A horizontal fire-tube/smoke-tube boiler Loos with a 2-pass system is available. Steam output: 2000kg/h, max. operating overpressure: 11.5bar, fuel: oil/gas. An on-site inspection is possible. ...

• more information

1 gebr. Boiler --------------------------- Manufacturer : LOOS Gunzenhausen Type : U-HD 1250 Heating surface approx. : 20 m² Boiler capacity max. : 1.250 kg/h Operating overpressure : 13.0 bar Increased test overpressure : 24.05 bar Water content at NW approx. : 993 l Water content full approx. : 1.365 l Year of manufacture : 2003 CE mark : 0036 equipped with Weishaupt gas burner type G7/1-D, ZMD-LN, 250-1,550 kW, 15-500 mbar, gas control section, control cabinet, feed water pump and the existing coarse and fine fittings. Econmizer: Eco 3, 82 kw, 31 bar, 238°C, 28 ltr.

1 gebr. Boiler --------------------------- Manufacturer : LOOS Gunzenhausen Type : U-HD 1250 Heating surface approx. : 20 m² Boiler capacity max. : 1.250 kg/h Operating overpressure : 13 bar Increased test overpressure : 23 bar Water content at NW approx. : 993 l Water content full approx. : 1.365 l Year of manufacture : 2003 CE mark : 0036 equipped with Weishaupt gas burner G7/1-D, ZMD, 300-1,750 kW, 15-500 mbar, Gas control section, control cabinet, feed water pump and the existing coarse and fine fittings.

gebr. Boiler --------------------------- Manufacturer : LOOS Gunzenhausen Type : U-HD 1250 Heating surface approx. : 20 m² Boiler capacity max. : 1.250 kg/h Operating overpressure : 13 bar Increased test overpressure : 23 bar Water content at NW approx. : 993 l Water content full approx. : 1.365 l Year of manufacture : 1997 equipped with Weishaupt gas burner G7/1-D, ZMD, 300-1,750 kW, 15-500 mbar, gas control section, Control cabinet, feed water pump, ECO and the existing coarse and fine fittings.

1 gebr. Boiler -------------------------------- Manufacturer : LOOS Gunzenhausen Type : UL-S 1250 Heating surface approx. : 25 sqm Capacity : 1,000 kg/h Operating overpressure : 13.0 bar Increased test pressure : 24.7 bar Ab. Operating temperature : 195° C Water content up to NW approx. : 1.785 l Water content full approx. : 2.320 l CE marking : CE 0036 Year of manufacture : 2006 equipped with Weishaupt gas/oil burner GL5/1-D/ ZMD, separate control cabinet, gas control system, feed water pump, and the existing coarse and fine fittings.

1 gebr. Boiler --------------------------- Manufacturer : LOOS Gunzenhausen Type : U-HD 1250 Heating surface approx. : 20 m² Boiler capacity max. : 1.250 kg/h Operating overpressure : 10.0 bar Increased test overpressure : 18.5 bar Water content at NW approx. : 993 l Water content full approx. : 1.365 l Year of construction : 2008 CE mark : 0036 equipped with Weishaupt gas burner G7/1-D, ZMD, 300-1,750 kW, 15-500 mbar, gas control section, Control cabinet with touch panel, feed water pump, ECO and the existing coarse and fine fittings.

1 gebr. Boiler --------------------------- Manufacturer : LOOS Gunzenhausen Type : U-HD 1250 Heating surface approx. : 20 m² Boiler capacity max. : 1.250 kg/h Operating overpressure : 13 bar Increased test overpressure : 23.4 bar Water content at NW approx. : 993 l Water content full approx. : 1.365 l Year of construction : 2000 equipped with Weishaupt gas burner type G7/1-D, ZMD, 300-1,750 kW, Gas control section, control cabinet, feed water pump and the existing coarse and fine fittings.

Two identical Loos steam boiler systems with Weishaupt burners are available. 1) 2x Loos International U-HD 1250 steam boilers, year of manufacture: 2003, max. operating pressure: 10bar, steam output: 1100kg/h, total volume: 1365l. 2) 2x Weishaupt G7/1-D ZD-LN gas burners, year of manufacture: 2003, category: I2ELL, gas type: N, output range: 250kW-1550kW, min./max. connection pressure: 15mbar/500mbar. Both systems including condensate collector and accessories. An on-site inspection is possible. Expected to be available starting 2027.

Steam capacity at 102 ºc of nutritious water --- 10000 kg / h Heat efficiency --- 6.5mW Permissible excess pressure --- 13 Bar Working pressure --- 12 Bar Water content --- 19 m³ Total water content --- 22.6 m³ Transport weight ---- 21,3 t Working weight --- 40.6 t Fuel --- Gas and diesel Manufacturer of water --- Weishaupt Type of water --- Weishaupt G 70 / 2A Water adjustment --- Modulated The heat is the voltage of the current volume --with full fire chamber --- 1.02 mW - without full fire chamber --- 1.21 mW Boiler efficiency - at 100% productivity --- 90% - at 50% productivity --- 90.5% Boilers are still running and video is available on request

with gas burners Weishaupt new glass wool new stainless steel sheets New storage engine Power Max 465 kW the boiler is uberholte with gas burner Weishaupt with new glass wool new grid grate Engine re-stored Power Max 465 kW the boiler is overhauled  ...
