Injection molding machines ARBURG 470C 1500-400

Clamping force: 1500 kN Arburg 470C 1500-400 with the Wittmann W711 robot
Year of Make: 2008

Injection unit:
Screw diameter: 45 mm
Injection weight: 232 g
Spray pressure: 1580 bar

Dosing volume: 254 ccm
Clamping unit:
Clamping force: 150 t
Spar spacing: 470x470 mm
Size of the clamping plates: 650x650 mm
Ejector: hydraulic
Clamping unit: hydraulic

Control: SELOGICA - Touchscreen

Additional equipment:
Euromap 67
Robot interface
Air Valve x 1
Hardened injection unit - Bimetal
Proportional valve on the injection unit – precise injection
Robot Wittmann W711
Year of Make: 2007
4-axis robot: 3 axes are driven by servo motors (electric); Axis C
Traversing in axes: X-420, Y-1200, Z-2000
Touch control panel
The safety package for robots
Robot with adapter
Purchase of the robot at an additional cost

Dimensions:
Weight: 4900 kg
Length/Width/Height: 4.44x1.63x2.09 m

Drive:
Pumps/motor: 18.5 kW
Heating capacity: 9.7 kW
Total power: 28.2 kW
All offered machines are started by our service technicians before they are sold.
It is possible to receive a video of the technical tests of the selected machine or to participate in live technical tests at our company in Łódź.

Price: On request
