Die Spotting Presses used for sale (24)

Key data: 150 t

For sale is a used hydraulic spotting press Millutensil MIL 163 from 2004 with a pressing force of 150 t. The 4-column press has a table size of 1,300 × 1,600 mm, a maximum installation height of 1,300 mm and a column spacing of 1,700 × 1,370 mm and is particularly suitable for spotting, try-out and tuning work in tool and mould making. Technical data + information: Spotting press – Millutensil MIL 163 – 150 T Allgemeine Disclosures - Manufacturer: Millutensil - Model: MIL 163 - Year of construction: 2004 - Type: 4-column spotting press - Press force: 150 T (adjustable) - Column spacing: 1,700 × 1,370 mm - Table size: 1,300 × 1,600 mm - Max. installation height: 1,300 mm - Table height from the ground: 610 mm - Overall dimensions (WxDxH): approx. 2,000 × 2,550 × 4,600 mm - Total weight: approx. 19,000 kg - T-slots: DIN 650 / 22 Werkzeugbelastung - Max.  ...

Rice spotting press Weight: 5000kg Auction-ID: A7-45416-138

Key data: 100 t

For sale is a used spotting press from the manufacturer Reis with an adjustable press force of up to 100 t. The 4-column press has a table size of 1600 × 1300 mm, a maximum open height of 950 mm and an ejector in the table, making it particularly suitable for spotting, tuning and tool work in mould and tool making. Here are the technical data of the offered machine: Technical data + information: Spotting press – REIS TUS 80-100 Allgemeine Disclosures - Name: spotting press - Manufacturer: REIS - Type: TUS 80-100 - Type: 4-column press - Year of construction: 1998 - Press force: 26–100 T (adjustable) - Retraction force max.: 45 T - Table size: 1600 x 1300 mm - Max. table load: 5,000 kg - Open height max.: 950 mm - Overall dimensions (WxDxH): approx. 3400 x 4200 x 3700 mm - Total weight: approx. 8,500 kg - T-slots: DIN 650 – 22 mm Hydraulik - Hydraulic pum ...

Column spacing 1800 x 1000 mm, passage height 1900 mm Auction-ID: A1-44702-19

Key data: 200 t, 2500 mm, 200 mm

Spotting press – manufacturer Reis – from automotive production For sale is a spotting press from the manufacturer Reis. The machine comes from the ongoing production of a well-known automobile manufacturer in Berlin. All maintenance and service intervals were carried out regularly. The plant is currently under power and can be demonstrated in the production environment. Despite its year of manufacture, the machine is in a technically perfect and well-maintained condition. It is particularly suitable for precise spotting and tuning work in tool and mould making. A viewing is possible at any time by prior appointment. Dismantling and loading are carried out by the buyer. On request, dismantling, loading and organisation of transport can be taken over by us for a separate charge. Here are the technical data of the offered machine: # Technical data + information: Spotting Pre ...

pressure: 100 ttable length: 1800 mmtable width: 1550 mmtable travel: 2000 mmdayligth: 1800 mmtotal power requirement: 19,5 KVAweight of the machine ca.: 22 tThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 200 t, 1800 mm, 1600 mm

Spotting press with injection unit – manufacturer Reis – from automotive production For sale is a spotting press with integrated injection unit from the manufacturer Reis. The machine comes from the ongoing production of a well-known automobile manufacturer in Berlin. All maintenance and service intervals were carried out regularly. The plant is currently under power and can be demonstrated in the production environment. Despite its year of manufacture, the machine is in a technically perfect and well-maintained condition. It is particularly suitable for precise spotting and tuning work in tool and mould making. A viewing is possible at any time by prior appointment. Dismantling and loading are carried out by the buyer. On request, dismantling, loading and organisation of transport can be taken over by us for a separate charge. Here are the technical data of the off ...

pressure: 4000 kNtable length: 2500 mmtable width: 2000 mmdayligth: 2500 mmstroke: 2600 mmtank capacity: 1000 ltotal power requirement: 56 kVAweight of the machine ca.: 85 tdimensions of the machine ca.: 9,2 x 3,1 x 8,2 mintegrated wax-injection unit with 0-5 bar The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 40 t

Reis TUS 60 40kn spotting press On offer is a used, but very well preserved spotting press of the Reis brand. The TUS 60 40kn model has proven to be extremely reliable and powerful since it was manufactured in 1981. With an impressive 40 tonne locking mechanism, this machine is perfect for demanding tasks. Details: Year of Make: 1981 Tumbler: 40 tons Although used, this machine is in good condition. It is immediately ready for use and a valuable addition to any workshop.

pressure: 200 ttable length: 2200 mmtable width: 1550 mmdayligth: 2200 mmram return capacity: 6.000 kgtable load capacity: 10.000 kptotal power requirement: ? ca. 25-30 kWweight of the machine ca.: 30 tdimensions of the machine ca.: 4 7 7 mPacking: ca. 13,4 x 3 x 3 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 50 t, 1100 mm, 800 mm

Used spotting press, manufacturer Reis, type TUS 80, built in 1999, For more data, see machine map. The sale takes place from the site without dismantling.! The machine was fully functional until the end.

pressure: 200 ttable length: 1600 mmtable width: 1300 mmdayligth: 1800 mmControl: Simatic ram return capacity: 6000 kgtable load capacity: 7000 kptotal power requirement: ? ca. 25-30 kWweight of the machine ca.: 19 tdimensions of the machine ca.: 2,95 5 6 mSpecial price 49,900 EUR from foundation upon acceptance until January 30, 2026. Normal price from warehouse.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

