Fluid Bed Dryer BINDER DCRVF1200x7 - 25 t/h

Fluid Bed Dryer Type: DCRVF1200x7
Rationale:
The material to be dried is placed on the inflow floor and fed there from bottom to top with the
Drying air flows through. As a result, the good is heated with constant vibration and the moisture
driven out.
The vibration prevents the formation of bubbles in the fluidized bed of fine-grained products as well as the
Segregation for products with a broad grain spectrum. The vibration also loosens up coarse
grains and an almost complete emptying of the entire body. The dwell time of the product can be reduced by
adjustment of the vibration.
Specifications:
Dryer width: 1200 mm
Overall length: 7.0 m
Length of the dry zone: 4.25 m
Length of the cooling zone 2.75 m
Tilt: horizontal
Execution:
· Air flow trough in welded steel construction with the necessary inlet and outlet openings
· Exhaust hood with expansion zone, the necessary inlet, outlet and inspection openings
· Conveyor and air inlet floor made of stainless steel incl. lateral wear protection
· Dryer inlet with compensator, tension straps, incl. counter frame without cut-out
· Dryer spout, with round hose compensator and tension straps
· Hot air, cooling air and exhaust E571548 air E571548 compressor
Drive:
Single-mass oscillation system consisting of 2 double unbalance motors
Drive power: 2 x 4.0 kW
Speed: approx. 750 min-1
Voltage: 400 V
Frequency: 50 Hz
Degree of protection: IP65/F
Additional facilities:
· Frequency converter
· Weirs for layer height adjustment, adjustable from the outside
· Insulation of the dryer and radiator hood
Support:
Spring type: Rubber hollow spring with fabric insert
Material: Special rubber with raised
Damping properties
Total weight: approx. 4,900 kg
