Semi-Automatic 8 Tray Carton Glue Dispensing Plant LUNEX Modell M
packaging machines / other packaging machinery
Technical data: Dimensions and weight Width of the machine: 2230 mm Length of the machine: 2400 mm Weight of the machine: 1550 kg approx. Performance 0 – approx. 55 m / min, endurance run. Cycle operation power / hour depending on the operator. Up to 2,000 pcs/hour depending on packaging Drive ...
Manufacturer: LUNEX
Model:Modell M
Type of machine: Semi-Automatic 8 Tray Carton Glue Dispensing Plant
item-No.: 170102507
Quantity: 1
Date: 26.08.2026
Year of manufacture:
Location:
Germany
42551 Velbert
Price:
Your price suggestion:
Technical data:
Dimensions and weight
Width of the machine: 2230 mm
Length of the machine: 2400 mm
Weight of the machine: 1550 kg approx.
Performance
0 – approx. 55 m / min, endurance run.
Cycle operation power / hour depending on the operator.
Up to 2,000 pcs/hour depending on packaging
Drive
Belt press belt 1 x 0.75 kW
Noise
70 dB (or less)
Connection
3 x 400 V, 25A, 50 Hz, powered by the LUNEX basic machine.
Compressed air
None
Formats
Min. width approx. 60 mm depending on the packaging
Min. length approx. 150 mm depending on the packaging
Max. width 1600 mm (= passage width)
Max. length in principle not limited
Material
All formats depend on the nature of the packaging.
Dimensions are valid for folded blanks.
Motor Glulam Bridge
Lenze Type: MDXMA2M080-32 (IP 55)
50/60 Hz 0.75/0.92 kW
400/230 V 1.90/3.30 Amp.
Dimensions and weight
Width of the machine: 2230 mm
Length of the machine: 2400 mm
Weight of the machine: 1550 kg approx.
Performance
0 – approx. 55 m / min, endurance run.
Cycle operation power / hour depending on the operator.
Up to 2,000 pcs/hour depending on packaging
Drive
Belt press belt 1 x 0.75 kW
Noise
70 dB (or less)
Connection
3 x 400 V, 25A, 50 Hz, powered by the LUNEX basic machine.
Compressed air
None
Formats
Min. width approx. 60 mm depending on the packaging
Min. length approx. 150 mm depending on the packaging
Max. width 1600 mm (= passage width)
Max. length in principle not limited
Material
All formats depend on the nature of the packaging.
Dimensions are valid for folded blanks.
Motor Glulam Bridge
Lenze Type: MDXMA2M080-32 (IP 55)
50/60 Hz 0.75/0.92 kW
400/230 V 1.90/3.30 Amp.