REIS TUS 115 OK 100 Die Spotting Press pressure 100 t table surface area 890 x 1280 mm ram surface 1000 x 1200 mm distance between columns 1250 mm stroke 1035 mm distance table/ram, max. stroke up, adjustment up 1035 mm side window 700 mm table height over floor 630 mm max. tool weight 7 t max. capacity of swivelling ram plate 3,5 t oil volume 180 l power capacity 9,0 kW weight 11 t Dimensions (WxDxH): 2,1 x 3,8 x 3,9 m swiveling ram movable table table - tiltable ram interlocking hydraulic ejector in table

pressure: 200 ttable length: 1600 mmtable width: 1300 mmdayligth: 1700 mmtotal power requirement: kWweight of the machine ca.: 19 tdimensions of the machine ca.: 2,95 5 6 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Millutensil spotting press BV25/PM - Output force adjustable (with max. pressure): 100 - 800 kgf - Ejector stroke max.: 120 mm - Hydraulic pressure adjustable from 5 - 100 bar - Width: 150 cm - Depth: 150 cm - Height: 200 cm - With operating instructions Good condition, fully functional, can be viewed and tried out on site. Shipping also abroad. Sightseeing: Basically, I would like to point out that the article can be viewed and tested under power before purchase in order to rule out misunderstandings. Please ask questions before purchasing to avoid confusion. If you have any general questions or would like to make an appointment for a viewing, I can be reached at any time on the telephone number below or above. Errors in the description and prior sale excepted. VAT is shown separately on my invoices. Shipping with forwarding agent.

pressure: 20 ttable length: 670 mmtable width: 570 mmtotal power requirement: 8 kWweight of the machine ca.: 4 tdimensions of the machine ca.: 2 x 2 x 3 mNo. 2886Spotting press 200 kNRICE TUS 60 OK 20Stroke approx. 700Drive: 7,5 kWHydraulic controlExtendable table 670 x 570 mm,Swivel-out top plate 670 x 570 mm,Installation height 740 mmClearance between the columns 620 mm,Space requirement L/W/H 1870 x 1620 x 3000 mm,Weight approx. 3.5 to.Asking price: 8.500,-- ex works / EXWAsking price: 12.900,-- EXW warehouse loaded free on suitable truckThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 18 t

Specifications: Clamping force 18 tons Opening force 20 tons Adjustable force in each case Lifting speed adjustable approx. 0 - 1 m/min Extendable table size 800 x 660 mm Installation height min 230 mm Installation height max. 760 mm

pressure: 40 ttable length: 1280 mmtable width: 900 mmtotal power requirement: 7 kWweight of the machine ca.: 8 tdimensions of the machine ca.: 3 x 2 x 3,6 m mNo. 5282Spotting press 400 kNREIS TUS 90 OK 40Working area: table 900 x 1280Column passage 930 x 705 mmTable top 900 x 1280 mmram plate 900 x 1200 mmInstallation height 1035 mmSpace requirement approx. 3 x 2 x 3.6 mTransport dimensions approx. 4 loading meters, width 2.20 / height 2.80Weight approx. 8 tonsThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Technical details Pressure 110 t Technology Passage width 1200 x 1000 mm Stroke 1200 mm Machine weight approx. 12 t Space requirement approx. 4500 x 4300 x 2700 mm Master cylinder 1 piece Installation height (distance table to plunger plate) 1200 mm Table height 700 mm Table can be extended by 1200 mm Table tiltable by 45 degrees Upper tool folds down by 180 degrees Table rotatable by 180 degrees Table load max. 10 t Travel speed of the table 25 mm/sec Flow speed 195 mm/sec Return speed 130 mm/sec Working speed adjustable from 0 to 10 mm/sec. Table area between the columns 1250 x 1000 mm Engines WEG Accessories Paint structure RAL 7035 (light grey) Additional information Painting cladding, doors, maintenance balcony RAL 1021 (Yellow) Painting accessories RAL 7021 (dark grey) Columns and cylinders are made of tool steel SAE 1045 (identical to German standard C4 ...

pressure: 40 ttable length: 670 mmtable width: 570 mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Pressing force: 40 t table size: 670 x 470 mm plunger surface: 670 x 470 mm clearance between the pillars: 620/470 mm gr. Height: 740 mm Preß speed: 20 mm / s rapid traverse: 50 mm ejector force: 3T Electr. Supply: 380 V, 9.5 kW space: 2200 x 1875 x 3000 mm weight: 2400 kg

pressure: 200 ttable length: 2500 mmtable width: 1800 mmtable travel: 2700 mmdayligth: 2250 mmupper clamping surface:: 1800x2500 column base area: 1900 mmtotal power requirement: 22 KWweight of the machine ca.: 30 tdimensions of the machine ca.: . mNominal force: 1000 kNTop plate pivotsTable is movableThe tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively.About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit.Your Markus Hirsch TeamThe data for this ad was created w ...

pressure: 100 ttable length: 1250 mmtable width: 900 mmtable travel: 1200 mmdayligth: 700 mmupper clamping surface:: 1000x1200 total power requirement: KVAweight of the machine ca.: 12 tdimensions of the machine ca.: . mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 100 ttable length: 2000 mmtable width: 1580 mmstroke: mmpressing speed: mm/secvoltage: 400 Vreturn capacity: tmax. table loading capacity: 10.000 / 20.000 kgtotal power requirement: 18 kWweight of the machine ca.: 22 tdimensions of the machine ca.: 5,65 x 2,95 x 5,85 mSerial no: 03.246.00max. Distance between columns (width) 1620 mmmax.load upper tableno swiveling 10t / swiveling 6tmax.load lower table 22tThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
