Injection molding machines ARBURG ALLROUNDER CENTEX 320 C
machines for plastic / injection moulding machines / Injection molding machines
ARBURG ALLROUNDER CENTEX 320 C 500 – 250 (Year 2002) Serial number: 188161 – Machine no. 30 Clamping force: 500 kN EUROMAP: 500-250. Operating hours in automatic mode: 38,560 h. Hydraulic pump operating hours: 48,759 h. Cycles: 6,502,482. Spindle diameter: 40 mm. Distance between columns: 320 x ...
Manufacturer: ARBURG
Model:ALLROUNDER CENTEX 320 C
Type of machine: Injection molding machines
item-No.: 169326274
Quantity: 1
Date: 21.10.2026
Year of manufacture: 2002
Location:
Spain
Price: 7,000 EUR
Seller-item-No.:GEST-007B
ARBURG ALLROUNDER CENTEX 320 C 500 – 250 (Year 2002)
Serial number: 188161 – Machine no. 30
Clamping force: 500 kN
EUROMAP: 500-250.
Operating hours in automatic mode: 38,560 h.
Hydraulic pump operating hours: 48,759 h.
Cycles: 6,502,482. Spindle diameter: 40 mm.
Distance between columns: 320 x 320 mm.
Platen dimensions: 446 x 446 mm.
Injection unit (EUROMAP): 250.
Approximate injection volume: 106 m³.
Injection weight (PS): 97 g.
Operating voltage: 400 V – 3 – 50 Hz.
Heating: 6.5 kW.
Pump motor: 1 x 15.00 kW.
Total power: 21.5 kW.
Weight: 2,330 kg.
Serial number: 188161 – Machine no. 30
Clamping force: 500 kN
EUROMAP: 500-250.
Operating hours in automatic mode: 38,560 h.
Hydraulic pump operating hours: 48,759 h.
Cycles: 6,502,482. Spindle diameter: 40 mm.
Distance between columns: 320 x 320 mm.
Platen dimensions: 446 x 446 mm.
Injection unit (EUROMAP): 250.
Approximate injection volume: 106 m³.
Injection weight (PS): 97 g.
Operating voltage: 400 V – 3 – 50 Hz.
Heating: 6.5 kW.
Pump motor: 1 x 15.00 kW.
Total power: 21.5 kW.
Weight: 2,330 kg.
