismantling: by buyer
Original price: €13,099.00

1 ProfiCool Genius for outdoor installation
1.1 ProfiCool Genius PCGE 250
Cooling capacity: 17.4 kW at +8°C refrigerant outlet
and +32°C ambient temperature
Cooling water recooler. Mains connection 3-phase
1.2 Hydraulic design – single-circuit system
1.3 Pump P5-AS13B
Piped and connected ready for operation. Mains connection:
400V/3Ph/50Hz ±5%.
1.4 Overflow valve. Material: brass. Built-in.
1.5 Pressure gauge, 0-6 bar, for water pressure indication
1.6 Refrigeration design refrigerant R407C
1.7 Condenser, air-cooled
1.8 Axial fans, low noise
1.9 Electrical design 3/PE AC 50Hz 400V ±5% 1 piece
for three-phase four-wire system (or five-wire system for
installation package for low ambient temperatures).
1.10 Electronic Controller with Digital Display Type: Dixell IC120
1.11 Collective fault notification
Any faults that occur are potential-free on the terminal
and can thus be processed externally.
1.12 Remote Control
To be switched on and off via the consumer. M5732589 Toggles
cooling, fan and M5732589 the pump. Two contacts on
Terminal block.
1.13 Installation package for ambient temperatures < +10°C
Composed of speed-controlled fan, protection
from low-pressure faults and additional oil heating
for compressor.
1.14 Glycol additive (ETHYLENE-GLYCOL!) of 34% by volume
1.15 Weather protection roof to protect against precipitation
ATTENTION: For technical reasons, this
Option package in the device variant THREE-phase 3/PE AC,
a power supply 3+N/PE AC, i.e. WITH
NEUTRAL CONDUCTOR to consider
1.16 Air filter for condensers. Material: Aluminium
1.17 Standard paint finish in RAL 7035 (light grey)

seller offer No. resale 9947
