Injection molding machines ARBURG 470C 1500-150/150

Clamping force: 1500 kN Arburg 470C 1500-150/150 / 2K machine / machine in very good technical condition
Year of Make: 2005

Injection unit:
Screw diameter: 25 mm
Injection weight: 49 g
Spray pressure: 2500 bar
Dosing volume: 54 ccm

Clamping unit :
Clamping force: 150 t
Spar spacing: 470x470 mm
Size of the clamping plates: 685x685 mm
Ejector: hydraulic
Clamping unit: hydraulic

Control: SELOGICA

Additional equipment:
2K Machine
Euromap 67
Robot interface
Air Valve x 1
Hydraulic core pull x 1
Hardened injection unit - Bimetal
Proportional valve on the injection unit – precise injection
Type of injection unit: Vario - This offers the possibility of using the injection unit, e.g. for side spraying
Parallel movements
The vertical injection unit - screw diameter fi 25 mm (49 g/hp)
It is possible to change screw diameters in both injection units for the screw diameters recommended by the manufacturer: 30, 35 mm

Dimensions:
Weight: 5700 kg

Drive:
Pumps/motor: 30 kW
Heating capacity: 2 x 9.4 kW
Total power: 48.8 kW

All offered machines are started by our service technicians before they are sold.
It is possible to receive a video of the technical tests of the selected machine or to participate in live technical tests at our company in Łódź.

Price: On request
seller offer No. resale 169625131
