Surgical Mask /foodpad /fruit pad / meat pad ANDRITZ QUANZHO 800

Surgical Mask /foodpad /fruit pad / meat pad Production Line for Sale

ype :
Surgical Mask /foodpad /fruit pad / meat pad Production Line for Sale
Year(s) :
2020
Quantity :
1
Location :
Seller or machines location:
MIDDLE EAST
Last check :
06 Dec. 2025
Description
meat pad, fruit pad, food pad , surgical mask production line

The 3-ply mask production system offered here combines efficiency and safety features with a first-class mask of type II / IIR optimized for high wearing comfort. The integrated extra module "Single Pack" enables the mask production machine to pack each mask individually wrapped at full speed of up to 800 masks / min. The film rolls also have an autosplice function, so that the system weld the film together on the fly while unit operation.

The mask is made up of 3 layers of non-woven material:
- An outer layer of spunbond
- A meltblown filtration layer
- An inner layer of spunbond
- nosepiece
- Elastic ear band

These product features are realized thanks to the use of precise welding rollers, a modern and intuitive HMI with touchscreen function for simple and clear operation, as well as web guiding systems implemented. Intelligent sensors ensure that the material levels are precisely determined. If a low material level is detected, the material is welded to one another using the autosplice function without stopping the system.

Plant details:
- Solid, high-quality system structure with over 25 tonnes for maximum stability
- Pneumatic material winding shafts for flexible and easy exchange of the rolls
- Pneumatic material winding shafts in double design for quick set-up times and convenient handling
- Adjustable web tension through pneumatic modules
- Autosplice function for convenient material welding at the end of the roll
- Individually controlled winding shafts for maximum precision
- Servo driven unwinder, PLC control
- Sensor technology for material presence control
- Automated alarm & stop function in the event of material tear
- Web guiding for maximum precision of the raw material
- Large and intuitive touchscreen
- The touch screen can display the diameter of the rolls, the material ratio, the servo load and alarm codes
- The machine speed can be conveniently set on the F6332592 touchscreen
- Error F6332592 messages can be tracked in the alarm and error history. These include:
Raw material, joining, splicing and fan defects
- The production quantities and other details can be viewed on the HMI aswell

Performance data:
- Power consumption: on request
- Power connection: 380 V / 50 Hz
- Number of cycles: up to 800 masks / min. - depending on the material
- Carton: depending on the packaging format
- Compressed air: 6-8 bar with sufficient volume / reserve
- Dimensions: 15 m x 4 m x 3 m (LxWxH) - different depending on the equipment
- Weight: 25 tonnes - varies depending on the equipment

System modules:
- Nose wire unit
- Unwinding units for spunbond, meltblown and ear loop with automatic splicing unit
- Face mask side embossing unit
- Triple folding face mask.
- Face mask on the side embossing unit
- End cutting unit (high speed steel)
- Product exit conveyor
- Single pack packaging module
- Security doors with sliding construction
seller offer No. resale 800
