Double Column Presses HYMAG HSP. 2.1-30
metal working machines / presses / Double Column Presses
Manufacturer: HYMAG
Model:HSP. 2.1-30
Type of machine: Double Column Presses
item-No.: 168643748
Quantity: 1
Date: 28.01.2026
Year of manufacture: 1983
Location:
Germany
63322 Rödermark
Price:
Seller-item-No.:Lg.-Nr. 25461
Offer 25461
Technical data:
- Max. pressing force 30 t
- Press pressure regulation
- Stroke infinitely adjustable up to 200 mm
- Lifting speed adjustable
- Max. installation height 450 mm
- Machine table with T slots W 800 x D 500 mm
- Penetration between the columns 600 mm
- Usable table surface W 800 x D 500 M6337496 mm
- Drive 400 V / 11 kW
- Space requirement approx. W 1000 x H 2300 x D 1600 mm
- Weight approx. 2500 kg
Technical data:
- Max. pressing force 30 t
- Press pressure regulation
- Stroke infinitely adjustable up to 200 mm
- Lifting speed adjustable
- Max. installation height 450 mm
- Machine table with T slots W 800 x D 500 mm
- Penetration between the columns 600 mm
- Usable table surface W 800 x D 500 M6337496 mm
- Drive 400 V / 11 kW
- Space requirement approx. W 1000 x H 2300 x D 1600 mm
- Weight approx. 2500 kg
