Thread Milling Machines HECKERT ZFWVG 250/3W x 1250
metal working machines / milling machines / Thread Milling Machines
max. workpiece diameter: 500 mmthreading length: 1250 mmmax. module: 10 min. module: 1 workpiece dia. over saddle: 250 mmspindle bore of workspindle: 102 mmquill stroke: 100 mmworkpiece turning speeds: 0,0032 - 2,6 U/minfeeds - rolls: 0,027 - 5,66 mm/WUfeeds - longitudinal: 0,3 - 198 mm/minmain ...
Manufacturer: HECKERT
Model:ZFWVG 250/3W x 1250
Type of machine: Thread Milling Machines
item-No.: 170033624
Quantity: 1
Date: 12.10.2026
Year of manufacture: 1989
Location: ab Werksstandort,unter Strom
Price:
Machine in stock:Yes
Seller-item-No.:1020-20289
max. workpiece diameter: 500 mm
threading length: 1250 mm
max. module: 10
min. module: 1
workpiece dia. over saddle: 250 mm
spindle bore of workspindle: 102 mm
quill stroke: 100 mm
workpiece turning speeds: 0,0032 - 2,6 U/min
feeds - rolls: 0,027 - 5,66 mm/WU
feeds - longitudinal: 0,3 - 198 mm/min
main drive: 4 kW
swivel angle for work spindle: 90/120 °
diameter of hob: 150 mm
milling width: 100 mm
hob turning speeds: 45 - 560/900 U/min
total power requirement: 9,5 kW
weight of the machine ca.: 4,2 t
Machine equiped with:
- Heavy Duty Hob Head ApFw
- change gears
- Milling Head ApFF
- Single Indexing Device ETE
- Bush Rest
- Coolant Tank
